FORD EXPLORER 1996 2.G Owners Manual

Steering Column Controls
141
*
[SC06450(ALL)09/95]
To change the position of the steering wheel, push the release
lever under the steering column away from you. Tip the
steering wheel to the desired position. Pull the lever back into
place to lock the steering wheel.
*
[SC07250(ALL)12/89]
Be sure the steering wheel locks in a notch. It is not infinitely
adjustable. Do not adjust the steering wheel while the vehicle is
in motion.
%*
[SC07300(ALL)03/91]
Speed Control (If equipped)
*
[SC07400(ALL)06/95]
If your vehicle has speed control, you can automatically
maintain a constant speed at or above 30 mph (50 km/h).
*
[SC07450(ALL)06/95]
Use of radio transmitting equipment that is not Federal
Communications Commission (FCC) or in Canada the Canadian
Radio and Telecommunications Commission (CRTC) approved
may cause the speed control to malfunction. Therefore, use only
properly installed FCC (CRTC in Canada) approved radio
transmitting equipment in your vehicle.
[SC07500(ALL)10/94]
7-1/2 pica art:0020091-F
The speed control switches
*
[SC07800(ALL)08/95]
To set the speed control:
*
[SC08000(ALL)08/95]1.
Press and release the ON switch.
[SC08100(ALL)02/95]2.
Accelerate to the desired speed above 30 mph (48 km/h)
using the accelerator pedal.
File:07unscx.ex
Update:Thu Feb 29 09:06:35 1996

142
[SC08300(ALL)03/95]3.
Press SET ACCEL switch and release it immediately. This
will set your speed. If you keep this switch pressed, your
speed will continue to increase and will not be set until the
switch is released.
*
[SC08500(ALL)08/95]4.
Take your foot off the accelerator pedal. Your vehicle will
maintain the speed you set.
*
[SC08600(ALL)08/95]
If you drive up or down a steep hill, your vehicle may
momentarily slow down or speed up, even though the speed
control is on. This is normal.
[SC08630(ALL)09/95]
NOTE: If your vehicle is equipped with an automatic
transmission, and if your speed increases above your
set speed while driving in
j(Overdrive) on a
downhill grade, you may want to shift to D (Drive) to
reduce vehicle speed. This can be accomplished by
pushing in the Transmission Control switch which is
located on the end of the gearshift lever. The speed
control cannot reduce the vehicle speed if it goes
above your set speed on a downhill grade. For the
best fuel economy during normal driving conditions,
leave the shift select in
j(Overdrive), or resume as
soon as practical.
[SC08675(ALL)03/95]
NOTE: If your vehicle is equipped with a 5 speed manual
transmission, and if your speed increases above your
set speed while driving in 5 (Fifth) gear on a downhill
grade, you may want to shift to 4 (Fourth) gear to
reduce vehicle speed. Depressing the clutch pedal
cancels speed control, therefore speed control must be
reset by pressing the SET ACCEL or RESUME
switches. Speed control cannot reduce the vehicle
speed if it goes above your set speed on a downhill
grade.
File:07unscx.ex
Update:Thu Feb 29 09:06:35 1996

Steering Column Controls
143
*
[SC08700(ALL)08/95]
RWARNING
Do not use the speed control in heavy traffic or on roads
that are winding, slippery, or unpaved.
*
[SC08801(ALL)05/95]
In mountainous areas, at higher elevations, or when pulling a
trailer, the speed control may not be able to maintain the preset
speed with the transmission in
j(Overdrive).
*
[SC08850(ALL)06/92]
If your vehicle comes with a 5-speed manual transmission, you
may prefer to drive in 4 (Fourth) gear, in mountainous areas or
at high altitudes, to improve speed control performance.
*
[SC09275(ALL)12/91]
In order to downshift (with a manual transmission) with the
speed control operating, you must press either the brake or
clutch pedal long enough to disengage the speed control. Wait a
second before depressing the clutch again and making the shift
so that the speed control can fully return to the idle position.
*
[SC09325(ALL)05/95]
RWARNING
Do not shift the transmission into N (Neutral) with the
speed control on.
[SC09350(ALL)03/95]
To maintain a preset speed under the above conditions, with
electronically controlled transmissions Ð press the Transmission
Control Switch (TCS). The indicator light will turn on and
illuminate the words ªO/D OFF.º This will cancel ªOverdrive.º
You can press the Transmission Control Switch (TCS) on or off
at any speed. For the best fuel economy during normal driving
conditions, press the Transmission Control Switch (TCS) to turn
off the light. This allows overdrive operation.
File:07unscx.ex
Update:Thu Feb 29 09:06:35 1996

144
[SC09375(ALL)10/94]
quarter page
art:0021255-A
Transmission control switch
%*
[SC09400(ALL)08/95]
Accelerating With the Speed Control Operating
*
[SC09500(ALL)08/95]
You can use the accelerator pedal to speed up momentarily.
When you take your foot off the accelerator, the vehicle will
return to the set speed.
%*
[SC09600(ALL)08/95]
Resetting the Speed Control
*
[SC09700(ALL)06/95]
To reset the speed control to alower speed, press and hold the
COAST switch. Let your vehicle slow down to the desired
speed and release the COAST switch.
*
[SC09750(ALL)10/94]
Your vehicle has a ªtap-downº feature that allows you to
decrease your current speed in increments of 1 mph (1.6 km/h)
by a momentary tap of the COAST switch. Multiple taps of the
COAST switch will decrease your vehicle speed 1 mph
(1.6 km/h) for each tap. For example, if you are currently set at
65 mph (104 km/h) and tap the COAST switch 5 times your
vehicle speed will decrease and set at 60 mph (96 km/h).
*
[SC09800(ALL)06/95]
To reset the speed control to ahigher speed, you can follow
any of these procedures:
[SC09900(ALL)08/94]
n
Accelerate to the desired speed, then press the SET ACCEL
switch and release it immediately.
[SC10100(ALL)08/94]
n
Press and hold the SET ACCEL switch, then accelerate to
your desired speed and release the switch.
File:07unscx.ex
Update:Thu Feb 29 09:06:35 1996

Steering Column Controls
145
*
[SC10250(ALL)10/94]
n
TAP-UP Ð This allows you to increase your current speed in
increments of 1 mph (1.6 km/h) by a momentary tap of the
SET-ACCEL switch. Multiple taps of the SET-ACCEL switch
will increase your vehicle speed 1 mph (1.6 km/h) for each
tap. For example, if you are currently set at 60 mph
(96 km/h) and tap the SET-ACCEL switch 5 times your
vehicle speed will increase and set at 65 mph (104 km/h).
*
[SC10300(ALL)06/95]
Turning the Speed Control Off
*
[SC10400(ALL)06/95]
You can cancel the speed control while you are driving.
[SC10550(ALL)08/94]
n
Press the OFF switch. The speed control is off. If you want
to resume speed control, press the ON switch and reset the
speed control by pressing the SET ACCEL switch.
[SC10600(ALL)06/94]
n
Press the brake or clutch pedal slightly. The speed control is
suspended, but you can reset it by pressing SET ACCEL or
return to the previous set speed with the RSM switch.
*
[SC10800(ALL)10/95]
In addition, the speed control is turned off each time you turn
the vehicle ignition off.
*
[SC11100(ALL)11/89]
Driving uphill or on a steep grade
*
[SC11200(ALL)05/95]
When the speed control is on, your vehicle may significantly
drop speed when driving uphill, especially with a heavy load. If
the speed drops more than 8 to 14 mph (15 - 25 km/h) the
automatic speed control will, by design, be canceled. You may
have to temporarily resume manual speed control while driving
up a steep grade in order to maintain the speed you desire.
[SC11300(ALL)05/95]
If the speed control ªdropped outº after your climb is
completed, the speed of your light truck can be reset with the
SET ACCEL switch, or returned to the previous set speed with
the RSM switch, as long as you are driving over 30 mph
(50 km/h).
File:07unscx.ex
Update:Thu Feb 29 09:06:35 1996

146
%*
[SC11500(ALL)08/95]
Cancelling and Resuming a Set Speed
*
[SC11600(ALL)06/95]
If you press the brake pedal, the speed control is cancelled. You
can return to the speed you set by using the RSM switch, as
long as you did not press the OFF switch.
*
[SC11700(ALL)08/95]
To resume the speed you had before, you must be driving at
least 30 mph (50 km/h).
*
[SC11800(ALL)05/93]
Press and release the RSM switch. Your vehicle gradually
returns to the previously set speed and then maintains it.
*
[SC11850(ALL)03/95]
RWARNING
If your vehicle has speed control, do not use it on
slippery roads. You could lose control of your vehicle
and could injure someone.
[SC12000( X)06/95]
Speed Control Indicator (If equipped)
[SC12100( X)08/94]
A SPEED CONTROL light is displayed in the instrument cluster
when the speed control system is engaged. The display will turn
off when the brake pedal is pressed or if speed control is shut
off.
*
[SC12200( X)05/95]
This display does not indicate any problems with the speed
control, but is simply a convenient way of knowing when it is
active.
File:07unscx.ex
Update:Thu Feb 29 09:06:35 1996

147
Features
*
[FV00350(ALL)02/95]
Your vehicle has a variety of features designed for your
comfort, convenience and safety. Read this chapter to find out
about standard and optional features.
%*
[FV00601(ALL)01/95]
Doors
*
[FV00701(ALL)06/95]
Door Handles and Locks
[FV00901( X)08/94]
17-1/2 pica
art:0020548-C
Inside handles
File:08unfvx.ex
Update:Thu Feb 29 13:56:40 1996

148
[FV01502( X)10/94]
10-1/2 pica
art:0021367-A
Outside handles and locks
[FV01600( X)10/95]
Two step unlock feature (if equipped)
[FV01620( X)10/95]
This feature allows you to unlock all vehicle doors with the key.
[FV01640( X)10/95]1.
Unlock driver door with key.
[FV01660( X)12/95]2.
Repeat unlock procedure within 5 seconds. All doors will
unlock when the key is returned to the vertical position
(position of the key before removal).
[FV01680( X)10/95]
NOTE: This feature can be activated by all outside locks on
vehicles equipped with keyless entry.
%*
[FV01801(ALL)03/95]
Anti-theft front door lock knobs
*
[FV01901(ALL)10/89]
Anti-theft lock knobs are designed to preclude unlocking the
door by pulling up on the bullet type lock knob. To unlock and
open the front door from the inside of the vehicle, pull on the
inside door handle.
File:08unfvx.ex
Update:Thu Feb 29 13:56:40 1996

Features
149
[FV02001( X)01/91]
Setting the Childproof Locks for the Rear Doors
*
[FV02101( X)03/95]
In addition to standard or power locks, your vehicle has
childproof locks for the rear doors. If you set these locks, the
rear doors cannot be opened from the inside of the vehicle. The
doors can still be opened from the outside when the lock knobs
are raised.
[FV02300( X)08/94]
17-1/2 pica
art:0020545-C
The child lock lever
*
[FV02401( X)03/95]
To set the childproof lock on each rear door, open the rear
door.
[FV02601( X)01/95]
Find the lever near the white label with the word LOCKED in
green letters. Move the lever up.
*
[FV02801( X)03/95]
To release the childproof lock, open the rear door from the
outside.
*
[FV03001( X)06/95]
Move the lever down.
File:08unfvx.ex
Update:Thu Feb 29 13:56:40 1996

150
[FV04900( X)08/94]
Liftgate Handle and Locks
[FV05000( X)10/94]
10-1/2 pica art:0020550-F
Liftgate handle and locks
[FV05100( X)11/89]
You can unlock the liftgate by using the key. To open the
liftgate, rotate the handle clockwise and to open the liftgate
window, rotate the handle counterclockwise.
[FV05200( X)05/95]
You can lock the liftgate by using the key, pushing the lock
button down, or using the power door lock switch on the left
side of the cargo area.
*
[FV05300( X)10/89]
Make certain that you close the liftgate door and window before
driving your vehicle. If you do not, possible damage may occur
to the liftgate door lift cylinders and attaching hardware.
*
[FV05400( X)08/95]
RWARNING
When driving your vehicle make sure that the liftgate
door and window are closed to prevent exhaust fumes
from being drawn into the vehicle. This will also prevent
cargo from falling out.
*
[FV05900( X)12/93]
The liftgate area is only intended for cargo, not passengers. You
can open and close the liftgate from outside the vehicle. It
cannot be opened from inside the cargo area.
File:08unfvx.ex
Update:Thu Feb 29 13:56:40 1996
