FORD MUSTANG 1997 4.G Owners Manual

110 [SS08700(M )12/95]Convertible models
[SS08800(M )12/95]
one third page art:0011230-A
Entering the rear seat (convertible)
[SS08900(M )12/95]
To enter the rear seat:
[SS09000(M )12/95]
1. Remove the shoulder belt from the seat belt
guide on top of front seat.
[SS09100(M )12/95]
2. Remove the lap belt from the seat belt guide
on side of seat.
[SS09200(M )12/95]
3. Enter the rear seat in front of the safety belt.
[SS09300(M )12/95]
4. Place the lap and shoulder belt into the
guides to allow use by the front seat
passengers.
% [SS09400(M )12/95]
Folding Rear Seat (Coupe only)
[SS09500(M )12/95]
To fold down the rear seats, gently pull on the
release straps.
[SS09600(M )12/95]
NOTE: It may be necessary to apply slight
hand pressure to top of seatback while
pulling on release strap.
File:06rcssm.ex
Update:Mon Feb 24 10:16:50 1997

111 [SS09700(M )12/95]
one third page art:0011249-A
Rear seat release straps
*
[SS09800(M )01/96]
To raise the rear seatback:
*
[SS09900(M )01/96]
1. Push the seatback upward until it locks in
place.
[SS10000(M )12/95]
2. Make sure the seatback is firmly latched by
pushing forward and backward on it.
*
[SS10100(M )02/96]
WARNING
Check to see that the seat and seatback
are latched securely in position. Keep
floor area free of objects that would
prevent proper seat engagement. Never
attempt to adjust the seat while the
vehicle is in motion.
%
*
[SS10500( ALL)02/96]
Important Safety Belt Information
*
[SS10600( ALL)02/96]
The use of safety belts helps to restrain you and
your passengers in case of a collision. In most
states and in Canada the law requires their use.
*
[SS10700( ALL)02/96]
Safety belts provide best restraint when:
*
[SS10800( ALL)02/96]
q
the seatback is upright
*
[SS10900( ALL)02/96]
q
the occupant is sitting upright (not slouched)
*
[SS11000( ALL)02/96]
q
the lap belt is snug and low on the hips
File:06rcssm.ex
Update:Mon Feb 24 10:16:50 1997

112
*
[SS11100( ALL)02/96]
q
the shoulder belt is snug against the chest
*
[SS11200( ALL)02/96]
q
the knees are straight forward
[SS11300(M )12/95]
q
seat belt is placed in guide on top of seat
*
[SS11400( ALL)02/96]
To help you remember to fasten your safety belt,
a warning light may come on and a chime may
sound. SeeSafety Belt Warning Light and Chimein
theInstrumentationchapter.
*
[SS11500( ALL)02/96]
See the following sections in this chapter for
directions on how to properly use these safety
belts. Also seeSafety Restraints for Childrenin this
chapter for special instructions about using
safety belts for children.
*
[SS11600( ALL)01/96]
WARNING
It is extremely dangerous to ride in a
cargo area, inside or outside of a vehicle.
In a collision, people riding in these areas
are more likely to be seriously injured or
killed. Do not allow people to ride in any
area of your vehicle that is not equipped
with seats and safety belts. Be sure
everyone in your vehicle is in a seat and
using a safety belt properly.
*
[SS11700( ALL)02/96]
WARNING
Always drive and ride with your seatback
upright and the lap belt snug and low
across the hips.
File:06rcssm.ex
Update:Mon Feb 24 10:16:50 1997

113
*
[SS11800( ALL)02/96]
WARNING
All safety belt assemblies, including
retractors, buckles, front seat belt buckle
support assemblies (slide bar) (if
equipped) shoulder belt height adjusters
(if equipped) and child safety seat tether
bracket assemblies (if equipped), and
attaching hardware, should be inspected
after any collision. Ford recommends that
all safety belt assemblies used in vehicles
involved in a collision be replaced.
However, if the collision was minor and a
qualified technician finds that the belts do
not show damage and continue to operate
properly, they do not need to be replaced.
Safety belt assemblies not in use during a
collision should also be inspected and
replaced if either damage or improper
operation is noted.
*
[SS11900( ALL)02/96]
WARNING
Children should always ride with the
seatback in the fully upright position.
*
[SS12000( ALL)02/96]
WARNING
Never let a passenger hold a child on his
or her lap while the vehicle is moving.
The passenger cannot protect the child
from injury in a collision.
*
[SS12100( ALL)02/96]
WARNING
Lock the doors of your vehicle before
driving to lessen the risk of the door
coming open in a collision.
File:06rcssm.ex
Update:Mon Feb 24 10:16:50 1997

114
%*
[SS12200( ALL)02/96]
Combination Lap and Shoulder
Belts
*
[SS12300( ALL)12/95]
While your vehicle is in motion, the combination
lap and shoulder belt adjusts to your movement.
However, if you brake hard, corner hard or if
your vehicle receives an impact of 5 mph
(8 km/h) or more, the lap and shoulder belt
locks and helps reduce your forward movement.
*
[SS12400( ALL)01/96]
After you get into your vehicle, close the door
and lock it. Then adjust the seat to the position
that suits you best.
[SS12500(M )12/95]
Before fastening the front seat belt, make sure
the shoulder belt passes through the belt holder
on the top of the seatback.
[SS12600( ALL)12/95]
To fasten the belt,pull the lap/shoulder belt
from the retractor so that the shoulder portion of
the belt crosses your shoulder and chest. Be sure
the belt is not twisted. If it is, remove the twist.
Insert the belt tongue into the proper buckle
until you hear a snap and feel it latch. Make
sure the tongue is securely fastened in the
buckle.
[SS12800(M )04/96]
one third page art:0011200-C
Fastening the front seat combination lap and shoulder belt
(coupe models)
File:06rcssm.ex
Update:Mon Feb 24 10:16:50 1997

115 [SS12900(M )12/95]
one third page art:0011225-B
Fastening the front seat combination lap and shoulder belt
(convertible models)
[SS13100(M )12/95]
one third page art:0010502-A
Fastening the rear seat combination lap and shoulder belt
coupe and convertible
*
[SS13200( ALL)02/96]
NOTE: Be sure to read and understand
Important Safety Belt Informationin
this chapter.
% [SS13500(M )12/95]
Safety Belts for Front Passenger (Coupe
Only) and Rear (Coupe and Convertible)
Outboard Seating Positions
[SS13800(M )12/95]
Your vehicle is equipped with a dual locking
mode retractor on the shoulder belt portion of
the combination lap/shoulder safety belt for
front seat passengers (coupe) and rear outboard
passenger seats (coupe and convertible).
File:06rcssm.ex
Update:Mon Feb 24 10:16:50 1997

116
*
[SS13900( ALL)02/96]
Dual locking mode retractors operate in two
ways:
*
[SS14000( ALL)02/96]
Vehicle sensitive (emergency) locking mode
[SS14100( ALL)12/95]
In this operating mode, the shoulder belt
retractor will allow the occupant freedom of
movement, locking tight only on hard braking,
hard cornering or impacts of approximately
5 mph (8 km/h) or more. The retractor can also
be made to lock by pulling/jerking on the belt.
%*
[SS14200( ALL)02/96]
Automatic locking mode
*
[SS14300( ALL)08/95]
In this operating mode, the shoulder belt
retractor will be automatically locked and remain
locked when the combination lap/shoulder
safety belt is buckled, and does not allow the
occupant freedom of movement. This mode
provides the following:
[SS14400( ALL)04/96]
q
A tight lap/shoulder belt fit on the occupant.
[SS14500( ALL)04/96]
q
Child seat or infant carrier installation
restraint.
*
[SS14600( ALL)03/96]
WARNING
Rear-facing child seats or infant carriers
should never be placed in the front seats.
*
[SS14700( ALL)01/96]
This modemust be usedwhen installing a child
safety seat on the front passenger seat and rear
outboard seats where dual locking retractors are
provided.
File:06rcssm.ex
Update:Mon Feb 24 10:16:50 1997

117
*
[SS14800( ALL)01/96]
To switch the retractor from the emergency
locking mode to the automatic locking mode,
perform the following steps:
*
[SS14900( ALL)02/96]
1. Buckle the lap/shoulder combination belt.
*
[SS15000( ALL)01/96]
2. Grasp the shoulder portion of the belt and
pull downward until all of the belt is
extracted and, when allowed to retract, a
clicking sound is heard. At this time, the belt
retractor is in the automatic locking mode
(child restraint mode).
*
[SS15100( ALL)12/95]
3. A clicking sound will continue to be heard
as the belt is allowed to retract.
[SS15200( ALL)04/96]
NOTE: When the combination lap/shoulder
belt is unbuckled and allowed to
retract completely, the retractor will
switch back to the vehicle sensitive
(emergency) locking mode. See the
detailed instructions underSafety Seats
for Childrenin this chapter.
% [SS15300(M )12/95]
Front Passenger Lap Belt Retractor
(Convertible Only)
[SS15400(M )02/96]
Dual locking mode passenger seat lap belt
retractors operate in two ways:
[SS15500(M )02/96]
Your convertible is equipped with a dual locking
mode retractor on thelap beltpart of the
lap/shoulder belt for the front seat passenger.
*
[SS15600(M )02/96]
Vehicle sensitive (emergency) locking mode
[SS15700(M )12/95]
In this operating mode, the lap belt retractor will
allow the occupant freedom of movement,
locking tight only on hard braking, hard
cornering or impacts of approximately 5 mph
(8 km/h) or more. The retractor cannot be made
to lock by pulling on the belt.
File:06rcssm.ex
Update:Mon Feb 24 10:16:50 1997

118 %
*
[SS15800(M )02/96]
Automatic locking mode
[SS15900(M )04/96]
In this operating mode, the lap belt retractor will
remain locked and does not allow the occupant
freedom of movement. This mode provides the
following:
*
[SS16000(M )01/96]
q
A tight lap/shoulder belt on the occupant.
*
[SS16100(M )01/96]
q
Child safety seat installation.
[SS16200(M )12/95]
This modemust be usedwhen installing a
forward facing child safety seat on the front
passenger seat. To switch the retractor from
the vehicle sensitive (emergency) locking
mode to the automatic locking mode,
perform the following steps:
*
[SS16300(M )03/96]
WARNING
Rear-facing child seats or infant carriers
should never be placed in the front seats.
[SS16400(M )12/95]
1. Buckle the lap/shoulder belt.
[SS16500(M )04/96]
2. Grasp the lap portion of the belt below the
child seat label. Pull upward until all of the
belt is extracted and a click is heard. At this
time, the lap belt retractor is in the
automatic locking mode (child restraint
mode).
*
[SS16600(M )12/95]
3. Allow the belt to retract. A clicking sound
will be heard as the belt retracts. This
indicates that the retractor is in the
automatic locking mode.
[SS16700(M )04/96]
4. Push down on the child seat as you pull
down on the belt to remove slack in the belt.
File:06rcssm.ex
Update:Mon Feb 24 10:16:50 1997

119
*
[SS16800(M )02/96]
NOTE: When the combination lap/shoulder
belt is unbuckled and allowed to
retract completely, the retractor will
switch to the vehicle sensitive
(emergency) locking mode. See the
detailed instructions underSafety Seats
for Childrenin this chapter.
*
[SS18300( ALL)01/96]
WARNING
The lap belts should fit snugly and as low
as possible around the hips, not around
the waist.
*
[SS18500( ALL)02/96]
WARNING
Each seating position in your vehicle has a
specific safety belt assembly which is
made up of one buckle and one tongue
that are designed to be used as a pair. 1)
Use the shoulder belt on the outside
shoulder only. Never wear the shoulder
belt under the arm. 2) Never swing it
around your neck over the inside
shoulder. 3) Never use a single belt for
more than one person.
File:06rcssm.ex
Update:Mon Feb 24 10:16:50 1997
