FORD PROBE 1997 2.G Owners Manual

168 %
*
[ER04000(ALL)02/96]
The Temporary Spare Tire
%*
[ER04100(ALL)02/96]
You may have a high pressure temporary spare
tire. This spare tire is smaller than a regular tire
and is designed for emergency use only. Use it
only when you get a flat tire and replace it as
soon as you can. This spare tire is marked with
the words ªTEMPORARY USE ONLYº so that
you can easily identify it.
*
[ER04200(ALL)02/96]
RWARNING
If you use the temporary spare tire
continuously or do not follow these
precautions, the tire could fail, causing
you to lose control of the vehicle, possibly
injuring yourself or others.
*
[ER04300(ALL)02/96]
When you drive with the temporary spare tire,
DO NOT:
*
[ER04400(ALL)02/96]
q
exceed 50 mph (80 km/h) under any
circumstances.
*
[ER04500(ALL)02/96]
q
load your vehicle so that it is heavier than
the maximum vehicle load rating listed on
the tire decal.
*
[ER04700(ALL)02/96]
q
use tire chains on this tire.
File:10prerp.ex
Update:Thu Jun 13 09:57:39 1996

169
*
[ER04800(ALL)02/96]
q
try to repair the temporary spare tire or
remove it from its wheel.
*
[ER04900(ALL)02/96]
q
use the wheel for any other type of vehicle.
*
[ER05000(ALL)02/96]
q
drive through an automatic car wash with
this tire. Because the temporary spare tire is
smaller than a conventional tire, it reduces
the ground clearance. Your vehicle may get
caught in the rails and it could be damaged.
%*
[ER05100(ALL)02/96]
Spare Tire Location
[ER05200(ALL)01/96]
The temporary spare tire is stored in the luggage
compartment, under the mat and floorboard.
[ER05300(ALL)01/96]
one third page art:0032099-A
Location of the temporary spare tire and jacking equipment
[ER05650(ALL)01/96]
To remove the jack and the temporary spare,
turn the bolt counterclockwise.
File:10prerp.ex
Update:Thu Jun 13 09:57:39 1996

170 %
*
[ER07600(ALL)03/96]
Preparing to Change the Tire
*
[ER07700(ALL)01/96]
1. Make sure that your vehicle will not move
or roll. If you have an automatic transaxle,
put the gearshift in P (Park). If you have a
manual transaxle, put the gearshift in 1
(First). Set the parking brake and block the
wheel that is diagonally opposite the tire
that you are changing.
[ER07800(ALL)01/96]
one third page art:0030146-A
Blocking the wheel diagonally opposite the tire being
changed
*
[ER08000(ALL)01/96]
When one of the front wheels is off the ground,
the transaxle alone will not prevent the vehicle
from moving or slipping off the jack, even if the
vehicle is in P (Park) or 1 (First). To prevent the
vehicle from moving when you change one of
the front tires, put a block behind the wheel that
is diagonally opposite to the tire.
*
[ER08100(ALL)03/96]
RWARNING
If the vehicle slips off the jack, you or
someone else could be seriously injured.
File:10prerp.ex
Update:Thu Jun 13 09:57:39 1996

171
*
[ER08200(ALL)01/96]
2. Get out the spare tire and jack.
% [ER08300(ALL)01/96]
3. Remove any wheelcovers or hubcaps with
the tapered end of a wheel nut wrench.
Insert the handle of the wrench and twist it
against the inner wheelcover flange. Remove
any chrome nuts or plastic caps covering the
wheel lug nuts.
[ER08500(ALL)03/96]
4. Loosen the wheel lug nuts by pulling up on
the handle of the wrench one half-turn
counterclockwise. Do not remove the wheel
lug nuts until you raise the tire off the
ground.
%*
[ER08600(ALL)01/96]
Removing and Replacing the Tire
%*
[ER08700(ALL)01/96]
1. Find the jack notch next to the door of the
tire that you are changing. Put the jack in
the jack notch and turn the handle of the
jack clockwise until the wheel is completely
off the ground.
*
[ER08800(ALL)01/96]
RWARNING
To lessen the risk of personal injury, do
not put any part of your body under the
vehicle while changing a tire. Do not start
the engine when your vehicle is on the
jack. The jack is only meant for changing
the tire.
File:10prerp.ex
Update:Thu Jun 13 09:57:39 1996

172 [ER09000(ALL)01/96]
half page art:0030149-DJack mounting position
File:10prerp.ex
Update:Thu Jun 13 09:57:39 1996

173 [ER09300(ALL)01/96]
2. Remove the lug nuts by using the lug
wrench. Never loosen the hub nuts. See the
following illustration if you are not sure
where to find the lug nuts.
[ER09400(ALL)01/96]
half page art:0032086-B
Lug nut positions
*
[ER09700(ALL)01/96]
3. Replace the flat tire with the spare tire.
[ER09800(ALL)01/96]
4. Replace the lug nuts and tighten snug. The
beveled edge faces inward. Do not fully
tighten the lug nuts until you lower the
vehicle. If you do, you could force the
vehicle off the jack.
File:10prerp.ex
Update:Thu Jun 13 09:57:39 1996

174 [ER09990(ALL)04/96]Your vehicle has metric (12 mm) wheel studs
and lug nuts. During wheel removal and
replacement, make certain that you use the same
lug nuts to reinstall the wheel or replace them
with nuts of the same metric size and threading.
*
[ER10000(ALL)01/96]
RWARNING
Installation of an English thread nut on a
metric stud (or vice-versa) will not
properly secure the wheel to the hub.
Damaged studs may result in wheel
separation and possible injury.
*
[ER10200(ALL)03/96]
5. Lower the vehicle by turning the jack handle
counterclockwise.
[ER10300(ALL)01/96]
6. Remove the jack and fully tighten the lug
nuts in the order shown in the illustration
under step 2.
[ER10700(ALL)01/96]
7. Put the tire, jack, and wrench away.
[ER10750(ALL)01/96]
8. Unblock the wheels.
%
*
[ER11000(ALL)02/96]
Jump-Starting Your Vehicle
[ER11100(ALL)01/96]
Your vehicle has a Motorcraft maintenance-free
battery. Your vehicle's battery may die if you
leave the lights on or any electrical equipment
on after you turn the engine off. If this happens,
you may be able to jump-start from a booster
battery to start your vehicle.
*
[ER11150(ALL)02/96]
RWARNING
The gases around the battery can explode
if exposed to flames, sparks, or lit
cigarettes. An explosion could result in
injury or vehicle damage.
File:10prerp.ex
Update:Thu Jun 13 09:57:39 1996

175
*
[ER11200(ALL)02/96]
RWARNING
To protect yourself when charging a
battery, always shield your face and eyes.
Make sure that you can breathe fresh air.
%*
[ER11300(ALL)02/96]
RWARNING
Applying too much pressure on the ends
when lifting a battery could cause acid to
spill. Lift the battery with a carrier or
with your hands on the opposite corners.
%*
[ER11400(ALL)05/96]
RWARNING
Batteries contain sulfuric acid which burns
skin, eyes, and clothing.
*
[ER11500(ALL)02/96]
If the acid touches someone's skin, eyes, or
clothing, immediately flush the area with water
for at least 15 minutes. If someone swallows the
acid, have him or her drink lots of milk or water
first, then Milk of Magnesia, a beaten egg, or
vegetable oil. Call a doctor immediately.
*
[ER11600(ALL)01/96]
RWARNING
Do not push-start your vehicle. You could
damage the catalytic converter. For further
information, seeJumper Cablesin the
Index.
*
[ER11700(ALL)02/96]
To avoid damaging your vehicle or your battery,
and to avoid injury to yourself, follow these
directions for preparing your vehicle to
jump-start and connecting the jumper cables in
the order they are given. If in doubt, call for
road service.
File:10prerp.ex
Update:Thu Jun 13 09:57:39 1996

176 %
*
[ER11800(ALL)02/96]
Preparing Your Vehicle
*
[ER11900(ALL)02/96]
1. Your vehicle has a 12-volt starting system, so
you need to use a 12-volt jumper system.
You will damage your starting motor,
ignition system, and other electrical parts if
you connect them to a 24-volt power supply
(either two 12-volt batteries in series or a
24-volt generator set).
*
[ER12000(ALL)02/96]
2. Do not disconnect the battery of the disabled
vehicle. You could damage the vehicle's
electrical system.
*
[ER12100(ALL)02/96]
3. Park the booster vehicle close to the hood of
the disabled vehicle.Make sure the vehicles
do not touch each other.Set the parking
brake on both vehicles and stay clear of the
engine cooling fan and other moving parts.
*
[ER12200(ALL)02/96]
4. Check all battery terminals and remove any
excessive corrosion before you attach the
jumper cables.
%*
[ER12400(ALL)02/96]
Connecting the jumper cables
*
[ER12500(ALL)02/96]
1. Connect one end of the first jumper cable to
the positive (+) terminal of the discharged
battery. (You can connect either jumper cable
to the positive (+) terminal, as long as you
use the same cable for both positive
terminals.) Most jumper cables have a red
cable and a black cable. The red cable is
generally used for the positive terminals and
the black for the negative ones.
*
[ER12600(ALL)02/96]
2. Connect the other end of the first cable to
the positive (+) terminal of the booster
battery.
*
[ER12700(ALL)02/96]
3. Connect one end of the second cable to the
negative (S) terminal of the booster battery
Ð NOT to the discharged battery.
File:10prerp.ex
Update:Thu Jun 13 09:57:39 1996

177
*
[ER12800(ALL)01/96]
4. Connect the other end of the second cable to
a good metallic surface on the engine or
frame of the disabled vehicle.
*
[ER12900(ALL)02/96]
RWARNING
Do not connect the end of the second
cable to the negative (S) terminal of the
battery to be jumped. A spark may cause
an explosion of the gases that surround
the battery.
[ER13000(ALL)01/96]
two third page art:0030135-C
The sequence for connecting the jumper cables
File:10prerp.ex
Update:Thu Jun 13 09:57:39 1996
