FORD F250 1997 Owners Manual

201
*
[GF21770(FM)01/96]
Automatic Transmissions
[GF21780(F )05/96]
thirty-six pica chart:0020172-MFile:09ltgff.ex
Update:Thu May 30 15:25:49 1996
ProCarManuals.com

202 [GF21790(F )05/96]
thirty-six pica chart:0020497-K
File:09ltgff.ex
Update:Thu May 30 15:25:49 1996
ProCarManuals.com

203 [GF21810(F )05/96]
thirty-six pica chart:0021091-F
File:09ltgff.ex
Update:Thu May 30 15:25:49 1996
ProCarManuals.com

204 [GF21820(F )05/96]
thirty-six pica chart:0021092-C
File:09ltgff.ex
Update:Thu May 30 15:25:49 1996
ProCarManuals.com

205 [GF21825(F )05/96]
thirty-six pica chart:0021602-A
File:09ltgff.ex
Update:Thu May 30 15:25:49 1996
ProCarManuals.com

206 [GF21830(F )05/96]
thirty-six pica chart:0020499-J
File:09ltgff.ex
Update:Thu May 30 15:25:49 1996
ProCarManuals.com

207 [GF21840(F )05/96]
thirty-six pica chart:0020944-G
File:09ltgff.ex
Update:Thu May 30 15:25:49 1996
ProCarManuals.com

208 [GF21850(F )05/96]
thirty-six pica chart:0021096-F
File:09ltgff.ex
Update:Thu May 30 15:25:49 1996
ProCarManuals.com

209 [GF21852(F )05/96]
twenty-two pica chart:0021603-A
[GF21870(F )04/96]
Required equipment
[GF21880(F )04/96]
q
Super Cooling is required with trailers over
2,000 lb (907 kg).
[GF21890(F )04/96]
q
Super Cooling and Handling/Suspension
Package or trailer towing package is required
with trailers over 3,500 lb (1587 kg).
*
[GF21900(FM)05/96]
Preparing to Tow
*
[GF21910(FM)05/96]
For your safety and for the good of your
vehicle, use the right equipment for the type of
trailer you tow. Also, make sure that all towing
equipment is properly attached to your vehicle.
If you are not certain that you are using the
right equipment in the proper manner, see your
Ford or Lincoln-Mercury dealer.
File:09ltgff.ex
Update:Thu May 30 15:25:49 1996
ProCarManuals.com

210 %
*
[GF21920(FM)01/96]
Hitches
*
[GF21940(F )01/96]
Do not install a single or multi-clamp type
bumper hitch, or a hitch which attaches to the
axle. Underbody mounted hitches are acceptable
if installed properly. Follow towing instructions
of a reputable rental agency.
*
[GF21960(FM)01/96]
Whenever a trailer hitch and hardware are
removed, make sure all mounting holes in the
underbody are properly sealed to prevent
noxious gases or water from entering.
*
[GF22000(F )01/96]
Step bumper (If equipped)
*
[GF22010(F )01/96]
The optional step bumpers have a built-in hitch
and only requires a ball with a one inch shank
diameter. This step bumper has a Class III
capability (5000 lb/2,270 kg trailer weight and
500 lb/680 kg tongue weight).
*
[GF22060(FM)01/96]
Safety chains
*
[GF22070(FM)01/96]
Always use safety chains between your vehicle
and trailer. Cross chains under the trailer tongue
and allow slack for turning corners. Connect
safety chains to the vehicle frame or hook
retainers.Never attach chains to the bumper.
[GF22090(FM)01/96]
Trailer Brakes
*
[GF22100(FM)01/96]
Separate trailer brakes are required on most
towed vehicles weighing over 1,500 lb (680 kg).
*
[GF22110(FM)05/96]
RWARNING
Do not connect a trailer's hydraulic brake
system directly to your vehicle's brake
system. Your vehicle may not have
enough braking power and your chances
of having a collision greatly increase.
