FORD THUNDERBIRD 1996 10.G Owners Manual

148
*
[AS26900(MBC )02/95]
q
How to change the side of the tape being
played
*
[AS27000(MBC )03/95]
The alternate track (other side) of the tape
can be selected at any time by pushing both
fast-wind buttons (
hand
g) at the
same time.
*
[AS27100(MBC )02/95]
How to eject the tape
*
[AS27250(MBC )02/95]
To stop the tape and eject the cassette, press the
ªEJECTº button. The radio will resume playing.
*
[AS27300(MBC )02/95]
Using the DolbyHB noise reduction feature
*
[AS27400(MBC )02/95]
NOTE: Noise reduction system manufactured
under license from Dolby Labs
Licensing Corporation. ªDolbyº and
double-D symbol are trademarks of
Dolby Laboratories Licensing
Corporation.
*
[AS27500(MBC )05/95]
Push thekbutton to activate. Push again to
deactivate.
*
[AS27600(MBC )02/95]
Tips on Caring for the Cassette Player and
Tapes
*
[AS27700(MBC )02/95]
In order to keep your cassette tape player
performing the way it was meant to, read and
follow these simple precautions:
*
[AS27750(MBC )02/95]
q
Using a Ford Cassette Cleaning Cartridge to
clean the tape player head after 10-12 hours
of play will help maintain the best playback
sound and proper tape operation.
*
[AS27800(MBC )02/95]
q
Only cassettes that are 90 minutes long or
less should be used. Tapes longer than 90
minutes are thinner and subject to breakage
or may jam the tape player mechanism.
File:rcasb.ex
Update:Mon Feb 19 10:49:06 1996

149
*
[AS27900(MBC )02/95]
q
Protect cassettes from exposure to direct
sunlight, high humidity and extreme heat or
cold. If they are exposed to extreme
conditions, allow them to reach a moderate
temperature before playing.
*
[AS28001(MBC )02/95]
q
If a tape is loose inside the cassette, tighten it
before playing by putting your finger or a
pencil into one of the holes and turning the
hub until the tape is tight.
*
[AS28101(MBC )02/95]
q
Loose labels on cassette tapes can become
lodged in the mechanism. Remove any loose
label material before inserting a cassette.
*
[AS28200(MBC )03/95]
q
Do not leave a tape in the cassette tape
player when not in use. High heat in the
vehicle can cause the cassette to warp.
File:rcasb.ex
Update:Mon Feb 19 10:49:06 1996

150 % [AS43455( BC )02/95]
full page art:0060575-CHigh-Level Audio System
File:rcasb.ex
Update:Mon Feb 19 10:49:06 1996

151
*
[AS43458( BC )03/95]
High-Level Audio System
*
[AS43460(MBC )02/95]
Using the Controls on Your New Radio
*
[AS43470(MBC )04/95]
How to turn the radio on and off
*
[AS43480(MBC )04/95]
Press the ªPOWERº button to turn the radio on.
Press it again to turn it off.
*
[AS43500(MBC )04/95]
How to adjust the volume
*
[AS43510(MBC )04/95]
Press the +/± side of the ªVOLUMEº button to
increase/decrease volume. Bars illuminate in the
display to show the relative volume level.
*
[AS43520(MBC )04/95]
NOTE: If the volume level is set above a
certain listening level when the
ignition switch is turned off, when the
ignition switch is turned back on, the
volume will come back to a ªnominalº
listening level. However, if the radio
power is turned off (with the
ªPOWERº button), the volume will
remain in the position it was set at
when radio power is switched back on.
*
[AS43530(MBC )04/95]
Selecting the AM or FM frequency band
*
[AS43540(MBC )02/95]
Push the ªAM/FMº button to select the desired
frequency band or to stop/store cassette tape
(when in cassette mode). Pushing the button
more than once will alternate between AM, FM1
and FM2. These functions are used with the
station memory buttons described underHow to
tune radio stations.
File:rcasb.ex
Update:Mon Feb 19 10:49:06 1996

152 %
*
[AS43550(MBC )05/95]
How to tune radio stations
*
[AS43560(MBC )04/95]
There are four ways for you to tune in a
particular station. You can manually locate the
station using the ªSCAN/TUNEº button,
ªSEEKº the station, ªSCANº to the station or
select the station by using the memory buttons,
which you can set to any desired frequency.
These four methods are described below.
*
[AS43570(MBC )05/95]
q
Using the ªTUNEº function
*
[AS43580(MBC )03/95]
You can change the frequency up or down
one increment at a time (FM changes in
increments of 200 kHz; AM changes in
increments of 10 kHz) by first pressing the
ªSCAN/TUNEº button twice (display shows
ªTUNEº), then Ðwithin approximately five
secondsÐpressing and releasing either the
right (
a) or left (
b) side of the ªSEEKº
button. To change frequencies quickly, press
andhold downeither the right or left side of
the ªSEEKº button.
*
[AS43590(MBC )04/95]
Manual tuning adjusts your radio to any
allowable broadcast frequency, whether or
not a station is present on that frequency.
(SeeAll About Radio Frequenciesin this
section.)
*
[AS43600(MBC )04/95]
q
Using the ªSEEKº function
*
[AS43610(MBC )04/95]
This feature on your radio allows you to
automatically select listenable stations up or
down the frequency band. Press the right
(
a) side of the ªSEEKº button to select the
next listenable station up the frequency band.
Press the left (
b) side of the button to select
the next listenable station down the
frequency band. By holding the button down,
listenable stations can be passed over to reach
the desired station.
File:rcasb.ex
Update:Mon Feb 19 10:49:06 1996

153
*
[AS43630(MBC )01/95]
q
Using the ªSCANº function
*
[AS43640(MBC )03/95]
Pressing the ªSCAN/TUNEº button once
enters the scan mode (display will indicate
ªSCNº). Pushing the right (
a) side of the
ªSEEKº button will begin the scan mode up
the frequency band, stopping on each
listenable station for approximately a
five-second sampling. Pushing the left (
b)
side of the ªSEEKº button will begin the scan
mode down the frequency band, again
stopping on each listenable station for
approximately a five-second sampling.
*
[AS43650(MBC )04/95]
To stop the scan mode on the presently
sampled station press the ªSCAN/TUNEº
button again.
*
[AS43670(MBC )04/95]
q
Setting the Station Memory Preset buttons
*
[AS43680(MBC )02/95]
Your radio is equipped with 6 station
memory buttons. These buttons can be used
to select up to 6 preset AM stations and 12
FM stations (6 in FM1 and 6 in FM2).
*
[AS43690(MBC )02/95]
Follow the easy steps below to set these buttons
to the desired frequencies:
*
[AS43700(MBC )04/95]
1. Select a band, then select a frequency.
*
[AS43720(MBC )04/95]
2. Press one of the memory buttons and hold
the button until the sound returns. That
station is now held in memory on that
button.
*
[AS43730(MBC )04/95]
3. Follow the two steps above for each station
memory preset button you want to set.
File:rcasb.ex
Update:Mon Feb 19 10:49:06 1996

154
*
[AS43750(MBC )04/95]
q
Using the Automatic Memory Load feature
*
[AS43760(MBC )03/95]
If no stations are in memory preset, you can
activate theAuto Memory Loadfeature by
pressing and holding the ªAUTO PRESETº
buttonfor approximately three seconds.
Auto Memory Load sets all memory buttons
in AM, FM1 and FM2 sequentially by seeking
out the first six strong stations for the
respective band and storing them in memory
buttons 1-5. (FM2 will store the second set of
strong stations from the FM band.)
*
[AS43770(MBC )04/95]
With Auto Memory Store, you can
continually set strong stations into your
memory buttons without losing your existing
memory presets, which is especially handy
while traveling. Your radio will automatically
set your memory buttons to the strong local
stations so you don't have to continually
manually tune to existing stations.
*
[AS43780(MBC )02/95]
Activate Auto Memory Store by pushing the
ªAUTO PRESETº button once. Your radio
will set the first five strong stations of the
band you are in (AM, FM1 or FM2) into the
memory buttons. The display will show
ªAUTOº, then run through the frequencies,
stopping momentarily on the stations being
set into the memory buttons. The radio is
now in the ªAUTOº mode and this display
will show ªAUTOº each time a preset is
activated.
*
[AS43790(MBC )04/95]
NOTE: If there are less than five strong
stations in the frequency band, the
remaining unfilled buttons will store
the last strong station detected on the
band.
File:rcasb.ex
Update:Mon Feb 19 10:49:06 1996

155
*
[AS43800(MBC )04/95]
After all stations have been filled, the radio
will begin playing the station stored on
memory button 1.
*
[AS43810(MBC )04/95]
To deactivate the Auto Memory Store mode
and return to the manually-set memory
button stations (or those stations set using
Auto Memory Load), simply push the
ªAUTO PRESETº button. Display will show
ªAUTOº then ªOFFº. The next time Auto
Memory Store is activated on that band, the
radio will store the next set of five strong
stations.
*
[AS43830(MBC )02/95]
Adjusting the tone balance and speaker
output of your radio
*
[AS43850(MBC )04/95]
q
Increasing or decreasing bass response
*
[AS43860(MBC )02/95]
Push the ªAUDIOº button repeatedly until
the display reads ªBASS.º Push the right (+)
side of the ªVOLUMEº button to increase
bass (more ªlowsº), and push the left (s)
side to decrease bass (less ªlowsº).
*
[AS43870(MBC )04/95]
q
Increasing or decreasing treble response
*
[AS43880(MBC )02/95]
Push the ªAUDIOº button repeatedly until
the display reads ªTREB.º Push the right (+)
side of the ªVOLUMEº button to increase
treble (more ªhighsº), and push the left (s)
side to decrease treble (less ªhighsº).
*
[AS43890(MBC )04/95]
q
Adjusting speaker balance
*
[AS43900(MBC )02/95]
Balance control allows you to adjust the
sound distribution between the right and left
speakers. Push the ªAUDIOº button
repeatedly until the display reads ªBAL.º
Push the right (+) side of the ªVOLUMEº
button to shift the sound to the right
speakers, and push the left (s) side to shift
the sound to the left speakers.
File:rcasb.ex
Update:Mon Feb 19 10:49:06 1996

156
*
[AS44010(MBC )04/95]
q
Adjusting speaker fader
*
[AS44020(MBC )02/95]
Fade control allows you to adjust the sound
distribution between the front and rear
speakers. Push the ªAUDIOº button
repeatedly until the display reads ªFADE.º
Push the right (+) side of the ªVOLUMEº
button to shift the sound to the front
speakers, and push the left (s) side to shift
the sound to the rear speakers.
*
[AS44030(MBC )04/95]
NOTE: Illuminated bars in the display show
relative levels of bass and treble, and
positions of speaker balance and fader
functions (left to right, front to rear).
*
[AS44040(MBC )02/95]
Using the Controls of Your Cassette Tape
Player
*
[AS44050(MBC )04/95]
NOTE: Radio power must be on to use the
cassette tape player or eject a tape.
[AS44060(MBC )04/95]
NOTE: Adjust the volume, treble, bass, balance
and fader controls in the same manner
as for radio stations.
*
[AS44070(MBC )02/95]
How to insert a tape
*
[AS44080(MBC )02/95]
Your cassette tape player is equipped with
power loading. Once you insert a tape and push
slightly (with theopen edge to the right), the
loading mechanism draws the tape the rest of
the way in and play will begin after a
momentary tape tightening process. Display
indicates ªMº (for metal/CrO
2) while tape is
playing.
*
[AS44090(MBC )02/95]
NOTE: A cassette tape can be loaded and
stored with the ignition and radio
power off.
File:rcasb.ex
Update:Mon Feb 19 10:49:06 1996

157
*
[AS44100(MBC )02/95]
How to locate a desired track on the tape
*
[AS44110(MBC )02/95]
There are four ways to quickly locate a desired
selection on the tape. You can use the fast
forward, rewind, ªSEEKº or ªSCANº function.
Following are brief descriptions of each.
*
[AS44120(MBC )02/95]
q
Fast forwarding the tape
[AS44140(MBC )02/95]
To fast forward the tape, press the ªFFº
button. The radio will automatically begin
playing until fast forward is manually
stopped (by pushing the ªPLAY PROGº
button) or the end of the tape is reached.
*
[AS44160(MBC )01/95]
At the end of the tape, the direction
automatically reverses and plays the other
side of the tape.
[AS44170(MBC )02/95]
q
Fast rewinding the tape
[AS44180(MBC )02/95]
To rewind the tape, press the ªREWº button.
The radio will automatically begin playing
when rewind is manually stopped (by
pushing the ªPLAY PROGº button) or the
beginning of the tape is reached.
*
[AS44190(MBC )01/95]
q
Using the ªSEEKº function with your cassette
tape player
[AS44200(MBC )03/95]
While in the tape mode, push the right (
a)
side of the ªSEEKº button to seek forward to
the next selection on the tape. Push the left
(
b) side to seek the beginning of the current
tape selection.
*
[AS44210(MBC )03/95]
NOTE: If you want to restart a currently
playing tape selection, press the left
(
b) side of the ªSEEKº button after
approximately three seconds into the
current selection.
*
[AS44220(MBC )03/95]
Whirling sprockets in the display (l)
indicate the direction of tape travel.
File:rcasb.ex
Update:Mon Feb 19 10:49:06 1996
