full page art:0032028-HInstrument panel
File:05prcfp.ex
Update:Tue Jun 11 11:03:33 1996
Page 52 of 288
49 %
*
[CF00600(ALL)03/96]
NOTE: Any cleaner or polish that increases the
gloss (shine) of the upper part of the
instrument panel should be avoided.
The dull finish in this area is to help
protect the driver from undesirable
windshield reflection.
%
*
[CF00700(ALL)01/96]
The Climate Control System
*
[CF01000(ALL)01/96]
Heating Only System (Without Air
Conditioning)
*
[CF01100(ALL)01/96]
Function selection
[CF01300(ALL)01/96]
The heater in your vehicle has three controls
used for air direction, temperature and fan
speed. The function selector control lets you
direct heated or unheated air through the
instrument panel registers, or down to the floor.
It also allows you to vent your vehicle with
outside air.
[CF01400(ALL)01/96]
one third page art:0032040-C
Heating only system control panel
[CF01800(ALL)01/96]
Turning the function selector control all the way
to the right (V) directs air to defroster vents
and the side window defoggers only.
[CF01900(ALL)01/96]
With the function selector control in the MIX
position, air is directed out the defrosters, side
defoggers and the floor heater outlets.
File:05prcfp.ex
Update:Tue Jun 11 11:03:33 1996
Page 53 of 288
50 [CF02000(ALL)01/96]The FLOOR position directs air out the floor
outlets and the side window defoggers.
[CF02100(ALL)01/96]
Ventilate your vehicle with outside air by
choosing the VENT position.
[CF03000(ALL)01/96]
Temperature control
[CF03100(ALL)01/96]
The air temperature can be adjusted by moving
the marker on the temperature control to the red
area for warm air, or to the blue area for
unheated air. The air will become warmer or
cooler depending on how far the control is
turned.
[CF03400(ALL)01/96]
Fan speed control
[CF03500(ALL)01/96]
Fan speed can be controlled by turning the
control from LO to HI.
*
[CF03600(ALL)04/96]
Turning On the Heat
*
[CF03800(ALL)01/96]
To heat the inside of your vehicle:
[CF03850(ALL)01/96]
1. Turn the function selector control to FLOOR.
[CF03900(ALL)01/96]
When FLOOR is selected, air is directed
through the floor registers, and a little air is
also directed at the windshield and side
windows to help prevent fogging.
[CF03975(ALL)01/96]
2. Turn the temperature control all the way to
the right in the red area, or to the desired
temperature.
[CF04000(ALL)04/96]
3. Set the fan at the desired speed.
File:05prcfp.ex
Update:Tue Jun 11 11:03:33 1996
Page 54 of 288
51 [CF04300(ALL)04/96]
Defrosting the Windshield and Side
Windows
[CF04500(ALL)01/96]
1. Turn the function selector control to the
defrost position.
[CF04550(ALL)01/96]
WhenVis selected, air is directed to the
windshield and side windows.
[CF04600(ALL)01/96]
2. Turn the temperature control to the desired
temperature.
[CF04650(ALL)04/96]
3. Set the fan at the desired speed.
[CF04700(ALL)04/96]
Heating and Defrosting at the Same Time
[CF05000(ALL)01/96]
1. Set the function selector control to MIX.
[CF05100(ALL)01/96]
2. Set the temperature and fan speed as
desired.
[CF05200(ALL)04/96]
Ventilating Your Vehicle With Outside Air
*
[CF05300(ALL)08/95]
On mild days, you may want to ventilate your
vehicle with outside air. To open the vents:
[CF05400(ALL)01/96]
1. Turn the function selector control to VENT.
[CF05500(ALL)01/96]
When VENT is selected, air is directed out of
the panel registers.
[CF05600(ALL)01/96]
2. Turn the temperature control to the desired
temperature.
[CF05700(ALL)04/96]
3. Set the
H(fan speed) as desired.
File:05prcfp.ex
Update:Tue Jun 11 11:03:33 1996
Page 55 of 288
52
*
[CF05800(ALL)05/96]
Tips for controlling the temperature in your
vehicle
*
[CF05900(ALL)01/96]
q
To vary the temperature inside your vehicle,
move the temperature selector toward the red
area for warmer air and toward the blue area
for cooler air.
*
[CF06000(ALL)01/96]
q
If you drive with the fan off and the
windows closed, the windows may fog up.
To prevent fogging:
[CF06100(ALL)01/96]
1. Set the function selector control to VENT,
MIX, FLOOR or theVposition.
*
[CF06200(ALL)01/96]
2. Set the desired temperature.
*
[CF06300(ALL)04/96]
3. Set the
H(fan speed) to the desired
position.
*
[CF06400(ALL)01/96]
q
Do not put objects under the front seats that
will interfere with the flow of air to the back
seats.
*
[CF06500(ALL)01/96]
q
Remove any snow, ice, or leaves from the
area below the windshield on the outside of
your vehicle. They could block the air intake.
File:05prcfp.ex
Update:Tue Jun 11 11:03:33 1996
Page 56 of 288
53
*
[CF06600(ALL)01/96]
Air Conditioning System (If equipped)
[CF06800(ALL)01/96]
Operate the air conditioning by using the climate
controls on the center of the instrument panel.
[CF06900(ALL)01/96]
one third page art:0032041-A
Air conditioning controls
*
[CF06950(ALL)01/96]
Sometimes you may notice slight engine surging
if you have the air conditioner on. This is
normal, as the system is designed to cycle the
compressor on and off to maintain desired
cooling. The reduced compressor operation
should benefit fuel economy.
*
[CF07000(ALL)01/96]
On some vehicles with air conditioning,
wide-open throttle acceleration will temporarily
cut off the air conditioning.
*
[CF07050(ALL)01/96]
Since the air conditioner removes a lot of
moisture from the air during operation, it is
normal for water to drip on the pavement under
the air conditioner drain after you have stopped
the vehicle.
[CF07150(ALL)01/96]
Action for heating and windshield defrosting are
identical for cars equipped with either the
Heating Only Systemor theHeating and Air
Conditioning System. For instructions about these
functions, see the previous section,Heating Only
System. For instructions about using the air
conditioning, see the following sections.
File:05prcfp.ex
Update:Tue Jun 11 11:03:33 1996
Page 57 of 288
54 [CF07200(ALL)04/96]If the inside of your vehicle is very warm, drive
for a few minutes with the windows down. This
forces most of the hot, stale air out of the
vehicle and helps the air conditioning cool the
vehicle faster.
[CF07350(ALL)01/96]
MAX A/C
[CF07400(ALL)01/96]
When MAX A/C is selected, cooled interior air
is recirculated through the system. This position
is more efficient than NORM A/C.
*
[CF07500(ALL)01/96]
To cool your vehicle quickly in warm weather:
[CF07600(ALL)01/96]
1. Turn the function selector control to MAX
A/C.
[CF07700(ALL)01/96]
2. Turn the temperature control to the blue
(cool) area.
[CF07800(ALL)04/96]
3. Set the fan at the desired speed.
[CF08000(ALL)03/96]
Because MAX A/C uses recirculated air, MAX is
usually more efficient than NORM A/C. You
can switch to outside air NORM A/C at any
time, especially after the vehicle has cooled
down.
[CF08100(ALL)03/96]
You may notice a slight odor when using the
MAX A/C position. This is normal. If the odor
becomes annoying, switch the function selector
to NORM A/C.
[CF08200(ALL)01/96]
To provide the most quiet operation when using
MAX A/C, reduce the fan speed after a
comfortable temperature has been reached.
[CF08300(ALL)04/96]
NORM A/C
[CF08400(ALL)01/96]
When maximum air conditioning is not needed,
you can use the NORM A/C position to cool
your vehicle with outside air. Cooling your
vehicle this way brings in outside air and is
quieter, but it is less efficient.
File:05prcfp.ex
Update:Tue Jun 11 11:03:33 1996
Page 58 of 288
55
*
[CF08500(ALL)01/96]
To cool your vehicle using outside air:
[CF08600(ALL)01/96]
1. Turn the function selector control to NORM
A/C.
[CF08700(ALL)01/96]
2. Turn the temperature control all the way to
left to the blue (cool) area.
[CF08800(ALL)04/96]
3. Set the fan at the desired speed.
[CF08900(ALL)01/96]
In mild weather, setting the function selector
control in the VENT position will add cool air to
your vehicle without using the air conditioning.
You will get better fuel economy without using
the air conditioning.
*
[CF09000(ALL)01/96]
Engine Idle Speed Control System
*
[CF09100(ALL)01/96]
Genuine Ford air conditioning (either
factory-installed or dealer-installed) has an
engine idle speed control system that
compensates for engine speed loss that may
occur when the air conditioning compressor is
running. This idle speed control holds the engine
idle essentially constant, regardless of whether
the air conditioning system is on or off.
[CF09200(ALL)01/96]
NOTE: Whenever service to the air
conditioning system is required, make
sure the service facility uses a
refrigerant recycling system. These
systems will capture the refrigerant for
reuse. Releasing certain refrigerants
into the atmosphere is hazardous to the
environment.
File:05prcfp.ex
Update:Tue Jun 11 11:03:33 1996
Page 59 of 288
56
*
[CF09300(ALL)01/96]
Rear Window Defroster (If equipped)
[CF09400(ALL)01/96]
quarter page art:0032068-D
Rear window defroster button
[CF09500(ALL)01/96]
The defroster for the rear window clears frost,
fog, or thin ice from both the inside and outside
of the rear window. The rear window defroster
button is located on the lower right of the
instrument panel below the climate control
panel. This button is also used to activate your
heated power mirrors (if equipped).
*
[CF09600(ALL)03/96]
To defrost the rear window:
[CF09700(ALL)03/96]
1. Clear any snow and/or ice from the rear
window.
*
[CF09800(ALL)03/96]
2. Get in your vehicle and start the engine.
[CF09900(ALL)01/96]
3. Press the rear defrost button. The indicator
light turns on.
[CF10000(ALL)01/96]
The defroster turns off automatically after 15 to
25 minutes. If the window is not clear, turn on
the defroster again. It will also automatically
shut off any time the engine is shut off.
%*
[CF10100(ALL)03/96]
NOTE: Never use sharp instruments or
window cleaners with abrasives to
clean the inside of your rear window.
If you do, you may damage the heating
elements that are bonded to the inside
of the rear window and cause damage
to the rear window defroster.
File:05prcfp.ex
Update:Tue Jun 11 11:03:33 1996
Page 60 of 288
57 [CF10120(ALL)05/96]
Rear Window Wiper and Washer
[CF10140(ALL)05/96]
The rear window wiper and washer buttons are
located on the instrument panel below the
climate control panel.
[CF10160(ALL)05/96]
one inch art:0032069-D[CF10180(ALL)05/96]
To operate the rear wiper, push the rear window
wiper button. Push the button a second time to
turn the wiper off. To operate the rear washer,
push and hold the rear window washer button
in. The washer will spray until the button is
released.
%*
[CF10182(ALL)05/96]
Fog Lamps (If equipped)
[CF10184(ALL)05/96]
The fog lamps only operate when the headlamps
are on low beam. To activate fog lamps, push
the button on the control panel below the
climate controls. An indicator light on the button
will illuminate. Push the button again to turn
the fog lamps off.
[CF10186(ALL)05/96]
quarter page art:0032079-E
Fog lamp button
File:05prcfp.ex
Update:Tue Jun 11 11:03:33 1996
