9
Safety Restraints
%*
[SR00500( ALL)04/95]
Important Safety Belt Information
*
[SR00600( ALL)03/95]
The use of safety belts helps to restrain you and
your passengers in case of a collision. In most
states and in Canada the law requires their use.
*
[SR00800( ALL)08/95]
Safety belts provide best restraint when:
*
[SR00900( ALL)08/95]
q
the seatback is upright
*
[SR01000( ALL)08/95]
q
the occupant is sitting upright (not slouched)
*
[SR01100( ALL)08/95]
q
the lap belt is snug and low on the hips
*
[SR01200( ALL)08/95]
q
the shoulder belt is snug against the chest
*
[SR01300( ALL)08/95]
q
the knees are straight forward
[SR01310(M )06/93]
q
seat belt is placed in guide on top of seat
*
[SR02100( ALL)07/95]
To help you remember to fasten your safety belt,
a warning light may come on and a chime may
sound. SeeSafety Belt Warning Light and Chimein
theWarning Lights and Gaugeschapter.
*
[SR02500( ALL)07/95]
See the following sections in this chapter for
directions on how to properly use these safety
belts. Also seeSafety Restraints for Childrenin this
chapter for special instructions about using
safety belts for children.
%*
[SR02600( ALL)05/95]
RWARNING
Make sure that you and your passengers
wear safety belts. Always drive and ride
with your seatback upright and the lap
belt snug and low across the hips.
File:03rcsrm.ex
Update:Wed Mar 27 09:23:48 1996
Page 12 of 332
10
*
[SR02700( ALL)06/95]
RWARNING
Never wear the shoulder belt under the
arm. Never swing it around the neck over
the inside shoulder. Never use a single
belt for more than one person or across
more than one seating position. Each
seating position in your vehicle has a
specific safety belt assembly which is
made up of one buckle and one tongue
that are designed to be used as a pair.
Failure to follow these precautions could
increase the risk and/or severity of injury
in a collision.
*
[SR02801( ALL)05/95]
RWARNING
Ford recommends that all safety belt
assemblies and attaching hardware should
be inspected by a qualified technician
after any collision. Safety belt assemblies
not in use during a collision should also
be inspected and replaced if either
damage or improper operation is noted.
*
[SR02901( ALL)08/95]
RWARNING
To reduce the risk of serious injury in a
collision, children should always ride with
the seatback upright.
*
[SR03001( ALL)08/95]
RWARNING
Never let a passenger hold a child on his
or her lap while the vehicle is moving.
The passenger cannot protect the child
from injury in a collision.
File:03rcsrm.ex
Update:Wed Mar 27 09:23:48 1996
Page 13 of 332
11
*
[SR03200( ALL)09/95]
RWARNING
Lock the doors of your vehicle before
driving to lessen the risk of the door
coming open in a collision.
%
*
[SR03700( ALL)05/95]
Combination Lap and Shoulder
Belts
*
[SR03800( ALL)01/95]
While your vehicle is in motion, the combination
lap and shoulder belt adjusts to your movement.
However, if you brake hard, corner hard or if
your vehicle receives an impact of 5 mph
(8 km/h) or more, the lap and shoulder belt
locks and helps reduce your forward movement.
*
[SR04100( ALL)05/95]
After you get into your vehicle, close the door
and lock it. Then adjust the seat to the position
that suits you best.
[SR04300(M )06/93]
Before fastening the front seat belt, make sure
the shoulder belt passes through the belt holder
on the top of the seatback.
[SR04400( ALL)06/93]
To fasten the belt,pull the lap/shoulder belt
from the retractor so that the shoulder portion of
the belt crosses your shoulder and chest. Be sure
the belt is not twisted. If it is, remove the twist.
Insert the belt tongue into the proper buckle
until you hear a snap and feel it latch. Make
sure the tongue is securely fastened in the
buckle.
File:03rcsrm.ex
Update:Wed Mar 27 09:23:48 1996
Page 14 of 332
12 [SR04555(M )03/95]
one third page art:0011200-BFastening the front seat combination lap and shoulder belt
(coupe models)
[SR04557(M )03/95]
one third page art:0011225-B
Fastening the front seat combination lap and shoulder belt
(convertible models)
File:03rcsrm.ex
Update:Wed Mar 27 09:23:48 1996
Page 15 of 332
13 [SR04650(M )03/95]
one third page art:0010502-A
Fastening the rear seat combination lap and shoulder belt
coupe and convertible
*
[SR04675( ALL)07/95]
NOTE: Be sure to read and understand
Important Safety Belt Informationat
the beginning of this chapter.
% [SR04678(M )03/95]
Safety Belts for Front Passenger (Coupe
Only) and Rear (Coupe and Convertible)
Outboard Seating Positions
[SR04681(M )03/95]
Your vehicle is equipped with a dual locking
mode retractor on the shoulder belt portion of
the combination lap/shoulder safety belt for
front seat passengers (coupe) and rear outboard
passenger seats (coupe and convertible).
*
[SR04682( ALL)08/95]
Dual locking mode retractors operate in two
ways:
*
[SR04683( ALL)08/95]
Vehicle sensitive (emergency) locking mode
[SR04684( ALL)03/95]
In this operating mode, the shoulder belt
retractor will allow the occupant freedom of
movement, locking tight only on hard braking,
hard cornering or impacts of approximately
5 mph (8 km/h) or more. The retractor can also
be made to lock by pulling/jerking on the belt.
File:03rcsrm.ex
Update:Wed Mar 27 09:23:48 1996
Page 16 of 332
14 %
*
[SR04685( ALL)08/95]
Automatic locking mode
*
[SR04686( ALL)03/95]
In this operating mode, the shoulder belt
retractor will be automatically locked and remain
locked when the combination lap/shoulder
safety belt is buckled, and does not allow the
occupant freedom of movement. This mode
provides the following:
*
[SR04687( ALL)08/95]
q
A tight lap/shoulder belt fit on the occupant.
*
[SR04688( ALL)08/95]
q
Child seat or infant carrier installation
restraint.
*
[SR04689( ALL)09/95]
RWARNING
Never install a rear-facing child seat or
infant carrier in the right front passenger
seat.
*
[SR04690( ALL)09/95]
This modemust be usedwhen installing a child
safety seat on the front passenger seat and rear
outboard seats where dual locking retractors are
provided.
*
[SR04691( ALL)08/95]
To switch the retractor from the emergency
locking mode to the automatic locking mode,
perform the following steps:
*
[SR04692( ALL)08/95]
1. Buckle the lap/shoulder combination belt.
*
[SR04693( ALL)09/95]
2. Grasp the shoulder portion of the belt and
pull downward until all of the belt is
extracted and, when allowed to retract, a
clicking sound is heard. At this time, the belt
retractor is in the automatic locking mode
(child restraint mode).
*
[SR04694( ALL)10/95]
3. A clicking sound will continue to be heard
as the belt is allowed to retract.
File:03rcsrm.ex
Update:Wed Mar 27 09:23:48 1996
Page 17 of 332
15 [SR04695( ALL)09/95]
NOTE: When the combination lap/shoulder
belt is unbuckled and allowed to
retract completely, the retractor will
switch back to the vehicle sensitive
(emergency) locking mode. See the
detailed instructions underSafety Seats
for Childrenin this chapter.
% [SR04696(M )03/95]
Front Passenger Lap Belt Retractor
(Convertible Only)
[SR04697(M )10/95]
Your convertible is equipped with a dual locking
mode retractor on thelap beltpart of the
lap/shoulder belt for the front seat passenger.
[SR04698(M )10/95]
Dual locking mode passenger seat lap belt
retractors operate in two ways:
*
[SR04699(M )08/95]
Vehicle sensitive (emergency) locking mode
[SR04700(M )03/95]
In this operating mode, the lap belt retractor will
allow the occupant freedom of movement,
locking tight only on hard braking, hard
cornering or impacts of approximately 5 mph
(8 km/h) or more. The retractor cannot be made
to lock by pulling on the belt.
%*
[SR04701(M )08/95]
Automatic locking mode
*
[SR04702(M )06/95]
In this operating mode, the lap belt retractor will
remain locked and does not allow the occupant
freedom of movement. This mode provides the
following:
*
[SR04705(M )08/95]
q
A tight lap/shoulder belt on the occupant.
*
[SR04710(M )08/95]
q
Child safety seat installation.
[SR04715(M )03/95]
This modemust be usedwhen installing a
forward facing child safety seat on the front
passenger seat. To switch the retractor from
the vehicle sensitive (emergency) locking
mode to the automatic locking mode,
perform the following steps:
File:03rcsrm.ex
Update:Wed Mar 27 09:23:48 1996
Page 18 of 332
16
*
[SR04720(M )09/95]
RWARNING
Never install a rear-facing child seat or
infant carrier in the right front passenger
seat.
[SR04725(M )03/95]
1. Buckle the lap/shoulder belt.
*
[SR04730(M )06/95]
2. Grasp the lap portion of the belt below the
child seat label. Pull upward until all of the
belt is extracted and a click is heard. At this
time, the lap belt retractor is in the
automatic locking mode (child restraint
mode).
*
[SR04735(M )03/95]
3. Allow the belt to retract. A clicking sound
will be heard as the belt retracts. This
indicates that the retractor is in the
automatic locking mode.
*
[SR04740(M )03/95]
4. Pull down on the belt to remove slack in the
belt.
*
[SR04745(M )08/95]
NOTE: When the combination lap/shoulder
belt is unbuckled and allowed to
retract completely, the retractor will
switch to the vehicle sensitive
(emergency) locking mode. See the
detailed instructions underSafety Seats
for Childrenin this chapter.
File:03rcsrm.ex
Update:Wed Mar 27 09:23:48 1996
Page 19 of 332
17
*
[SR05400( ALL)07/95]
RWARNING
The lap belts should fit snugly and as low
as possible around the hips, not around
the waist.
*
[SR05600( ALL)05/95]
RWARNING
Failure to follow these precautions could
increase the risk and/or severity of injury
in a collision. 1) Use the shoulder belt on
the outside shoulder only. Never wear the
shoulder belt under the arm. 2) Never
swing it around your neck over the inside
shoulder. 3) Never use a single belt for
more than one person.
[SR05800( ALL)05/95]
To unfasten all the belts:
[SR05900(MBC )06/93]
1. Push the release button on the end of the
buckle. This allows the tongue to unlatch
from the buckle.
[SR06400(M )12/93]
quarter page art:0010559-F
Unfastening the front (coupes) and rear outboard
lap/shoulder belts
File:03rcsrm.ex
Update:Wed Mar 27 09:23:48 1996
Page 20 of 332
18 [SR06500(M )08/93]
quarter page art:0010616-BUnfastening the Mustang convertible front outboard
lap/shoulder belts
*
[SR06600( ALL)03/95]
2. While the belt retracts, guide the tongue to
its stowed position. If you do not guide the
tongue, it may strike you or part of the
vehicle.
[SR06800(M )05/94]
3. (Coupe only). Place the belt in the belt
holder at the top of the seatback. The
retracted belt should be stored on this holder
when not in use, except when a passenger is
entering or leaving the rear seat area of the
vehicle.
