FORD FOCUS 2014 3.G Quick Reference Guide
Page 1 of 10
Quick reference guide
Two Thousand fourTeen
EM5J 19G217 AA
Ford Motor Company
Customer Relationship Center
U.S. • 1-800-392-3673 (FORD)
(TDD for the hearing impaired:
Ford of Canada’s
Customer Relationship Centre
Canada • 1-800-565-3673 (FORD)
Quick Reference Guide Focus
Litho in U.S.A.
This Quick Reference Guide is not intended to replace your vehicle Owner’s Manual which contains more detailed
information concerning the features of your vehicle, as well as important safety warnings designed to help reduce the risk
of injury to you and your passengers. Please read your entire Owner’s Manual carefully as you begin learning about your
new vehicle and refer to the appropriate chapters when questions arise. All information contained in this Quick Reference
Guide was accurate at the time of duplication. We reserve the right to change features, operation and/or functionality of any
vehicle specification at any time. Your Ford dealer is the best source for the most current information. For detailed operating
and safety information, please consult your Owner’s Manual.
Page 2 of 10
4 – 5 Instrument Panel
6 – 7 SYNC
8 – 10 SYNC with MyFord Touch
12 – 14 Function
15 – 17 Comfort
18 – 19 Essential Information
TaBLe of conTenT s
Basic Commands • What can I say?
• List of commands
• Main menu
• Go back
• Vehicle health report
• Pair my phonePhone • Phone list of commands
• Call on cell/at
• Call voicemail
• Do not disturb
• Listen to text messages
• Audio list of commands
- You can also get
detailed lists of
commands for radio,
Sirius and SD card
- FM <87.9-107.9>
- FM preset <#>
- Play track <1-512>
- Play song
- Play album
- Preset <#>
SYNC® ServicesIf equipped, must say “Services” first,
• What can I say?
• Business search
• Operator (for direction or
• News, sports, weather,
horoscopes, stock quotes,
movies or travel
Climate control list of
• Climate temperature
• Navigation list of commands
- Destination street address
- Destination home
- Navigation voice
- Navigation voice volume
- Repeat instruction
• Travel Link list of commands:
- Movie listings
- Fuel prices
commonL y used sync® Voice commands
Some services may not be available in your area.
Refer to your Owner’s Manual, visit the website or
call the toll-free number for more information. For U.S. customers: visit SyncMyRide.com
or call 1-800-392-3673 (select Option
1 or 2 for language, then Option 3). For Canadian customers: visit SyncMyRide.ca
or call 1-800-565-3673 (select Option 1 or 2
for language, then Option 3).
** Available only with MyFord Touch
Learn More About Your
Scan the country-appropriate QR code
with your smartphone (make sure you
have a scanner app installed) and you
can access even more information
about your vehicle.
Driving while distracted can result in
loss of vehicle control, crash and injury.
We strongly recommend that you
use extreme caution when using any
device that may take your focus off
the road. Your primary responsibility
is the safe operation of your vehicle.
We recommend against the use of any
hand-held device while driving and
encourage the use of voice-operated
systems when possible. Make sure you
are aware of all applicable local laws
that may affect the use of electronic
devices while driving.
Page 3 of 10
1 Trunk*/Liftgate* Release
2 Cruise Control*
To Set Your Cruise Control Speed
1. Press the ON control and release.
2. Accelerate to the desired speed.
3. Press the SET + control and release,
then take your foot off the accelerator.
After you set your speed, you can press
SET +/ SET – to adjust your cruise speed. To
disable, tap the brake, press the clutch pedal
or pull the CAN (Cancel) control toward you.
Note: Using the clutch pedal to cancel a set
speed may cause the engine speed to
3 Information Display
Provides information about various systems
on your vehicle. Use the left, 5-way controls
located on the steering wheel to choose and
confirm settings and messages. Refer to the
Information Displays chapter of your Owner’s
Manual for more information.
4 Service Engine Soon Light
Illuminates briefly when the ignition
is turned on. If it remains on or is blinking after the engine is started, the On-Board
Diagnostics (OBD-II) system has detected a
Drive in a moderate fashion and
contact your authorized dealer as soon
5 Tilt/Telescope Steering Column
Unlock the steering wheel by pulling the
lever down. Adjust the wheel to the desired
position. Push the lever back up to lock the
steering wheel in place.
6 Voice Controls*
Pull toward you to access
Press to answer a call.
Press to exit phone mode or end a call.
7 Push Button Start*
Allows you to start your vehicle by pressing
the ENGINE START/STOP button while
fully pressing down on the brake (automatic
transmission) or clutch and brake (manual
transmission) pedal(s). Press the button
again to turn the engine off.
Note: Your intelligent access key must be
inside the vehicle for keyless starting to work.
8 Audio Controls*
Use the right-hand, 5-way controls to
adjust your audio system:
(Volume): Press to increase (+)
or decrease (–) volume levels.
(Seek): Press the right arrow to hear the
next saved radio station, CD track or MP3 choice.
Press the left arrow to hear the previous selection.
Press M to select a different audio source.
9 Wiper Controls
Use the rotary control on the stalk to adjust the
wipe intervals. Pull the stalk toward you to spray
and wash the windshield. Press the button at the
end of the lever to turn the rear wiper* on, off or
change to intermittent wipe.
10 Hazard Control
11 Power Door Locks
Press the control to lock or unlock
the doors. When the light on the
button is on, it indicates that all
of the doors and the luggage compartment are
locked. When the light is off, it indicates that either
the luggage compartment or one or more of the
doors are unlocked.
Page 4 of 10
Why Do I Need a SYNC Owner Account?
A SYNC owner account is required for Vehicle Health Report
activation and the ability to view your reports online. You’ll
also be able to take advantage of all of SYNC’s Services*
and personalization features, such as saving your Favorites
and Points of Interest. You’ll receive the latest software
updates that add new places, directions and information;
and if you have questions, you’ll get free customer support.
Note: Your SYNC system may offer advanced features such
as SYNC Services, AppLink
TM and Vehicle Health Reports. Visit
the website or call the toll-free number for more information.
See the inside front cover of this guide for details.
Using My Phone with SYNC
Note: You must download your phone book to make phone
calls with voice commands by name.
Making a Phone Call
Use SYNC to make a phone call to anyone in your phone
book by pulling the voice control
. When prompted, give a
For example, you could say “Call Jake Smith at home”.
SYNC repeats the command back to you and dials
Note: You can also make phone calls by pulling the voice
. When prompted, give the voice command “Dial”,
then say the phone number. Answering Incoming Calls
Whenever you have an incoming call, you will be able to see
the name and number of the person calling in your display.
Press the phone button
to answer an incoming call. You
can hang up at any time by pressing the phone button .
Do Not Disturb Mode
This feature blocks incoming calls and text messages, and
saves them for later. You still have access to outgoing calls
when this feature is active. Say the voice command “Do not
disturb on” to enable and “Do not disturb off” to disable.
Using SYNC to Access Digital Media
Plug in your USB media devices such as phones and MP3
players, and use SYNC to play all of your favorite music.
Note: SYNC indexes your music. The more music that is
stored on your device, the longer it takes SYNC to index.
Using Voice Commands to Play Music
1. Plug your media player into your USB port.
2. Pull the voice control
. When prompted, say
“USB”, then follow-up saying a voice command.
Getting Started with
Your SYNC System
SYNC is a hands-free, voice
recognition system used for
SYNC. Say the Word.
Before You Get Started
1. Set up your owner account at
SyncMyRide.com (U.S.) or
Register by following the
on-screen instructions. After
registering, you can see what
available services you are
2. SYNC uses a wireless
to communicate with your phone.
Turn Bluetooth mode on in your
phone’s menu options. This lets
your phone find SYNC. If you
need more details on setting
up your phone with SYNC, visit
SyncMyRide.com (U.S.) or
SyncMyRide.ca (Canada), or your
phone manufacturer’s website.
Pairing Your Phone
In order to use many of the features
of SYNC, you must first pair and
connect your phone with SYNC.
To Pair Your Phone for the First Time
1. Make sure that your vehicle is in
P (Park) or N (Neutral) with the
parking brake applied (for vehicles
with manual transmissions only)
and both your ignition and radio
are switched on.
2. Press the phone button. When
the display indicates no phone is
paired, press OK.
3. When Find SYNC appears in the
display, press OK.
4. Put your phone into Bluetooth
discovery mode. See your phone’s
user guide, if necessary.
5. When prompted on your phone’s
display, enter the six-digit PIN
provided by SYNC in the
6. The display will indicate when the
pairing is successful. The System May Prompt You to
• Set your phone as primary/
favorite (the primary phone
will receive messages
• Download your phone book
(this is required to use the full
set of voice commands).
• Turn on 911 Assist
• Make sure you accept SYNC’s
request to access your phone.
• To pair subsequent phones,
please refer to Pairing
Subsequent Phones in the SYNC
chapter of your Owner’s Manual.
• If you are experiencing pairing
problems, try performing a clean
pairing by deleting your device
from SYNC, deleting the SYNC
connection from your phone, and
then repeating the Pairing your
Phone with SYNC process.
Page 5 of 10
sync® wiTh myford Touch®*
Voice-control your phone for hands-
free calling with your phone securely
put away. With SYNC, you won’t even
need to know the phone number. Just
say the name of the person you want
from your contacts.
Your Phone Connects You with Many
Other Features and SYNC Services*
• Connect to SYNC Services for traffic,
directions, business searches and
Connect to Operator Assist to help
locate a listing or destination.
• Call for a Vehicle Health Report.
• Automatically connect with a 911
operator in the event of an accident
(if set to ON prior to the incident).
• Transfer calls seamlessly from
SYNC to phone as you get in or
out of your vehicle.
Refer to the MyFord Touch chapter
of your Owner’s Manual for
Get started with
The available voice-activated
navigation system includes:
• SiriusXM Traffic™
• SiriusXM Travel Link™
• GPS (Global Positioning System)
• 3-D mapping
Some features require activation. Refer
to the MyFord Touch chapter of your
Owner’s Manual for complete details.
Set a Destination
using a street
address, a city
center, a place on the map or a point
of interest (POI). The easiest way,
however, is by voice.
Pull the voice control
When prompted, say
“Destination street address”.
The system will ask you to say
the full address and will display
an example on screen.
3. You can then speak the address
naturally, such as: “One two three
Main Street, Anytown”.
You can also choose from up to
three different types of routes:
• Fastest: Uses the fastest moving
• Shortest: Uses the shortest
• Eco (EcoRoute): Uses the most
fuel efficient route.
Tips • Save your favorite locations by touching “Save to Favorites”.
• Change your map views from Heading Up, North Up or 3D.
Press the home icon at any time
to return to your home screen.
For additional support, refer to your
Owner’s Manual, visit the website
or call the toll-free number. See
the inside front cover of this
guide for details.
Before You Get Started
• Pair your phone with SYNC before
using MyFord Touch. See the Getting
Started with Your SYNC System section
for instructions on how to do this.
• Make sure your navigation SD card*
is inserted into the media port or your
navigation features will not work.
A Revolutionary Way to Connect with Your Vehicle.
Getting Started, Understanding SYNC
with MyFord Touch
Use the four-corner, four-color touchscreen to explore and interact with
your vehicle. The touchscreen works the same way traditional controls,
knobs and buttons do. Press the various corners on your touchscreen to
personalize the many features and settings of your vehicle all in one place.
The system provides easy interaction with your cellular phone, multimedia
entertainment, climate controls and navigation system*.
Get in Touch Using Your Four-corner Touchscreen
Phone, Navigation,* Climate and Entertainment are the four main operations of SYNC® with MyFord Touch®.
Each feature has its own corner represented by its own color.
*if equipped*if equipped
Page 6 of 10
2014 focussync® wiTh my ford Touch®* continued
SYNC with MyFord Touch controls the temperature,
airflow direction and fan speed for you and
To use voice commands to operate the climate controls,
say a voice command like “Climate temperature 72
degrees” and MyFord Touch will make that adjustment.
Set Your Temperature
• Touch the lower-right, blue corner on the touchscreen.
• Set your exact, desired temperature using the
+ or – buttons.
No matter how you store your music, SYNC makes it
yours to enjoy when you’re behind the wheel. Just press
the lower-left, red corner of the touchscreen. From here,
you can easily go between AM/FM, Sirius and other media
sources. You use your touchscreen or the audio controls
on your steering wheel to interact with your digital media.
Bring in Your Own Music
Gain access to any audio source by voice and even control
how each operates, like changing radio stations, CD tracks
or music on one of the following devices:
• SD Card
• A/V In
For additional support, refer to your Owner’s Manual, visit
the website or call the toll-free number. See the inside
front cover of this guide for details.
Intelligent Access Key*
Note: Your intelligent access key must be within 3 feet
(1 meter) of your vehicle.
To unlock a front door: Pull the front exterior door handle.
To lock all of the doors: Press and hold the door handle
To unlock and open the trunk: Press the exterior trunk
release button near the license plate.
The intelligent access key also contains a mechanical
key blade, which can be used to unlock the driver door,
if necessary.Remote Start*
Remote start allows you to start the engine from outside
your vehicle using your transmitter.
and then press twice within three seconds.
2. Once inside, apply the brake while pressing the ENGINE
3. Shift into D (Drive) and go.
If You Have an Integrated Keyhead Transmitter
1. Insert the key into the ignition.
2. Turn the ignition on as you normally would before driving.
To turn the engine off from outside the vehicle after
using your remote start: Press
Allows you to program speed
restrictions, limited volume
levels, safety belt reminders
and more. For complete
information, refer to the
MyKey chapter in your
Page 7 of 10
Rear View Camera*
Provides a video image
of the area behind the
vehicle in either the
rearview mirror or the
display in the center of
the instrument panel.
The image automatically
appears when the vehicle
is in R (Reverse) and
uses green, yellow and
red guides to alert you of
your proximity to objects.
Integrated Blind Spot Mirrors
Designed to assist you
by increasing the visibility
along the side of
• The integrated convex
mirror is built into the
upper outboard corner
of the exterior mirrors.
• As an approaching
vehicle moves toward
you, you will see its
reflection first in the
main mirror, and then
in the blind spot mirror.
Forward and Reverse Sensing Systems*
Sounds an audible
warning tone if there is an
obstacle near the vehicle’s
front or rear bumpers.
• As the vehicle
moves closer to the
obstacle, the rate
of the warning
• The front sensors automatically activate when the
vehicle is in D (Drive) and will detect objects up to
27 inches (70 centimeters) away.
• The reverse sensors are activated automatically when
the vehicle is in R (Reverse), and will detect objects up to
6 feet (2 meters) away.
See the Parking Aids chapter in your Owner’s Manual for
complete information on your vehicle’s sensing systems.
Note: Visibility aids do not replace the need to watch where
the vehicle is moving. Refer to your Owner’s Manual for
safety information, more details and limitations.
Active Park Assist* The active park assist
system can detect an
available parallel parking
space and automatically
steer the vehicle into that
space (hands-free). The
system instructs the driver with visual and/or audible
instructions with regard to braking, accelerating and
shifting gears in order to safely park the vehicle.
• To initiate active park assist, press the AUTO |P|
button located near the center console on the
• To stop the parking procedure, grab the steering wheel
or press the control again. For complete information,
refer to the Parking Aids chapter in your Owner’s Manual.
Note: The driver is always responsible for controlling the
vehicle, supervising the system and intervening, if required.
Towing Your Focus
Towing your Focus behind an RV or any other vehicle may
be limited. Refer to Towing the Vehicle on Four Wheels in
the Towing chapter of your Owner’s Manual.
Autolamps* The headlamps will
switch on and off
low light situations
or during inclement
weather. They will
remain on for a period
of time after you
switch the ignition
off. You can adjust
the time delay using
Headlamp Exit Delay
After you switch the ignition off, you can switch the
headlamps on by pulling the direction indicator lever
toward you. You will hear a short tone. The headlamps
will switch off automatically after three minutes with any
door open or 30 seconds after the last door has been
closed. You can cancel this feature by pulling the direction
indicator toward you again or switching the ignition on.
Page 8 of 10
funcTion continued2014 focus
The ambient lighting system illuminates the interior with
a choice of several colors. The ambient lighting control
is located in the overhead console. Rotate the control
knob to switch the feature on and adjust the desired
brightness. Press the palette button to cycle through
your color choices.
Ambient lighting will switch on when the following
conditions have been met:
• You switch the ignition on, or
• You switch the headlamps on.
The traction control system helps avoid drive wheel
spin and loss of traction.
If your vehicle begins to slide, the system applies
the brakes to individual wheels and, when needed, reduces engine power at the same time. If the wheels
spin when accelerating on slippery or loose surfaces,
the system reduces engine power in order to
In certain situations (for example, stuck in snow or
mud), turning the traction control off may be beneficial
as this allows the wheels to spin with full engine power.
Turn the traction control system off through
the information display.
AdvanceTrac® Stability Control System
The system helps you keep control of your vehicle when
on a slippery surface. The electronic stability control
portion of the system helps avoid skids and lateral slides,
while the traction control system helps avoid drive wheel
spin and loss of traction.
The lamps will switch on when you open any door, press
a remote control button or press the overhead control.
to switch off the
door illumination function
when you open any door.
again to switch
the door illumination
function back on.
to turn the
overhead lamps on and off.
Tilting Head Restraints*
Your vehicle’s front-row head
restraints can be adjusted.
To raise: Pull up on the
To lower: Press the head
restraint down while pressing
and holding the guide sleeve
To tilt the head restraint: Gently pull the top of the head
To return it to its upright position: Tilt it forward once
more and release.
Note: Do not attempt to force the head restraint backward
after it is tilted. Instead, continue tilting it forward until the
head restraint releases to the upright position.
Heated front Seats*
The heated front seat controls are located on the center
console near the gearshift lever.
To Use, Simply
• Adjust the dial to the desired
• Choose from 0–5 (off-high).
Lift the control to adjust the height
of the seat. Lift the control to adjust the angle
of the seatback.
Dual Zone Temperature Control*
You can operate the
temperature with one control,
called single zone, or two,
called dual zone where both
driver and front passenger
can select independent
temperatures using their own
To operate the dual zone: Use the rotary control on the
passenger’s side. Single zone automatically shuts off.
You can now adjust the driver’s side and passenger’s side
To return back to single zone: Press and hold the AUTO
button for 2–4 seconds. The passenger’s temperature
switches to the driver’s temperature setting.
1415*if equipped *if equipped
Page 9 of 10
Auxiliary Power Points
The power points may
be found on the center
console or on the rear
of the center console,
depending on your
vehicle style. A power
point can be used to
power your smaller
electrical devices that require up to 180 watts. Run the
vehicle for full capacity use of the power point.
To prevent the battery from being discharged:
• Do not use the power point longer than necessary
when the vehicle is not running.
• Do not leave devices plugged in overnight or when
the vehicle is parked for extended periods.
Rear Window Buffeting
You may hear a pulsing noise when one or both of the
rear windows are open. Lower a front window slightly to
reduce this noise.
• Press the switch to open the window.
• Lift the switch to close the window.
Folding the Rear Seats
Your rear seatback can fold down for more versatile
cargo storage and transport. Your vehicle may have split
seatbacks* that must be folded individually.
To lower the seatback(s), do the following:
• Remove the outboard head restraint(s).
• Press the unlock buttons located on the top outboard
sides of each seatback.
• Push the seatback forward.
Note: Make sure you
stow the safety belt
in the belt stowage
clip to prevent it from
getting caught in the
• In vehicles with split-folding seatbacks, you can flip
the seat cushions forward before folding the seatback
for additional cargo space.
• When raising the seatback(s), make sure you hear the
seat latch into place and that no red portion is visible
on the release button on both sides.
The moonroof control is located on the overhead console
and is equipped with a one-touch open and close feature.
To stop motion during one-touch operation, press the
control a second time.
• Press and release the rear of the control to open the
moonroof. The moonroof will stop short of the fully
opened position. This position helps to reduce
• Press and release the control again to fully open
• Press and release the front of the control to close
the moonroof. Trunk*/Liftgate* Release
To open the trunk/
liftgate from the inside
of your vehicle, press the
button located on the
instrument panel, near
the headlamp switch.
If your car is unlocked, you
can open it from the outside
by pressing the release
button located under the
handle and above the
If your vehicle is locked
and the intelligent access
transmitter* is within
3 feet (1 meter) of the
trunk/liftgate, you can open it from the outside by
pressing the release button located above the
You can also use the keyless remote.
Page 10 of 10
2014 focusessenTiaL informa Tion
Fuel Tank Capacity/Fuel Info
Your vehicle has a 12.4 gallon (46.9L) fuel tank capacity.
Your vehicle may be flex-fuel capable. If so, it will have
a yellow ring around the fuel inlet. Flex fuel vehicles
are designed to use ETHANOL (E85) fuel blends and
UNLEADED FUEL. Please see your Owner’s Manual for
specific refueling instructions when using E85.
Non-flex fuel vehicles use only UNLEADED fuel with an
octane rating of 87. Do not use fuel
E20 - E85 ethanol (E85),
diesel fuel, fuel-methanol, leaded fuel or any other
fuel because it could damage or impair the emission
Easy Fuel® Sy s t e m
• Put your vehicle into P (Park) and turn the ignition off.
• Open the fuel-filler door.
• Insert the nozzle.
• Begin fueling.
• Wait 10 seconds between
the time the refueling nozzle
is shut off until you remove
the nozzle from the vehicle
to allow residual fuel in the
nozzle to drain into
• When using a portable fuel container, slowly insert the
fuel funnel (located in the spare tire compartment)
and pour the fuel into the funnel.
Note: Do not use aftermarket funnels as they will not work
with the Easy Fuel system and may cause damage. Properly
clean the funnel after each use.
Tire Pressure Monitoring System
Your vehicle illuminates a low tire pressure warning light in your instrument cluster when one or more of your
tires is significantly underinflated. If this happens, stop
and check your tires as soon as possible, then inflate them
to the proper pressure. Refer to the Inflating Your Tires
section in the Wheels and Tires chapter of your Owner’s
Manual for more information.
Location of Spare Tire and Tools
Your spare tire and tools are located beneath the carpeted
floor panel in the rear of your vehicle.
• The spare tire is designed for emergency use
only and should be replaced as soon as possible.
• For complete details on changing your tire, refer
to the Changing a Road Wheel section in the
Wheels and Tires chapter of your Owner’s Manual.
Powershift Six-speed Automatic Transmission*
This transmission is designed for
fun-to-drive performance and
exceptional fuel efficiency, by using the
advantages of a manual transmission
with the convenience of an automatic
transmission. You may notice the
following characteristics of
• Mechanical noises after the engine is turned off, after
the driver door is opened and during some transmission
shifting events. These are normal and do not
• Firm gearshifts when moving the accelerator pedal
back and forth quickly.
Your transmission continuously makes electronic
adjustments to optimize shift quality and acceleration
performance. Most adjustments will be made during the
first 1,000 miles (1610 kilometers) of operation. During
this break-in period, slight vibrations may be felt when
accelerating the vehicle from low speeds.
Your new Ford vehicle comes with the assurance and
support of 24-hour emergency roadside assistance.
To receive roadside assistance in the United States,
call 1-800-241-3673. In Canada, call 1-800-665-2006.
SelectShift Automatic® Transmission*
Gives you the ability to manually
change gears if you’d like. To use,
move the gearshift lever from D (Drive)
to S (Sport). Activate SelectShift by
using the + / – thumb toggle located
on the side of your gearshift lever to
manually make shifts. Press the (+)
button to upshift. Press the (–)
button to downshift.
