17
*
[IS05400(ALL)01/96]
The fuel gauge indicator may vary slightly while
the vehicle is in motion. This is the result of fuel
movement within the tank. You can get a more
accurate reading with the vehicle on smooth,
level ground.
[IS05500(ALL)01/96]
Charging System Gauge
[IS05600(ALL)01/96]
This gauge tells you your battery's voltage when
you turn your ignition key to ON. When you
start your engine, the pointer should move to
the NORMAL range if you are not operating
any electrical accessories. (If electrical accessories
are operating and the engine is not running, the
pointer may move into the red area).
[IS05700(ALL)01/96]
If the pointer moves into the red area when no
electrical accessories are operating, have the
vehicle's electrical system checked.
%*
[IS05800(ALL)04/96]
Engine Oil Pressure Gauge
[IS05900(ALL)01/96]
The gauge needle should stay in the NORMAL
range (indicating normal engine oil pressure). If
the needle drops below the NORMAL range into
the low range, there is a loss of oil pressure.
[IS06000(ALL)01/96]
If this happens:
*
[IS06100(ALL)04/96]
1. Pull off the road as soon as safely possible.
*
[IS06200(ALL)04/96]
2. Shut off the engine immediately or severe
engine damage could result.
[IS06300(ALL)01/96]
3. Check the oil level when the vehicle is on
level ground.
[IS06400(ALL)01/96]
4. Add only as much oil as the engine needs
before you drive the vehicle again. Do not
overfill the oil reservoir. For more
information, seeAdding engine oilin the
Index.
File:03prisp.ex
Update:Thu May 16 09:43:45 1996
Page 22 of 288
18 %
*
[IS06500(ALL)03/96]
Engine Coolant Temperature Gauge
*
[IS06600(ALL)02/96]
This gauge indicates the temperature of the
engine coolant, not the coolant level. If the
coolant is not at its proper level or mixture, the
gauge indication will not be accurate.
[IS06650(ALL)04/96]
The pointer usually moves from C (cold) into
the NORMAL band as your vehicle warms up.
Under most driving conditions, the pointer
should stay in the NORMAL band. If you are
driving in heavy traffic or on an extended grade
in hot weather, the pointer may reach to the top
of the NORMAL band.
*
[IS06700(ALL)04/96]
If, under any circumstances, the pointer moves
above the NORMAL band, the engine is
overheating and continued operation may cause
engine damage.
*
[IS06800(ALL)03/96]
If your engine overheats:
*
[IS06900(ALL)03/96]
1. Pull off the road as soon as it is safely
possible.
*
[IS07000(ALL)04/96]
2. Shut off the engine immediately or severe
engine damage could result.
*
[IS07100(ALL)01/96]
3. Let the engine cool.
*
[IS07200(ALL)01/96]
4. Check the coolant level following the
instructions on checking and adding coolant
to your engine. (SeeEngine coolantin the
Index.) If you do not follow these
instructions, you or others could be injured.
*
[IS07250(ALL)01/96]
For instructions on checking and adding coolant
to your engine, seeEngine coolantin the Index. If
you do not follow these instructions, you or
others could be injured.
File:03prisp.ex
Update:Thu May 16 09:43:45 1996
Page 23 of 288
19
*
[IS07300(ALL)04/96]
5. Refer toAdding Engine Coolantin the
Maintenance and Carechapter. Add as much
coolant as your engine needs. If the engine
continues to overheat, have the cooling
system serviced.
%*
[IS07500(ALL)03/96]
Speedometer
*
[IS07600(ALL)03/96]
The speedometer tells you how many miles
(kilometers) per hour your vehicle is moving.
%*
[IS07700(ALL)03/96]
Odometer
*
[IS07800(ALL)01/96]
The odometer tells you the total number of miles
(kilometers) your vehicle has been driven.
%*
[IS08000(ALL)01/96]
Trip Odometer
[IS08100(ALL)01/96]
Use the trip odometer to track your mileage.
Simply set the trip odometer to zero by pressing
the reset button.
%*
[IS09000(ALL)03/96]
Tachometer
[IS09100(ALL)01/96]
The tachometer indicates approximate engine
revolutions per minute, and is located on the
right-hand side of the instrument cluster. The
tachometer pointer may move slightly when the
key is placed in the ACC or ON position, with
the engine off. This pointer movement is normal,
and will not affect the accuracy of the
tachometer once the engine is running.
File:03prisp.ex
Update:Thu May 16 09:43:45 1996
Page 24 of 288
21
Electronic Sound Systems
*
[AS00950(ALL)08/95]
full page art:0060648-B
Compact Disc Radio
File:04prasp.ex
Update:Mon Jun 3 10:03:33 1996
Page 25 of 288
22
%*
[AS00975(ALL)10/95]
Compact Disc Radio
*
[AS01000(ALL)10/95]
The Compact Disc Radio combines the Electronic
Stereo Radio with the Ford Compact Disc Player.
*
[AS01300(ALL)08/95]
Using the Controls on Your New Radio/CD
Player
*
[AS01400(ALL)04/92]
Most of the features of this unit work for both
radio and CD operation, depending on which
mode the unit is in. Also, some of the buttons
control several different functions, so be sure to
read all of the operating instructions carefully.
*
[AS01500(ALL)03/96]
How to turn the radio on and off
*
[AS01600(ALL)10/95]
Press the ªPOWERº button to turn the radio on.
Press it again to turn it off.
*
[AS01625(ALL)03/96]
How to adjust the volume
*
[AS01650(ALL)03/96]
Press the (R/S) side of the ªVOLº button to
increase/decrease the volume. Bars illuminate in
the display to show the relative volume level.
*
[AS01675(ALL)02/96]
NOTE: If the volume level is set above a
certain listening level when the
ignition switch is turned off, when the
ignition switch is turned back on, the
volume will come back to a ªnominalº
listening level. However, if the radio
power is turned off, the volume will
remain in the position it was set at
when radio power was switched off.
*
[AS01700(ALL)03/96]
Selecting the AM or FM frequency band
*
[AS01800(ALL)10/95]
Push the ªAM/FMº button to select the desired
frequency band. When in the radio mode,
pushing the button more than once will alternate
between AM, FM1 and FM2. These functions are
used with the station memory buttons described
underHow to tune radio stations.
File:04prasp.ex
Update:Mon Jun 3 10:03:33 1996
Page 26 of 288
23 %
*
[AS01900(ALL)03/96]
How to tune radio stations
*
[AS02000(ALL)10/95]
There are four ways for you to tune in a
particular station. You can manually locate the
station using the ªSCAN/TUNEº button,
ªSEEKº the station, ªSCANº to the station or
select the station by using the memory buttons,
which you can set to any desired frequency.
These four methods are described below.
*
[AS02100(ALL)10/95]
q
Using the ªSCAN/TUNEº button to manually
tune
[AS02200(ALL)04/95]
You can change the frequency up or down
one increment at a time (FM changes in
increments of 200kHz; AM changes in
increments of 10kHz) by first pressing the
ªSCAN/TUNEº button twice (display shows
ªTUNEº), then Ðwithin approximately five
secondsÐpressing and releasing either the
top (
b) or bottom (
a) half of the ªSEEKº
button. To change frequencies quickly, press
andhold downeither the top or bottom half
of the ªSEEKº button.
*
[AS02300(ALL)03/96]
Manual tuning adjusts your radio to any
allowable broadcast frequency, whether or
not a station is present on that frequency.
(SeeAll About Radio Frequenciesin this
section.)
*
[AS02400(ALL)04/96]
q
Using the ªSEEKº function
*
[AS02500(ALL)04/96]
This feature on your radio allows you to
automatically select listenable stations up or
down the frequency band. Press the top (
a)
half of the ªSEEKº button to select the next
listenable station up the frequency band.
Press the bottom (
b) half of the button to
select the next listenable station down the
frequency band. By pressing and holding the
button, listenable stations can be passed over
to reach the desired station.
File:04prasp.ex
Update:Mon Jun 3 10:03:33 1996
Page 27 of 288
24
*
[AS02600(ALL)02/96]
q
Using the ªSCAN/TUNEº button to scan
radio stations
*
[AS02700(ALL)04/96]
Pressing the ªSCAN/TUNEº button once
enters the scan mode (display will indicate
ªSCNº). Pushing the top (
a) half of the
ªSEEKº button will begin the scan mode up
the frequency band, stopping on each
listenable station for approximately five
seconds. Pushing the bottom (
b) half of the
ªSEEKº button will begin the scan mode
down the frequency band, again stopping on
each listenable station for approximately five
seconds.
*
[AS02800(ALL)03/96]
To stop the scan mode on the presently
sampled station, press the ªSCAN/TUNEº
button again.
*
[AS03000(ALL)02/96]
q
Setting the Station Memory Preset buttons
%*
[AS03100(ALL)08/95]
Your radio is equipped with 5 station
memory buttons. These buttons can be used
to select up to 5 preset AM stations and 10
FM stations (5 in FM1 and 5 in FM2). Follow
the easy steps below to set these buttons to
the desired frequencies.
*
[AS03200(ALL)03/96]
1. Select a band, then select a frequency.
*
[AS03400(ALL)10/95]
2. Press one of the memory preset buttons and
hold the button until the sound returns. That
station is now held in memory on that
button.
*
[AS03500(ALL)10/95]
3. Follow the two steps above for each station
memory preset button you want to set.
*
[AS03601(ALL)03/96]
NOTE: If the vehicle's battery is disconnected,
the clock and station memory preset
buttons will need to be reset.
File:04prasp.ex
Update:Mon Jun 3 10:03:33 1996
Page 28 of 288
25
*
[AS03701(ALL)10/95]
q
Using the Automatic Memory Load feature
*
[AS03801(ALL)08/95]
You can activate theAuto Memory Load
feature by pressing and holding the ªAUTO
PRESETº buttonfor approximately three
seconds. Auto Memory Load sets all memory
buttons in AM, FM1 and FM2 sequentially by
seeking out the first five strong stations for
the respective band and storing them in
memory buttons 1-5. (FM2 will store the
second set of strong stations from the FM
band.)
*
[AS03901(ALL)05/96]
With Auto Memory Store, you can continually
set strong stations into your memory buttons
without losing your existing memory presets,
which is especially helpful while traveling. Your
radio will automatically set your memory
buttons to the strong local stations so you don't
have to continually manually tune to existing
stations.
*
[AS04001(ALL)02/96]
Activate Auto Memory Store by pushing the
ªAUTO PRESETº button once. Your radio will
set the first five strong stations of the band you
are in (AM, FM1 or FM2) into the memory
buttons. The display will show ªAUTO,º then
run through the frequencies, stopping
momentarily on the stations being set into the
memory buttons. The radio is now in the
ªAUTOº mode and the display will show
ªAUTOº each time a preset is activated.
*
[AS04101(ALL)10/95]
NOTE: If there are fewer than five strong
stations in the frequency band, the
remaining unfilled buttons will store
the last strong station detected on the
band.
*
[AS04201(ALL)03/96]
After all stations have been filled, the radio will
begin playing the station stored on memory
button 1.
File:04prasp.ex
Update:Mon Jun 3 10:03:33 1996
Page 29 of 288
26
*
[AS04301(ALL)02/96]
To deactivate the Auto Memory Store mode and
return to the manually-set memory button
stations (or those stations set using Auto
Memory Load), simply push the ªAUTO
PRESETº button. Display will show ªAUTOº
then ªOFF.º The next time Auto Memory Store
is activated on that band, the radio will store the
next set of five strong stations.
*
[AS04400(ALL)08/95]
Using the ªAUDIOº button to adjust the
tone balance and speaker output
*
[AS04500(ALL)02/96]
q
Increasing or decreasing bass response
*
[AS04600(ALL)08/95]
Push the ªAUDIOº button repeatedly until
the display reads ªBASS.º Push the ª+º side
of the ªVOLº button to increase bass (more
ªlowsº), and push the ª-º side to decrease
bass (less ªlowsº).
*
[AS04700(ALL)02/96]
q
Increasing or decreasing treble response
*
[AS04800(ALL)08/95]
Push the ªAUDIOº button repeatedly until
the display reads ªTREB.º Push the ª+º side
of the ªVOLº button to increase treble (more
ªhighsº), and push the ª-º side to decrease
treble (less ªhighsº).
*
[AS05100(ALL)02/96]
q
Adjusting speaker balance
*
[AS05200(ALL)08/95]
Balance control allows you to adjust the
sound distribution between the right and left
speakers. Push the ªAUDIOº button
repeatedly until the display reads ªBAL.º
Push the ª+º side of the ªVOLº button to
shift the sound to the right speakers, and
push the ª-º side to shift the sound to the
left speakers.
File:04prasp.ex
Update:Mon Jun 3 10:03:33 1996
Page 30 of 288
27
*
[AS05300(ALL)04/96]
q
Adjusting speaker fader
*
[AS05400(ALL)08/95]
Fade control allows you to adjust the sound
distribution between the front and rear
speakers. Push the ªAUDIOº button
repeatedly until the display reads ªFADE.º
Push the ª+º side of the ªVOLº button to
shift the sound to the front speakers, and
push the ª-º side to shift the sound to the
rear speakers.
*
[AS05500(ALL)09/95]
NOTE: Illuminated bars in the display show
relative levels of bass and treble and
positions of speaker balance and fader
functions after adjustments are made,
then revert to volume level set.
%*
[AS05600(ALL)08/95]
Clock operation
*
[AS05700(ALL)08/95]
When in the radio mode, push the ªCLOCKº
button to switch from radio frequency to clock.
Only the clock numerals will be displayed in the
clock mode Ð there is no A.M./P.M. indication.
When in the clock mode, the time will be
displayed until the button is pushed again.
However, if you retune the radio while it is in
the clock mode, the new radio frequency will be
displayed for approximately ten seconds and
then change back to clock.
*
[AS05800(ALL)08/95]
When in the CD mode, push the ªCLOCKº
button to change the display from elapsed time
mode to track number mode to clock mode. If
the CD track selection is changed when you are
in the clock or elapsed time mode, the new track
number will be displayed for approximately ten
seconds and then revert back to the previous
mode.
File:04prasp.ex
Update:Mon Jun 3 10:03:33 1996
