Starting the Engine
[ST05500(ALL)02/95]
To start the engine:
[ST05600(ALL)02/95]1.
Follow the steps underPreparing to Start Your Vehicleand
underTesting the Warning Lightsin this section.
*
[ST05700(ALL)01/93]2.
Keep your foot on the brake pedal and turn the ignition key
to ON.
[ST05800(ALL)02/95]3.
DO NOT depress the accelerator pedal when starting your
engine. DO NOT use the accelerator until after the engine is
running and you are ready to drive away.
[ST05900(ALL)02/95]4.
Turn the key to the START position until the engine starts.
(Release the key after the engine has started and it will
return to the ON position.)
[ST06000(ALL)02/95]
If you have difficulty in turning the key, rotate the steering
wheel slightly to relieve any binding.
%*
[ST06600(ALL)04/94]
For a cold engine:
*
[ST06700(ALL)04/95]
n
At temperatures10ÊF (-12ÊC) andbelow:If the engine does
not start infifteen (15) secondson the first try, turn the key
to OFF, wait approximately ten (10) seconds so you do not
flood the engine, then try again.
*
[ST06800(ALL)04/95]
n
At temperaturesabove10ÊF(-12ÊC):If the engine does not
start infive (5) secondson the first try, turn the key to OFF,
wait approximately ten (10) seconds so you do not flood the
engine, then try again.
*
[ST06900(ALL)04/94]
For a warm engine:
*
[ST07000(ALL)04/95]
n
Do not hold the key in the START position for more than
five (5) secondsat a time. If the engine does not start within
five (5) seconds on the first try, turn the key to the OFF
position. Wait a few seconds after the starter stops, then try
again.
File:wnsts.ex
Update:Tue Mar 19 08:25:19 1996

Starting Your Windstar
59
*
[ST07030(ALL)04/95]
Whenever you start your vehicle, release the key as soon as the
engine starts. Excessive cranking could damage the starter or
flood the engine.
*
[ST07060(ALL)02/95]
After you start the engine, let it idle for a few seconds.Keep
your foot on the brake pedaland release the parking brake.
Put the gearshift lever in gear, slowly release the brake pedal
and drive away in the normal manner.
*
[ST07090(ALL)02/95]
NOTE: Your vehicle has an interlock that prevents you from
shifting out of P (Park) unless your foot is on the
brake pedal.
*
[ST07200(ALL)03/95]
If the engine still does not start after two attempts:
*
[ST07300(ALL)03/95]1.
Turn the key to the OFF position and wait about two
minutes.
*
[ST07400(ALL)04/95]2.
Press the accelerator all the way to the floor and hold it.
[ST07500(ALL)02/95]3.
Turn the key to the START position.
[ST07600(ALL)02/95]4.
Release the key when the engine starts.
[ST07700(ALL)02/95]5.
Release the accelerator gradually as the engine speeds up.
Then drive away in the normal manner.
*
[ST07800(ALL)04/95]
If the engine still does not start, the fuel pump shut-off switch
may have been triggered. For directions on how to reset the
switch seeFuel Pump Shut-Off Switchlater in this chapter.
[ST07900(ALL)02/95]
A computer system controls the engine's idle rpm. When you
start your vehicle, the engine's idling rpm normally runs high.
These faster engine speeds will make your vehicle move slightly
faster than when the engine is at its normal warm engine idle
speed. It should, however, slow down when the vehicle warms
up. If it does not, have the idle rpm checked.
File:wnsts.ex
Update:Tue Mar 19 08:25:19 1996

60
*
[ST08100(ALL)05/95]
RWARNING
Do not park, idle, or drive your vehicle in dry grass or
other dry ground cover. The emission system heats up
the engine compartment and exhaust system, which can
start a fire.
%*
[ST08300(ALL)03/95]
Using the Engine Block Heater (If equipped)
(Standard in Canada)
[ST08400(ALL)03/94]
Using your engine block heater is strongly recommended if you
live in a region where temperatures consistently reachs20ÊF
(s29ÊC) orbelow during the winter months. An engine block
heater warms the engine coolant which improves starting,
warms up the engine faster, and allows the heater-defrost
system to respond more quickly.
*
[ST08600(ALL)05/95]
RWARNING
To prevent electrical shock, do not use your heater with
ungrounded electrical systems or two-pronged (cheater)
adapters.
*
[ST08700(ALL)01/93]
For best results, plug the heater in at least three hours before
you start your vehicle. Using the heater for longer than three
hours will not damage the engine, so you can leave it plugged
in all night to start your vehicle the following morning.
File:wnsts.ex
Update:Tue Mar 19 08:25:19 1996

Starting Your Windstar
61
%*
[ST09900(ALL)02/95]
What To Do If The Engine Does Not Start
%*
[ST10000(ALL)02/95]
Fuel Pump Shut-Off Switch
*
[ST10100(ALL)03/95]
If the engine cranks but does not start or does not start after a
collision, the fuel pump shut-off switch may have been
triggered. The shut-off switch is a device intended to stop the
fuel pump when your vehicle has been involved in a substantial
jolt.
*
[ST10200(ALL)03/95]
Once the shut-off switch is triggered, you must reset the switch
by hand before you can start your vehicle.
[ST10300(ALL)06/94]
The fuel pump shut-off switch reset button is located behind the
jack access cover under the jack in the cargo compartment.
[ST10400(ALL)02/94]
10-1/2 pica
art:0050046-A
Fuel pump shut-off switch reset button location
*
[ST10500(ALL)05/95]
RWARNING
If you see or smell fuel, do not reset the switch or try to
start your vehicle. Have all the passengers get out of the
vehicle and call the local fire department or a towing
service.
File:wnsts.ex
Update:Tue Mar 19 08:25:19 1996

62
*
[ST10600(ALL)02/95]
If your engine cranks, but does not start after a collision:
*
[ST10700(ALL)02/95]1.
Turn the key in the ignition to the OFF position.
*
[ST10800(ALL)03/95]2.
Check under the vehicle for leaking fuel.
*
[ST10900(ALL)02/95]3.
If you do not see or smell fuel, push the fuel pump shut-off
reset button down. If the red button is already set, you may
have a different mechanical or electrical problem.
*
[ST11000(ALL)02/95]4.
Turn the ignition key to the ON position for a few seconds,
then turn it to the OFF position.
*
[ST11100(ALL)02/95]5.
Check under the vehicle again for leaking fuel. If you see or
smell fuel, do not start your vehicle again. If there is no fuel,
you can try to start your vehicle again.
*
[ST11200(ALL)02/95]6.
Check all vehicle warning lights before driving your vehicle.
%*
[ST11300(ALL)02/95]
Guarding Against Exhaust Fumes
[ST11400(ALL)02/95]
Carbon monoxide, although colorless and odorless, is present in
exhaust fumes.
*
[ST11500(ALL)02/95]
RWARNING
Never let your vehicle idle in an enclosed area, and do
not sit in a parked vehicle, (with the engine running) for
more than a short period of time. Exhaust fumes,
particularly carbon monoxide, might build up. These
fumes are harmful and could kill you.
*
[ST11600(ALL)02/95]
RWARNING
If you ever smell exhaust fumes of any kind inside your
vehicle, have your dealer inspect and fix your vehicle
immediately. Do not drive if you smell exhaust fumes.
These fumes are harmful and could kill you.
File:wnsts.ex
Update:Tue Mar 19 08:25:19 1996

Starting Your Windstar
63
*
[ST11700(ALL)02/95]
Have the exhaust and body ventilation systems checked by a
qualified technician whenever:
*
[ST11800(ALL)02/95]
n
your vehicle is raised for service
*
[ST11900(ALL)02/95]
n
the sound of the exhaust system changes
*
[ST12000(ALL)02/95]
n
your vehicle has been damaged in an accident
[ST12100(ALL)02/95]
If the exhaust system has any indications of leaks it should be
repaired immediately.
*
[ST12200(ALL)02/95]
Improve your ventilation by keeping all air intake vents clear of
snow, leaves, and other objects.
[ST12300(ALL)02/95]
If the engine idles while you are stopped in an open area for
long periods of time, open the windows at least one inch. Also,
adjust the heating or air conditioning to bring in outside air.
*
[ST12400(ALL)02/95]
Read the sectionClimate Control Systemsfor instructions on
bringing fresh outside air into your vehicle. Refer to the Index.
File:wnsts.ex
Update:Tue Mar 19 08:25:19 1996

65
Warning Lights and Gauges
%*
[LG00250(ALL)01/95]
The instrument panel (dashboard) on your vehicle is divided
into several different sections. The illustrations on the following
pages show the major parts of the instrument panel that are
described in this chapter. Some items shown may not be on all
vehicles.
*
[LG00270(ALL)02/95]
Your vehicle has one of the following clusters:
[LG00290(ALL)06/94]
n
Mechanical Cluster
[LG00300(ALL)05/89]
n
Mechanical Cluster with a tachometer
[LG00320(ALL)10/93]
n
Electronic Cluster
*
[LG00330(ALL)05/94]
If you are not sure which cluster your vehicle has, check the
diagrams on the following pages.
File:wnlgs.ex
Update:Tue Mar 19 08:25:03 1996

66
[LG00401(ALL)04/95]
33-1/2 pica
art:0050230-C
Mechanical Cluster
File:wnlgs.ex
Update:Tue Mar 19 08:25:03 1996

Warning Lights and Gauges
67
[LG00450(ALL)04/95]
33-1/2 pica art:0050127-F
The mechanical cluster with tachometer
File:wnlgs.ex
Update:Tue Mar 19 08:25:03 1996

68
%*
[LG00475(ALL)06/94]
The Mechanical Cluster
[LG00501(ALL)06/94]
The following warning lights and gauges are on the Mechanical
Cluster. All of these indicators alert you to the status of vehicle
systems or possible problems with your vehicle. Some of the
lights listed are optional. The following section explains each of
the indicators.
[LG00600(ALL)12/93]
Warning and Indicator Lights
%*
[LG00900(ALL)03/95]
Brake System Light
[LG01000(ALL)11/93]
The warning light for the brakes indicates two things Ð that
either the parking brake is on or not fully released, or that the
brake fluid level is low in the master cylinder reservoir. If the
fluid level is low, the brake system should be checked by a
qualified service technician.
[LG01100(ALL)11/93]
6 pica art:0050144-B
The brake system light
[LG01200(ALL)12/93]
The BRAKE light normally comes on when you turn the
ignition key to the ON or START position to verify that the
indicator bulb is working. If the light stays on or comes on
when the engine is running and after you have released the
parking brake fully, have the hydraulic brake system serviced.
*
[LG01300(ALL)05/95]
RWARNING
The BRAKE light indicates that the brakes may not be
working properly. Have the brakes checked immediately.
