FORD WINDSTAR 1996 1.G Owners Manual

Servicing Your Windstar
311
[SV07750(ALL)02/95]
We do not recommend gasolines labeled ªregularº that are sold
with octane ratings of 86 or even less in high altitude areas.
%*
[SV07850(ALL)05/95]
Do not be concerned if your vehicle sometimes knocks lightly.
However, if it knocks heavily under most driving conditions on
the recommended octane rating fuel, see your dealer or a
qualified service technician to prevent any engine damage.
%*
[SV07950(ALL)05/95]
Fuel quality
*
[SV08050(ALL)02/95]
If you are experiencing starting, rough idle, or hesitation
problems try a different brand of fuel. If the condition persists,
see your dealer or qualified service technician.
*
[SV08850(ALL)05/95]
It should not be necessary to add any aftermarket products to
your fuel tank if you continue to use a high-quality fuel.
File:wnsvs.ex
Update:Tue Mar 19 08:16:43 1996

312
%*
[SV08950(ALL)04/95]
Gasolines for clean air
*
[SV09050(ALL)05/95]
Ford approves the use of gasolines, including those
reformulated, that contain oxygenates such as ethanol (10%
maximum), and MTBE (15% maximum). If methanol is used, the
gasoline should contain no more than 5% with cosolvents.
%*
[SV10200(ALL)05/95]
Safety Information Relating to Automotive Fuels
*
[SV10300(ALL)05/95]
RWARNING
Automotive fuels can cause serious injury or death if
misused or mishandled.
*
[SV10400(ALL)05/95]
Gasoline and other automotive fuels are extremely flammable.
Turn your vehicle off and do not smoke while refueling your
vehicle. Keep sparks and other sources of ignition away from
fuels.
*
[SV10500(ALL)02/95]
Automotive fuels can be harmful or fatal if swallowed. Never
attempt to siphon any fuel by mouth.
*
[SV10600(ALL)02/95]
If any fuel is swallowed, call a physician or poison control
center immediately.Do not delay calling a physician merely
because no adverse effects are noticed at first; the toxic effects
of fuels may not become apparent for many hours.
File:wnsvs.ex
Update:Tue Mar 19 08:16:43 1996

Servicing Your Windstar
313
*
[SV10700(ALL)02/95]
If gasoline is swallowed, do not induce vomiting. If a
gasoline-methanol blend is swallowed, induce vomiting under
the direction of a physician or poison control center.
*
[SV10800(ALL)02/95]
Gasoline and gasoline-methanol blends may contain small
amounts of carcinogens, such as benzene. Long-term exposure to
unleaded gasoline vapors has caused cancer in laboratory
animals. Excessive inhalation of fuel vapors can cause headache,
dizziness, nausea, poor coordination, and other symptoms which
could interfere with your ability to safely operate your vehicle.
Avoid breathing vapors while refueling. If fuel vapors are
inhaled in excessive quantities, move the victim to fresh air and
seek medical attention.
*
[SV10900(ALL)02/95]
Fuels can also be harmful if absorbed through the skin. Be
careful not to splash fuel on yourself or your clothing. If fuel is
splashed on the skin, promptly remove contaminated clothing
and wash the skin thoroughly with soap and water.
*
[SV11000(ALL)05/95]
Fuels can cause severe eye irritation and possibly eye damage. If
fuel is splashed in the eyes, remove contact lenses (if worn),
flush with large amounts of water for 15 minutes, and seek
medical attention.
*
[SV11100(ALL)05/95]
You should be particularly careful if you are taking the
medication ªAntabuseº or other forms of disulfiram for the
treatment of alcoholism. There is a possibility that breathing the
vapors of a gasoline-methanol blend, or skin contact with such a
blend, may cause the same kind of adverse reaction as drinking
an alcoholic beverage. In sensitive individuals, serious personal
injury or sickness could result. Consult a physician promptly if
you experience an adverse reaction.
[SV12050(ALL)02/95]
NOTE: Avoid running out of fuel because this situation may
have an adverse effect on modern powertrain
components.
File:wnsvs.ex
Update:Tue Mar 19 08:16:43 1996

314
%*
[SV12100(ALL)05/95]
Running Out of Fuel
*
[SV12200(ALL)01/93]
If your vehicle runs out of fuel, try to stop on level ground
away from traffic. Add at least two gallons (8 liters) of fuel to
start your vehicle again. If your vehicle is not on level ground,
you may need as much as five gallons (20 liters) of fuel to start
it.
[SV12300(ALL)02/95]
You may need to turn the ignition to START several times
before engaging the starter (leaving it in that position several
seconds each time) before the fuel system starts to pump fuel
from the tank to the engine.
%*
[SV12400(ALL)05/95]
Fuel Economy
*
[SV12500(ALL)05/95]
Fuel economy is an estimate of the efficiency of your vehicle
and can be calculated as Miles Per Gallon (MPG) or Liters Per
100 Kilometers (L/100K).
*
[SV12600(ALL)01/93]
To calculate the fuel economy:
*
[SV12700(ALL)05/95]1.
Fill the tank completely and record the inital odometer
reading.
*
[SV12800(ALL)05/95]2.
Every time you buy fuel record the amount (in gallons or
liters) purchased.
*
[SV13000(ALL)01/93]3.
Divide the total number of miles that you have driven by
the total number of gallons that your vehicle has used. This
will give you the average numbers of miles per gallon.
*
[SV13100(ALL)05/93]
In metric, multiply the number of liters used by 100 and
divide the answer by the number of kilometers traveled. This
will give you the number of liters used per 100 km.
File:wnsvs.ex
Update:Tue Mar 19 08:16:43 1996

Servicing Your Windstar
315
*
[SV13200(ALL)01/93]
Comparisons With Environmental Protection Agency
(EPA) Fuel Economy Estimates
[SV13300(ALL)02/95]
EPA fuel economy figures are obtained from laboratory tests
under simulated road conditions and therefore are estimates
which may not reflect the actual conditions you experience. The
tests also do not exactly duplicate your personal style of
driving, including all your stops, starts, and lane changes. Other
factors that may affect fuel economy include using the air
conditioning, driving speed, vehicle load and tire inflation
pressure. The EPA fuel economy estimate is not a guarantee
that you will achieve the fuel economy shown.
%*
[SV13400(ALL)05/95]
Improving Fuel Economy
[SV13500(ALL)11/93]
You can improve the fuel economy for your vehicle in three
ways:
[SV13600(ALL)09/93]1.
Maintain your vehicle effectively. A well-tuned, properly
maintained vehicle gives you better fuel economy. Follow the
schedules for maintaining your vehicle that are in the
Maintenance Schedule and Recordbooklet.
[SV13700(ALL)02/95]2.
Drive your vehicle efficiently. Change your driving habits to
conserve fuel:
*
[SV13800(ALL)03/95]
n
Do not drive with your foot on the brake.
[SV13900(ALL)05/95]
n
Watch traffic so that you do not have to stop suddenly.
[SV14000(ALL)02/95]
n
Do not accelerate suddenly. Drive at a steady speed
whenever you can.
*
[SV14100(ALL)03/95]
n
Do not let the engine idle for a long time.
[SV14200(ALL)02/95]
n
Do not carry loads that are too heavy. To find out the limits
for the loads that your vehicle can carry, seeDriving with a
heavy loadin the Index.
File:wnsvs.ex
Update:Tue Mar 19 08:16:43 1996

316
[SV14300(ALL)02/95]
n
Keep the tires properly inflated. To find out the
recommended tire pressure, seeChecking the pressure of the
tireslater in this chapter.
[SV14400(ALL)02/95]
n
Use your air conditioning system wisely. To find out about
fuel economy and air conditioning, seeClimate control systems
in the Index.
[SV14500(ALL)02/95]
In addition to your individual driving habits, optional
equipment, such as air conditioning, can have a significant effect
on fuel economy. Various aftermarket add-on items that increase
aerodynamic drag can also reduce fuel economy.
%*
[SV14600(ALL)03/95]
Engine Oil Recommendations
*
[SV14750(ALL)04/95]
We recommend using Motorcraft oil or an equivalent oil
meeting Ford Specification ESE-M2C153-E and displaying the
American Petroleum Institute CERTIFICATION MARK on the
front of the container.
*
[SV14800(ALL)03/95]
Use only engine oils displaying the American Petroleum
Institute CERTIFICATION MARK on the front of the container:
*
[SV14850(ALL)05/94]
10-1/2 pica
art:0001314-A
The API Certification Mark
File:wnsvs.ex
Update:Tue Mar 19 08:16:43 1996

Servicing Your Windstar
317
*
[SV15000(ALL)01/95]
Neveruse:
*
[SV15100(ALL)01/95]
n
ªNon-Detergentº oils
*
[SV15200(ALL)04/95]
n
Oils labeled API SA, SB, SC, SD, SE, SF or SG
%*
[SV15300(ALL)01/95]
n
Additional engine oil additives, oil treatments or engine
treatments
%*
[SV15400(ALL)03/95]
Engine oils with anSAE 5W-30viscosity arePREFERREDfor
your vehicle. They provide the best engine performance, fuel
economy and engine protection for all climates down to-15ÊF
(-25ÊC).
%*
[SV15550(ALL)03/95]
Synthetic engine oils which are CERTIFIED and of the preferred
viscosity may be used in your engine. The engine oil and oil
filter must still be changed according to the maintenance
schedule.
%*
[SV15600(ALL)01/95]
Checking and Adding Engine Oil
*
[SV15700(ALL)03/95]
Since the proper amount of engine oil is important for safe
engine operation, check the oil using the dipstick each time you
put fuel in your vehicle. Remember the engine must be off, the
oil must be warm and the vehicle must be parked on level
ground.
%*
[SV15800(ALL)03/95]
Checking the engine oil level:
*
[SV15900(ALL)02/95]1.
Turn the engine off after it has warmed up and allow a few
minutes for the engine oil to drain back into the oil pan.
*
[SV16000(ALL)03/95]2.
Set the parking brake, making sure the gearshift is securely
latched in P (Park).
*
[SV16100(ALL)02/95]3.
Open the hood. Protect yourself from engine heat.
[SV16200(ALL)08/94]4.
Locate the dipstick labelled ªEngine Oilº and carefully pull it
out of the engine.
*
[SV16300(ALL)01/95]5.
Wipe the dipstick clean and put it back into position, making
sure it is fully seated.
File:wnsvs.ex
Update:Tue Mar 19 08:16:43 1996

318
[SV16400(ALL)02/95]
7-1/2 pica art:0050073-D
Engine oil dipstick
*
[SV16500(ALL)02/95]6.
Carefully, pull the dipstick out again. If the oil level is below
the ªADD 1 QT.º line, add engine oil as necessary. If the oil
level is beyond the letter ªFº in FULL, engine damage or
high oil consumption may occur and some oil must be
removed from the engine.
*
[SV16600(ALL)01/95]7.
Put the dipstick back in and make sure it is fully seated.
*
[SV16700(ALL)01/95]
It may be necessary to add some oil between oil changes. Make
sure you use a CERTIFIED engine oil of the preferred viscosity.
Your vehicle's warranty coverage may not apply if engine
damage is caused by the use of improper engine oil.
*
[SV16800(ALL)03/95]
Add engine oil through the oil filler cap highlighted in yellow.
To add oil, remove the filler cap and use a funnel to pour oil
into the opening. Be careful not to overfill the engine. Recheck
the oil level after you finish adding oil.
%*
[SV16900(ALL)01/95]
Changing the Engine Oil and the Oil Filter
*
[SV17200(ALL)04/95]
Refer to theMaintenance Schedule and Recordbooklet for
additional information.
% [SV18200(ALL)12/93]
NOTE: Always dispose of used automotive fluids in a
responsible manner. Follow your community's
standards for disposing of these types of fluids. Call
your local recycling center to find out about recycling
automotive fluids.
File:wnsvs.ex
Update:Tue Mar 19 08:16:43 1996

Servicing Your Windstar
319
*
[SV18300(ALL)05/95]
RWARNING
Continuous contact with USED motor oil has caused
cancer in laboratory mice.
*
[SV18320(ALL)05/95]
Protect your skin by washing with soap and water.
%*
[SV18400(ALL)03/95]
Engine Coolant
%*
[SV18500(ALL)02/95]
Checking the engine coolant
[SV18600(ALL)11/93]
Your vehicle's engine coolant protects the engine from
overheating in the summer and from freezing in the winter.
Check the level of the engine coolant at least once a month, but
preferably each time you stop for fuel. Simply check the coolant
reservoir, located in the engine compartment. The coolant
should stay slightly above the ªFULL COLDº mark.
*
[SV18700(ALL)01/95]
Adding engine coolant
*
[SV18900(ALL)05/95]
RWARNING
Do not put engine coolant in the container for the
windshield washer fluid.
*
[SV18920(ALL)05/95]
If sprayed to clean the glass, engine coolant or antifreeze could
make it difficult to see through the windshield.
File:wnsvs.ex
Update:Tue Mar 19 08:16:43 1996

320
[SV18950(ALL)11/93]
17-1/2 pica
art:0050025-B
Engine coolant recovery reservoir fill location
%*
[SV18975(ALL)01/95]
Use Ford Premium Cooling System Fluid or an equivalent
engine coolant that meets Ford Specification ESE-M97B44-A. Do
not use alcohol or methanol antifreeze and do not use engine
coolant mixed with alcohol or methanol antifreeze. If you do
not use the proper coolant, the aluminum radiator on your
vehicle will corrode.
*
[SV19000(ALL)01/93]
Whenever you remove the radiator cap, make sure that you also
check the condition of the radiator cap rubber seals. Make sure
they are clean and free of any dirt. Rinse off with water, if
necessary. When you replace the radiator cap, make sure the
radiator filler neck seats are clean. Also check that the overflow
hose is not kinked or turned in such a way that prevents an
easy flow.
File:wnsvs.ex
Update:Tue Mar 19 08:16:43 1996
