If the battery is operating under cold weather
conditions, the pointer may indicate in the upper
range of the NORMAL band while the battery is
charging. If you are running electrical accessories
with the engine off or idling at a low speed, or
the battery is not fully charged, the pointer may
move toward the lower end of the NORMAL
band.
*
[IS07500(FM)04/96]
If it stays outside the NORMAL band, have your
vehicle's electrical system checked as soon as it
is safely possible.
*
[IS07600(F )03/96]
quarter page art:0020052-D
Battery voltage gauge
%*
[IS07800(FM)04/96]
Engine Oil Pressure Gauge
*
[IS07900(FM)01/96]
This gauge indicates the engine's oil pressure,
not the oil level. However, if your engine's oil
level is low, it could affect the oil pressure. With
the engine running, the pointer should move
into the NORMAL band. If the pointer drops
below the NORMAL band while the engine is
running, you have lost oil pressure and
continued operation will cause severe engine
damage.
*
[IS08000(FM)05/96]
If you lose engine oil pressure:
*
[IS08100(FM)04/96]
1. Pull off the road as soon as safely possible.
*
[IS08200(FM)04/96]
2. Shut off the engine immediately or severe
engine damage could result.
File:03ltisf.ex
Update:Tue May 28 08:40:24 1996
ProCarManuals.com

20
*
[IS08300(FM)01/96]
3. Check the engine's oil level, following the
instructions on checking and adding engine
oil. Refer toEngine oilin the Index. If you
do not follow these instructions, you or
others could be injured. To assure an
accurate reading, your vehicle should be on
level ground.
*
[IS08400(FM)01/96]
4. If the level is low, add only as much oil as
necessary before you start the engine again.
Do not overfill. Do not operate the engine if
the pointer is below the NORMAL band,
regardless of the oil level. Contact your
nearest dealer for further service actions.
*
[IS08500(F )03/96]
quarter page art:0020057-D
Engine oil pressure gauge
%*
[IS08700(FM)03/96]
High Beam Light
*
[IS08800(FM)01/96]
This light comes on when the headlamps are
turned on high beam or when you flash the
lights.
*
[IS08900(FM)03/96]
one inch art:0020537-B
High beam indicator light
File:03ltisf.ex
Update:Tue May 28 08:40:24 1996
ProCarManuals.com

21 %
*
[IS09000(F )03/96]
ªHeadlamps Onº Alert Chime
[IS09100(F )04/96]
This chime will sound if you open the door
while the headlamps or parklamps are on.
%*
[IS09200(FM)03/96]
Fuel Gauge
*
[IS09300(FM)01/96]
The fuel gauge displays approximately how
much fuel is in the fuel tank only when the
ignition switch is ON.
*
[IS09500(FM)01/96]
The fuel gauge indicator may vary slightly when
the vehicle is in motion.
*
[IS09600(FM)01/96]
With ignition switch OFF, the fuel gauge
indicator may drift from the ignition switch ON
position.
[IS09700(F )04/96]
quarter page art:0020691-C
Fuel gauge
%*
[IS09900(FM)03/96]
Engine Coolant Temperature Gauge
*
[IS10000(FM)01/96]
This gauge tells you the temperature of the
engine coolant, not the coolant level. If the
coolant is not at its proper level or mixture, the
gauge indicator will not be accurate.
*
[IS10100(FM)01/96]
The pointer moves from the C (cold) mark into
the Normal band as the engine coolant warms
up. It is acceptable for the pointer to fluctuate
within the Normal band under normal driving
conditions. Under certain driving conditions,
such as heavy stop and go traffic or driving up
hills in hot weather, the pointer may move to
the top of the Normal band.
File:03ltisf.ex
Update:Tue May 28 08:40:24 1996
ProCarManuals.com

22
*
[IS10200(FM)04/96]
If, under any circumstances, the pointer moves
above the NORMAL band, the engine is
overheating and continued operation may cause
engine damage.
*
[IS10300(FM)03/96]
If your engine overheats:
*
[IS10400(FM)03/96]
1. Pull off the road as soon as it is safely
possible.
*
[IS10500(FM)03/96]
2. Turn off the engine. If you do not stop the
engine as soon as safely possible, severe
engine damage could result.
*
[IS10600(FM)03/96]
3. Let the engine cool.DO NOT REMOVE
COOLANT SYSTEM FILL CAP UNTIL
THE ENGINE IS COOL.
*
[IS10700(FM)03/96]
4. Check the coolant level following the
instructions on checking and adding coolant
to your engine, seeEngine Coolantin the
Index. If you do not follow these
instructions, you or others could be injured.
*
[IS10800(FM)01/96]
For instructions on checking and adding coolant
to your engine, seeEngine coolantin the Index. If
you do not follow these instructions, you or
others could be injured.
[IS10900(F )04/96]
quarter page art:0020535-D
Engine coolant temperature gauge
File:03ltisf.ex
Update:Tue May 28 08:40:24 1996
ProCarManuals.com

23 %
*
[IS11100(FM)03/96]
Speedometer
*
[IS11200(FM)03/96]
The speedometer tells you how many miles
(kilometers) per hour your vehicle is moving.
*
[IS11300(F )03/96]
Your vehicle contains a speedometer which
receives its input from the Anti-Lock brake
sensor. The speedometer is also used to provide
a speed signal for correct operation of the
vehicle's Powertrain Control Module (PCM),
electronic transmission, and speed control (if so
equipped). Because of this, it is very
IMPORTANT to change the speedometer's
internal conversion constant if the size of the
tires on the vehicle is changed. Changing the
conversion constant to the proper value when
the tires are changed will also ensure that the
speedometer retains the original factory-set
accuracy.
*
[IS11500(F )03/96]
Some vehicles are equipped with a vehicle speed
(mph/km/h) limiting device that is contained
within the Powertrain Control Module (PCM).
The purpose of this device is to maintain peak
vehicle speed below a specified limit. (Vehicle
speed limits may vary based on engine
displacement.)
*
[IS11600(F )03/96]
If you are experiencing an ªengine cut-outº
condition at high speeds, it may be the result of
this limiting device. It is a normal condition and
can be avoided by reducing vehicle/engine
speed.
File:03ltisf.ex
Update:Tue May 28 08:40:24 1996
ProCarManuals.com

24
*
[IS11700(F )03/96]
one third page art:0020871-C
Speedometer
%*
[IS11900(FM)01/96]
Odometer/Trip Odometer
*
[IS12000(FM)05/96]
The Liquid Crystal Display (LCD) odometer is a
combination trip odometer and total odometer.
The total odometer is normally displayed. To see
the trip odometer, press and release the SELECT
control on the upper right side of the
speedometer. To zero out the trip odometer,
press and release the RESET control on the
upper left side of the speedometer while the trip
odometer is displayed. If the trip odometer is
displayed, press and release the SELECT control
to return the display to the total odometer value.
% [IS12100(F )04/96]
Tachometer (If equipped)
*
[IS12200(F )03/96]
The tachometer will show you the engine's
speed measured in revolutions per minute
(RPM).
*
[IS12300(F )03/96]
The tachometer may move slightly when the key
is placed in the ACC or ON position, with the
engine off. This is normal and does not affect
the performance of the tachometer when the
engine is running.
File:03ltisf.ex
Update:Tue May 28 08:40:24 1996
ProCarManuals.com

25
*
[IS12400(F )03/96]
Some vehicles are equipped with an engine
speed (RPM) limiting device contained within
the powertrain control module (PCM). The
purpose of this device is to maintain peak
engine speed (RPM) below a specified limit. This
feature is only evident on automatic transmission
vehicles when shifting manually (1, 2, D) and on
all manual transmission units. (Engine speed
limits may vary based on engine displacement.)
*
[IS12500(F )03/96]
If you are experiencing an ªengine cut-outº
condition at high speeds, it may be the result of
this limiting device. It is a normal condition and
can be avoided by reducing vehicle/engine
speed.
[IS12600(F )04/96]
one third page art:0020869-C
Tachometer
File:03ltisf.ex
Update:Tue May 28 08:40:24 1996
ProCarManuals.com

27
Electronic Sound Systems
*
[AS01100(F )08/95]
full page art:0060648-B
Compact Disc Radio
File:04ltasf.ex
Update:Tue May 28 08:40:59 1996
ProCarManuals.com

28
%*
[AS01200(F )10/95]
Compact Disc Radio
*
[AS01250(F )10/95]
The Compact Disc Radio combines the Electronic
Stereo Radio with the Ford Compact Disc Player.
*
[AS01300(F )08/95]
Using the Controls on Your New Radio/CD
Player
*
[AS01400(F )10/95]
Most of the features of this unit work for both
radio and CD operation. Also, some of the knobs
and buttons control several different functions,
so be sure to read all of the operating
instructions carefully.
*
[AS01500(F )03/96]
How to turn the radio on and off
*
[AS01600(F )10/95]
Press the ªPOWERº button to turn the radio on.
Press it again to turn it off.
*
[AS01625(F )03/96]
How to adjust the volume
*
[AS01650(F )03/96]
Press the (R/S) side of the ªVOLº button to
increase/decrease the volume. Bars illuminate in
the display to show the relative volume level.
*
[AS01675(F )02/96]
NOTE: If the volume level is set above a
certain listening level when the
ignition switch is turned off, when the
ignition switch is turned back on, the
volume will come back to a ªnominalº
listening level. However, if the radio
power is turned off, the volume will
remain in the position it was set at
when radio power was switched off.
*
[AS01700(F )03/96]
Selecting the AM or FM frequency band
*
[AS01800(F )10/95]
Push the ªAM/FMº button to select the desired
frequency band. When in the radio mode,
pushing the button more than once will alternate
between AM, FM1 and FM2. These functions are
used with the station memory buttons described
underHow to tune radio stations.
File:04ltasf.ex
Update:Tue May 28 08:40:59 1996
ProCarManuals.com

29 %
*
[AS01900(F )03/96]
How to tune radio stations
*
[AS02000(F )10/95]
There are four ways for you to tune in a
particular station. You can manually locate the
station using the ªSCAN/TUNEº button,
ªSEEKº the station, ªSCANº to the station or
select the station by using the memory buttons,
which you can set to any desired frequency.
These four methods are described below.
*
[AS02100(F )10/95]
q
Using the ªSCAN/TUNEº button to manually
tune
*
[AS02200(F )04/96]
You can change the frequency up or down
one increment at a time (FM changes in
increments of 200kHz; AM changes in
increments of 10kHz) by first pressing the
ªSCAN/TUNEº button twice (display shows
ªTUNEº), then Ðwithin approximately five
secondsÐpressing and releasing either the
top
aor bottom
bhalf of the ªSEEKº
button. To change frequencies quickly, press
andhold downeither the top or bottom half
of the ªSEEKº button. While you are
manually tuning, the display will show a
blinking ªMº.
*
[AS02300(F )03/96]
Manual tuning adjusts your radio to any
allowable broadcast frequency, whether or
not a station is present on that frequency.
(SeeAll About Radio Frequenciesin this
section.)
File:04ltasf.ex
Update:Tue May 28 08:40:59 1996
