FORD MUSTANG 1996 4.G Owners Manual
Manufacturer: FORD, Model Year: 1996, Model line: MUSTANG, Model: FORD MUSTANG 1996 4.GPages: 332, PDF Size: 3.21 MB
Page 111 of 332
113
*
[FV08775( ALL)02/95]
NOTE: The operating range of the remote
entry system can also be affected by
weather conditions (such as very cold
temperatures) or structures around the
vehicle (buildings, other vehicles, radio
and TV towers, etc.). Typical operating
range will allow you to be up to 33
feet (10 meters) away from your
vehicle.
*
[FV08800(MBC )02/95]
quarter page art:0020790-A
Replacing the batteries
*
[FV08825(MBC )02/95]
The transmitter can be snapped apart to replace
the batteries by twisting a thin coin between the
two halves of the transmitter. DO NOT TAKE
THE FRONT PART OF THE TRANSMITTER
APART. When installing the new batteries, be
sure to place the positive (+) side down as
marked. Snap the two halves back together.
%*
[FV08850( ALL)02/95]
Replacement/additional transmitters
*
[FV08875(MBC )02/95]
In the event a transmitter is lost, return the
remaining transmitters to your dealer for
reprogramming of your remote entry system.
This is necessary to prevent further unauthorized
use of the lost transmitter.
*
[FV08900(MBC )02/95]
Additional transmitters may be purchased from
your dealer (remote entry system will work with
up to four transmitters). Return your existing
transmitters to your dealer so the remote entry
system can be reprogrammed with your new
and existing transmitters.
File:08rcfvm.ex
Update:Wed Mar 27 09:32:34 1996
Page 112 of 332
114
*
[FV08925( ALL)06/95]
THIS DEVICE COMPLIES WITH PART 15 OF
THE FCC RULES. OPERATION IS SUBJECT
TO THE FOLLOWING TWO CONDITIONS:
(1) THIS DEVICE MAY NOT CAUSE
HARMFUL INTERFERENCE, AND (2) THIS
DEVICE MUST ACCEPT ANY
INTERFERENCE RECEIVED, INCLUDING
INTERFERENCE THAT MAY CAUSE
UNDESIRED OPERATION.
%
*
[FV08950( ALL)02/95]
Windows
%*
[FV08975(M )03/91]
Using the Power Windows (If equipped)
[FV08990(MBC )03/03]
Each door has a power control that opens and
closes the window on that door. The driver's
door has a master control panel that operates the
windows.
*
[FV09050( ALL)01/95]
Power windows can only be opened or closed
when the ignition switch is in the ON or ACC
position.
*
[FV09075( ALL)08/95]
RWARNING
Do not let children play with the power
windows. They may seriously hurt
themselves. Make sure occupants are clear
of the window(s) before closing.
File:08rcfvm.ex
Update:Wed Mar 27 09:32:34 1996
Page 113 of 332
115 [FV09100(M )03/95]
half page art:0010232-C
The master controls on the driver's door Ð convertible
shown
*
[FV09400(M GV)05/95]
To lock out all window switches except the
master controls, press the window lock switch
once. To restore control to the individual
windows, press the switch again.
%*
[FV09500(M GV)05/95]
There is also an Express Down feature on the
driver's power window.
[FV09600(M GV)05/95]
To operate, actuate driver's power window
switch to the down position for less than 0.4
seconds; the window will then open
automatically. To terminate automatic operation
before the window completely opens, operate the
switch again, for less than 0.4 seconds, to either
the up or down position. Actuating the switch
for greater than 0.4 seconds provides
conventional power window operation. Closing
of the power window is conventional operation
only.
File:08rcfvm.ex
Update:Wed Mar 27 09:32:34 1996
Page 114 of 332
116
%*
[FV15700( ALL)01/95]
Seats
%*
[FV15710( ALL)04/95]
Head Restraints
*
[FV15720( ALL)04/95]
If you use them properly, head restraints will
help protect your head and neck in a collision.
*
[FV15730( ALL)05/95]
A head restraint helps protect you best if you
position it behind your head and not behind
your neck.
*
[FV15740( ALL)02/95]
Standard head restraints
*
[FV15750( ALL)01/95]
You can adjust the head restraints for your
comfort and protection.
[FV15770( ALL)05/92]
one third page art:0010048-C
Adjusting the head restraint
[FV15776(M )06/93]
The four-way head restraint (standard on
GT models)
*
[FV15785(M )06/95]
Your vehicle has the four-way head restraint.
You can adjust it in four directions. You can
raise it two (2) inches (50 mm) from its normal
position, or you can move it forward up to 60Ê
until you reach the desired position.
File:08rcfvm.ex
Update:Wed Mar 27 09:32:34 1996
Page 115 of 332
117 [FV15790(M )07/93]
one third page art:0010049-B
The four-way head restraint
% [FV15800(MBC )06/93]
Adjusting Manual Seats
*
[FV16000( ALL)02/89]
In the front seats, you can move the whole seat
forward or backward or tilt the back of the seat
forward or backward.
[FV16100(MBC )05/92]
To move the seats forward or backward:
*
[FV16300(M )06/95]
1. Find the adjustment lever at the lower left
corner of the front seat.
*
[FV16500(M )08/94]
2. Push the lever to the left to unlock the seat.
*
[FV16600( ALL)08/95]
3. Move the seat to the desired position.
*
[FV16800(M )08/95]
4. Release the lever to latch the seat in its new
position. Make sure the seat locks securely in
place.
File:08rcfvm.ex
Update:Wed Mar 27 09:32:34 1996
Page 116 of 332
118 [FV17000(M )06/93]
one third page art:0010253-BThe front seat adjustment lever
*
[FV17100(MBC )08/95]
To recline the front manual seats:
*
[FV17200( ALL)06/95]
1. On the side of the seat, find the handle for
the recliner.
*
[FV17300( ALL)08/95]
2. Lift the handle up and hold it in place.
*
[FV17400( ALL)01/95]
3. Lean against the back of the seat and adjust
it to the position you want. You can tilt the
seat back or bring it forward.
*
[FV17500( ALL)08/95]
4. Release the handle to lock the seat in its new
position.
[FV17510(M )06/93]
NOTE: Seat back recline angle is restricted to
prevent interference with interior trim
panels on convertible models.
*
[FV17600( ALL)08/95]
RWARNING
Never adjust the driver's seat or seatback
when the vehicle is moving.
*
[FV17700( ALL)08/95]
RWARNING
To reduce the risk of serious injury in a
collision, always drive and ride with your
seatback upright and the lap belt snug
and low across the hips.
File:08rcfvm.ex
Update:Wed Mar 27 09:32:34 1996
Page 117 of 332
119 %
*
[FV17900(MBC )01/95]
Seatback Recline
[FV18000(M )06/93]
one third page art:0010255-C
Front seatback release levers
[FV18250(M )05/89]
It is necessary to use the seatback release when
folding the back of the front seat forward for
rear seat passenger entry or exit. This release
handle is located on the lower outboard back of
the seat. The seatback locks automatically when
returned to the normal position.
[FV18275(M )03/95]
To allow rear seat passenger access, use one
hand to pull up on the release handle while the
other hand pushes the seatback forward.
[FV18450(M )09/89]
RWARNING
Do not allow packages or other objects to
interfere with the normal positions of the
seatback or the emergency seatback
release. This may prevent the seatback
from returning to its upright latched
position and could cause personal injury.
File:08rcfvm.ex
Update:Wed Mar 27 09:32:34 1996
Page 118 of 332
120 % [FV18575(M )05/95]Using the Power Seat (If equipped)
[FV18750(M )05/95]
If your vehicle has a driver side power seat, you
can adjust it in several directions. Using the seat
adjustment switch, located on the front outboard
corner of the driver's seat, you can raise or
lower the whole front seat and move the seat
forward or backward.
[FV18835(M )03/92]
half page art:0010732-A
The seat controls on the driver's seat
*
[FV18850( ALL)08/95]
RWARNING
Do not pile cargo higher than the
seatbacks to avoid injuring people in a
collision or sudden stop.
File:08rcfvm.ex
Update:Wed Mar 27 09:32:34 1996
Page 119 of 332
121 [FV19500(M )05/95]
Sport Seat Controls (GT models)
% [FV19510(M )08/93]
Using the Power Lumbar Supports
[FV19512(M )08/93]
You can inflate a lumbar support pad in the seat
back. To inflate the lumbar pad, push the (+)
side of the rocker switch. To deflate push the (-)
side of the switch.
[FV19515(M )08/93]
Using the Lateral Support Handwheel
(driver only)
[FV19520(M )08/93]
To increase lateral support rotate the handwheel
counterclockwise. To decrease lateral support
turn the handwheel clockwise.
[FV19600(M )05/95]
half page art:0010262-G
GT seat controls
File:08rcfvm.ex
Update:Wed Mar 27 09:32:34 1996
Page 120 of 332
122 %
*
[FV19950(MBC )03/95]
Rear Seat Entry
[FV19955(M )03/95]
Coupe models
[FV20010(M )08/93]
one third page art:0011192-A
Entering the rear seat (coupe)
[FV20100(MBC )03/95]
The rotating boot on the lap belt is designed to
allow rear seat entry/exit. To enter the rear seat:
[FV20250(M )03/95]
1. Remove seat belt from seat belt guide on top
of front seat.
[FV20350(M )03/95]
2. Rotate the safety belt boot rearward.
[FV20403(M )03/95]
3. Enter the rear seat in front of the safety belt.
[FV20406(M )03/95]
4. Rotate the safety belt boot forward and place
the belt in the belt guide on the seat back to
allow use by the front seat passengers.
File:08rcfvm.ex
Update:Wed Mar 27 09:32:34 1996
