FORD ESCORT 1997 7.G Owners Manual

Item Ford part
nameFord part
numberFord
specification
Engine oil Motorcraft
5W-30 Super
Premium Motor
OilXO-5W-30 WSS-M2C153-F
Hinges and
latchesFord
Multi-Purpose
Grease Spray
(Aerosol)
F5AZ-19G209-AAESR-M1C159-A
and
ESB-M1C93A
Lock cylinders Penetrating
LubricantE8AZ-19A501-B N/A
Power steering
pumpPremium
Power Steering
FluidE6AZ-19582-AA ESW-M2C33-F
Automatic and
manual
transaxleMotorcraft
MERCONt
Multi-Purpose
(ATF)
Transmission
FluidXT-2-BDX,
-QDXMERCON
Wheel bearings,
rearMotorcraft
Premium
Long-Life
GreaseXG-1-C, -K ESA-M1C75-B
Windshield
washer fluid
reservoirUltra-Clear
Windshield
Washer
ConcentrateC9AZ-19550-AC
or
C9AZ-19550-BCESR-M17P5-A
Capacities and specifications
181

ENGINE DATA
Engine 2.0 liter; 121 CID; 4 cylinder (in-line);
compression ratio 9.2:1; single overhead cam;
split port induction (SPI)
Horsepower 110 at 5,000 rpm
Torque 169 Nm (125 lb ft at 3,750 rpm)
Required fuel grade 87 (R+M)/2
Firing order /
Injection timing1-3-4-2
Spark plug gap 1.3 to 1.4 mm / 0.052 to 0.056
Ignition system DIS
Valve clearances cold
inlet exhaust0: Maintenance free 0: Maintenance free
VEHICLE DIMENSIONS
Dimensions Ð cm
(inches)Sedan Wagon
V1Overall length 443.25 cm (174.5 in) 439.1 cm (172.9 in)
V2Overall width
(excluding exterior
mirrors)168.00 cm (66.2 in) 170 cm (67 in)
V3Maximum height 135.00 cm (53.2 in) 136.9 cm (53.9 in)
V4Wheelbase 250.00 cm (98.4 in) 250 cm (98.4 in)
V5Track Front
Rear143.5 cm (56.5 in),
143.5 cm (56.5 in)143.5 cm (56.5 in),
143.5 cm (56.5 in)
Capacities and specifications
182

5
2
3
5
2
3
Capacities and specifications
183

4
1
4
1
Capacities and specifications
184

IDENTIFYING YOUR VEHICLE
Vehicle identification plate
The vehicle identification plate is
located on the front panel of the
engine compartment. This plate
bears technical information on
your vehicle and identifies various
components.
Vehicle identification number
The vehicle identification number
(VIN) is attached to a metal tag
and is located in the following
areas of your vehicle for maximum
theft protection:
²left and right front fenders
²hood
²left and right front doors
²front and rear bumper
²left and right rear quarter
panels
²decklid
²liftgate
²engine compartment
²transaxle
Engine number
The engine number is stamped on
the engine block.
FORD
1-
2-kg
kg kg
kg
UF0AXXGAGAJK07767
Capacities and specifications
185

If you believe that your vehicle has
a defect which could cause a crash
or could cause injury or death, you
should immediately inform the
National Highway Traffic Safety
Administration (NHTSA) in
addition to notifying Ford Motor
Company.
If NHTSA receives similar
complaints, it may open an
investigation and if it finds that a
safety defect existing in a group of
vehicles, it may order a recall and
remedy campaign. However,
NHTSA cannot become involved in
individual problems between you,
your dealer, or Ford Motor
Company.
To contact NHTSA, you may either
call the Auto Safety Hotline
toll-free at 1-800-424-9393
(202-366-0123 in the Washington
D.C. area) or write to:
NHTSA
U.S. Department of Transportation
400 Seventh Street
Washington D. C. 20590
You can also obtain other
information motor vehicle safety
from the hotline.
Reporting safety defects
186

Aiming headlamps ....................173
Air bag supplemental restraint
system ..........................................62
description ...........................62,63
disposal ......................................63
driver air bag ............................64
indicator light ........................7,64
operation ...................................63
tone generator ..........................64
wearing safety belts .................64
Air cleaner filter .......................145
replacing ..................................146
Air conditioning
manual heating and air
conditioning system .................19
Anti-lock brake system (ABS) ...93
noise ..........................................93
see also Brake ...........................93
warning light .............................94
Anti-theft system ........................45
arming the system ....................50
description ................................50
disarming a triggered system ..52
disarming an untriggered
system .......................................51
warning light ...............................9
Automatic transaxle ...................96
driving with ...............................96
fluid, adding ............................141
fluid, checking ........................140
Battery .......................................142
servicing ..................................143
Brakes ..........................................93
anti-lock .....................................93
anti-lock brake system (ABS)
warning light ...............................9
fluid, checking and adding ....133
power braking ...........................93
Break-in period .............................2
Bulbs, replacing ........................160
halogen ....................................161
headlamps ...............................162high-mount brakelamp ...........164
rear lamps ..........164,165,167,168
specifications ..........................172
Cargo area shade ........................41
Changing a tire .........................114
Charging system warning light ....9
Child safety seats
and air bags ............................185
Childproof locks ..........................33
Cleaning your vehicle ...............175
built-in child seat ...................178
engine compartment ..............177
exterior ....................................177
instrument panel ....................177
plastic parts ............................176
safety belts ..............................178
washing ....................................175
waxing .....................................175
wheels ......................................176
wiper blades ............................178
Climate control system ..............17
air conditioning .........................19
air distribution dial ...................19
temperature dial .......................18
Clutch
fluid ..........................................134
Controls ...................15,31,36,39,40
steering column ........................25
Daytime running light system ...26
Defects, reporting .....................186
Disabled vehicle (see Towing) 123
Driving under special
conditions
towing a trailer .......................105
Emergencies, roadside .............107
Emission control system ...157,158
Engine .................................129,182
check engine warning light .......7
Engine block heater ...................91
Engine coolant
checking and adding ..............136
low coolant warning light ........10
Index
187

Engine oil ..................................130
check oil warning light ...............9
checking and adding ..............130
Exhaust fumes ............................91
Fan ...............................................18
Flashing the lights ......................27
Floor mats ...................................39
Foglamps ..............................27,163
Fuel
capacity ...................................179
improving fuel economy ........106
low fuel warning light ................7
safety information relating to
automotive fuels .....................153
Fuel pump shut-off switch ..43,107
starting after a collision ...........43
Fuse panels
engine compartment ..............113
instrument panel ....................111
Fuses ..........................................109
charts ................................111,113
checking and replacing ..........109
circuit breakers .......................110
Gauges, Electronic ......................12
Gauges, Mechanical ....................12
engine coolant temperature
gauge .........................................13
fuel gauge ..................................13
odometer ...................................14
speedometer .............................13
trip odometer ............................14
Gearshift .................................36,97
GVWR (Gross Vehicle Weight
Rating) .......................................101
definition .................................101
Hazard flashers ....................29,107
Head restraints ...........................54
Headlamps
daytime running lights .............26
replacing bulbs .......................162
turning on and off ....................26High beams
indicator light .............................9
operation ...................................27
High-mount brakelamp
replacing the bulb ..................164
Hood ..........................................128
prop rod ..................................128
release lever ............................128
working under the hood ........124
Idle
relearning ................................144
Ignition
positions of the ignition ...........25
Inspection/maintenance (I/M)
testing ........................................158
Instrument cluster
sport .........................................6,7
standard ......................................6
Instrument panel ........................15
lighting up panel and interior 6,15
location of components ...........4,5
Interval wipers ............................30
Jump-starting your vehicle ......120
attaching cables ......................121
disconnecting cables ..............122
Lamps ........................................160
bulb replacement
specifications chart ................172
daytime running light system ..26
dome lamps .............................170
fog lamps ............................27,163
headlamps ..........................26,162
high beams ................................27
high-mount brakelamp ...........164
illuminated entry system .........33
interior lamps ....................31,170
map lamps ..........................31,171
replacing bulbs .......................160
tail lamps ..........................167,168
License plate lamps ..................165
Liftgate .................................40,164
warning light .............................10
Index
188

Lights, warning and indicator ......6
air bag .....................................7,64
anti-lock brakes (ABS) ..............9
anti-theft .....................................9
brake ............................................8
charging system ..........................9
checkcoolant .............................10
high beam ...................................9
liftgate ajar ................................10
low fuel ........................................7
oil pressure .................................9
safety belt ...................................8
service engine soon ....................7
turn signal indicator ...................9
upshift indicator .........................8
Load limits .................................101
GVWR ......................................101
trailer towing ..........................102
Lubricant specifications ...........180
Luggage rack .............................106
Manual transaxle .........................99
driving .......................................99
fluid, checking and adding ....134
shifting gears ..........................100
Mirrors
side view mirrors (power) .......16
Motorcraft parts ........................179
National Highway Traffic
Safety Administration ...............186
Parking brake ..............................94
automatic release .....................38
operation ...................................94
warning light ...............................8
Parts (see Motorcraft Parts) ...179
Power door locks ........................31
Power features
door locks ..................................31
windows ....................................34
Power steering
fluid, checking and adding ....139
Rear window
defroster ....................................24washer .......................................30
wiper ..........................................30
Refill capacities for fluids ........179
Relays ........................................109
Remote control ...........................45
Remote entry system .................45
illuminated entry ......................49
locking/unlocking doors ......46,47
opening the trunk .....................47
panic alarm ...............................49
Repairing paint chips ...............176
Reporting safety defects ..........186
Restraints, safety(see Safety
restraints) ....................................55
head ...........................................54
infant .........................................67
Roadside emergencies ..............107
Safety chains, when towing a
trailer .........................................104
Safety defects, reporting ..........186
Safety restraints ..........................55
adjusting the safety belts .........59
automatic locking mode
(retractor) .................................57
for children ...............................65
lap and shoulder belts ........56,59
maintenance ..............................60
proper use ............................55,56
vehicle sensitive locking
mode ..........................................57
warning light and chime ..8,10,62
Safety seats for children ............67
automatic locking mode
(retractor) .................................81
built-in child seat .....................74
in front seat ..............................68
in rear seat ................................70
tether anchorage hardware .....71
Seats ............................................53
adjusting the seat, manual .......53
child safety seats ......................67
folding rear seats ......................54
Index
189

head restraints ..........................54
split-folding rear seat ...............54
Servicing your vehicle
precautions when servicing ...124
servicing when you tow .........105
Special driving conditions ..........89
Specification chart, lubricants .180
Speed control ..............................27
Starting your vehicle ..................88
preparing to start your
vehicle .......................................86
starting a cold engine ..............89
starting a warm engine ............89
Steering wheel
tilting .........................................29
Tail lamps
bulb replacement .............167,168
Tilt steering wheel ......................29
Tire types ..................................152
Tires ...........................................148
changing ..................................114
checking the pressure ............150
replacing ..................................151
rotating ....................................151
snow tires and chains ............152
tire grades ...............................148
treadwear ................................148
Trailer towing ............................102
safety chains ...........................104
tips ...........................................105
trailer brakes ...........................104
trailer lamps ............................104
Transaxle .....................................96
fluid, checking and adding
(automatic) .............................139
Turn signal
indicator lights ............................9
Upshift indicator light ...........8,100
Upshift speeds ..........................100
Vehicle dimensions ...................182
Vehicle headlamp aiming
device (VHAD) .........................173Vehicle Identification Number
(VIN) ..........................................185
Ventilating your vehicle (see
Climate control) ................18,19,23
Warning chimes ...........................10
headlamps on ............................11
key in ignition ...........................11
safety belt .................................10
Washer fluid ..............................134
reservoir ..................................135
windshield .................................30
Windows
one-touch down ........................35
power windows, operating .......34
Windshield
washing ......................................30
Windshield washer fluid and
wipers
checking and adding fluid .....134
checking and replacing wiper
blades ......................................146
liftgate reservoir .....................135
operation ...................................30
Wrecker towing .........................123
Index
190
