To fill the fuel tank properly:
*
[SV10550( ALL)01/95]
NOTE: Extinguish all lit cigarettes, other
smoking materials, and any open
flames before fueling your vehicle.
*
[SV10600( ALL)01/95]
1. Remove the fuel cap by following the
instructions above underRemoving the Fuel
Capin this chapter. Proceed to add fuel to
the tank only if your vehicle is on level
ground.
*
[SV10700( ALL)05/95]
2. Make sure that you pump unleaded fuel and
put the nozzle all the way inside the fuel
filler pipe.
*
[SV10800( ALL)05/95]
3. If you spill any fuel on the body of your
vehicle, clean it off immediately. The fuel
may dull or soften the paint if you do not
wash it off.
%*
[SV10900( ALL)05/95]
4. Replace the fuel cap completely when you
are finished. Turn it clockwise 1/4 turn until
it is tight. It will click when it is fully
tightened.
%*
[SV11300( ALL)05/95]
Running Out of Fuel
*
[SV11400( ALL)05/95]
If your vehicle runs out of fuel, try to stop on
level ground away from traffic. Add at least two
gallons (8 liters) of fuel to start your vehicle
again. If your vehicle is not on level ground,
you may need as much as five gallons (20 liters)
of fuel to start it.
*
[SV11500( ALL)05/95]
You may need to crank the engine several times
before the fuel system starts to pump fuel from
the tank to the engine.
%*
[SV11600( ALL)05/95]
Fuel Economy
*
[SV11700( ALL)05/95]
Fuel economy is an estimate of the efficiency of
your vehicle and can be calculated as Miles Per
Gallon (MPG) or Liters Per 100 Kilometers
(L/100K).
File:ltsvm.ex
Update:Tue Jun 20 16:44:35 1995

118
*
[SV11750( ALL)05/95]
Do not calculate fuel economy during your
vehicle's break-in period. This would not be an
accurate estimate of how much fuel your vehicle
will normally use.
*
[SV11800( ALL)05/95]
To calculate fuel economy:
*
[SV11900( ALL)05/95]
1. Fill the tank completely and record the inital
odometer reading.
*
[SV12000( ALL)05/95]
2. Every time you buy fuel record the
amount (in gallons or liters) purchased.
*
[SV12200( ALL)05/95]
3. After at least three to five tankfuls, fill the
fuel tank and record the final odometer
reading.
*
[SV12225( ALL)05/95]
4. Use these equations to calculate your fuel
economy.
*
[SV12250( ALL)05/95]
q
English: MPG = (total miles)/(gallons used).
*
[SV12275( ALL)05/95]
q
Metric: L/100K = (liters used) x 100/(total
kilometers)
%*
[SV12500( ALL)05/95]
Improving Fuel Economy
*
[SV12600( ALL)05/95]
Fuel economy is affected by a number of
variables which can reduce efficiency. You can
improve fuel economy by understanding these
variables and minimizing their effect.
*
[SV12700( ALL)05/95]
The following decrease fuel economy:
*
[SV12800( ALL)05/95]
q
Lack of regular, scheduled maintenance
*
[SV12900( ALL)05/95]
q
Driving with your foot on the brake
*
[SV13000( ALL)05/95]
q
Sudden stops
*
[SV13100( ALL)05/95]
q
Excessive speed
*
[SV13200( ALL)05/95]
q
Extended engine idling
*
[SV13300( ALL)05/95]
q
Heavy loads
*
[SV13400( ALL)05/95]
q
Underinflated tires
[SV13515( M)03/94]
q
Use your air conditioning system wisely.
File:ltsvm.ex
Update:Tue Jun 20 16:44:35 1995

119
%*
[SV13600( ALL)02/95]
Engine Oil Recommendations
*
[SV13610( ALL)05/95]
We recommend using Motorcraft oil or an
equivalent oil meeting Ford Specification
ESE-M2C153-E and displaying the American
Petroleum Institute CERTIFICATION MARK on
the front of the container.
*
[SV13655( ALL)03/95]
one third page art:0060020-D
The API Certification Mark
*
[SV13670( ALL)01/95]
Neveruse:
*
[SV13680( ALL)01/95]
q
ªNon-Detergentº oils
*
[SV13690( ALL)04/95]
q
Oils labeled API SA, SB, SC, SD, SE, SF or SG
%*
[SV13700( ALL)01/95]
q
Additional engine oil additives, oil treatments
or engine treatments
[SV13710( ALL)04/95]
Engine oils with anSAE 10W-30viscosity are
PREFERREDfor your vehicle which provide the
best engine protection for all climates down to
-5ÊF (-20ÊC). SAE5W-30 engine oils may also be
used down to-15ÊF (-25ÊC).
%*
[SV13725( ALL)03/95]
Synthetic engine oils which are CERTIFIED and
of the preferred viscosity may be used in your
engine. The engine oil and oil filter must still be
changed according to the maintenance schedule.
File:ltsvm.ex
Update:Tue Jun 20 16:44:35 1995

120
*
[SV13775( ALL)01/95]
Checking and Adding Engine Oil
*
[SV13800( ALL)03/95]
Since the proper amount of engine oil is
important for safe engine operation, check the oil
using the dipstick each time you put fuel in
your vehicle. Remember the engine must be off,
the oil must be warm and the vehicle must be
parked on level ground.
%*
[SV13900( ALL)03/95]
Checking the engine oil level:
*
[SV14000( ALL)02/95]
1. Turn the engine off after it has warmed up
and allow a few minutes for the engine oil
to drain back into the oil pan.
*
[SV14075( E M)03/95]
2. Set the parking brake, making sure the
gearshift is securely latched in P (Park).
*
[SV14100( ALL)02/95]
3. Open the hood. Protect yourself from engine
heat.
*
[SV14200( ALL)03/95]
4. Locate the engine oil dipstick (highlighted in
yellow) and carefully pull it out of the
engine.
*
[SV14300( ALL)01/95]
5. Wipe the dipstick clean and put it back into
position, making sure it is fully seated.
*
[SV14400( ALL)06/95]
quarter page art:0010364-D
Engine oil dipstick
File:ltsvm.ex
Update:Tue Jun 20 16:44:35 1995

121
*
[SV14500( ALL)02/95]
6. Carefully, pull the dipstick out again. If the
oil level is below the ªADD 1 QT.º line, add
engine oil as necessary. If the oil level is
beyond the letter ªFº in FULL, engine
damage or high oil consumption may occur
and some oil must be removed from the
engine.
*
[SV14600( ALL)01/95]
7. Put the dipstick back in and make sure it is
fully seated.
*
[SV14800( ALL)01/95]
It may be necessary to add some oil between oil
changes. Make sure you use a CERTIFIED
engine oil of the preferred viscosity. Your
vehicle's warranty coverage may not apply if
engine damage is caused by the use of improper
engine oil.
*
[SV15000( ALL)03/95]
Add engine oil through the oil filler cap
highlighted in yellow. To add oil, remove the
filler cap and use a funnel to pour oil into the
opening. Be careful not to overfill the engine.
Recheck the oil level after you finish adding oil.
%*
[SV16300( EFM)06/95]
Changing the Engine Oil and the Oil Filter
*
[SV16500( ALL)04/95]
Change the engine oil and oil filterper the
following, whichever occurs first.
[SV16601( M)03/94]
quarter page art:0021101-A
Oil change intervals
File:ltsvm.ex
Update:Tue Jun 20 16:44:35 1995

122
*
[SV16625( ALL)06/95]
NOTE: Idling the engine for extended periods
will accumulate more hours of use on
your vehicles than is actually indicated
by the mileage odometer.
Consequently, the odometer reading
can be often misleading when
determining the right time to change
your engine oil and filter.
*
[SV16800( ALL)06/95]
Refer to theMaintenance Schedule and Record
booklet for additional information.
%*
[SV17250( ALL)04/95]
NOTE: Always dispose of used automotive
fluids in a responsible manner. Follow
your community's standards for
disposing of these types of fluids. Call
your local recycling center to find out
about recycling automotive fluids.
*
[SV17275( ALL)06/95]
RWARNING
Continuous contact with USED motor oil
has caused cancer in laboratory mice.
*
[SV17280( ALL)05/95]
Protect your skin by washing with soap and
water.
*
[SV17300( ALL)03/95]
Engine Coolant
*
[SV17400( ALL)02/95]
Checking the engine coolant
*
[SV17700( ALL)10/89]
Your vehicle's engine coolant protects the engine
from overheating in the summer and from
freezing in the winter. Check the level of the
engine coolant at least once a month, but
preferably each time you stop for fuel. Simply
look at the engine coolant recovery reservoir
located in the engine compartment. To locate
this reservoir, see the diagram of your vehicle's
engine underEngine typesin this chapter.
File:ltsvm.ex
Update:Tue Jun 20 16:44:35 1995

123
*
[SV17750( ALL)03/95]
If the engine coolant has not been checked for a
long period of time the engine coolant reservoir
may eventually empty. If the engine coolant
reservoir empties, check the engine coolant level
in the radiator. Read the following warnings
before removing the radiator cap. If it is
necessary to fill the radiator, refer to theEngine
Coolant Refill Procedurein this chapter for
instructions.
[SV17800( M)02/92]
Your cooling system is of the coolant recovery
type. The engine coolant recovery reservoir is a
one-piece molded unit. Engine coolant in the
system expands with heat and overflows into the
engine coolant recovery reservoir. When the
system cools down, coolant is drawn back into
the radiator.
*
[SV18125( M)01/95]
Adding engine coolant
% [SV18175( M)07/93]
one third page art:0020728-B
Adding engine coolant
*
[SV18400( ALL)05/95]
RWARNING
Do not put engine coolant in the container
for the windshield washer fluid.
File:ltsvm.ex
Update:Tue Jun 20 16:44:35 1995

124
*
[SV18420( ALL)06/95]
If sprayed to clean the glass, engine coolant or
antifreeze could make it difficult to see through
the windshield.
*
[SV18500( ALL)05/95]
RWARNING
Never remove the coolant recovery cap
while the engine is running or hot.
*
[SV18600( ALL)05/95]
RWARNING
Follow these steps to minimize risk of
personal injury.
*
[SV18700( ALL)03/95]
1. Before you remove the cap, turn the engine
off and let it cool. Even when the engine is
cool, be careful when you remove the
radiator cap.
*
[SV18800( ALL)05/95]
2. When the engine is cool, wrap a thick cloth
around the cap and turn it slowly
counterclockwise to the first stop.
*
[SV18900( ALL)03/95]
3. Step back while the pressure releases.
*
[SV19000( ALL)05/95]
4. When you are sure that all the pressure has
been released, use the cloth to press, turn,
and remove cap.
*
[SV19100( ALL)03/95]
5. Stand away from the radiator opening. Hot
steam may blow out or hot engine coolant
may even splash out.
File:ltsvm.ex
Update:Tue Jun 20 16:44:35 1995

125 %
*
[SV19500( ALL)01/93]
Freezing Protection
*
[SV19600( ALL)03/91]
The factory-installed solution of Ford Premium
Cooling System Fluid and water will protect
your vehicle tos35ÊF (s37ÊC).Check the freeze
protection rating of the engine coolant at least
once a year, just before winter.
*
[SV19701( ALL)06/95]
Add engine coolant only to the recovery
reservoir.If the coolant level is low, add to the
reservoir a 50/50 mixture of water and the type
of engine coolant that Ford specifies. You may
add water by itself only in an emergency, but
you should replace it with a 50/50 mixture as
soon as possible.
*
[SV19801( ALL)02/95]
Ford Premium Cooling System Fluid is an
optimized formula that will protect all metals
and rubber elastomers used in Ford engines for
four years or 50,000 miles (80,000 km). It is not
necessary and not recommended to use
supplemental coolant additives in your gasoline
powered vehicle. These additives may harm
your engine cooling system. Follow the
recommended service interval for changing your
engine coolant.
*
[SV19851( ALL)04/94]
NOTE: When you change or add engine
coolant, it is important to maintain
your engine coolant concentration
between 40%(-11ÊF [-24ÊC]) and 60%
(-62ÊF [-52ÊC]),depending on your local
climate conditions. Below 40% you will
lose freeze protection and above 60%
your engine may overheat on a warm
day.
File:ltsvm.ex
Update:Tue Jun 20 16:44:35 1995

126 %
*
[SV19950( ALL)03/95]
NOTE: Do not use an engine coolant that does
not meet all 14 requirements of Ford
Specification ESE-M97B44-A. The use
of an improper coolant may void your
warranty for the engine cooling system.
Use only a premium nationally
recognized brand name engine coolant.
*
[SV19960( ALL)05/95]
Ford Motor Company expressly authorizes the
Ford Rotunda engine coolant recycling process
and chemicals. Use only Ford Rotunda recycled
engine coolant or an equivalent recycled engine
coolant that is certified by the supplier to meet
Ford specification ESE-M97B44-A.
%*
[SV19980( ALL)04/95]
NOTE: Always dispose of used automotive
fluids in a responsible manner. Follow
your community's standards for
disposing of these types of fluids. Call
your local recycling center to find out
about recycling automotive fluids.
%*
[SV20001( ALL)01/95]
Use Ford Premium Cooling System Fluid or an
equivalent engine coolant that meets Ford
Specification ESE-M97B44-A. Do not use alcohol
or methanol antifreeze and do not use engine
coolant mixed with alcohol or methanol
antifreeze. If you do not use the proper coolant,
the aluminum radiator on your vehicle will
corrode.
*
[SV20100( ALL)01/95]
Leave the engine coolant in all year. Make sure
that the coolant will not freeze at the
temperature level in which you drive during
winter months. Keep a mixture of engine coolant
in your engine that has a protection rating of at
least-34ÊF (-37ÊC), orwhatever protection rating
is appropriate for the climate in which you live.
*
[SV20125( ALL)03/95]
To find out how much engine coolant mixture
your vehicle's coolant system can hold, seeRefill
capacities for fluidsin the Index.
File:ltsvm.ex
Update:Tue Jun 20 16:44:35 1995
