FORD THUNDERBIRD 1996 10.G Owners Manual

178
*
[DR16900( ALL)04/94]
If you must drive through high water, drive
slowly. You may have limited traction or wet
brakes, so allow extra stopping distance because
your vehicle will not stop as quickly as usual.
*
[DR17000( ALL)01/95]
After you drive through the standing water,
apply your brakes gently several times as your
vehicle moves slowly. This helps to dry the
brakes.
%
*
[DR17100( ALL)03/95]
Driving With a Heavy Load
*
[DR17200( ALL)01/95]
There are limits to the amount of weight your
vehicle can carry or tow. The total weight of
your vehicle, plus the weight of the passengers
and cargo, should never be more than the Gross
Vehicle Weight Rating (GVWR). Also, the weight
that your vehicle carries over the front axle and
rear axle should never be more than the Gross
Axle Weight Rating (GAWR) for the respective
axle.
% [DR17300( ALL)05/94]
You can find your vehicle's GVWR and GAWR
on the Safety Compliance Certification Label on
the left front door lock facing or the door latch
post pillar.
*
[DR17400( ALL)01/95]
The weight limits of your vehicle's tires affect
the GVWR or GAWR limitations. Usage of
replacement tires with higher weight limit than
originals does not increase GVWR or GAWR.
Usage of lower capacity replacement tires may
lower GVWR and GAWR limitations.
*
[DR17500( ALL)02/95]
RWARNING
If the GVWR or the GAWR specified on
the Safety Compliance Certification Label
is exceeded, your vehicle may be damaged
or you may lose control and injure
someone.
File:rcdrb.ex
Update:Mon Feb 19 10:48:37 1996

179 %
*
[DR17503( ALL)01/95]
Limiting Your Vehicle's Load
*
[DR17506( ALL)01/95]
The load that you add to your vehicle must not
exceed the maximum load stated on the Safety
Compliance Certification Decal attached to the
left front door pillar.
*
[DR17509( ALL)01/95]
To figure the weight of your vehicle's load, add
the weights of:
*
[DR17512( ALL)01/95]
q
the driver and passengers
*
[DR17515( ALL)01/95]
q
luggage and any other items that you put in
your vehicle
*
[DR17518( ALL)01/95]
q
the tongue load of the loaded trailer
*
[DR17521( ALL)01/95]
q
the weight of any equipment that has been
added to your vehicle since it was delivered
to your dealer
*
[DR17524( ALL)01/95]
If you do not know the actual weights of these
items, use the following procedure to figure the
weight of a load:
*
[DR17527( ALL)01/95]
1. Weigh your vehicle without the driver,
passengers and luggage. You might take
your vehicle to a shipping company or an
inspection station for trucks.
*
[DR17530( ALL)01/95]
2. Then weigh your vehicle with the driver,
passengers and luggage.
*
[DR17533( ALL)01/95]
3. Subtract the first reading from the second to
figure the total weight of the load.
*
[DR17536( ALL)01/95]
After determining this load, you must also make
sure that the total weight of your vehicle, plus
the load it carries, is less than its GVWR. Also,
make sure that the weight your vehicle carries
over each axle is less than the GAWR for the
respective axle.
File:rcdrb.ex
Update:Mon Feb 19 10:48:37 1996

180
*
[DR17539( ALL)01/95]
If your vehicle exceeds the GVWR, remove cargo
from your vehicle accordingly. If your vehicle
exceeds the GAWR for either axle, shift the load
or remove cargo accordingly.
*
[DR17542( ALL)05/95]
RWARNING
Improper distribution of your vehicle's
load or carrying weight in excess of the
amount shown on the tire decal can cause
rapid tire wear or loss of vehicle control.
%
*
[DR17550(MBC )04/95]
Trailer Towing
*
[DR17650( ALL)01/95]
Your vehicle does not come from the factory
fully equipped to tow. No towing packages are
available through Ford or Lincoln/Mercury
dealers.
*
[DR17700( ALL)01/95]
Because towing a trailer puts extra strain on
your vehicle, you must follow certain
precautions for your safety and the good of your
vehicle:
*
[DR17800( ALL)01/95]
q
Stay within the load limits for towing your
vehicle. (SeeTrailer towing specificationsin this
chapter.)
*
[DR17900( ALL)01/95]
q
Carefully and thoroughly prepare your
vehicle for towing, making sure to use the
right equipment and to attach it properly.
(SeePreparing to Towin this chapter.)
*
[DR18000( ALL)01/95]
q
Use extra caution when driving your vehicle
while you tow. (SeeDriving while you towin
this chapter.)
*
[DR18100( ALL)01/95]
q
Service your vehicle more frequently if you
tow a trailer. (SeeServicing your vehicle if you
towin this chapter.)
File:rcdrb.ex
Update:Mon Feb 19 10:48:37 1996

181
*
[DR18175( ALL)01/95]
Ten to 15% of the loaded trailer's weight should
be on the tongue. However, the tongue load
should never exceed 10% of the maximum
weight that your vehicle can safely tow.
*
[DR18250( ALL)05/95]
RWARNING
Do not tow a trailer when the temporary
spare tire is being used.
[DR18300( ALL)12/94]
Your vehicle is classified as a light duty towing
vehicle. The amount of weight that you can
safely tow depends on the optional equipment
on your vehicle. See the following chart.
% [DR18400( ALL)03/90]
Trailer towing specifications
[DR18600( BC )03/95]
six pica chart:0010654-D*
[DR20900( ALL)01/95]
Preparing to Tow
*
[DR21000( ALL)01/95]
For your safety and for the good of your
vehicle, use the right equipment for the type of
trailer you tow. Also, make sure that all towing
equipment is properly attached to your vehicle.
If you are not certain that you are using the
right equipment in the proper manner, see your
Ford or Lincoln-Mercury dealer.
*
[DR21100( ALL)01/95]
Do not use hitches that clamp onto your
vehicle's bumper. The bumper is not designed to
bear the load.
*
[DR21125( ALL)01/95]
Always check the pressure in all your vehicle's
tires when preparing to tow (see inflation
recommendation on the tire label).
File:rcdrb.ex
Update:Mon Feb 19 10:48:37 1996

182 %
*
[DR21150( ALL)01/95]
Using the hitch
*
[DR21200(MBC )01/95]
Your vehicle uses aload carryinghitch. Because
this type of hitch places the tongue load of a
trailer on the rear wheels of your vehicle, you
must distribute the load in your trailer so that
only 10 to 15% of the total weight of the trailer
is on the tongue.
*
[DR21600( ALL)01/95]
Tie down the load so that it does not shift and
change the weight on the hitch. This will
prevent damage to your vehicle and make your
vehicle easier to handle.
%*
[DR21650( ALL)01/95]
Connecting the safety chains
*
[DR21700( ALL)01/95]
Always attach the trailer's safety chains to your
vehicle. They help protect your trailer if the
hitch breaks.
*
[DR21800( ALL)01/95]
To connect the trailer's safety chains:
*
[DR21900( ALL)01/95]
1. Cross the chains under the trailer tongue
and attach them to your vehicle's frame or
hook retainers. Never attach the safety
chains to your vehicle's bumper. The bumper
is not designed to bear the weight of a
trailer.
*
[DR22000( ALL)01/95]
2. Make sure that you leave enough slack in
the chains to allow you to turn corners.
*
[DR22100( ALL)01/95]
If you use a rental trailer, follow the instructions
that the rental agency gives you.
File:rcdrb.ex
Update:Mon Feb 19 10:48:37 1996

183 %
*
[DR22150( ALL)01/95]
Connecting the trailer's brakes
*
[DR22200( ALL)01/95]
Electric brakes and manual, automatic, or
surge-type hydraulic brakes are safe if you
install them properly and adjust them according
to the manufacturer's instructions. Be sure that
your trailer's brakes meet local and federal
regulations.
[DR22250( ALL)03/95]
If your vehicle is equipped with the optional
trailer tow package, provisions have been made
under the instrument panel for installation of an
electronic brake controller.
*
[DR22300( ALL)05/95]
RWARNING
Do not connect a trailer's hydraulic brake
system directly to your vehicle's brake
system. Your vehicle may not have
enough braking power and your chances
of having a collision greatly increase.
%*
[DR22350( ALL)01/95]
Connecting the trailer's lights
*
[DR22400( ALL)01/95]
Do not connect a trailer's lighting system
wiring directly to your vehicle's lighting system
wiring.To get the proper equipment for
hooking up your trailer's lights, see your local
trailer dealer and your Ford dealer. Be sure to
follow their instructions carefully.
[DR22450( ALL)03/95]
If your vehicle is equipped with the optional
trailer tow package, the proper lamp wiring and
equipment has been installed at the factory. The
trailer feed wire (supplied in a box in the
luggage compartment) needs a connector
compatible with your trailer prior to installation.
*
[DR22500( ALL)01/95]
If you do not install trailer lights correctly, you
may cause damage to the vehicle's lighting
system.
File:rcdrb.ex
Update:Mon Feb 19 10:48:37 1996

184 %
*
[DR22600( ALL)01/95]
Driving While You Tow
*
[DR22650( ALL)01/95]
Be especially careful when driving while you
tow a trailer. Never drive faster than 45 mph
(70 km/h) when you tow in hilly country on
hot days. Also, anticipate stops so that you can
brake gradually.
[DR22950(MBC )09/93]
If you tow in Overdrive while riding through
hilly country, your vehicle may frequently shift
between Overdrive and Third gears. To prevent
your vehicle from shifting too much, depress the
Transmission Control Switch (TCS). This will
also give the engine more power going up hills
and better engine braking going down hills.
%*
[DR23000( ALL)01/95]
If you use the speed control while you are
towing on very long, steep grades, the speed
control may shut off.
*
[DR23100( ALL)01/95]
Servicing your vehicle if you tow
*
[DR23200( ALL)08/93]
If you tow a trailer for a long distance, your
vehicle will need to be serviced more frequently
than usual. Refer to theMaintenance Schedule and
Recordbooklet for additional information.
File:rcdrb.ex
Update:Mon Feb 19 10:48:37 1996

185
Roadside Emergencies
%*
[RE00400( ALL)03/95]
Jump-Starting Your Vehicle
*
[RE00450( ALL)01/95]
Your vehicle's battery may die if you leave the
lights on or any electrical equipment on after
you turn the engine off. If this happens, you
may be able to jump-start from a booster battery
to start your vehicle.
*
[RE00500( ALL)02/95]
RWARNING
The gases around the battery can explode
if exposed to flames, sparks, or lit
cigarettes. An explosion could result in
injury or vehicle damage.
*
[RE00600( ALL)02/95]
RWARNING
To protect yourself when charging a
battery, always shield your face and eyes.
Make sure that you can breathe fresh air.
%*
[RE00700( ALL)05/95]
RWARNING
Applying too much pressure on the ends
when lifting a battery could cause acid to
spill. Lift the battery with a carrier or
with your hands on the opposite corners.
%*
[RE00800( ALL)05/95]
RWARNING
Batteries contain sulfuric acid which burns
skin, eyes, and clothing.
File:rcreb.ex
Update:Mon Feb 19 10:48:15 1996

186
*
[RE00900( ALL)05/95]
If the acid touches someone's skin, eyes, or
clothing, immediately flush the area with water
for at least 15 minutes. If someone swallows the
acid, have him or her drink lots of milk or water
first, then Milk of Magnesia, a beaten egg, or
vegetable oil. Call a doctor immediately.
*
[RE01000( ALL)03/95]
To avoid damaging your vehicle or your battery,
and to avoid injury to yourself, follow these
directions for preparing your vehicle to jump-start
and connecting the jumper cables in the order they
are given. If in doubt, call for road service.
*
[RE01100( ALL)03/95]
Preparing Your Vehicle
[RE01150( ALL)11/90]
NOTE: also see label on battery.
*
[RE01200( ALL)03/95]
1. Your vehicle has a 12-volt starting system, so
you need to use a 12-volt jumper system.
You will damage your starting motor,
ignition system, and other electrical parts if
you connect them to a 24-volt power supply
(either two 12-volt batteries in series or a
24-volt generator set).
*
[RE01300( ALL)03/95]
2. Do not disconnect the battery of the disabled
vehicle. You could damage the vehicle's
electrical system.
*
[RE01400( ALL)04/95]
3. Park the booster vehicle close to the hood of
the disabled vehicle.Make sure the vehicles
do not touch each other.Set the parking
brake on both vehicles and stay clear of the
engine cooling fan and other moving parts.
*
[RE01500( ALL)03/95]
4. Check all battery terminals and remove any
excessive corrosion before you attach the
jumper cables.
*
[RE01600( ALL)02/95]
5. Turn on the heater fan in both vehicles.
Turning on the fan helps protect the
electrical system from voltage surges. Turn
off all other switches and lights in both
vehicles to prevent possible damage to either
vehicle's electrical systems.
File:rcreb.ex
Update:Mon Feb 19 10:48:15 1996

187 %
*
[RE01700( ALL)05/95]
Connecting the jumper cables
*
[RE01800( ALL)03/95]
1. Connect one end of the first jumper cable to
the positive (+) terminal of the discharged
battery. (You can connect either jumper cable
to the positive (+) terminal, as long as you
use the same cable for both positive
terminals.) Most jumper cables have a red
cable and a black cable. The red cable is
generally used for the positive terminals and
the black for the negative ones.
*
[RE01900( ALL)04/95]
2. Connect the other end of the first cable to
the positive (+) terminal of the booster
battery.
*
[RE02000( ALL)03/95]
3. Connect one end of the second cable to the
negative (s) terminal of the booster battery
Ð NOT to the discharged battery.
[RE02100( ALL)01/95]
4. Connect the other end of that cable to a
good metallic surface on the engine or frame
of the disabled vehicle making sure it is
clear of any rotating engine components. The
following illustrations show where you can
find a metallic surface.
*
[RE02200( ALL)05/95]
RWARNING
Do not connect the end of the second
cable to the negative (s) terminal of the
battery to be jumped. A spark may cause
an explosion of the gases that surround
the battery.
File:rcreb.ex
Update:Mon Feb 19 10:48:15 1996
