Page 71 of 321

FORD MUSTANG 1997 4.G Manual PDF 69
%*
[CF28900( ALL)01/96]
Windshield Wipers and Washer
*
[CF29000( ALL)04/96]
To turn on the windshield wipers, the ignition
key must be turned to the ON or ACC position.
[CF29100( ALL)12/95]
Rotate

Page 72 of 321

FORD MUSTANG 1997 4.G Manual PDF 70
*
[CF29700( ALL)01/96]
Windshield Washer
*
[CF29800( ALL)12/95]
To clean the windshield, push in the end of the
wiper knob. For a constant spray, keep the knob
pushed in. After you release the knob

Page 73 of 321

FORD MUSTANG 1997 4.G Manual PDF 71
%*
[CF30300( ALL)03/96]
Hazard Flasher
*
[CF30400( ALL)05/96]
The hazard flasher serves as a warning to other
drivers to be careful when approaching or
passing your vehicle.
[CF30600(M )05/96]
one

Page 74 of 321

FORD MUSTANG 1997 4.G Manual PDF 72
%*
[CF30700( ALL)05/96]
Horn
*
[CF30800( ALL)01/96]
To sound the horn, push the center pad area of
the steering wheel.
[CF31000(M )12/95]
half page art:0011165-B
The horn on the steering wheel
%*
[

Page 75 of 321

FORD MUSTANG 1997 4.G Manual PDF 73 [CF31400(MBC )12/95]
half page art:0010088-B
The lever to tilt the steering wheel
*
[CF31600( ALL)01/96]
To change the position of the steering wheel,
pull the release lever on the column toward yo

Page 76 of 321

FORD MUSTANG 1997 4.G Manual PDF 74
%*
[CF31700( ALL)03/96]
Speed Control (If equipped)
[CF31730(MBC )03/96]
half page art:0001014-B
The speed control switches on the steering wheel
%*
[CF31800( ALL)05/96]
To Turn Speed Control Off
*

Page 77 of 321

FORD MUSTANG 1997 4.G Manual PDF 75
*
[CF32700( ALL)05/96]
Speed control cannot reduce the vehicle speed if
it increases above the set speed on a downhill. If
your vehicle speed is faster than the set speed
while driving on a downhil

Page 78 of 321

FORD MUSTANG 1997 4.G Manual PDF 76
*
[CF33500( ALL)05/96]
To Set a Lower Set Speed
*
[CF33600( ALL)05/96]
q
Press and hold COAST. Release the switch
when the desired vehicle speed is reached.
OR
*
[CF33700( ALL)05/96]
q
Press and re

Page 79 of 321

FORD MUSTANG 1997 4.G Manual PDF 77
[CF35500( ALL)03/96]
Map and Reading Lamps
*
[CF35600( ALL)12/95]
Your vehicle has two map lamps for the
passenger and the driver. To turn on the map
lamps, push the switch next to each lamp.
[CF35

Page 80 of 321

FORD MUSTANG 1997 4.G Manual PDF 78
*
[CF38700( ALL)01/96]
RWARNING
Make sure you can see clearly through the
rearview mirror at all times. Do not block
your vision. If you cannot see through the
mirror, it could result in a collisio
