FORD PROBE 1997 2.G User Guide
Manufacturer: FORD, Model Year: 1997, Model line: PROBE, Model: FORD PROBE 1997 2.GPages: 288, PDF Size: 1.64 MB
Page 11 of 288
7
Instrumentation
%*
[IS00600(ALL)01/96]
The instrument panel (dashboard) on your
vehicle is divided into several different sections.
The illustrations on the following pages show
the major parts of the instrument panel that are
described in this chapter. Some items shown
may not be on all vehicles.
*
[IS00700(ALL)05/96]
In your vehicle, the warning lights and gauges
are grouped together on the instrument panel.
We call this grouping an instrument cluster.
File:03prisp.ex
Update:Thu May 16 09:43:45 1996
Page 12 of 288
8
%*
[IS01000(ALL)01/96]
The Mechanical Cluster
[IS01100(ALL)05/96]
full page art:0032080-B
Instrument cluster
File:03prisp.ex
Update:Thu May 16 09:43:45 1996
Page 13 of 288
9 [IS01200(ALL)05/96]
full page art:0032045-I
Warning light locations on the instrument cluster
File:03prisp.ex
Update:Thu May 16 09:43:45 1996
Page 14 of 288
10 [IS01300(ALL)05/96]The instrument cluster on the Probe GT model is
similar to the one shown. The two exceptions
are: the speedometer on the GT model shows
140 mph (225 km/h) and it has a 7,000 rpm
red-line tachometer.
[IS01400(ALL)01/96]
one third page art:0032087-B
GT model speedometer and tachometer
[IS01500(ALL)01/96]
The following warning lights and gauges are on
the cluster. All of the warning lights and gauges
alert you to possible problems with your vehicle.
The following sections detail what each of these
indicators means.
File:03prisp.ex
Update:Thu May 16 09:43:45 1996
Page 15 of 288
11
%*
[IS01600(ALL)04/96]
Indicator Lights and Chimes
%*
[IS01700(ALL)03/96]
Safety Belt Warning Light and Chime
[IS01800(ALL)01/96]
This warning light and chime remind you to
fasten your safety belt. If you do not fasten your
safety belt before the ignition is turned to ON,
the chime will sound for 4 to 8 seconds and the
warning light will illuminate for 1 to 2 minutes,
or until the safety belt is fastened. If you fasten
the safety belt before the ignition is turned to
ON, neither the light nor chime will activate.
[IS01900(ALL)01/96]
one inch art:0032097-A
Safety belt light
%*
[IS02000(ALL)05/96]
Air Bag Readiness Light
*
[IS02050(ALL)05/96]
This light illuminates for six seconds when the
ignition is turned to the ON position. If the light
fails to illuminate, continues to flash, remains on,
or if a series of five beeps is heard, have the
system serviced as soon as possible.
[IS02100(ALL)01/96]
one inch art:0032051-A
Air bag readiness light
File:03prisp.ex
Update:Thu May 16 09:43:45 1996
Page 16 of 288
12
*
[IS02120(ALL)05/96]
RWARNING
If any of these things happen, even
intermittently, have the air bag system
serviced at your Ford or Lincoln-Mercury
dealer immediately.
%*
[IS02200(ALL)01/96]
Brake System Warning Light
[IS02300(ALL)03/96]
Your vehicle has a divided brake system. If one
part isn't working, the other part can still work
and stop you. For good braking, though, you
need both systems working well. If the warning
light illuminates, there could be a problem. Have
your brake system inspected right away.
[IS02400(ALL)03/96]
This light should illuminate as you start the
vehicle. If it doesn't illuminate then, have it
fixed so it will be ready to warn you if there's a
problem.
[IS02500(ALL)01/96]
one inch art:0030319-E
Brake system and parking brake light
[IS02600(ALL)03/96]
This light illuminates briefly when you turn the
ignition key to START. It normally goes off
shortly after the engine starts and you release
the parking brake, but it may stay on for up to
60 seconds. If the light stays on for longer than
60 seconds or comes on after you have fully
released the parking brake, have the hydraulic
brake system serviced.
File:03prisp.ex
Update:Thu May 16 09:43:45 1996
Page 17 of 288
13
*
[IS02700(ALL)03/96]
This light will also illuminate if the parking
brake does not release fully. If it does stay on
afterthe parking brake is fully released, it
means there may be a brake problem. Pull off
the road and stop carefully. You may notice that
the pedal is harder to push, the pedal may go
closer to the floor, or it may take longer to stop
the vehicle. Try the brakes again after you have
stopped.
*
[IS02800(ALL)03/96]
RWARNING
The BRAKE light indicates that the brakes
may not be working properly. Have the
brakes checked immediately.
%*
[IS02900(ALL)03/96]
Anti-Lock Brake System Warning Light
[IS03000(ALL)03/96]
When the ignition switch is turned to the ON
position, the anti-lock brake system warning
light will illuminate. When the engine is started,
the anti-lock brake system control unit will
determine if all components of the system are
operating correctly. The warning light could
remain on for two to four seconds.
[IS03100(ALL)01/96]
one inch art:0032359-C
The anti-lock brake system warning light
*
[IS03200(ALL)03/96]
RWARNING
If the anti-lock brake system warning
light remains on or comes on while
driving, have the braking system checked
by a qualified service technician as soon
as possible.
File:03prisp.ex
Update:Thu May 16 09:43:45 1996
Page 18 of 288
14
*
[IS03300(ALL)03/96]
NOTE: If a fault occurs in the anti-lock
system, and the brake warning light is
not lit, the anti-lock system is disabled
but normal brake function remains
operational.
*
[IS03400(ALL)01/96]
NOTE: If your vehicle must be jump-started
because of a low battery, the Anti-Lock
Brake System warning light could
remain on. This is due to low battery
voltage and does not indicate a
malfunction in the system. Under these
circumstances, you should drive your
vehicle only after the battery has had
time to charge and the light has gone
out.
[IS03500(ALL)01/96]
The Low Fuel Light
[IS03600(ALL)03/96]
This light illuminates when fuel level in your
tank has reached approximately 2-3 gallons (7-10
liters).
[IS03700(ALL)01/96]
one inch art:0032048-A
Low fuel light
File:03prisp.ex
Update:Thu May 16 09:43:45 1996
Page 19 of 288
15 %
*
[IS03800(ALL)05/96]
High Beam Light
*
[IS03900(ALL)03/96]
This light illuminates when the headlamps are
turned to high beam or when you flash the
lights.
*
[IS04000(ALL)01/96]
one inch art:0030174-A
High beam light
%*
[IS04100(ALL)03/96]
Check Engine Warning Light
*
[IS04200(ALL)03/96]
This light illuminates when the electronic engine
control system is not working properly. This is
the computer that controls the operating
conditions of the engine.
*
[IS04300(ALL)01/96]
one inch art:0030175-B
Check engine warning light
[IS04400(ALL)03/96]
This light illuminates briefly when you turn the
ignition to the ON position, but should turn off
when the engine starts. If the light does not
come on when you turn the ignition to the ON
position or if it comes on and stays on when
you are driving, have your vehicle serviced as
soon as possible. This indicates a possible
problem with one of the engine's emission
control systems.You do not need to have your
vehicle towed in.
File:03prisp.ex
Update:Thu May 16 09:43:45 1996
Page 20 of 288
16
*
[IS04500(ALL)04/96]
If the light flashes briefly while you are driving,
it means that the condition is no longer present.
[IS04600(ALL)01/96]
O/D OFF Light (If equipped)
[IS04700(ALL)05/96]
This light tells you that the overdrive off (O/D
OFF) button on the shift selector has been
pushed. When the light is on, the transaxle will
not shift into overdrive. Depressing the button
on the shift selector again will return the vehicle
to ªoverdrive onº mode. The transaxle will be in
the ªoverdrive onº mode when the vehicle is
started even if the O/D OFF mode was selected
when the vehicle was last shut off. Refer to the
Drivingchapter for more information.
[IS04800(ALL)03/96]
If the light does not illuminate when the O/D
OFF button is pressed, or if the light flashes
when you are driving, have your vehicle
serviced at the first opportunity. If this condition
persists, damage could occur to the transaxle.
[IS04900(ALL)01/96]
one inch art:0032053-A
Overdrive OFF light
*
[IS05000(ALL)04/96]
Gauges
%*
[IS05100(ALL)05/96]
Fuel Gauge
*
[IS05200(ALL)01/96]
The fuel gauge displays approximately how
much fuel you have in the fuel tank.
*
[IS05300(ALL)01/96]
The ignition must be turned off while putting
fuel in the tank in order to get a correct fuel
gauge reading after the ignition is turned on.
