FORD PROBE 1997 2.G Owners Manual

209
*
[MC25100(ALL)03/96]
q
Make sure the weight of your load is evenly
distributed.
*
[MC25200(ALL)03/96]
q
Adjust tire pressure to recommended
specifications found on the Safety Compliance
Certification Label.
*
[MC25300(ALL)03/96]
If you do not take these precautions, your tires
may fail or go flat.
*
[MC25390(ALL)03/96]
Ford Motor Company recommends obeying
posted speed limits.
*
[MC25400(ALL)03/96]
RWARNING
Driving too fast for conditions creates the
possibility of loss of vehicle control.
Driving at very high speeds for extended
periods of time may result in damage to
vehicle components.
[MC25600(ALL)01/96]
At least once a month, check the pressure in all
your vehicle's tires, including the spare. Use an
accurate tire pressure gauge. Check the tire
pressure when tires are cold, that is, after the
vehicle has been parked for at least one hour or
has been driven less than 3 miles (5 km).
[MC25700(ALL)01/96]
You can find your vehicle's proper tire inflation
pressure on the tire decal on the right door lock
pillar.
*
[MC25850(ALL)01/96]
RWARNING
Improperly inflated tires can affect vehicle
handling and can fail suddenly, possibly
resulting in loss of vehicle control.
File:11prmcp.ex
Update:Thu May 16 12:08:53 1996

210 %
*
[MC25875(ALL)01/96]
Tire Inspection and Maintenance
*
[MC25880(ALL)03/96]
Inspect the tire treads, and remove stones, nails,
glass or other objects that may be wedged in the
tread grooves. Check for holes or cuts that may
permit air to leak from the tire, and make the
necessary repairs.
*
[MC25890(ALL)01/96]
Inspect the tire sidewalls for cuts, bruises and
other damage. If you suspect internal damage to
the tire, have it removed and checked. You may
need to repair or replace it.
%*
[MC25900(ALL)01/96]
Tire Rotation
*
[MC26000(ALL)01/96]
Because your vehicle's front and rear tires
perform different jobs, they often wear
differently. To make sure your tires wear evenly
and last longer, rotate them as indicated in the
following diagram.
*
[MC26100(ALL)01/96]
Do not include the spare tire as part of your
rotation.
*
[MC26150(ALL)02/96]
For tire rotation intervals, see theMaintenance
Schedulebooklet. If you notice the tires wearing
unevenly, have them checked.
[MC26202(ALL)01/96]
one third page art:0030223-B
Rotating the tires
File:11prmcp.ex
Update:Thu May 16 12:08:53 1996

211 %
*
[MC26400(ALL)01/96]
Replacing the Tires
[MC26500(ALL)01/96]
We recommend that you use the same size and
type when making tire replacements. The
standard model uses P195/65 R14 tires, and the
GT model is equipped with P225/50VR16 tires.
If your standard model vehicle is equipped with
a 3-spoke aluminum wheel, you will need
P205/55H R15 tires.
*
[MC26700(ALL)01/96]
Replace any tires that show wear bands. When
your tire shows a wear band, it has only 1/16
inch (2 mm) of tread left.
*
[MC26800(ALL)01/96]
quarter page art:0060006-A
A worn-out tire
*
[MC26900(ALL)02/96]
Because your vehicle's tires may wear unevenly,
you may need to replace them before a wear
band appears across the entire tread.
*
[MC27000(ALL)01/96]
RWARNING
When replacing full size tires, never mix
radial, bias-belted, or bias-type tires. Use
only the tire sizes that are listed on the
tire pressure decal. Make sure that all tires
are the same size, speed rating, and
load-carrying capacity. Use only the tire
combinations recommended on the decal.
If you do not follow these precautions,
your vehicle may not drive properly and
safely.
File:11prmcp.ex
Update:Thu May 16 12:08:53 1996

212
*
[MC27100(ALL)01/96]
Tires that are larger or smaller than your
vehicle's original tires may also affect the
accuracy of your speedometer.
%*
[MC27200(ALL)03/96]
Wheel and Tire Matching
*
[MC27250(ALL)03/96]
See an authorized tire dealer for proper
servicing procedures. Wheels and tires must be
properly removed, matched and remounted to
maintain the best possible ride.
%*
[MC28100(ALL)01/96]
Information About Tire Quality Grades
*
[MC28200(ALL)01/96]
New vehicles are fitted with tires that have their
Tire Quality Grade (described below) molded
into the tire's sidewall. These Tire Quality
Grades are determined by standards that the
United States Department of Transportation has
set.
*
[MC28250(ALL)01/96]
Tire Quality Grades apply to new pneumatic
tires for use on passenger cars. They do not
apply to deep tread, winter-type snow tires,
space-saver or temporary use spare tires, tires
with nominal rim diameters of 10 to 12 inches or
limited production tires as defined in Title 49
Code of Federal Regulations Part 575.104(c)(2).
*
[MC28300(ALL)01/96]
U.S. Department of Transportation Ð Tire
quality grades:The U.S. Department of
Transportation requires Ford to give you the
following information about tire grades exactly
as the government has written it.
%*
[MC28399(ALL)01/96]
Treadwear
*
[MC28400(ALL)01/96]
The treadwear grade is a comparative rating
based on the wear rate of the tire when tested
under controlled conditions on a specified
government test course. For example, a tire
graded 150 would wear one and one-half (1 1/2)
times as well on the government course as a tire
graded 100. The relative performance of tires
File:11prmcp.ex
Update:Thu May 16 12:08:53 1996

213
depends upon the actual conditions of their use,
however, and may depart significantly from the
norm due to variations in driving habits, service
practices and differences in road characteristics
and climate.
*
[MC28499(ALL)01/96]
Traction A B C
*
[MC28500(ALL)05/96]
The traction grades, from highest to lowest, are
A, B, and C, and they represent the tire's ability
to stop on wet pavement as measured under
controlled conditions on specified government
test surfaces of asphalt and concrete. A tire
marked C may have poor traction performance.
*
[MC28550(ALL)05/96]
RWARNING
The traction grade assigned to this tire is
based on braking (straightahead) traction
tests and does not include cornering
(turning) traction.
*
[MC28699(ALL)01/96]
Temperature A B C
*
[MC28700(ALL)05/96]
The temperature grades are A (the highest), B,
and C, representing the tire's resistance to the
generation of heat and its ability to dissipate
heat when tested under controlled conditions on
a specified indoor laboratory test wheel.
Sustained high temperature can cause the
material of the tire to degenerate and reduce tire
life, and excessive temperature can lead to
sudden tire failure. The grade C corresponds to
a level of performance which all passenger car
tires must meet under the Federal Motor Vehicle
Safety Standard No. 109. Grades B and A
represent higher levels of performance on the
laboratory test wheel than the minimum
required by law.
File:11prmcp.ex
Update:Thu May 16 12:08:53 1996

214
*
[MC28725(ALL)05/96]
RWARNING
The temperature grade for this tire is
established for a tire that is properly
inflated and not overloaded. Excessive
speed, underinflation, or excessive
loading, either separately or in
combination, can cause heat buildup and
possible tire failure.
%*
[MC28750(ALL)01/96]
Snow tires
*
[MC28770(ALL)01/96]
During the winter months in some climates, you
may need to use snow tires and occasionally
chains for your tires.
*
[MC28790(ALL)01/96]
RWARNING
Snow tires must be the same size and
grade as the tires you currently have on
your vehicle.
*
[MC28810(ALL)01/96]
Use chains on the tires only in an emergency or
if the law requires them where you live. If you
choose to use chains on your vehicle's tires, be
aware of the following:
*
[MC28820(ALL)01/96]
q
Tire chains may scratch or chip aluminum
wheels. IT IS RECOMMENDED THAT TIRE
CHAINS ARE INSTALLED ON STEEL
WHEELS ONLY. Be sure to remove wheel
covers (if equipped) from steel rims before
using tire chains to avoid scratches or
damage.
[MC28830(ALL)04/96]
q
Do not use tire chains if you have the GT
model.
*
[MC28840(ALL)01/96]
q
Local regulations may prohibit or restrict the
use of tire chains. Investigate the laws and
regulations in your area before installing
chains.
File:11prmcp.ex
Update:Thu May 16 12:08:53 1996

215
*
[MC28860(ALL)01/96]
q
Put the chains on the front tires tightly with
the ends held down securely. Retighten the
chains after driving 1/2 mile (1 km). Follow
the chain manufacturer's instructions.
*
[MC28870(ALL)01/96]
q
Do not drive faster than 30 mph (50 km/h)
or the chain manufacturer's recommended
speed limit, whichever is lower. Avoid
bumps, holes and sharp turns. If you can
hear the chains rub or bang against your
vehicle, remove the chains to prevent damage
to your vehicle.
*
[MC28880(ALL)01/96]
q
Tire chains may affect vehicle handling. Drive
carefully and avoid hard braking.
*
[MC28890(ALL)01/96]
q
Do not use chains on temporary spare tires.
They may damage the vehicle and the tire.
*
[MC29025(ALL)01/96]
q
Remove tire chains at the first opportunity
after using them on snow and ice. Do not use
the chains on dry roads.
%
*
[MC30000(ALL)01/96]
Filling the Fuel Tank
[MC30050(ALL)03/96]
Fuel filler door release lever
[MC30100(ALL)01/96]
Your vehicle is equipped with a fuel filler door
release. To open the fuel filler door, pull up on
the release lever which is located in front of the
driver's seat and near the door.
[MC30200(ALL)01/96]
Remote Fuel Filler-Lid Release Override
[MC30300(ALL)01/96]
If the release does not operate, open the
hatchback, remove the trim on the left rear side,
reach into the opening and pull the latch toward
the rear (see the service manual for trim
removal). You should wear gloves to protect
your hands from any sharp edges when you use
the fuel filler-lid release override.
File:11prmcp.ex
Update:Thu May 16 12:08:53 1996

216 [MC30400(ALL)01/96]
half page art:0032107-CManual fuel filler-lid override (behind left rear trim panel
in hatch)
[MC30500(ALL)01/96]
To fill the fuel tank:
*
[MC30600(ALL)01/96]
1. After opening the fuel filler door, remove
the cap carefully and slowly by turning it
counterclockwise 1/2 to 3/4 turn.
*
[MC30700(ALL)01/96]
RWARNING
The fuel system may be under pressure. If
the fuel cap is venting vapor or if you
hear a hissing sound, wait until it stops
before completely removing the cap.
*
[MC30800(ALL)01/96]
2. Put the nozzle all the way inside the fuel
filler pipe before pumping the fuel.
File:11prmcp.ex
Update:Thu May 16 12:08:53 1996

217
*
[MC30900(ALL)01/96]
NOTE: If you spill any fuel on the body of
your vehicle, clean it off immediately.
The fuel may dull or soften the paint
if you do not wash it off.
%*
[MC31000(ALL)03/96]
3. Replace the fuel cap completely when you
are finished. Turn it clockwise 1/4 turn until
it is tight. It will click when it is fully
tightened.
*
[MC31100(ALL)01/96]
4. Push the fuel door closed.
*
[MC31200(ALL)01/96]
If you lose the fuel cap, replace it with an
authorized Motorcraft or equivalent part.
%*
[MC31300(ALL)01/96]
RWARNING
If you do not use the proper fuel cap, the
pressure in the fuel tank can damage the
fuel system or cause it to work improperly
in a collision.
*
[MC31400(ALL)01/96]
NOTE: If you replace your fuel cap with an
aftermarket fuel filler cap, the customer
warranty may be void for any damage
to the fuel tank and/or fuel system.
%*
[MC31500(ALL)01/96]
Choosing the Right Fuel
*
[MC31600(ALL)05/96]
Use only UNLEADED FUEL. The use of leaded
fuel is prohibited by law and could damage
your vehicle. The damage may not be covered
by your warranty.
*
[MC31700(ALL)05/96]
Your vehicle was not designed to use fuel
containing manganese-based additives such as
MMT. Additionally, vehicles certified to
California emission standards (indicated on the
underhood Vehicle Emissions Control
Information label) are designed to operate on
California reformulated gasolines. If California
reformulated gasoline is not available when you
File:11prmcp.ex
Update:Thu May 16 12:08:53 1996

218refuel, your vehicle can be operated on
non-California fuels. However, even though your
engine will perform adequately on other
gasolines, the performance of the emission
control devices and systems may be adversely
affected. Repair of damage caused by using a
fuel that your vehicle was not designed for may
not be covered by your warranty.
[MC31800(ALL)03/96]
Octane Recommendations
[MC31900(ALL)03/96]
Your 2.0L engine is designed to use regular
gasoline with an (R+M)/2 octane rating of 87.
We do not recommend gasolines labeled as
ªregularº in high altitude areas that are sold
with octane ratings of 86 or even less.
[MC32000(ALL)03/96]
Your 2.5L engine is designed to use premium
gasoline for optimum performance with an
(R+M)/2 octane rating of 91 or higher. Gasolines
with lower octane ratings can be used, but
performance may decrease. We do not
recommend gasolines labeled as ªpremiumº in
high altitude areas that are sold with octane
ratings less than 91.
*
[MC32100(ALL)05/96]
Do not be concerned if your vehicle sometimes
knocks lightly. However, if it knocks heavily
under most driving conditions on the
recommended octane fuel, see your dealer or a
qualified service technician to prevent any
engine damage.
*
[MC32200(ALL)05/96]
Fuel Quality
*
[MC32300(ALL)05/96]
If you are experiencing starting, rough idle or
hesitation problems try a different brand of fuel.
If the condition persists, see your dealer or a
qualified service technician.
*
[MC32400(ALL)05/96]
The American Automobile Manufacturers
Association (AAMA) issued a gasoline
specification to provide information on high
File:11prmcp.ex
Update:Thu May 16 12:08:53 1996
