FORD WINDSTAR 1997 1.G Owners Manual

Driving
241
[GF16600(ALL)01/96]
Complete the following steps to start your vehicle after it has
been parked on a grade:
[GF16700(ALL)01/96]1.
Apply the foot service brake pedal and hold.
*
[GF16800(ALL)03/96]2.
Start the engine.
*
[GF16900(ALL)01/96]3.
Shift the gearshift lever into gear and release the parking
brake.
[GF17000(ALL)01/96]4.
Release the foot service brake pedal and move the vehicle
uphill to free the wheel chocks.
[GF17100(ALL)01/96]5.
Apply the foot service brake pedal and hold while another
person retrieves the chocks.
%*
[GF17200(ALL)01/96]
Four Season Roof Rack (If equipped)
[GF17300(ALL)12/95]
Always load your luggage as far back as it will safely go on the
four season roof rack. Do not load more than 165 pounds
(75 kg) on the roof rack structure or 100 pounds (45 kg) on the
roof panel slats. Be careful that your vehicle does not exceed the
Gross Vehicle Weight Rating (GVWR) or its Gross Axle Weight
Rating (GAWR front and rear). The GVWR and GAWR are
located on the Safety Compliance Certification Label (located on
the driver's door pillar).
[GF17400(ALL)12/95]
7-1/2 pica art:0050109-A
The four season roof rack
File:09wngfs.ex
Update:Thu Jul 18 11:01:42 1996

242
[GF17500(ALL)12/95]
The rear cross-bar can be adjusted forward and backward. Place
your luggage between the bars, adjust the rear bar, and secure
the luggage with rope to the bars. Items carried on the roof
rack must be properly secured before driving your vehicle.
[GF17600(ALL)12/95]
10-1/2 pica
art:0050032-B
The adjustable cross-bar
%*
[GF17700(ALL)01/96]
Driving Under Special Conditions
%*
[GF17800(ALL)01/96]
Tips for Safe Driving
[GF17900(ALL)04/96]
As with any new vehicle, yours may drive and handle
differently from your previous vehicle. Use greater care until
you become accustomed to its features and driving
characteristics.
[GF18000(ALL)04/96]
Always operate your vehicle within reasonable limits. Abrupt
changes in acceleration, deceleration, turning, or combinations of
these maneuvers can cause a vehicle to behave differently than
anticipated, especially when road conditions vary.
[GF18100(ALL)04/96]
For example, even with anti-lock brakes, extreme braking can
make it difficult to control the direction of the vehicle. Use a
ªsqueezeº technique. Push on the brake pedal with steadily
increasing force. This allows the wheels to brake, yet continue to
roll so that you may steer in the direction you want to travel.
File:09wngfs.ex
Update:Thu Jul 18 11:01:42 1996

Driving
243
WARNING
Drivingtoo fas tfo rcondition screate sth epossibilit yof
WARNING
Do no tspi nthewheel sat ove r35 mp h(55 km/h) .The

244
WARNING
To avoi dskiddin gan dlosin gcontro lon slipper yroads,
WARNING
Th eAnti-Loc kBrak eSyste mma yno tpreven tbrake

Driving
245
WARNING
Do no texcee dtheGVW Ror th eGAW Rspecifie don the

246
%*
[GF21500(ALL)01/96]
Towing a Trailer
*
[GF21600(ALL)01/96]
Towing a trailer puts an additional load on your vehicle's
engine, transaxle, axle, brakes, tires and suspension. For your
safety and for the good of your vehicle, use the right equipment
for the type of trailer you tow.
*
[GF21700(ALL)01/96]
n
Stay within the load limits when you tow.
*
[GF21800(ALL)01/96]
n
Carefully and thoroughly prepare your vehicle for towing,
making sure to use the right equipment and to attach it
properly. SeePreparing to Towin this section.
*
[GF21900(ALL)01/96]
n
Use extra caution when driving your vehicle while you tow.
SeeDriving While You Towin this section.
*
[GF22000(ALL)01/96]
n
Service your vehicle more frequently if you tow a trailer. See
Servicing Your Vehicle if You Towin this section.
*
[GF22100(ALL)01/96]
Do not tow a trailer until your vehicle has been driven at least
500 miles (800 km).
File:09wngfs.ex
Update:Thu Jul 18 11:01:42 1996

247
Roadside Emergencies
*
[ER00200(ALL)01/96]
The hazard flasher is used to alert other drivers to hazardous
situations.
*
[ER00300(ALL)01/96]
The hazard flasher switch operates the same lamps as the turn
signal lever. When the hazard flasher is activated, all of these
lamps will flash on and off. The turn signal indicators cannot be
used when the hazard lamps are flashing. Operation of the
hazard flashers does not affect operation of the brakelamps.
*
[ER00400(ALL)01/96]
The flashers work even with the key out of the ignition. The
flashers will work for up to two hours when the battery is fully
charged and in good condition. They will not drain the battery
excessively. If the flashers run for longer than two hours or if
your battery is not fully charged, your battery may be drained
to the point where the vehicle will not start.
%*
[ER00500(ALL)01/96]
What To Do If The Engine Does Not Start
%*
[ER00600(ALL)01/96]
Fuel Pump Shut-Off Switch
*
[ER00700(ALL)03/96]
If the engine cranks but does not start or does not start even
after a small collision, the fuel pump shut-off switch may have
been activated. The shut-off switch is a device intended to stop
the fuel pump when your vehicle has been involved in a
substantial jolt.
*
[ER00800(ALL)03/96]
Once the shut-off switch is activated, you must reset the switch
by hand before you can start your vehicle.
[ER00900(ALL)12/95]
The fuel pump shut-off switch reset button is located behind the
jack access cover under the jack in the cargo compartment.
File:10wners.ex
Update:Tue Jul 9 12:14:55 1996

248
[ER01010(ALL)01/96] If th eengin ecrank sbu tdoe sno tstar tor if yo uhav eha da
WARNING
If yo useeor smel lfuel ,do no trese tth eswitc hor try to

Roadside Emergencies
249
*
[ER01600(ALL)01/96]4.
Turn the ignition key to the ON position for a few seconds,
then turn it to the OFF position.
*
[ER01700(ALL)01/96]5.
Check under the vehicle again for leaking fuel. If you see or
smell fuel, do not start your vehicle again. If there is no fuel,
you can try to start your vehicle again.
*
[ER01800(ALL)03/96]6.
Check all vehicle warning lights before driving your vehicle.
[ER01900(ALL)01/96]
Fuses and Maxi-Fuses
[ER02000(ALL)01/96]
Fuses and maxi-fuses (high-current fuses) protect your vehicle's
electrical system from overloading. If electrical parts in your
vehicle are not working, the system may have been overloaded
and caused a blown fuse. Before you replace or repair any
electrical parts, check the appropriate fuses.
[ER02100(ALL)01/96]
17-1/2 pica
art:0050026-A
Fuse panel location
File:10wners.ex
Update:Tue Jul 9 12:14:55 1996

250
[ER02200(ALL)01/96]
The following charts tell you which fuses protect each electrical
part of your vehicle. If a fuse blows (opens) a circuit, all the
parts of your vehicle that use that circuit will not work.
[ER02300(ALL)01/96]
Once you have determined which fuses to check, follow the
procedures underChecking and replacing fuses.
[ER02400(ALL)04/96]
NOTE: Fuse links should only be repaired by your dealer.
%*
[ER02500(ALL)01/96]
Checking and Replacing Fuses
*
[ER02600(ALL)01/96]
If you need to check a fuse, find the fuse panel for the electrical
system, which is located under the instrument panel, and follow
these steps:
*
[ER02700(ALL)01/96]1.
To remove the fuse panel cover, pull down on the fuse panel
cover handle.
[ER02800(ALL)01/96]
17-1/2 pica
art:0050027-A
Fuse puller tool location Ð fuse panel cover
