service FORD MUSTANG 2003 Workshop Manual

REMOVAL AND INSTALLATION
Switch —
Window Regulator Control
Removal
1. CAUTION: Use a shop towel or similar material between the tool and the door trim
panel or damage to the door trim panel may occur.
Position the window regulator switch plate aside. 1. Pull at the service notch.
2. Lift to release the clip at the rear edge.
2. Remove the window regulator control switch. 1. Remove the screws.
2. Disconnect the connectors.
Installation 1. To install, reverse the removal procedure.
SECTION 501-
11: Glass, Frames and Mechanisms 2003 Mustang Workshop Manual Klj . 1 ba
22003 Mustang Workshop Manual
18. 11. 2011file:///C:/Ford/2000 - 2004/tsocache/SHEF_5108/S3B~us~en~ ...

REMOVAL AND INSTALLATION
Switch —
Door Lock
Removal
1. CAUTION: Place a rag between the window regulator switch plate and the door trim
panel to avoid damaging the door trim panel.
Position the window regulator switch plate (14524) aside. 1. Pull at service notch.
2. Lift to release the clip at the rear edge.
2. Remove the screws and the door lock switch (14017).
Installation 1. To install, reverse the removal procedure.
SECTION 501-
14A: Handles, Locks, Latches and Mechanisms 2003 Mustang Workshop Manual Klj . 1 ba
22003 Mustang Workshop Manual
18. 11. 2011file:///C:/Ford/2000 - 2004/tsocache/SHEF_5108/S3B~us~en~ ...

z
If the driver safety belt is buckled while the warning indicator is illuminated and the reminder
chime is sounding, then the safety belt warning indicator and reminder chime turn off.
z If the driver safety belt is buckled before the ignition switch is turned to ON, then the safety belt
warning light will turn on for 3 seconds and then off. The indicator chime will remain off.
Belt Minder (if equipped)
The Belt Minder feature is a supplemental warning to the safety belt warning function. This feature
provides additional reminders to the driver that the driver's safety belt is unbuckled by intermittently
sounding a chime and illuminating the safety belt warning lamp in the instrument cluster.
Safety Belt Extension
A safety belt that is too short even when fully extended can be lengthened. The safety belt extension
(611C22) is available. This assembly will add approximately 20 cm (8 inches) to the length of the
safety belt. Use the safety belt extension only if the safety belt is too short when fully extended. Do not
use the safety belt extension to alter the fit of the shoulder belt across the torso. Safety belt extensions
are available at no cost from any authorized Ford or Lincoln- Mercury dealer.
Lower Anchors and Tethers for Children (LATCH)
The lower anchors and tethers for children (LATCH) system is a standarized and uniform attachment
system for installing child safety seats in passenger vehicles. LATCH- equipped child safety seats have
two lower attachments that connect to the vehicle portion of the LATCH system.
The vehicle portion of the system consists of two attachment points (6- mm wires) bolted to the floor
pan at both second row outboard seating positions. The attachment points protrude from the biteline
between the seat cushion and seat backrest.
If a child safety seat was in use during a collision, inspect the vehicle portion of the system for
damage. If any of the attachment points (6- mm wires) are damaged, a new one must be installed. See
the appropriate removal and installation procedure in this section for service.
Attaching Safety Seats with Tether Straps
Some manufacturers make child safety seats that include a tether strap that goes over the back of the
vehicle seat and attaches to an anchoring point. Other manufacturers offer the tether strap as an
accessory. Contact the manufacturer of the child safety seat for information about ordering a tether
strap. If... Then...
The driver's safety belt is not buckled
approximately 5 seconds after the safety
belt warning light has turned off... The Belt Minder feature is activated —
the safety belt
warning light illuminates and the warning chime sounds for
6 seconds every 30 seconds, repeating for approximately
5 minutes or until safety belt is buckled. The driver's safety belt is buckled while
the safety belt indicator light is
illuminated and the safety belt warning
chime is sounding... The Belt Minder feature will not activate.
The driver's safety belt is buckled before
the ignition switch is turned to the ON
position... The Belt Minder feature will not activate. Klj . 2 ba
32003 Mustang Workshop Manual
18. 11. 2011file:///C:/Ford/2000 - 2004/tsocache/SHEF_5108/S3B~us~en~ ...

Component Test
Carry out the appropriate Functional Test(s) as determined in Inspection and Verification.
Functional Test I (Buckle and Tongue)
The safety belt buckle and tongue assembly must operate freely during the latching and unlatching
function. Fasten the safety belt by inserting the tongue (male portion) into the buckle (female portion).
1. Verify the following during the latching sequence: zTongue insertion is not hindered by excessive effort.
z A click is heard when the buckle latches the tongue.
2. Verify the system integrity by forcefully pulling on the belt webbing.
3. Unlatch the belt by fully depressing the buckle release button, and allowing the belt to release and retract.
4. Verify the following during the unlatching process: zPush-button depression does not require excessive effort.
z Tongue can be removed easily from the buckle.
5. Repeat the above steps three times.
6. If the inspection reveals an obvious concern(s) that can be readily identified, service as required. Do not attempt to carry out any repair on the buckle and tongue assembly. If a
concern exists with either component, a new safety belt buckle and safety belt and retractor
assembly must be installed.
Functional Test II (Retractor)
The safety belt and retractor assembly must be freely operational for extraction and retraction of the
safety belt webbing between full extension and in- vehicle stowed positions.
1. Extract and retract the safety belt between the full extension and stowed positions.
2. Verify the retractor operates without excessive effort or binding.
3. Install a new safety belt buckle retractor and tongue assembly if no obvious concerns are noticed and the complaint has been verified. z
Circuitry.
z Excessive pressure on the
occupant during normal
wear, the webbing cannot
be extracted, excessive
slack in webbing does not
retract z
Front safety
belt retractor
and tongue.
z Rear safety
belt retractor
and tongue. z
Carry out the Functional
Test. REFER to
Component Test.
INSTALL a new retractor
and tongue if necessary. Klj . 2 ba
42003 Mustang Workshop Manual
18. 11. 2011file:///C:/Ford/2000 - 2004/tsocache/SHEF_5108/S3B~us~en~ ...

Functional Test III (System Road Test Inspection)
1. NOTE: If the RH or the rear safety belts are to be tested, the assistance of a passenger is
required.
Fasten the safety belts and proceed to a safe area.
2. Attain a speed of 8 km/h (5 mph).
3. WARNING: The driver and passenger must be prepared to brace themselves if the
retractor does not lock.
Test the safety belts. 1. Grasp the shoulder harness and prepare to lean forward.
2. WARNING: The maximum brake application should be on dry concrete or
equivalent hard surface, NEVER on wet pavement or gravel.
WARNING: The driver and passenger must be prepared to brace themselves
in the event the retractor does not lock.
Make a maximum brake application without a skid.
3. NOTE: Do not jerk on the safety belt webbing when carrying out this test. Lean forward slightly when the brake application is made.
4. The safety belts should lock up with minimum webbing extension.
5. If there is a lockup of both shoulder straps, the safety belt assemblies are functioning correctly. Should either or both retractors fail to lock up at the 8 km/h (5 mph) speed, repeat the test at a
constant 24 km/h (15 mph) speed. (This test must be carried out with the assistance of a RH
front or rear passenger if the RH front or rear safety belts are to be tested).
6. CAUTION: Before installing a new safety belt assembly, inspect the mounting area
for damage and distortion. If the retractor of a new safety belt assembly has been bolted
into a damaged or distorted mounting area, the retractor could be warped and may not
function. If this is the case, remove the retractor and return the sheet metal to the
original configuration and install another complete safety belt assembly.
If the retractors do not lock up at the 24 km/h (15 mph) test, return the vehicle for service of
malfunctioning safety belts.
Functional Test IV (Automatic Locking Retractor) WARNING: After any vehicle collision, the safety belt system at all outboard seating
positions (except driver, which has no "automatic locking retractor" feature) must be checked
by a qualified technician to verify that the "automatic locking" feature for child seats is still
functioning correctly, in addition to other checks for correct safety belt system function. A new
safety belt and retractor assembly must be installed if the safety belt assembly's "automatic
locking retractor" feature or any other safety belt function is not operating correctly when
checked according to the procedures in the workshop manual. Failure to install a new safety
belt and retractor assembly could increase the risk of injury in collisions.
1. Position the seat back into the full up position. Klj . 3 ba
42003 Mustang Workshop Manual
18. 11. 2011file:///C:/Ford/2000 - 2004/tsocache/SHEF_5108/S3B~us~en~ ...

DIAGNOSIS AND TESTING
Air Bag Supplemental Restraint System (SRS)
Refer to Wiring Diagrams Cell
46 , Air Bag for schematic and connector information.
Restraint System Diagnostic Tool Warning WARNING: This tool is for restraint system service only. Remove from vehicle prior to
road use. Failure to remove could result in injury and possible violation of vehicle safety
standards.
Diagnosing Customer Concerns Without Hard DTCs
If a lamp fault code (LFC) is reported by the customer but is not present when the vehicle comes in for
service, follow the Diagnostic Instructions procedure in this section to identify the intermittent DTC.
Once the DTC is known, read the Normal Operation section of the pinpoint test for the DTC involved.
zFollow the deactivation procedure in this section.
z Determine the location of components involved in creating that code.
z Perform a thorough visual inspection of:
„components.
„ connectors.
„ splices and wiring harnesses.
„ pinched wires.
„ worn insulation on conductors.
Refer to the Possible Causes section of the pinpoint test for the DTC involved, which lists the common
concerns that relate to the DTC. Concerns are listed according to priority.
Diagnosing Customer Concerns with Hard DTCs
WARNING: The restraint system diagnostic tool is for restraint system service only.
Remove from vehicle prior to road use. Failure to remove could result in injury and possible
violation of vehicle safety standards. SECTION 501-
20B: Supplemental Restraint System 2003 Mustang Workshop Manual Special Tool(s)
Diagnostic Tool, Restraint
System
418-
F088 (105- R0012) Klj . 1 ba
62003 Mustang Workshop Manual
18. 11. 2011file:///C:/Ford/2000 - 2004/tsocache/SHEF_5108/S3B~us~en~ ...

Most air bag supplemental restraint system (SRS) diagnostic procedures will require the use of the
deactivation and reactivation procedures in this section.
The deactivation and reactivation require the installation and removal of restraint system diagnostic
tools. These procedures require removal of driver air bag module, and the disconnection of the
passenger air bag module. This reduces the risk of deployment of air bag modules and safety belt
pretensioners while diagnostics are being carried out.
Restraint system diagnostic tools are required to carry out diagnosis and testing of the supplemental
restraint system (SRS). It is not acceptable to short-circuit the air bag module connections with a
jumper wire. If a jumper wire is used to short- circuit the air bag module connections, a lamp fault code
(LFC) will be displayed.
WARNING: The restraint system diagnostic tool is for restraint system service only.
Remove from vehicle prior to road use. Failure to remove could result in injury and possible
violation of vehicle safety standards.
The reactivation procedure requires the removal of any restraint system diagnostic tools installed and
the reconnection of any air bag modules disconnected.
Deactivation Procedure
WARNING: If the supplemental restraint system (SRS) is being serviced, the system must
be deactivated and restraint system diagnostic tools must be installed. Refer to Air Bag Supplemental Restraint System (SRS) in this section.
The air bag restraint system diagnostic tools must be removed and the air bag modules
reconnected when the system is reactivated to avoid non- deployment in a collision, resulting in
possible personal injury.
NOTE: Diagnostics or repairs are not to be performed on a seat equipped with a seat side air bag with
the seat in the vehicle. Prior to attempting to diagnose or repair a seat concern when equipped with a
seat side air bag, the seat must be removed from the vehicle and the restraint system diagnostic tools
must be installed in the seat side air bag electrical connectors. The restraint system diagnostic
tools must be removed prior to operating the vehicle over the road.
NOTE: After diagnosing or repairing an SRS, the restraint system diagnostic tools must be
removed before operating the vehicle over the road.
NOTE: After diagnosing or repairing a seat system, the restraint system diagnostic tools must be
removed before operating the vehicle over the road.
NOTE: The SRS must be fully operational and free of faults before releasing the vehicle to the
customer.
1. WARNING: To avoid accidental deployment and possible personal injury, the
backup power supply must be depleted before repairing or replacing any front or side air
bag supplemental restraint system (SRS) components and before servicing, replacing,
adjusting or striking components near the front or side air bag sensors, such as doors,
instrument panel, console, door latches, strikers, seats and hood latches.
Please refer to the appropriate vehicle shop manual to determine location of the front air
bag sensors.
The side air bag sensors are located at or near the base of the B- pillar. Klj . 2 ba
62003 Mustang Workshop Manual
18. 11. 2011file:///C:/Ford/2000 - 2004/tsocache/SHEF_5108/S3B~us~en~ ...

To deplete the backup power supply energy, disconnect the battery ground cable and
wait at least one minute. Be sure to disconnect auxiliary batteries and power supplies (if
equipped).
Disconnect the battery ground cable. For additional information, refer to
Section 414 - 01 .
2. Wait at least one minute for the backup power supply in the restraints control module (RCM) to deplete its stored energy.
3. WARNING: Carry a live air bag module with the air bag and trim cover pointed away
from your body. This will reduce the risk of injury in the event of an accidental
deployment.
WARNING: Do not set an air bag module down with the trim cover face down. This
will reduce the risk of injury in the event of an accidental deployment.
Remove the driver air bag module from the vehicle. Refer to Driver Air Bag Module in this
section.
4. WARNING: The restraint system diagnostic tool is for restraint system service only.
Remove from vehicle prior to road use. Failure to remove could result in injury and
possible violation of vehicle safety standards.
Connect a restraint system diagnostic tool to the vehicle harness at the top of the steering
column.
5. Disconnect the passenger air bag module electrical connector.
6. WARNING: The restraint system diagnostic tool is for restraint system service only.
Remove from vehicle prior to road use. Failure to remove could result in injury and
possible violation of vehicle safety standards.
Connect a restraint system diagnostic tool to the vehicle harness.
7. Reconnect the battery ground cable. For additional information, refer to Section 414 - 01 .
Reactivation Procedure 1. WARNING: The restraint system diagnostic tool must be removed and the air bag
modules reconnected when the system is reactivated to avoid non- deployment in a
collision, resulting in possible personal injury.
WARNING: The restraint system diagnostic tool is for restraint system service only.
Remove from vehicle prior to road use. Failure to remove could result in injury and
possible violation of vehicle safety standards.
Disconnect the battery ground cable. Refer to Section 414 - 01 .
2. Wait at least one minute for the backup power supply in the restraints control module (RCM) to deplete its stored energy.
3. Remove the restraint system diagnostic tool from the vehicle harness connector at the top of the Klj . 3 ba
62003 Mustang Workshop Manual
18. 11. 2011file:///C:/Ford/2000 - 2004/tsocache/SHEF_5108/S3B~us~en~ ...

steering column.
4. WARNING: Carry a live air bag module with the air bag and trim cover pointed away
from your body. This will reduce the risk of injury in the event of an accidental
deployment.
Install the driver air bag module. Refer to Driver Air Bag Module in this section.
5. WARNING: The restraint system diagnostic tool is for restraint system service only.
Remove from vehicle prior to road use. Failure to remove could result in injury and
possible violation of vehicle safety standards.
Remove the restraint system diagnostic tool from the vehicle harness connector at the
passenger air bag module.
6. Connect the passenger air bag module electrical connector.
7. Reconnect the battery ground cable. For additional information, refer to Section 414 - 01 .
8. Prove out the system.
Prove Out Procedure
Turn the ignition switch from the OFF to the RUN position and visually monitor the air bag indicator
with the air bag modules or restraint system diagnostic tools installed. The air bag indicator will light
continuously for approximately six seconds and then turn off. If an air bag supplemental restraint
system (SRS) fault is present, the air bag indicator will either: zfail to light.
z remain lit continuously.
z flash.
The flashing might not occur until approximately 30 seconds after the ignition switch has been turned
from the OFF to the RUN position. This is the time required for the restraints control module (RCM) to
complete the testing of the SRS. If the air bag indicator is inoperative and an SRS fault exists, a chime
will sound in a pattern of five sets of five beeps. If this occurs, the air bag indicator will need to be
repaired before diagnosis can continue.
Glossary
Restraint System Diagnostic Tool
Restraint system diagnostic tools are used to simulate air bag module connections to the system.
Disconnect the Component
Disconnect the component means disconnect the component vehicle harness connector. It does not
mean remove the component. Do not reconnect a disconnected component unless instructed to do so. Deactivate the System Klj . 4 ba
62003 Mustang Workshop Manual
18. 11. 2011file:///C:/Ford/2000 - 2004/tsocache/SHEF_5108/S3B~us~en~ ...

Deactivate the system means to perform the deactivation procedure. Refer to Deactivation Procedure
in this section.
Prove Out the System
Prove out the system means to turn the ignition switch from the OFF to the RUN position and visually
monitor the air bag indicator with the air bag modules installed. Refer to Prove Out Procedure in this
section.
Reactivate the System
Reactivate the system means to perform the reactivation procedure. Refer to Reactivation Procedure
in this section.
Reconnect the System
Reconnect the system means to reconnect all system components. Refer to Air Bag System
Reconnect Checklist in this section.
Install a New Component
Install a new component means to remove the existing component and install a new authorized part
obtained from Ford Customer Service Division.
Verify the System
Verify the system means to prove out the system with restraint system diagnostic tools for the air bag
modules in place of components.
Air Bag System Reconnect Checklist
The checklist below should be completed following diagnosis or repair of any air bag system concern.
1. Is the connector at the base of the steering column connected?
2. Are the air bag modules connected?
3. Is the restraints control module (RCM) connected?
4. Is the vehicle battery connected? Klj . 5 ba
62003 Mustang Workshop Manual
18. 11. 2011file:///C:/Ford/2000 - 2004/tsocache/SHEF_5108/S3B~us~en~ ...
