FORD RANGER 1998 2.G Owners Manual

ItemFord part
name or
equivalentFord part
numberFord
specification
Power steering fluid,
transfer case fluid and
transmission fluid
(manual)Motorcraft
MERCONt
AT FXT-2-QDX MERCONt
Automatic transmission
(4R44E and 5R55E)Motorcraft
MERCONtV
AT FXT-5-QM
MERCONtV
Windshield washer fluidUltra-clear
windshield
washer
concentrateC9AZ-
19550-ABESR-
M17P5-A
1Add 118 ml (4 oz.) of additive friction modifier C8AZ-19B546±A, Ford
specification EST-M2C118±A for complete refill of Traction-Lok axles.
ENGINE DATA
Engine 2.5L I4 engine 3.0L V6 engine 4.0L V6 engine
Cubic inches 153 182 245
Horsepower 119 @ 5000 rpm 150 @ 5000 rpm 160 @ 4200 rpm
Torque 146 lbs. ft. @
3000 rpm185 lbs. ft. @
3250 rpm225 lbs. ft. @
2750 rpm
Required fuel
grade87 octane 87 octane 87 octane
Firing order 1-3-4-2 1-4-2-5-3-6 1-4-2-5-3-6
Spark plug
gap1.07-1.17 mm
(0.042-.046 inch)1.07-1.17 mm
(0.042-.046 inch)1.3-1.4 mm
(0.052-.056 inch)
Ignition
systemEDIS EDIS EDIS
Compression
ratio9.4:1 9.14:1 9.0:1
Capacities and specifications
151

VEHICLE DIMENSIONS
Vehicle
dimensionsRegular Cab
Short Wheel
Base (SWB)
mm (in)Regular Cab
Long Wheel
Base (LWB)
mm (in)Supercab
mm (in)
(1) Overall length 4 763 (187.5) 5 093 (200.5) 5 153 (202.9)
(2) Overall width 1 785 (70.3) 1 785 (70.3) 1 785 (70.3)
(3) Overall height
4x2/4x41 575 (62.0) /
1 655 (65.2)1 586 (62.4) /
1 655 (65.2)1 585 (62.4) /
1 684 (66.3)
(4) Wheelbase 2 831 (111.4) 2 983 (117.4) 3 192 (125.7)
(5) Track - Front 1 486 (58.5) 1 486 (58.5) 1 485 (58.5)
(5) Track - Rear 1 455 (57.3) 1 455 (57.3) 1 455 (57.3)
2
5
3
Capacities and specifications
152

1
4
1
4
Capacities and specifications
153

IDENTIFYING YOUR VEHICLE
Safety compliance label
The National Highway Traffic Safety
Administration Regulations require
that a Safety Compliance
Certification Label be affixed to a
vehicle and prescribe where the
Safety Compliance Certification
Label may be located. The Safety
Compliance Certification Label is
located on the front door latch pillar
on the driver's side.
Vehicle identification number
The vehicle identification number is
attached to a metal tag and is
located on the driver side
instrument panel.
Engine number
The engine number (the last eight numbers of the vehicle identification
number) is stamped on the engine block, transmission, frame and
transfer case (if equipped).
MFD. BY FORD MOTOR CO. IN U.S.A.
EXT PNT: XXXXXX XXXXXX RC: XX DSO: XXXX F0000
BAR INT TR TP/PS R AXLE TR SPR T0000
X XX XXX X XX X XXXX
UTC
ÑFOHT-15294A10-GA
MAXIMUM LOAD=OCCUPANTS + LUGGAGE=XXXKG/XXXXLB
OCCUPANTS: X TOTAL X FR X 2ND X RR OCCUPANTS LUGGAGE
XX XXXKG/XXXXLB
TIRE: XXXX/XXXXX XXX X XXXKG/XXXXLB
PRESSURE (FR) XXX kPa/33 PSI COLD
PRESSURE (RR) XXX kPa/33 PSI COLD
TRAILER TOWING - SEE OWNER GUIDE
DATE: XXXXX GVWR:XXXXX LB/ XXXXX KG
VIN: XXXXXXXXXXXXXXXXX TYPE: XXXXXXXXXXXXXXX FGAWR: XXXXXX/XXXXXXX RGAWR: XXXXXXX/XXXXXXX
THIS VEHICLE CONFORMS TO ALL APPLICABLE FEDERAL
MOTOR VEHICLE SAFETY STANDARDS IN EFFECT ON THE
DATE OF MANUFACTURE SHOWN ABOVE.
XXXXXXXXXXXXXXXXX
AIR BAG
Capacities and specifications
154

REPORTING SAFETY DEFECTS (U.S. ONLY)
If you believe that your vehicle has
a defect that could cause a crash, or
could cause injury or death, you
should immediately inform the
National Highway Traffic Safety
Administration (NHTSA) in addition
to notifying Ford Motor Company.
If NHTSA receives similar complaints, it may open an investigation, and
if it finds that a safety defect exists in a group of vehicles, it may order a
recall and remedy campaign. However, NHTSA cannot become involved
in individual problems between you, your dealer or Ford Motor Company.
To contact NHTSA, you may either call the Auto Safety Hotline toll-free
at 1±800±424±9393 (202±366±0123 in the Washington D.C. area) or write
to:
NHTSA
U.S. Department of Transportation
400 Seventh Street
Washington D.C. 20590
You can also obtain other information about motor vehicle safety from
the Hotline.
Reporting safety defects
155
