FORD MUSTANG 1998 4.G Owner's Guide

²Push the AUDIO
control repeatedly
until the display
reads TREB.
²Press (+) or (þ) on
the volume control
to increase or
decrease treble output.
Speaker balance adjust
Speaker sound distribution can be adjusted between
the right and left speakers.
²Push the AUDIO
control repeatedly
until the display
reads BAL.
²Press the (+) side of
the volume control
to shift sound to the
right speakers.
²Press the (þ) side of the volume control to shift
sound to the left speakers.
Speaker fade adjust
Speaker sound distribution can be adjusted between
the front and rear speakers.
²Push the AUDIO
control repeatedly
until the display
reads FADE.
²Press the (+) side of
the volume control
to shift sound to the
front speakers.
²Press the (þ) side of the volume control to shift
sound to the rear speakers.
Tape play select
Insert a cassette tape into the cassette deck.
AUDIO
VOLUME
AUDIO
VOLUME
AUDIO
VOLUME
Controls and features
31

Push only slightly when inserting a cassette tape
(with the open edge to the right). A cassette deck
loading mechanism pulls the tape in the rest of the
way.
Press PLAY to begin
cassette tape play.
Rewind/fast forward function in tape mode
Press the control to
rewind the tape.
Play will continue once
the beginning of the
tape is reached or rewind is stopped.
Press the control to
fast forward the tape.
Once the end of the
tape is reached, tape
direction reverses and the opposite side of the tape
plays.
Tape eject
Press the control to
stop and eject a tape.
DolbyTnoise reduction
Dolbytnoise reduction
manufactured under
license from Dolby
Laboratories Licensing
Corporation operates only in tape mode. Dolbyt
reduces the amount of hiss and static during tape
playback.
Press the
button to activate (and deactivate)
Dolbytnoise reduction.
PLAYPROG
REW
FF
EJCT
Controls and features
32

Setting the clock
Press the CLOCK
control while
simultaneously
depressing the SEEK
control.
²Press
to set the
hours.
²Press
to set the
minutes.
Premium AM/FM Stereo Single CD
Radio/Premium Sound or MACH 460 Sound
SystemTwith Single CD Radio
Power control
Press the control to
turn the audio system
on or off.
Volume control
Press the control to
raise or lower volume.
If the volume is set
above a certain level
and the ignition is
turned off, the volume
will come back on at a ªnominalº listening level
when the ignition switch is turned back on. If you
wish to maintain your preset volume level, turn the
audio system off with the power control before
switching off the ignition.
CLOCK
SEEK
DISC
12345CLOCK
VOL+
–SEEK
FFREV
PLAY
STOPSCANTUNE
AM/FMCOMP
AUDIOAUTO
PRESET
POWER EJECT
AUTOMATIC DNR
POWER
VOL+
–
Controls and features
33

AM/FM select
The AM/FM select
control works in radio
mode and allows you
to select AM or FM
frequency bands.
Press the control to switch between AM, FM1 or
FM2 memory preset stations.
Tune adjust
The tune control works in radio mode.
Tune adjust in radio mode
²Press the SCAN/
TUNE control twice.
²
Within approximately
five seconds, press
and release either
oron the
SEEK button to
change to the next
frequency up or
down.
²Press and hold downorto quickly move
through the frequencies.
Seek function
The seek function control works in radio mode.
Seek function in radio mode
²Pressto find the
next listenable
station down the
frequency band.
²Press
to find the
next listenable
station up the frequency band.
AM/FM
SCAN
TUNE
SEEK
SEEK
Controls and features
34

Scan function
The scan function
works in radio mode.
Scan function with compact disc radio
²Press the SCAN/
TUNE control once.
²Push
on the
SEEK control to
hear a brief sampling
of listenable stations
up the frequency
band.
²Push
to hear a
brief sampling of
listenable stations down the frequency band.
Setting memory preset stations
1. Select the frequency
band with the AM/FM
select control.
2. Select a station. Refer toTune adjustorSeek
functionfor more information on selecting a station.
3. Press and hold a memory preset control until the
sound returns, indicating the station is held in
memory on the control you selected.
If the battery is disconnected, the memory preset
stations will need to be reset.
Automatic memory store (if equipped)
Automatic memory store allows you to set strong
radio stations without losing your original manually
SCAN
TUNE
SCAN
TUNE
SEEK
AM/FM
12345CLOCK
Controls and features
35

set preset stations. This feature is helpful on trips
when you travel between cities with different radio
stations.
Starting automatic memory store
1. Select a frequency
using the AM/FM select
control.
2. Press the AUTO
PRESET control.
3. When the first six strong stations are filled, the
station stored in memory preset control 1 will start
playing.
If there are less than six strong stations available on
the frequency band, the remaining memory preset
controls will all store the last strong station
available.
Deactivating automatic memory store
To deactivate automatic memory store and return to
your audio system's manually set memory stations,
press the AUTO PRESET control again.
Speaker balance adjust
Speaker sound distribution can be adjusted between
the right and left speakers.
²Push the AUDIO
control repeatedly
until the display
reads BAL.
²Press the (+) side of
the volume control
to shift sound to the
right speakers.
²Press the (þ) side of
the volume control
to shift sound to the left speakers.
AM/FM
AUTO
PRESET
AUDIO
VOL+
–
Controls and features
36

Speaker fade adjust
Speaker sound distribution can be adjusted between
the front and rear speakers.
²Push the AUDIO
control repeatedly
until the display
reads FADE.
²Press the (+) side of
the volume control
to shift sound to the
front speakers.
²Press the (þ) side of
the volume control
to shift sound to the rear speakers.
Reverse/fast forward in CD mode
²Press the control for
less than three
seconds for slow
reverse.
²Press the control for more than three seconds for
fast reverse.
²Press the control for
less than three
seconds for slow
forward action.
²Press the control for more than three seconds for
fast forward action.
CD eject
Press the control to
stop and eject a CD.
If a disc is ejected from
the CD player but is
not removed within approximately 10 seconds, the
player will automatically reload the disc for storage
(unless the disc is automatically ejected because it
was inserted upside down, in which case the disc
will not be automatically reloaded).
AUDIO
VOL+
–
REV
FF
EJECT
Controls and features
37

Compression feature
Compression adjust brings soft and loud CD
passages together for a more consistent listening
level.
Press the COMP control to activate and deactivate
compression adjust.
The effect of the feature varies with the music
content.
Setting the clock
Press the CLOCK
control while
simultaneously
depressing the SEEK control.
²Press
to set the
hours.
²Press
to set the
minutes.
Single Disc CD Player (if equipped)
Power and volume control
The compact disc player operates when the audio
system is on and a CD is inserted (label side up).
The volume is controlled by the VOLUME control on
the audio system.
CLOCK
SEEK
EJECT
AMS
SCANPLAY/STOPREV/FFSHUFFLE COMPRESS
DISC
Controls and features
38

Play function
The system enters the
PLAY mode when a CD
is loaded, label side up,
into the disc opening.
The PLAY indicator will illuminate. The CD
automatically loads into the unit and begins play at
the beginning of the first track. When the CD
reaches the end, the disc player automatically
returns to the beginning of the CD and resumes
play.
Stop function
Press the PLAY/STOP
control to temporarily
stop CD play. The stop
indicator illuminates
and operation returns to the radio or tape mode.
Press the control again to resume CD play.
Scan function
Press the SCAN control
to enter the scan
mode. The CD player
will begin scanning the
CD, stopping on each listenable track for
approximately eight seconds. This continues until
you press the SCAN control a second time or eject
the CD. While in the scan mode, the display flashes
SCAN.
Reverse/fast forward
To quickly
search for
a particular
point in a selection, press the right side of the
REV/FF control (to fast forward) or the left side (to
reverse). If you hold down the desired function for
longer than a few seconds, the process will speed
up. Release the button when you have reached the
desired point of the CD.
PLAY/STOP
PLAY/STOP
SCAN
REV/FF
Controls and features
39

If you hold down the fast forward control until the
end of the CD is reached, the display will show the
end time of the last track and the sound will be
muted. When the fast forward control is released,
the player will resume play at the beginning of the
first track.
AMS control
The AMS (Automatic
Music Search) control
on your CD player
allows you to quickly find a particular selection on
the disc. Press the left side of the AMS control to
locate a previous selection, or the right side to
locate a later selection.
Compression feature
Press the COMPRESS
control to activate (and
deactivate) compression
adjust. Compression
adjust brings soft and loud CD passages together for
a more consistent listening level.
Shuffle feature
The shuffle feature
plays all tracks on the
current CD in random
order.
Press the SHUFFLE control to start this feature.
Random order play will continue until the control is
pressed again.
Eject
Push the EJECT
control to stop CD play,
eject the CD, and
resume radio or tape
operation.
AMS
COMPRESS
SHUFFLESHUFFLE
EJECT
Controls and features
40
