FORD ESCORT 1998 7.G Service Manual

Locking the doors
Press this control to lock all doors
(and liftgate on wagons). On
vehicles equipped with the driver's
door only remote entry system,
only the driver's door will lock.
To confirm doors are closed and
locked, press the lock control a
second time within five seconds.
The door(s) will lock again, the
horn will chirp once and the lamps
will flash.
If any of the doors are open or
ajar, the horn will make two quick
chirps, reminding you to properly
close the doors.
This process will also arm your
anti-theft system (if equipped).
For more information on arming
the anti-theft system, refer to
Anti-theft systemin this chapter.
Opening the trunk
Press the control once to open the
trunk. On wagons, pressing the
control will unlock (but not open)
the liftgate.
Be certain the trunk is closed
before driving your vehicle. The
trunk may appear closed, but it
may not be latched. Failure to do
so may cause objects to fall out of
the trunk or block rear view vision.
Controls and features
41

Sounding a panic alarm
Press this control to activate the
alarm.
To deactivate the alarm, press the
control again or turn the ignition
to ACC or ON.
This device complies with part 15
of the FCC rules and with RS-210
of Industry Canada. Operation is
subject to the following two
conditions: (1) This device may
not cause harmful interference,
and (2) This device must accept
any interference received,
including interference that may
cause undesired operation.
Changes or modifications not
expressly approved by the
party responsible for
compliance could void the
user's authority to operate the
equipment.
Replacing the batteries
The transmitter is powered by two
coin type three-volt lithium
batteries. Typical operating range
will allow you to be up to 10
meters (33 feet) away from your
vehicle. A decrease in operating
range can be caused by:
²battery failure
²weather conditions
²nearby radio towers
²structures around the vehicle
²other vehicles parked next to
the vehicle
To replace the batteries:
Controls and features
42

1. Twist a thin coin between the
two halves of the transmitter. DO
NOT TAKE THE FRONT PART OF
THE TRANSMITTER APART.
2. Place the positive (+) side of
new batteries down. Refer to the
diagram inside the transmitter
unit.
3. Snap the two halves back
together.
Replacing lost transmitters
Take all your vehicle's transmitters
to your dealer for reprogramming
if:
²a transmitter is lost or
²you want to purchase additional
transmitters (up to four may be
programmed).
To reprogram the transmitters,
place the key in the ignition and
switch from OFF to ON eight times
in rapid succession (within 10
seconds). After doors lock/unlock,
press any button on all
transmitters (up to four). With
each button press of the
transmitters, the door should cycle
(lock/unlock) to confirm
programming. When completed,
switch the ignition to OFF. The
door locks should cycle
(lock/unlock) one last time to
confirm completion of
programming.
Controls and features
43

All transmitters must be
programmed at the same time.
Illuminated entry
Interior lamps will illuminate when
UNLOCK is pressed. The lamps
will illuminate for approximately 20
seconds or until the key is inserted
in the ignition and turned to ON or
until LOCK is pressed. The dome
lamp must be set to the DOOR
position in order for the
illuminated entry system to
operate.
ANTI-THEFT SYSTEM
(IF EQUIPPED)
When armed, the anti-theft system
will help protect your vehicle from
unauthorized entry.
Arming the anti-theft system
Turn the ignition to OFF and press
the lock control on the remote
entry transmitter.
Identifying an armed system
While the system is arming, the
THEFT light in the instrument
cluster will illuminate for 30
seconds. After 30 seconds, THEFT
will flash, indicating the system is
armed.
Controls and features
44

If the system is arming with the
doors open, the THEFT light will
stay illuminated until all the doors
are closed and then illuminate for
30 seconds and begin flashing.
When an unauthorized entry
occurs, the activated system will:
²flash the parking lamps and the
THEFT light
²sound the horn
The flashing parklamps and the
honking horn automatically shut
off after about three minutes and
will remain off unless another
unauthorized entry is attempted.
Disarming the anti-theft system
Disarming an untriggered
anti-theft system
Press the unlock control to disarm
the untriggered system. If the
driver armed the system but did
not exit the vehicle, disarm the
system by inserting the key and
turning the ignition to ON/ACC.
Using the ignition key to unlock
doors/trunk/liftgate will not disarm
the anti-theft system.
Controls and features
45

Disarming a triggered anti-theft
system
Press either the unlock or panic
control to disarm the system.
A triggered system may also be
disarmed by inserting the key and
turning the ignition to ACC or ON.
Controls and features
46

SEATING
Adjustable head restraints
(if equipped)
The head restraints can be moved
up and down.
Push control to lower head
restraint.
Front seats
Never adjust the driver's
seat or seatback when the
vehicle is moving.
Do not pile cargo higher
than the seatbacks to
avoid injuring people in a
collision or sudden stop.
Seating and safety restraints
47

Always drive and ride with
your seatback upright and
the lap belt snug and low across
the hips.
Lift handle to move seat forward
or backward.
Pull lever up to adjust seatback.
Seating and safety restraints
48

Driver seat memory recliner
(if equipped)
²Pull control to adjust seatback.
²To retain selected seatback
position, release seatback by
moving memory recliner control
forward to release seatback.
²Push seatback rearward until
the seatback latches. This will
be the first position selected.
Seating and safety restraints
49

Folding rear seats (if equipped)
Folding down the rear seats
If your vehicle is equipped with a
built-in child seat, the seatback
cannot be folded down unless the
built-in child seat is fully stowed.
SeeBuilt-in child seatsin this
chapter for more information.
To fold the seatback down:
²Press the latch control
downward or pull up on strap
and
²Push the seatback down.
Returning the seat to the
upright position
Check to see that the seat
and seatback is latched
securely in position. Keep floor
area free of objects that would
prevent proper seat engagement.
Never attempt to adjust the seat
while the vehicle is in motion.
To return the seat to the
upright/normal seating position:
²Rotate seat upward and latch.
The full rear bench seat is shown.
The split-folding rear seat (if
equipped) operates in a similar
manner.
Seating and safety restraints
50
