FORD EXCURSION 2001 1.G Rear Seat Entertainment System Manual

2. The VCP starts search playback in the normal (FF button) or reverse
(REW button) direction at a higher speed than normal.
3. To play the cassette normally, press the PLAY button.
AUXILIARY INPUT DEVICE CONNECTION
Connecting auxiliary video equipment
The Rear Seat Entertainment System accepts video and audio RCA type
connectors for all standard video games and video equipment (such as
camcorders) at the auxiliary input jacks of the media control panel.
Using AUX mode
1. Plug device into AUX input jacks on the media control panel.
2. Select AUX mode using the MEDIA control on the media control
panel.
3. Select Dual Play mode using the headphone/speaker control on the
media control panel.
Use only wired headphones plugged into the headphone jacks on the
media control panel. The wireless headphones are for the VCP only.
Operation
11

Use the following troubleshooting chart to remedy symptoms you may
experience.
Symptom Possible Cause Remedy
No picture on screen
after inserting a
videocassette (and
videocassette is
playing)RSEM control panel
not in VCP mode.Press MEDIA control
until VCP is selected.
Videocassette inserted
into VCP, but picture
does not come on
right awayThe VCP takes
approximately 10
seconds to play back
the videocassette.Wait 10 seconds for
picture to come on the
screen.
Snowy picture VCP heads are dirty. Use a head cleaner
cartridge.
VCP won't play and
DEW light is flashing
redMoisture is present
inside VCP and DEW
mode is active.Allow VCP to dry for
at least 20 minutes
(may take up to one
hour).
No sound over rear
speakers in any mode.Audio system is in
Dual Play mode.Press
headphone/speaker
control on RSEM
control panel.
Wireless headphones
don't function in
AM/FM1/FM2/AUX
modesWireless headphones
will not function in
these modes. Wireless
headphones are only
functional in VCP
mode.Plug wired
headphones into the
media control panel
headphone jacks when
in AM/FM1/FM2/AUX
modes.
Wireless headphones
have either no sound
or poor sound qualityWireless headphones
may have weak or
dead batteries.Replace worn-out
batteries.
Wireless headphones
do not work when I sit
in the front seat.The wireless
headphones only
function when worn in
a rear seating position.Move to a rear seating
position.
Troubleshooting
12
