Downshifting
*
[DR09100(M )03/95]
When you slow down or climb a steep hill,
always downshift before the engine starts to lose
power. Downshifting reduces the chance of
stalling and gives your vehicle better acceleration
to increase speed again.
*
[DR09200(M )03/95]
When you drive down steep hills, downshifting
helps you keep a safe speed and helps prevent
unnecessary wear on the brakes.
*
[DR09300(M )03/95]
When you come to a stop, do not downshift
through each gear. Disengage the clutch and use
the brake as necessary. Downshifting through
the gears decreases your vehicle's fuel economy.
[DR09400(M )03/95]
NOTE: Do not downshift into 1 (First) when
your vehicle is moving faster than
15 mph (24 km/h). This will damage
the clutch.
*
[DR09500(M )03/95]
Parking
*
[DR09600(M )03/95]
To park your vehicle, shift into 1 (First), set the
parking brake fully, and turn off the ignition.
*
[DR09700(M )05/95]
RWARNING
Do not park your vehicle in Neutral, it
may move unexpectedly and injure
someone. Use 1 (First) gear and set the
parking brake fully.
% [DR09720( ALL)03/95]
Traction-Lok Axle (If equipped)
[DR09730( ALL)12/91]
This axle provides added traction on slippery
surfaces, particularly when one wheel is on a
poor traction surface. Under normal conditions
the Traction-Lok axle functions as a standard
rear axle.
File:10rcdrm.ex
Update:Wed Mar 27 09:33:56 1996

186
*
[DR09740( ALL)03/93]
Extended use of other than matching size tires
on a Traction-Lok rear axle could result in a
permanent reduction in effectiveness. This loss of
effectiveness does not affect normal driving and
should not be noticeable to the driver.
*
[DR09750( ALL)05/95]
RWARNING
To avoid injury, never run the engine
with one wheel off the ground, such as
when changing a tire.
%
*
[DR09800( ALL)01/95]
Steering Your Vehicle
%*
[DR09900( ALL)01/95]
Your vehicle comes with power steering. Power
steering uses energy from the engine to help
steer your vehicle.
%*
[DR09950( ALL)04/95]
If the amount of effort needed to steer your
vehicle changes at a constant vehicle speed, have
the power steering system checked. If the power
steering system breaks down (or if the engine is
turned off), you can steer the vehicle manually
but it takes more effort.
*
[DR10000( ALL)01/95]
Never hold the steering wheel to the extreme
right or left for more than five seconds if the
engine is running. This can damage the power
steering pump.
%
*
[DR10500( ALL)03/95]
Brakes
%*
[DR10600( ALL)01/95]
Applying the Brakes
[DR10650( ALL)06/95]
Braking non ABS models
[DR10700(M )10/95]
All models have power 4-wheel disc brakes
(anti-lock on all four wheels is optional/standard
on Cobra models). They adjust automatically as
the brake pads or linings wear down.
*
[DR11100( ALL)05/95]
Apply the brake pedal gradually. Use the
ªsqueezeº technique Ð push on the brake pedal
with a steadily increasing force. This allows the
File:10rcdrm.ex
Update:Wed Mar 27 09:33:56 1996

187
wheels to continue to roll while you are slowing
down, which lets you steer properly.
[DR11300( ALL)03/95]
On vehicles without anti-lock brakes, extreme
braking can make the wheels lock and slide,
possibly decreasing your control of the steering.
If you lock the wheels, release the brake pedal
and repeat the ªsqueezeº technique.
[DR11310( ALL)05/95]
Braking with ABS brakes
[DR11400( ALL)03/95]
On vehicles with anti-lock brakes, the wheels
will not lock and slide when you press down
hard on the brake pedal. The anti-lock brakes
automatically start releasing and reapplying the
front brakes independently and the rear brakes
together whenever your wheels start to lock. Do
not ªpumpº the brake pedal on vehicles
equipped with anti-lock brakes. When this
happens, you will feel the brake pedal pulse.
This ªpulseº may be an unfamiliar feeling but it
is normal and indicates the ABS is working as
designed.
*
[DR11650( ALL)05/95]
Do not drive with your foot resting on the brake
pedal; you will wear out the linings and increase
your vehicle's stopping distance. Brake rotor
damage may also eventually occur.
*
[DR11700( ALL)09/95]
NOTE: If you are driving down a long or
steep hill, shift to a lower gear and do
not apply your brakes continuously. If
you apply your brakes continuously,
they may overheat and become less
effective.
%*
[DR11800( ALL)10/95]
Occasional brake squeal during light to moderate
stops does not affect the function of the brake
system and is normal. However, if the squeal
becomes louder or more frequent, have your
brakes inspected by your dealer or a qualified
service technician.
File:10rcdrm.ex
Update:Wed Mar 27 09:33:56 1996

188 [DR11900( ALL)05/94]Ford Motor Company has not found any
detrimental effects of popular mobile radio
transmitting equipment installed on vehicles
with the anti-lock brake system, if the equipment
is installed according to the manufacturer's
instructions. However, if mobile radio
transmitting equipment is installed in your
vehicle and, if either the anti-lock brake system
cycles or the check anti-lock light comes on at
any time other than right after you turn the key
to ON or during a sudden stop, have your
mobile radio dealer inspect the installation.
%*
[DR12000( ALL)03/95]
Parking Brake
*
[DR12050( ALL)01/95]
The parking brake should be used whenever
you park your vehicle.
[DR12100(M )01/89]
The brake handle is located between the front
seats.
[DR12600(M )03/95]
To set the parking brake after parking your
vehicle, apply the brake pedal with your right
foot and pull up on the parking brake handle.
The brake system warning light will glow.
[DR13100(M )08/93]
one third page art:0010314-B
The parking brake
File:10rcdrm.ex
Update:Wed Mar 27 09:33:56 1996

189
*
[DR13700(M )03/95]
RWARNING
When parking, do not use the gearshift in
place of the parking brake. Turn the key
to LOCK whenever you leave your
vehicle. Always set the parking brake
fully and make sure that the gearshift is
securely latched in P (Park) (automatic
transmission) or in 1 (First) (manual
transmission). Never leave your vehicle
unattended while it is running. If you do
not take these precautions, your vehicle
may move unexpectedly and injure
someone.
[DR13900(M )10/95]
To release the parking brake, pull the handle
upward, push in the button, then lower the
handle. The Brake System warning light will
glow if the parking brake is not fully released
when the engine is running.
*
[DR14200( ALL)03/95]
Always check the Brake Warning Light each
time you start your engine. Driving with the
parking brake on will cause the brakes to wear
out quickly and will reduce the fuel economy.
*
[DR14300( ALL)01/93]
RWARNING
If the parking brake is fully released, but
the Brake System light remains on, have
the brakes checked immediately. They
may not be working properly.
[DR14400( ALL)07/93]
The parking brake system is designed for static
parking only and is not designed to stop a
moving vehicle, but you can use the parking
brake to stop your vehicle in an emergency if
the normal brakes fail. However, since the
parking brake applies only the rear brakes, the
stopping distance will increase greatly and the
handling of your vehicle will be adversely
affected.
File:10rcdrm.ex
Update:Wed Mar 27 09:33:56 1996

190
%*
[DR14500( ALL)01/95]
Driving Under Special Conditions
%*
[DR14600( ALL)01/95]
Tips for Safe Driving
*
[DR14700( ALL)07/95]
As with any new vehicle, yours may drive and
handle differently from your previous vehicle.
Use care until you become accustomed to its
various features and driving characteristics.
*
[DR14800( ALL)03/95]
Operate your vehicle within reasonable limits.
Sudden acceleration, deceleration, turning, or
combinations of these maneuvers can cause a
vehicle to behave differently than anticipated.
%*
[DR15200( ALL)01/95]
Driving in Bad Weather
%*
[DR15300( ALL)01/95]
Slippery roads
*
[DR15400( ALL)03/95]
Drive cautiously on wet or snowy roads:
*
[DR15500( ALL)03/95]
q
Do not quickly move the steering wheel
unless necessary.
*
[DR15600( ALL)01/95]
q
Drive slower than you normally would.
*
[DR15700( ALL)02/95]
q
Do not use speed control.
*
[DR15800( ALL)01/95]
q
Give your vehicle more distance to stop.
*
[DR15900( ALL)03/92]
q
Pump the brake pedal steadily and evenly to
avoid locking your wheels. (Does not apply
to vehicles with anti-lock brakes.)
*
[DR16000( ALL)02/93]
q
Consider using one of the lower gears.
*
[DR16100(M )05/95]
RWARNING
To avoid losing control on slippery roads,
do not downshift into Low with the
automatic transmission when moving
faster than 20 mph (32 km/h). Do not
downshift into First with the manual
transmission when moving faster than
5 mph (8 km/h).
File:10rcdrm.ex
Update:Wed Mar 27 09:33:56 1996

191
*
[DR16225( ALL)03/95]
RWARNING
If your vehicle has speed control, do not
use it on slippery roads. You could lose
control of your vehicle and could injure
someone.
[DR16300(MBC )03/92]
If your vehicle gets stuck (for example, in mud
or snow), you may try to ªrockº it out of the
spot. Shift, in a steady rhythm, between forward
and reverse gears. At the same time, press
lightly on the accelerator.
*
[DR16400( ALL)05/95]
RWARNING
Do not spin the wheels at over 35 mph
(55 km/h). The tires may fail and injure a
passenger or bystander.
[DR16500( ALL)12/94]
By moving the vehicle backward and forward,
you may gain enough momentum to move out
of the spot. Do not rock the vehicle for more
than a few minutes. This may overheat the
engine, damage the transmission, or damage the
tires. If you are still stuck after a minute or two
of rocking, call for a tow truck.
%*
[DR16700( ALL)01/95]
High water
*
[DR16800( ALL)01/95]
Do not drive through flooded areas unless you
are sure that the water is below the bottom of
the wheel rims.
*
[DR16900( ALL)04/94]
If you must drive through high water, drive
slowly. You may have limited traction or wet
brakes, so allow extra stopping distance because
your vehicle will not stop as quickly as usual.
*
[DR17000( ALL)01/95]
After you drive through the standing water,
apply your brakes gently several times as your
vehicle moves slowly. This helps to dry the
brakes.
File:10rcdrm.ex
Update:Wed Mar 27 09:33:56 1996

192
%*
[DR17100( ALL)03/95]
Driving With a Heavy Load
*
[DR17200( ALL)01/95]
There are limits to the amount of weight your
vehicle can carry or tow. The total weight of
your vehicle, plus the weight of the passengers
and cargo, should never be more than the Gross
Vehicle Weight Rating (GVWR). Also, the weight
that your vehicle carries over the front axle and
rear axle should never be more than the Gross
Axle Weight Rating (GAWR) for the respective
axle.
% [DR17300( ALL)05/94]
You can find your vehicle's GVWR and GAWR
on the Safety Compliance Certification Label on
the left front door lock facing or the door latch
post pillar.
*
[DR17400( ALL)08/95]
The weight limits of your vehicle's tires affect
the GVWR or GAWR limitations. Usage of
replacement tires with higher weight limits than
originals does not increase GVWR or GAWR.
Usage of lower capacity replacement tires may
lower GVWR and GAWR limitations.
*
[DR17500( ALL)02/95]
RWARNING
If the GVWR or the GAWR specified on
the Safety Compliance Certification Label
is exceeded, your vehicle may be damaged
or you may lose control and injure
someone.
%*
[DR17503( ALL)01/95]
Limiting Your Vehicle's Load
*
[DR17506( ALL)01/95]
The load that you add to your vehicle must not
exceed the maximum load stated on the Safety
Compliance Certification Decal attached to the
left front door pillar.
*
[DR17509( ALL)01/95]
To figure the weight of your vehicle's load, add
the weights of:
*
[DR17512( ALL)01/95]
q
the driver and passengers
File:10rcdrm.ex
Update:Wed Mar 27 09:33:56 1996

193
*
[DR17515( ALL)01/95]
q
luggage and any other items that you put in
your vehicle
*
[DR17518( ALL)01/95]
q
the tongue load of the loaded trailer
*
[DR17521( ALL)01/95]
q
the weight of any equipment that has been
added to your vehicle since it was delivered
to your dealer
*
[DR17524( ALL)01/95]
If you do not know the actual weights of these
items, use the following procedure to figure the
weight of a load:
*
[DR17527( ALL)01/95]
1. Weigh your vehicle without the driver,
passengers and luggage. You might take
your vehicle to a shipping company or an
inspection station for trucks.
*
[DR17530( ALL)01/95]
2. Then weigh your vehicle with the driver,
passengers and luggage.
*
[DR17533( ALL)01/95]
3. Subtract the first reading from the second to
figure the total weight of the load.
*
[DR17536( ALL)01/95]
After determining this load, you must also make
sure that the total weight of your vehicle, plus
the load it carries, is less than its GVWR. Also,
make sure that the weight your vehicle carries
over each axle is less than the GAWR for the
respective axle.
*
[DR17539( ALL)01/95]
If your vehicle exceeds the GVWR, remove cargo
from your vehicle accordingly. If your vehicle
exceeds the GAWR for either axle, shift the load
or remove cargo accordingly.
*
[DR17542( ALL)05/95]
RWARNING
Improper distribution of your vehicle's
load or carrying weight in excess of the
amount shown on the tire decal can cause
rapid tire wear or loss of vehicle control.
File:10rcdrm.ex
Update:Wed Mar 27 09:33:56 1996

194
%*
[DR17550(MBC )04/95]
Trailer Towing
*
[DR17650( ALL)01/95]
Your vehicle does not come from the factory
fully equipped to tow. No towing packages are
available through Ford or Lincoln/Mercury
dealers.
*
[DR17700( ALL)01/95]
Because towing a trailer puts extra strain on
your vehicle, you must follow certain
precautions for your safety and the good of your
vehicle:
*
[DR17800( ALL)01/95]
q
Stay within the load limits for towing your
vehicle. (SeeTrailer towing specificationsin this
chapter.)
*
[DR17900( ALL)01/95]
q
Carefully and thoroughly prepare your
vehicle for towing, making sure to use the
right equipment and to attach it properly.
(SeePreparing to Towin this chapter.)
*
[DR18000( ALL)01/95]
q
Use extra caution when driving your vehicle
while you tow. (SeeDriving while you towin
this chapter.)
*
[DR18100( ALL)01/95]
q
Service your vehicle more frequently if you
tow a trailer. (SeeServicing your vehicle if you
towin this chapter.)
*
[DR18175( ALL)01/95]
Ten to 15% of the loaded trailer's weight should
be on the tongue. However, the tongue load
should never exceed 10% of the maximum
weight that your vehicle can safely tow.
*
[DR18250( ALL)05/95]
RWARNING
Do not tow a trailer when the temporary
spare tire is being used.
[DR18300( ALL)12/94]
Your vehicle is classified as a light duty towing
vehicle. The amount of weight that you can
safely tow depends on the optional equipment
on your vehicle. See the following chart.
File:10rcdrm.ex
Update:Wed Mar 27 09:33:56 1996
