FORD PROBE 1996 2.G Owners Manual

214
*
[SV09350(ALL)05/95]
If your vehicle has problems with starting, rough
idle or hesitation problems when the engine is
cold, it may be caused by fuel with low
volatility. Try a different brand of fuel. If the
condition persists, see your dealer or a qualified
service technician.
*
[SV09520(ALL)04/95]
Gasolines for clean air
*
[SV09530(ALL)06/95]
Fuels in certain areas of the country are required
to contain oxygenates to improve air quality.
Common oxygenates are ethanol or grain alcohol
(blended at no more than 10%), methanol or
wood alcohol (blended at no more than 5% with
cosolvents and additives), and MTBE or methyl
tertiary butyl ether (blended at no more than
15%).
*
[SV09540(ALL)05/95]
Reformulated fuel is also required in certain
areas of the U.S. These fuels are designed to
further reduce the emissions from your vehicle.
*
[SV09550(ALL)06/95]
Generally, you should not experience difficulties
operating your vehicle on fuels containing
oxygenates. We encourage you to use these
fuels.
*
[SV10185(ALL)06/95]
Safety Information Relating to Automotive
Fuels
*
[SV10195(ALL)05/95]
RWARNING
Automotive fuels can cause serious injury
or death if misused or mishandled.
*
[SV10197(ALL)05/95]
q
Turn vehicle off when refueling
*
[SV10199(ALL)05/95]
q
Do not smoke when refueling. Fuels are
extremely flammable.
*
[SV10201(ALL)05/95]
q
Do not siphon any fuel by mouth.
File:prsvp.ex
Update:Fri Jun 23 19:33:26 1995

215
*
[SV10205(ALL)05/95]
RWARNING
Gasoline or gasoline blended with
methanol can cause blindness and
possible death when swallowed. If any
fuel is swallowed, call a physician or
poison control center immediately.
*
[SV10209(ALL)05/95]
q
Avoid breathing vapors while refueling.
*
[SV10211(ALL)05/95]
q
If fuel is splashed on the skin, wash with
soap and water.
*
[SV10225(ALL)05/95]
q
If fuel is splashed in the eyes, remove contact
lenses (if worn), flush with water for 15
minutes, and seek medical attention.
*
[SV10227(ALL)05/95]
Gasoline and gasoline blends may contain small
amounts of carcinogens, such as benzene.
Long-term exposure to unleaded gasoline vapors
has caused cancer in laboratory animals.
*
[SV10230(ALL)05/95]
If you are taking the medication ªAntabuseº or
other forms of disulfiram for the treatment of
alcoholism, vapor or skin contact with a
gasoline-methanol blend may cause the same
kind of adverse reaction as drinking an alcoholic
beverage. In sensitive individuals, serious
personal injury or sickness could result. Consult
a physician promptly if you experience an
adverse reaction.
%*
[SV11300(ALL)05/95]
Running Out of Fuel
*
[SV11350(ALL)05/95]
NOTE: Avoid running out of fuel because this
situation may have an adverse effect on
modern powertrain components.
*
[SV11500(ALL)05/95]
You may need to crank the engine several times
before the fuel system starts to pump fuel from
the tank to the engine.
File:prsvp.ex
Update:Fri Jun 23 19:33:26 1995

216 %
*
[SV11600(ALL)05/95]
Fuel Economy
*
[SV11700(ALL)05/95]
Fuel economy is an estimate of the efficiency of
your vehicle and can be calculated as Miles Per
Gallon (MPG) or Liters Per 100 Kilometers
(L/100K).
*
[SV11750(ALL)05/95]
Do not calculate fuel economy during your
vehicle's break-in period. This would not be an
accurate estimate of how much fuel your vehicle
will normally use.
*
[SV11800(ALL)05/95]
To calculate fuel economy:
*
[SV11900(ALL)06/95]
1. Fill the tank completely and record the
initial odometer reading.
*
[SV12000(ALL)05/95]
2. Every time you buy fuel record the
amount (in gallons or liters) purchased.
*
[SV12200(ALL)05/95]
3. After at least three to five tankfuls, fill the
fuel tank and record the final odometer
reading.
*
[SV12225(ALL)05/95]
4. Use these equations to calculate your fuel
economy:
*
[SV12250(ALL)05/95]
q
English: MPG = (total miles driven)V
(gallons used)
*
[SV12275(ALL)05/95]
q
Metric: L/100k = (liters used)V
(100 kilometers)
*
[SV12300(ALL)05/95]
Comparisons With EPA Estimates
*
[SV12400(ALL)05/95]
EPA fuel economy figures are obtained from
laboratory tests under simulated road conditions
and may not reflect the actual conditions you
experience or your style of driving. The EPA
fuel economy estimate is not a guarantee that
you will achieve the fuel economy shown.
File:prsvp.ex
Update:Fri Jun 23 19:33:26 1995

217
*
[SV12650(ALL)05/95]
The following decrease fuel economy:
*
[SV12700(ALL)05/95]
q
Lack of regular, scheduled maintenance
*
[SV12800(ALL)05/95]
q
Rapid acceleration and excessive speed
*
[SV12850(ALL)05/95]
q
Driving with your foot on the brake
*
[SV12902(ALL)05/95]
q
Sudden stops
*
[SV12950(ALL)05/95]
q
Extended engine idling
*
[SV13000(ALL)05/95]
q
Using speed control in hilly terrain
*
[SV13100(ALL)05/95]
q
Extended use of the A/C, defroster, rear
window defroster and other accessories
*
[SV13200(ALL)05/95]
q
Underinflated tires
*
[SV13300(ALL)05/95]
q
Heavy loads
*
[SV13400(ALL)05/95]
q
Aftermarket add-ons such as bike, ski or
luggage racks, bug deflectors, etc.
*
[SV13600(ALL)03/95]
Engine Oil Recommendations
*
[SV13610(ALL)05/95]
We recommend using Motorcraft oil or an
equivalent oil meeting Ford Specification
ESE-M2C153-E and displaying the American
Petroleum Institute CERTIFICATION MARK on
the front of the container.
*
[SV13650(ALL)03/95]
one third page art:0060021-E
The API Certification Mark
File:prsvp.ex
Update:Fri Jun 23 19:33:26 1995

218
*
[SV13670(ALL)01/95]
Neveruse:
*
[SV13680(ALL)01/95]
q
ªNon-Detergentº oils
*
[SV13690(ALL)04/95]
q
Oils labeled API SA, SB, SC, SD, SE, SF or SG
%*
[SV13700(ALL)01/95]
q
Additional engine oil additives, oil treatments
or engine treatments
*
[SV13725(ALL)04/95]
Engine oils with anSAE 5W-30viscosity are
PREFERREDfor your vehicle. They provide the
best engine performance, fuel economy and
engine protection for all climates down to-15ÊF
(-25ÊC).
%*
[SV13750(ALL)03/95]
Synthetic engine oils which are CERTIFIED and
of the preferred viscosity may be used in your
engine. The engine oil and oil filter must still be
changed according to the maintenance schedule.
*
[SV13775(ALL)01/95]
Checking and Adding Engine Oil
*
[SV13800(ALL)03/95]
Since the proper amount of engine oil is
important for safe engine operation, check the oil
using the dipstick each time you put fuel in
your vehicle. Remember the engine must be off,
the oil must be warm and the vehicle must be
parked on level ground.
*
[SV13900(ALL)04/95]
Checking the engine oil level:
*
[SV14000(ALL)02/95]
1. Turn the engine off after it has warmed up
and allow a few minutes for the engine oil
to drain back into the oil pan.
*
[SV14050(ALL)05/94]
2. Set the parking brake fully and make sure
that the gearshift is securely latched in P
(Park) (automatic transaxle) or 1 (First)
(manual transaxle).
*
[SV14100(ALL)02/95]
3. Open the hood. Protect yourself from engine
heat.
*
[SV14200(ALL)03/95]
4. Locate the engine oil dipstick (highlighted in
yellow) and carefully pull it out of the
engine.
File:prsvp.ex
Update:Fri Jun 23 19:33:26 1995

219
*
[SV14300(ALL)01/95]
5. Wipe the dipstick clean and put it back into
position, making sure it is fully seated.
[SV14400(ALL)01/93]
one inch art:0032075-A
Engine oil dipstick
[SV14500(ALL)05/95]
6. Carefully, pull the dipstick out again. If the
oil level is below the L line, add engine oil
as necessary. If the oil level is beyond the
letter F, engine damage or high oil
consumption may occur and some oil must
be removed from the engine.
*
[SV14600(ALL)01/95]
7. Put the dipstick back in and make sure it is
fully seated.
%*
[SV14700(ALL)03/95]
Adding engine oil
*
[SV14800(ALL)01/95]
It may be necessary to add some oil between oil
changes. Make sure you use a CERTIFIED
engine oil of the preferred viscosity. Your
vehicle's warranty coverage may not apply if
engine damage is caused by the use of improper
engine oil.
*
[SV15000(ALL)03/95]
Add engine oil through the oil filler cap
highlighted in yellow. To add oil, remove the
filler cap and use a funnel to pour oil into the
opening. Be careful not to overfill the engine.
Recheck the oil level after you finish adding oil.
File:prsvp.ex
Update:Fri Jun 23 19:33:26 1995

220 %
*
[SV16300(ALL)06/95]
Changing the Engine Oil and the Oil Filter
*
[SV16400(ALL)04/95]
Change the engine oil and oil filterper the
following, whichever occurs first.
*
[SV16500(ALL)04/95]
one third page art:0060618-C
*
[SV16600(ALL)06/95]
Refer to theMaintenance Schedule and Record
booklet for additional information.
%*
[SV16700(ALL)04/95]
NOTE: Always dispose of used automotive
fluids in a responsible manner. Follow
your community's standards for
disposing of these types of fluids. Call
your local recycling center to find out
about recycling automotive fluids.
*
[SV17275(ALL)06/95]
RWARNING
Continuous contact with USED motor oil
has caused cancer in laboratory mice.
*
[SV17285(ALL)05/95]
Protect your skin by washing with soap and
water.
File:prsvp.ex
Update:Fri Jun 23 19:33:26 1995

221
*
[SV17400(ALL)03/95]
Engine Coolant
*
[SV17500(ALL)02/95]
Checking the engine coolant
*
[SV17550(ALL)01/95]
NOTE: Be sure to read and understand
Precautions When Servicing Your Vehicle
at the beginning of this chapter.
*
[SV17600(ALL)05/95]
RWARNING
The cooling fan is automatic and may
come on at any time. Always disconnect
the negative terminal of the battery before
working near the fan.
[SV17900(ALL)02/92]
Inspect the coolant level with the dipstick
attached to the reservoir cap. Remove the cap,
wipe it clean and then put it back in the
reservoir. Remove it again. The coolant level
should be between L and F.
[SV17950(ALL)01/92]
If the coolant level is at or below the L line, add
enough 50/50 mixture of specified coolant and
water to bring the level to the F mark.
File:prsvp.ex
Update:Fri Jun 23 19:33:26 1995

222 [SV18200(ALL)01/92]
half page art:0032038-BEngine coolant recovery reservoir and dipstick
*
[SV18500(ALL)01/95]
Adding engine coolant
*
[SV18600(ALL)05/95]
RWARNING
Do not put engine coolant in the container
for the windshield washer fluid.
*
[SV18610(ALL)06/95]
If sprayed to clean the glass, engine coolant or
antifreeze could make it difficult to see through
the windshield.
[SV18650(ALL)02/95]
Add engine coolant only to the recovery
reservoir Ð not to the radiator.If the coolant
level is low, add to the engine coolant recovery
reservoir container a 50/50 mixture of water and
the type of coolant that Ford specifies. Check the
coolant level again the next few times you drive
your vehicle.
File:prsvp.ex
Update:Fri Jun 23 19:33:26 1995

223 [SV18750(ALL)05/95]
RWARNING
Never remove the radiator cap or the
coolant system cap while the engine is
running or hot to avoid personal injury.
[SV20300(ALL)05/95]
2.5L Engine
[SV20305(ALL)04/95]
Before removing either cap, turn the engine off
and let it cool. Even when the engine is cool, be
careful when removing the caps.
[SV20310(ALL)04/95]
1. Locate the radiator breather cap and the
recovery reservoir cap in your engine
compartment. The cap on the left is the
radiator breather cap. The cap on the right is
the recovery reservoir cap.
[SV20320(ALL)04/95]
2. When the engine is cool, wrap a thick cloth
around the radiator breather cap and turn it
slowly to relieve pressure.
[SV20330(ALL)04/95]
3. Step back while the pressure releases.
[SV20335(ALL)04/95]
4. When you are sure all the pressure has been
released, use the cloth to turn and remove
cap.
[SV20340(ALL)04/95]
5. Stand away from the radiator opening. Hot
steam may blow out or hot engine coolant
may even splash out.
[SV20345(ALL)04/95]
6. After the pressure has been released you
may open the recovery reservoir cap and
add engine coolant. Failure to follow this
procedure could result in serious personal
injury.
File:prsvp.ex
Update:Fri Jun 23 19:33:26 1995
