FORD MUSTANG 1996 4.G Owners Manual

123 [FV20410(M )03/95]
Convertible models
[FV20420(M )08/93]
one third page art:0011230-A
Entering the rear seat (convertible)
[FV20425(M )03/95]
To enter the rear seat:
[FV20430(M )03/95]
1. Remove the shoulder belt from the seat belt
guide on top of front seat.
[FV20435(M )08/93]
2. Remove the lap belt from the seat belt guide
on side of seat.
[FV20440(M )03/95]
3. Enter the rear seat in front of the safety belt.
[FV20445(M )03/95]
4. Place the lap and shoulder belt into the
guides to allow use by the front seat
passengers.
File:08rcfvm.ex
Update:Wed Mar 27 09:32:34 1996

124 % [FV20450(M )12/93]Folding Rear Seat (Coupe only)
[FV20455(M )12/93]
To fold down the rear seats, gently pull on the
release straps.
[FV20460(M )12/93]
NOTE: It may be necessary to apply slight
hand pressure to top of seatback while
pulling on release strap.
[FV20465(M )12/93]
one third page art:0011249-A
Rear seat release straps
*
[FV20470(M )12/93]
To raise the rear seatback:
*
[FV20475(M )12/93]
1. Push the seatback upward until it locks in
place.
[FV20480(M )12/93]
2. Make sure the seatback is firmly latched by
pushing forward and backward on it.
*
[FV20485(M )05/95]
RWARNING
Securely latch the seatback in the upright
position to prevent the seatback or objects
from being thrown forward during a
sudden stop or collision.
File:08rcfvm.ex
Update:Wed Mar 27 09:32:34 1996

125 %
*
[FV20500( ALL)04/95]
Cleaning the Seats
*
[FV20600( ALL)07/95]
Leather and vinyl
*
[FV20650( ALL)05/95]
For routine cleaning, wipe the surface with a
soft, damp cloth. For more thorough cleaning,
wipe the surface with a leather and vinyl cleaner
or a mild soap.
%*
[FV20700( ALL)04/95]
Fabric
*
[FV20750( ALL)05/95]
Remove dust and loose dirt with a whisk broom
or a vacuum cleaner. Remove fresh spots
immediately. Follow the directions that come
with the cleaner.
*
[FV20775( ALL)09/95]
NOTE: Before using any cleaner, test it on a
small, hidden area of fabric. If the
fabric's color or texture is adversely
affected by a particular cleaner, do not
use it.
%
*
[FV20800( ALL)01/95]
Mirrors
[FV20810(M )03/94]
NOTE: The mirror mount is designed to
detach from windshield during air bag
deployment. Excessive force and/or
excessive up, down, side-to-side
adjustment can cause mirror to detach
from windshield.
*
[FV20850( ALL)05/95]
You can adjust your rearview mirror in any
direction. The special swivel bracket lets you
move the mirror up or down and from side to
side.
[FV21000( ALL)06/95]
RWARNING
Make sure you can see clearly through the
rearview mirror at all times. Do not block
your vision. If you cannot see through the
mirror, it could result in a collision,
injuring yourself and others.
File:08rcfvm.ex
Update:Wed Mar 27 09:32:34 1996

126 % [FV21100(M )06/93]Rearview Mirror and Lamp Assembly
(convertible only)
[FV21200(M )03/94]
This rearview mirror contains two lamps which
function as courtesy lamps when the doors are
open. These lamps also function as map lamps
when the doors are closed and the rocker switch
is activated.
[FV21300(M )08/93]
one third page art:0010266-B
The rearview mirror with lamps
File:08rcfvm.ex
Update:Wed Mar 27 09:32:34 1996

127 % [FV22700(M )06/93]
Adjusting the Side View Mirrors
[FV24200(M C )06/93]
The switch for controlling the dual electric
remote control mirrors is located on the driver's
door.
%*
[FV24400( ALL)01/95]
Do not clean the housing or glass of any mirror
with harsh abrasives, fuel or other
petroleum-based cleaning products.
[FV24520(M )03/95]
half page art:0010272-C
The mirror controls on the driver's door
*
[FV24700( ALL)04/95]
To adjust the side mirrors:
*
[FV24800( ALL)01/95]
1. Find the control switch in the driver's door
panel.
*
[FV24900( ALL)06/94]
2. Select the right or left mirror by moving the
selector switch to R or L.
[FV25000( ALL)06/93]
3. Move the knob in the direction of the arrows
for the direction you want to move the
mirror.
*
[FV25100( ALL)06/94]
4. Return the selector switch to the middle
position to keep the mirror in place.
File:08rcfvm.ex
Update:Wed Mar 27 09:32:34 1996

128 [FV28700( ALL)01/89]The Right Side Convex Mirror
*
[FV28800( ALL)02/94]
The side view mirror on the right is a convex
mirror. This mirror gives you a wider view of
the lanes on your right and behind you.
*
[FV28900( ALL)05/95]
RWARNING
The side view mirror on the right makes
objects appear smaller and farther away
than they actually are.
%
*
[FV28950( ALL)05/95]
Sun Visors
%*
[FV29100( ALL)05/94]
Turning on the Mirror Light on the Sun
Visors (If equipped)
[FV29300( ALL)06/93]
To turn on the visor mirror light, lift the mirror
cover.
[FV29700(M )08/93]
one third page art:0010276-B
The mirror on the sun visor
File:08rcfvm.ex
Update:Wed Mar 27 09:32:34 1996

129
%*
[FV30200(MBC )01/95]
Console
[FV30350(MBC )06/93]
Your vehicle has a full console. The full console
has the features shown in the illustration below.
[FV30400(M )08/93]
half page art:0010281-E
The features on the full console
File:08rcfvm.ex
Update:Wed Mar 27 09:32:34 1996

130
%*
[FV32725(M GV)03/95]
Power Point Electrical Outlet
[FV32750(M )10/95]
The power point outlet is located on the console
to the right of the shift lever. This outlet should
be used in place of the cigarette lighter for
optional electrical accessories.
[FV32775(M )09/95]
NOTE: Do not plug optional electrical
accessories into the cigarette lighter.
Electrical system damage could occur.
[FV32801(M )08/93]
half page art:0011193-A
Power point electrical outlet
[FV32825(M )08/93]
To access the outlet, flip the cover down.
File:08rcfvm.ex
Update:Wed Mar 27 09:32:34 1996

131
%*
[FV32875( ALL)01/95]
Storage Compartments
*
[FV32900(M GV)01/95]
Your vehicle may have several small storage
compartments:
[FV32910(M )05/94]
q
a glove compartment that locks.
[FV32920(M )05/94]
q
if equipped with power windows, two map
pockets on the panels of the front doors.
[FV32923(M )05/94]
q
center console storage compartment under the
arm rest that may be used for storage of CD's
or cassettes.
[FV32924(M )05/95]
q
coin holders located behind the ashtray. These
are deleted if fog lamps or convertible top are
ordered.
*
[FV33300( ALL)08/95]
RWARNING
Do not put objects on the ledge between
the back seat and the rear window, as
they can become dangerous projectiles and
injure someone.
%
*
[FV33400( ALL)01/95]
Trunk
*
[FV33500( ALL)01/95]
Opening the Trunk Manually
[FV33600(M )05/94]
The trunk in your vehicle gives you plenty of
room for storage:
[FV33700(M )06/93]
q
coupe Ð 10.8 cubic feet (.31 cubic meters)
[FV33900(M )06/93]
q
convertible Ð 8.5 cubic feet (.24 cubic meters)
%*
[FV34600( ALL)03/95]
To open and close the trunk from the outside:
[FV34900(M )06/93]
1. Insert the key into the lock to the right of
the license plate.
[FV35100( ALL)11/90]
2. Turn the key to the right until the trunk
opens.
[FV35300( ALL)11/90]
3. Remove the key before you close and lock
the lid.
[FV35450( ALL)06/93]
4. Shut the trunk lid completely.
File:08rcfvm.ex
Update:Wed Mar 27 09:32:34 1996

132 % [FV36200( ALL)03/95]Using the Remote Control for the
Trunk (If equipped)
[FV36400(M )08/93]
You can use the remote control inside your
glove compartment to unlock and open the
trunk. If equipped, you can also use your remote
entry system to open the trunk.
[FV36600(M )01/89]
quarter page art:0010286-A
The remote control for the trunk
% [FV37300(M )12/94]
Convertible (If equipped)
[FV37650(M )09/95]
NOTE: Do not store articles behind rear seat.
Articles stored in the convertible top
stowage compartment may break the
rear glass window when the top is
lowered.
% [FV38600(M )01/89]
Lowering the Convertible Top
[FV38700(M )03/93]
The convertible top can be lowered with the side
windows either up or down.
[FV38750(M )09/95]
NOTE: CONVERTIBLE TOP WILL NOT
OPERATE UNLESS PARKING BRAKE
IS ENGAGED. Do not lower the top
while the vehicle is moving because
the top may be severely damaged.
Also, do not lower the top when the
top material is wet.
[FV38800(M )01/89]
To lower the convertible top:
[FV38850(M )03/93]
1. Bring vehicle to a complete stop. Engage the
parking brake.
