Engine oil dipstick
*
[SV14500( ALL)02/95]
6. Carefully, pull the dipstick out again. If the
oil level is below the ªADD 1 QT.º line, add
engine oil as necessary. If the oil level is
beyond the letter ªFº in FULL, engine
damage or high oil consumption may occur
and some oil must be removed from the
engine.
*
[SV14600( ALL)01/95]
7. Put the dipstick back in and make sure it is
fully seated.
*
[SV14800( ALL)01/95]
It may be necessary to add some oil between oil
changes. Make sure you use a CERTIFIED
engine oil of the preferred viscosity. Your
vehicle's warranty coverage may not apply if
engine damage is caused by the use of improper
engine oil.
*
[SV15000( ALL)03/95]
Add engine oil through the oil filler cap
highlighted in yellow. To add oil, remove the
filler cap and use a funnel to pour oil into the
opening. Be careful not to overfill the engine.
Recheck the oil level after you finish adding oil.
File:ltsvf.ex
Update:Thu May 9 15:30:19 1996

323 %
*
[SV16300( EFM)01/95]
Changing the Engine Oil and the Oil Filter
*
[SV16500( ALL)04/95]
Change the engine oil and oil filterper the
following, whichever occurs first.
*
[SV16600(BEF )04/95]
one third page art:0060618-C
Oil change intervals
*
[SV16625( ALL)03/95]
NOTE: Idling the engine for extended periods
will accumulate more hours of use on
your vehicles than is actually indicated
by the mileage odometer.
Consequently, the odometer reading
can be often misleading when
determining the right time to change
your engine oil and filter.
*
[SV16650(BEF )03/95]
If you are using your Ford vehicle in a manner
which allows it to remain stationary while the
engine is running for long periods (door to door
delivery, taxi, police, power/utility company
trucks, or similar duty), then Ford recommends
you increase the frequency of oil and filter
changes to an interval equivalent to 200
ENGINE HOURS of use. Since most vehicles are
not equipped with hourmeters, it may be
necessary for you to approximate your idle time
and plan oil/filter changes accordingly.
File:ltsvf.ex
Update:Thu May 9 15:30:19 1996

324
*
[SV16700( EF )06/93]
If your vehicle is over 8500 GVWR and the
above conditions do not apply, change the
engine oil and oil filter every 6 months or 5,000
miles (8,000 km), whichever comes first.
*
[SV16800( ALL)04/95]
Refer to theMaintenance Schedule and Record
booklet for additional information.
*
[SV16900( EF )03/94]
NOTE: Refer to thePower Stroke Diesel Engine
Owner's Guide Supplementfor oil
viscosity, filter application and oil and
filter change intervals.
%*
[SV17250( ALL)04/95]
NOTE: Always dispose of used automotive
fluids in a responsible manner. Follow
your community's standards for
disposing of these types of fluids. Call
your local recycling center to find out
about recycling automotive fluids.
*
[SV17275( ALL)05/95]
RWARNING
Continuous contact with USED motor oil
has caused cancer in laboratory mice.
*
[SV17280( ALL)05/95]
Protect your skin by washing with soap and
water.
*
[SV17300( ALL)03/95]
Engine Coolant
*
[SV17400( ALL)02/95]
Checking the engine coolant
*
[SV17700( ALL)10/89]
Your vehicle's engine coolant protects the engine
from overheating in the summer and from
freezing in the winter. Check the level of the
engine coolant at least once a month, but
preferably each time you stop for fuel. Simply
look at the engine coolant recovery reservoir
located in the engine compartment. To locate
this reservoir, see the diagram of your vehicle's
engine underEngine typesin this chapter.
File:ltsvf.ex
Update:Thu May 9 15:30:19 1996

325
*
[SV17750( ALL)03/95]
If the engine coolant has not been checked for a
long period of time the engine coolant reservoir
may eventually empty. If the engine coolant
reservoir empties, check the engine coolant level
in the radiator. Read the following warnings
before removing the radiator cap. If it is
necessary to fill the radiator, refer to theEngine
Coolant Refill Procedurein this chapter for
instructions.
*
[SV17950(BEF )01/95]
Adding engine coolant
*
[SV18000(B F )07/94]
quarter page art:0020354-A
Adding engine coolant
*
[SV18150(B F )05/90]
quarter page art:0020360-C
Adding engine coolant
*
[SV18400( ALL)05/95]
RWARNING
Do not put engine coolant in the container
for the windshield washer fluid.
*
[SV18420( ALL)05/95]
If sprayed to clean the glass, engine coolant or
antifreeze could make it difficult to see through
the windshield.
File:ltsvf.ex
Update:Thu May 9 15:30:19 1996

326
*
[SV18500( ALL)05/95]
RWARNING
Never remove the coolant recovery cap
while the engine is running or hot.
*
[SV18600( ALL)05/95]
RWARNING
Follow these steps to minimize risk of
personal injury.
*
[SV18700( ALL)03/95]
1. Before you remove the cap, turn the engine
off and let it cool. Even when the engine is
cool, be careful when you remove the
radiator cap.
*
[SV18800( ALL)03/95]
2. When the engine is cool, wrap a thick cloth
around the cap and turn it slowly
counterclockwise to the first stop.
*
[SV18900( ALL)03/95]
3. Step back while the pressure releases.
*
[SV19000( ALL)04/95]
4. When you are sure that all the pressure has
been released, use the cloth to press, turn,
and remove cap.
*
[SV19100( ALL)03/95]
5. Stand away from the radiator opening. Hot
steam may blow out or hot engine coolant
may even splash out.
*
[SV19500( ALL)01/93]
Freezing Protection
*
[SV19600( ALL)03/91]
The factory-installed solution of Ford Premium
Cooling System Fluid and water will protect
your vehicle tos35ÊF (s37ÊC).Check the freeze
protection rating of the engine coolant at least
once a year, just before winter.
*
[SV19701( ALL)02/95]
Add engine coolant only to the recovery
reservoir.If the coolant level is low, add to the
reservoir a 50/50 mixture of water and the type
of engine coolant that Ford specifies. You may
add water by itself only in an emergency, but
you should replace it with a 50/50 mixture as
soon as possible.
File:ltsvf.ex
Update:Thu May 9 15:30:19 1996

327
*
[SV19801( ALL)02/95]
Ford Premium Cooling System Fluid is an
optimized formula that will protect all metals
and rubber elastomers used in Ford engines for
four years or 50,000 miles (80,000 km). It is not
necessary and not recommended to use
supplemental coolant additives in your gasoline
powered vehicle. These additives may harm
your engine cooling system. Follow the
recommended service interval for changing your
engine coolant.
*
[SV19851( ALL)04/94]
NOTE: When you change or add engine
coolant, it is important to maintain
your engine coolant concentration
between 40%(-11ÊF [-24ÊC]) and 60%
(-62ÊF [-52ÊC]),depending on your local
climate conditions. Below 40% you will
lose freeze protection and above 60%
your engine may overheat on a warm
day.
*
[SV19950( ALL)03/95]
NOTE: Do not use an engine coolant that does
not meet all 14 requirements of Ford
Specification ESE-M97B44-A. The use
of an improper coolant may void your
warranty for the engine cooling system.
Use only a premium nationally
recognized brand name engine coolant.
*
[SV19960( ALL)05/95]
Ford Motor Company expressly authorizes the
Ford Rotunda engine coolant recycling process
and chemicals. Use only Ford Rotunda recycled
engine coolant or an equivalent recycled engine
coolant that is certified by the supplier to meet
Ford specification ESE-M97B44-A.
%*
[SV19980( ALL)04/95]
NOTE: Always dispose of used automotive
fluids in a responsible manner. Follow
your community's standards for
disposing of these types of fluids. Call
your local recycling center to find out
about recycling automotive fluids.
File:ltsvf.ex
Update:Thu May 9 15:30:19 1996

328
*
[SV20001( ALL)01/95]
Use Ford Premium Cooling System Fluid or an
equivalent engine coolant that meets Ford
Specification ESE-M97B44-A. Do not use alcohol
or methanol antifreeze and do not use engine
coolant mixed with alcohol or methanol
antifreeze. If you do not use the proper coolant,
the aluminum radiator on your vehicle will
corrode.
*
[SV20100( ALL)01/95]
Leave the engine coolant in all year. Make sure
that the coolant will not freeze at the
temperature level in which you drive during
winter months. Keep a mixture of engine coolant
in your engine that has a protection rating of at
least-34ÊF (-37ÊC), orwhatever protection rating
is appropriate for the climate in which you live.
*
[SV20125( ALL)03/95]
To find out how much engine coolant mixture
your vehicle's coolant system can hold, seeRefill
capacities for fluidsin the Index.
*
[SV20151( ALL)01/95]
You may add water by itself only in an
emergency, but you should replace it with a
50/50 or appropriate mixture as soon as
possible.
*
[SV20200( ALL)01/95]
Have your dealer check the engine cooling
system for leaks if you have to add a quart
(liter) of engine coolant more than once a month.
%*
[SV20500( ALL)11/94]
Checking hoses
*
[SV20600( ALL)10/89]
Inspect all engine and heater system hoses for
deterioration, leaks and loose clamps before
adding or replacing engine coolant. Make
whatever repairs or replacements that are
necessary using Motorcraft parts or their
equivalents.
File:ltsvf.ex
Update:Thu May 9 15:30:19 1996

329
*
[SV20700( ALL)05/95]
Engine coolant drain and flush
*
[SV20800( ALL)10/89]
To drain your vehicle's engine coolant:
*
[SV20900( ALL)03/94]
1. Turn off the engine and let it cool. Fully
depressurize the engine cooling system by
covering the radiator cap with a thick cloth
and turning it slowly counterclockwise to the
first stop. Step back while the pressure
releases.
*
[SV20950( ALL)05/90]
2. Remove the cap.
*
[SV21000(B FM)05/90]
3. Attach a small hose to the drain tube at the
bottom of the radiator.
*
[SV21200( ALL)05/90]
4. Let the engine coolant drain into a suitable
container. Disconnect the lower radiator hose
at the radiator connector and drain any
remaining engine coolant into a container.
*
[SV21225( ALL)05/94]
5. Reconnect the lower radiator hose and close
the radiator drain cock.
*
[SV21250( ALL)10/94]
Proper procedures for flushing the cooling
system can be found in theTruck Service Manual.
*
[SV21300( ALL)02/95]
Engine coolant refill procedure
*
[SV21400( ALL)10/89]
After you have drained the engine cooling
system:
*
[SV21500( ALL)01/89]
1. Fill the radiator with a 50/50 mixture of the
specified engine coolant concentrate and
water. Allow several minutes for trapped air
to escape (bubble out) and for engine coolant
to flow through the radiator.
*
[SV21900( ALL)03/94]
2. Replace the radiator cap to its fully installed
position, then back off to the first stop. This
will prevent high pressure from building up
in the cooling system during this part of the
fill procedure.
File:ltsvf.ex
Update:Thu May 9 15:30:19 1996

330
*
[SV22100( ALL)10/89]
3. Start and idle the engine until the thermostat
opens and the radiator upper hose becomes
warm.
*
[SV22200( ALL)05/95]
4. Shut off the engine and allow the engine to
cool. Cover the radiator cap with a thick
cloth and cautiously remove it. Step back
while the pressure releases.
*
[SV22500( ALL)10/89]
5. Finally, check the radiator and add more
engine coolant if needed, following the
procedures noted above. Reinstall the
radiator cap securely, when finished.
*
[SV22525( ALL)05/90]
6. If more engine coolant is necessary, fill the
overflow reservoir to the appropriate level
marked on the bottle.
*
[SV22700(BEF )03/95]
Windshield Washer Fluid and
Wipers
*
[SV22800(BEF )03/95]
Washer Fluid
*
[SV22900(BEF )01/95]
Check the level of the windshield washer fluid
every time you stop for fuel. The reservoir for
the windshield washer fluid is located in the
engine compartment.
*
[SV23200(BEF )03/95]
Adding washer fluid
*
[SV23300(BEF )05/95]
RWARNING
Do not put windshield washer fluid in the
container for the engine coolant.
File:ltsvf.ex
Update:Thu May 9 15:30:19 1996

331
*
[SV23600(B F )02/92]
quarter page art:0020360-C
Adding windshield washer fluid
%*
[SV23850(BEF )01/95]
Use specially formulated windshield washer
fluid rather than plain water, because specially
formulated washer fluids contain additives that
dissolve road grime. For safety reasons, washer
fluids containing an appropriate antifreeze such
as methanol should be used in freezing weather
(temperatures below32ÊF [0ÊC]).State or local
regulations on Volatile Organic Compounds
(VOC's) may restrict use of the most common
antifreeze, methanol. Washer fluids containing
non-methanol antifreeze agents should be used
only if they provide cold weather protection
without damaging the vehicle's paint finish,
wiper blades, and windshield washer system.
*
[SV23900(BEF )10/89]
If you choose to use a windshield washing
solution that must be mixed, follow the
manufacturer's mixing instructions. Improperly
mixed solutions may freeze unexpectedly.
[SV24000(BEF )04/95]
NOTE: The addition of shields to the front of
the vehicle, as used to deflect bugs,
may also adversely affect the washer
system from delivering fluid to the
windshield. Devices such as bug
shields are not recommended to be
added to your new Ford product.
File:ltsvf.ex
Update:Thu May 9 15:30:19 1996
