Vehicle Symbol Glossary
Power Windows
Front/Rear
Power Window
Lockout
Child Safety Door
Lock/UnlockInterior Luggage
Compartment
Release Symbol
Panic AlarmEngine Oil
Engine CoolantEngine Coolant
Temperature
Do Not Open When
HotBattery
Avoid Smoking,
Flames, or SparksBattery Acid
Explosive GasFan Warning
Power Steering
FluidMaintain Correct
Fluid LevelMAX
MIN
Emission SystemEngine Air Filter
Passenger
Compartment Air
FilterJack
Check fuel cap
Introduction
5

5. Fully install the engine oil filler cap by turning the
filler cap clockwise 1/4 of a turn until three clicks
are heard until it is latched.
To avoid possible oil loss, DO NOT operate the
vehicle with the engine oil level indicator
and/or the engine oil filler cap removed.
Engine oil and filter recommendations
Look for this
certification trademark.
SAE 5W-20 engine oil is recommended.
Only use oils ªCertified For Gasoline Enginesº by the
American Petroleum Institute (API). Use Motorcraft
or an equivalent oil meeting Ford specification
WSS-M2C153±H.SAE 5W-20 oil provides
optimum fuel economy and durability
performance meeting all requirements for your
vehicle's engine.
Do not use supplemental engine oil additives, oil
treatments or engine treatments. They are
unnecessary and could, under certain conditions,
lead to engine damage which is not covered by your
warranty.
Change your engine oil and filter according to the
appropriate schedule listed in the scheduled
maintenance guide.
Ford production and aftermarket (Motorcraft) oil
filters are designed for added engine protection and
long life. If a replacement oil filter is used that does
not meet Ford material and design specifications,
start-up engine noises or knock may be experienced.
It is recommended you use the appropriate
Motorcraft oil filter (or another brand meeting Ford
specifications) for your engine application.
Maintenance and care
154

Many of the world's
automakers issued the
World-wide Fuel
Charter that
recommends gasoline
specifications to
provide improved
performance and
emission control
system protection for your vehicle. Gasolines that
meet the World-wide Fuel Charter should be used
when available. Ask your fuel supplier about
gasolines that meet the World-wide Fuel Charter. In
Canada, look for fuels that display theAuto
Makers' Choiceylogo.
Cleaner air
Ford endorses the use of reformulated
ªcleaner-burningº gasolines to improve air quality.
Running out of fuel
Avoid running out of fuel because this situation may
have an adverse affect on powertrain components.
If you have run out of fuel:
²You may need to cycle the ignition from OFF to
ON several times after refueling, to allow the fuel
system to pump the fuel from the tank to the
engine.
²Your ªService Engine Soonº indicator may come
on. For more information on the ªService Engine
Soonº indicator, refer to theInstrumentation
chapter.
Fuel Filter
For fuel filter replacement, see your dealer or a
qualified service technician. Refer to the scheduled
maintenance guide for the appropriate intervals for
changing the fuel filter.
Maintenance and care
185

Replace the fuel filter with an authorized
Motorcraft part. The customer warranty may
be void for any damage to the fuel system if an
authorized Motorcraft fuel filter is not used.
ESSENTIALS OF GOOD FUEL ECONOMY
Measuring techniques
Your best source of information about actual fuel
economy is you, the driver. You must gather
information as accurately and consistently as
possible. Fuel expense, frequency of fillups or fuel
gauge readings are NOT accurate as a measure of
fuel economy. We do not recommend taking fuel
economy measurements during the first 1 600 km
(1 000 miles) of driving (engine break-in period).
You will get a more accurate measurement after
3 000 km±5 000 km (2 000 miles-3 000 miles).
Filling the tank
The advertised fuel capacity of the fuel tank on your
vehicle is equal to the rated refill capacity of the fuel
tank as listed in theRefill capacitiessection ofthe
Capacities and specificationschapter.
The advertised capacity is the amount of the
indicated capacity and the empty reserve combined.
Indicated capacity is the difference in the amount of
fuel in a full tank and a tank when the fuel gauge
indicates empty. Empty reserve is the small amount
of fuel remaining in the fuel tank after the fuel
gauge indicates empty.
The amount of usable fuel in the empty reserve
varies and should not be relied upon to
increase driving range. When refueling your
vehicle after the fuel gauge indicates empty,
you might not be able to refuel the full amount
of the advertised capacity of the fuel tank due
to the empty reserve still present in the tank.
Maintenance and care
186

MOTORCRAFT PART NUMBERS
Component 3.8L OHV V6 engine 4.6L SOHC V8 engine
Air filter element FA-1611 FA-1634
Fuel filter FG-986 FG-986B
Battery BXT-59 BXT-59
Oil filter FL-400S FL-820S
PCV valve EV-152 EV-98
Spark plugs* AWSF-42EE** AWSF-32P
* Refer to Vehicle Emissions Control Information (VECI)
decal for spark plug gap information.
**If a spark plug is removed for inspection, it must be
reinstalled in the same cylinder. If a spark plug needs to
be replaced, use only spark plugs with the same service
part number suffix letter as shown on the engine decal.
REFILL CAPACITIES
Fluid Ford Part Name Application Capacity
Brake fluid High Performance
DOT 3 Motor
Vehicle Brake
FluidAll Fill to line on
reservoir
Engine oil
(includes filter
change)Motorcraft SAE
5W-20 Super
Premium Motor
OilAll 4.7L (5.0 quarts)
Engine coolant
1Motorcraft
Premium Engine
Coolant
(green-colored)
orMotorcraft
Premium Gold
Engine Coolant
(yellow-colored)3.8L OHV V6
engine11.2L (11.8
quarts)
4.6L SOHC V8
engine13.3L (14.1
quarts)
Power steering
fluidMotorcraft
MERCONtAT F3.8L OHV V6
engineKeep in FULL
HOT range on
dispstick
4.6L SOHC V8
engineFill to between
MIN and MAX
lines on reservoir
Capacities and specifications
206

The Dispute
Settlement
Board ..................... 216
Utilizing the
Mediation/Arbitration
Program ................. 219
D
Daytime running lamps
(see Lamps) .............. 18
Defrost
rear window ............ 19
Dipstick
automatic transmission
fluid ........................ 167
engine oil ............... 151
Doors
lubricant
specifications ........ 208
Driving under special
conditions
through water ....... 128
E
Emergencies, roadside
jump-starting ........ 141
Emission control
system ...................... 190
Engine .............. 209±210
check engine/service
engine soon light ...... 9
cleaning ................. 202
coolant ................... 157
idle speed
control ................... 171
lubrication
specifications. 208±209refill capacities ...... 206
service
points ............. 150±151
starting after a
collision ................. 130
Engine block
heater ....................... 106
Engine oil ................ 151
checking and
adding .................... 151
dipstick .................. 151
filter,
specifications. 154, 206
recommendations.. 154
refill capacities ...... 206
specifications. 208±209
Exhaust fumes ........ 107
F
Floor mats ................. 60
Fluid capacities ....... 206
Foglamps ................... 19
Fuel .......................... 180
calculating fuel
economy ................ 186
cap ................... 11, 182
capacity ................. 206
choosing the
right fuel ................ 183
comparisons with EPA
fuel economy
estimates ............... 190
detergent in fuel ... 185
filling your vehicle
with
fuel ......... 180, 182, 186
filter,
specifications. 185, 206
Index
230

Item Information
Required fuel Unleaded fuel only - 87
octane
Fuel tank capacity 59.4L (15.7 gallons)
Engine oil capacity (includes
filter change)4.7L (5.0 quarts). Use
Motorcraft SAE 5W-20 Super
Premium Motor Oil, Ford
specification WSS-M2C153-H
Tire size and pressure See label on inside of glove
box door.
Hood release Pull handle under the left
side of the instrument panel.
Coolant capacity-3.8L OHV
V6 engine
111.2L (11.8 quarts)
Coolant capacity-4.6L SOHC
V8 engine
113.3L (14.1 quarts)
Power steering fluid capacity Fill to line on reservoir or
dipstick. Use Motorcraft
MERCONtAT F.
Manual transmission fluid
capacity-3.8L OHV V6 engine
2
2.6L (5.6 pints). Use
Motorcraft MERCONtAT F.3
Manual transmission fluid
capacity-4.6L SOHC V8
engine
2
3.8L (8.0 pints). Use Mobil 1
SynthetictAT F.3
Automatic transmission fluid
capacity-3.8L OHV V6 engine
2
13.1L (13.9 quarts). Use
Motorcraft MERCONtV ATF.
4
Automatic transmission fluid
capacity-4.6L SOHC V8
engine
2
12.0L (12.8 quarts). Use
Motorcraft MERCONtV ATF.
4
Windshield washer fluid 3.8L (4.0 quarts). Use
Ultra-Clear Windshield
Washer Concentrate.
1Use either green-colored Motorcraft Premium Engine
Coolant or yellow-colored Motorcraft Premium Gold
Engine Coolant. DO NOT USE Ford Extended Life Engine
Coolant (orange in color). Refer toAdding engine
coolant, in the Maintenance and Care chapter.
2Ensure the correct automatic transmission fluid is used.
Transmission fluid requirements are indicated on the
dipstick or on the dipstick handle. MERCONtand
Filling station information
239
