The interior overhead lamp is
equipped with a battery saver
control system designed to prevent
excessive wear on the battery.
When a door is not closed
properly, the battery saver control
system timer is activated. The
timer will give you between eight
and ten minutes to close the door
before it automatically turns off
the interior overhead lamp. If the
door is left open, closed, and then
left open again, the timer will
automatically reset.
The battery saver control system is
not activated when the headlamps
are left on. A warning chime will
sound when the engine is turned
off to draw your attention to
headlamps left on.
Map lamp
The map lamps are located in the
rear portion of the interior
overhead lamp assembly.
Replacement of the two bulbs
requires removal of the bulb
assembly cover and the use of
several different tools. See a
qualified service technician or your
dealer for replacement of the map
lamp bulbs.
Hazard flasher
For more information on the
hazard flasher and hazard switch,
refer toUsing the hazard switch
in theRoadside emergencies
chapter. For bulb replacement, see
your dealer or a qualified service
technician.
Maintenance and care
171
Page 172 of 191
BULB SPECIFICATIONS
Function Number of
bulbsTrade number
Exterior illumination
Front park/turn lamps 2 3457
Foglamps (if equipped) 2 881
Headlamps Ð aero high and low
beam2 9007
Rear license plate lamp 2 168
High-mount brakelamp 1 921
Notchback Ð Backup lamp 2 3156
Notchback Ð Brakelamp 2 3157
Notchback Ð Rear/turn/side
marker2 3157
Liftgate wagon rear side marker
lamp2
(1 each side)168
Interior illumination
Cargo lamp liftgate (wagon) 1 12V/5W
Interior overhead lamp 2 12V/10W
Luggage compartment lamp (if
equipped)15W
PRNDL illumination 1 197
Heater control nomenclature 1 14V/3.0
High beam indicator 1 W
Instrument panel gauge (cluster) 4 194
Sport cluster w/ tachometer 2 194
Turn signal indicator 1 194
Upshift indicator (if equipped) (1 each) 194
Warning lights Ð all 194
Maintenance and care
172
Page 173 of 191
Function Number of
bulbsTrade number
Anti-theft LED 1 LED See your dealer
to order
replacement
assembly,
service part
#F57Z13B765-A
Aiming the headlamps
Your vehicle is equipped with a
variable headlamp aiming device
(VHAD) on each headlamp
reflector extension and headlamp
housing. Each headlamp may be
properly aimed in the horizontal
direction and the vertical direction
by performing the following steps.
The horizontal aim must be
adjusted first. This procedure
requires the use ofa4mmbox
wrench or open end wrench.
Position the vehicle on a surface
that is level in the front-to-rear
direction.
If the vehicle cannot be placed on
a true level surface, the headlamps
still can be adjusted using the
VHAD if the slope of the surface is
accurately known and does not
differ by more than 30.5 mm (1.2
in) from true level.
Maintenance and care
173
Page 174 of 191
Adjusting the horizontal aim
1. With the hood open, locate the
horizontal indicator and adjusting
screw.
2.Usea4mmwrench to turn the
horizontal adjusting screw until the
reference mark on the reflector
extension aligns with the ``O''
reference mark on the horizontal
indicator when viewed directly
from above.
3. When the horizontal aim has
been adjusted, close the headlamp
access panel.
Adjusting the vertical aim
1. Do not adjust the vertical aim
until after adjusting the horizontal
aim.
2. With the hood open, locate the
bubble level vertical aim indicator.
It is visible when viewed from
above the rear of the headlamp.
3. With the vehicle on a level
surface, usea4mmwrench to
turn the vertical aim adjustment
screw (outboard screw) located on
the back of the lamp assembly
clockwise or counterclockwise until
the bubble in the spirit level is
centered when viewed from
directly above the bubble.
4. Close the hood.
If the vehicle is on a downward or
upward slope of not more than
1.2É, the VHAD's bubble level can
be used to correct for the effects
of the surface slope, provided that
the slope is accurately known.
Maintenance and care
174
Page 175 of 191
Each graduation of the bubble
level represents 0.19É of downward
or upward slope. To correct for the
effects of surface slope, turn the
vertical aim adjustment screw until
the bubble is centered at a
position corresponding to the slope
of the surface.
CLEANING AND CARING FOR
YOUR VEHICLE
Contact your dealer for more
information on recommended
cleaners and their availability in
your area.
Washing your vehicle
Wash your vehicle regularly with
cold or lukewarm water. Never use
strong detergents or soap. If your
vehicle is particularly dirty, use a
quality car shampoo. Always use a
clean sponge and plenty of water
for best results. We recommend
that you have the underbody of
your vehicle washed at the end of
the winter to remove deposits left
by snow, salt, and water.
Wax the body paintwork of your
vehicle several times a year. This
will help to retain the glossy
paintwork finish and water
droplets will run off more easily.
Remove any after dealer
accessories, such as
antennae, before entering a
commercial car wash.
Maintenance and care
175
Page 176 of 191
After washing your vehicle, apply
the brakes several times to dry
them.
Repairing paint chips
Minor scratches or paint damage
from road chippings may be
camouflaged with Ford exterior
lacquer touch-up paint,
AL81-XXXX-B or
ALBZ-19500-XXXXA. XXXX
indicates the code, meeting Ford
specification ESR-M2P100-C.
Follow the application instructions
on the product. Be sure to remove
aggressive particles such as bird
droppings, tree resins, insect
remains, tar spots, and road salt,
that may damage your paint.
Cleaning the wheels
Wash the wheels with the same
detergent used to clean the body
of your vehicle. Do not use acid
based wool cleaners, steel wool,
fuel, or strong detergents. Never
use abrasives that will damage the
finish of special wheel surfaces.
Use a tar and road oil remover to
remove grease and tar.
Cleaning plastic parts
Some of the vehicle's trim parts
are plastic. Clean with a tar and
road oil remover if necessary. Use
a vinyl cleaner for routine cleaning.
Do not clean plastic parts with
thinners, solvents, or petroleum
based cleaners.
Maintenance and care
176
Page 177 of 191
Cleaning the instrument panel
Any cleaner or polish that
increases the gloss of the upper
portion of the instrument panel
should be avoided. The dull finish
in this area is to help protect the
driver from windshield reflection.
Cleaning the exterior lamps
Do not use dry paper towels,
chemical solvents, or abrasive
cleaners to clean the lamps; these
products may cause scratches or
crack the lamps.
Cleaning the engine
A clean engine is more efficient
than a dirty one because a buildup
of grease and dirt acts as an
insulator and keeps the engine
warmer than normal. Follow these
guidelines to clean your engine:
²Take care when using a power
washer to clean the engine. The
high pressure fluid could
penetrate sealed parts and
cause damage.
²In order to avoid cracking the
engine block or fuel injection
pump, do not spray these
components with cold water.
²The alternator and air intake
must be covered to prevent
water damage when cleaning the
engine.
²Never wash or rinse the engine
while it is running; water in a
running engine may cause
internal damage.
Maintenance and care
177
Page 178 of 191
Cleaning the wiper blades
If the blades do not wipe properly,
clean both the windshield and the
wiper blades using undiluted
windshield washer solution or a
mild detergent. Rinse thoroughly
with clean water. Do not use fuel,
kerosene, paint thinner, or other
solvents to clean the wiper blades;
these fluids will damage the
blades.
Cleaning the built-in child seat
Clean the built in child seat with
mild soap and water. Do not use
household cleaning products
because they may weaken the
safety belt webbing or damage the
vinyl parts of the seat.
The child seat liner is removable
and may be machine washed and
air dried.
Cleaning and maintaining the
safety belts
Clean the safety belts with a mild
soap solution recommended for
cleaning upholstery or carpets. Do
not bleach or dye the belts; this
may weaken the belt webbing.
Check the safety belt system
periodically to ensure there are no
nicks, wear, or cuts. If the vehicle
has been involved in an accident,
have all the safety belts and child
seat anchoring brackets (if
equipped) examined by a qualified
technician.
Maintenance and care
178
Page 179 of 191
MOTORCRAFT PART NUMBERS
Component Ford part number Ð 2.0 liter
SPI engine
Air filter F7CX-9601-AA
Battery BX-58C
Fuel filter FG-862
Oil filter FL400-A
PCV valve EV-229
Spark plug* AGSF-34-E
* Refer to the Vehicle Emission
Control Information (VECI) decal,
located on the underside of the
hood, for gap specifications.
REFILL CAPACITIES
Your vehicle's fuel capacity
The fuel capacity for your vehicle
is 48.0 L (12.7 gallons).
²To avoid overspill from the filler
neck, stop fueling at the second
automatic shut off.
²For more information on fueling
your vehicle, refer toChoosing
the right fuelin the
Maintenance and carechapter.
Capacities and specifications
179
Page 180 of 191
Capacities Ð liters (quarts) 2.0 liter SPI engine
Engine Oil Ð including filter /
excluding filter3.8 L (4.0 qt) / 3.3 L (3.5 qt)
Manual transaxle 3.35 L (3.55 qt)
Automatic transaxle Ð full torque
converter / empty torque
converter3.9 L (4.1 qt) / 6.3 L (6.7 qt)
Radiator filler cap 110 kPa (16 psi)
Engine coolant
Iautomatic transaxle
Imanual transaxle6.0 L (6.3 qt)
5.0 L (5.3 qt)
LUBRICANT SPECIFICATIONS
Item Ford part
nameFord part
numberFord
specification
Brake master
cylinderFord High
Performance
DOT 3 Motor
Vehicle Brake
FluidC6AZ-19542-AB ESA-M6C25-A,
DOT 3
Constant
velocity jointsCV Joint
Grease Ð High
TemperatureE43Z-19590-A ESP-MIC207-A
Door
weatherstripsSilicone
Lubricant
(tube)
(aerosol)COAZ-19553-AA
D7AZ-19553-AAESR-M13P4-A
ESR-M13P4-A
Engine coolant Ford Premium
Cooling System
FluidE2FZ-19549-AA,
-BESE-M97B44-A
Capacities and specifications
180
