Page 110 of 434
GMC Terrain/Terrain Denali Owner Manual (GMNA-Localizing-U.S./Canada/
Mexico-12146071) - 2019 - crc - 7/27/18
Storage 109
Storage
Storage Compartments
Storage Compartments . . . . . . . 109
Glove Box . . . . . . . . . . . . . . . . . . . . 109
Cupholders . . . . . . . . . . . . . . . . . . . 109
Center Console Storage . . . . . . 109
Additional Storage Features
Cargo Cover . . . . . . . . . . . . . . . . . . 110
Cargo Tie-Downs . . . . . . . . . . . . . 111
Convenience Net . . . . . . . . . . . . . 111
Roof Rack System
Roof Rack System . . . . . . . . . . . . 111
Storage
Compartments
{Warning
Do not store heavy or sharp
objects in storage compartments.
In a crash, these objects may
cause the cover to open and
could result in injury.
Glove Box
Open the glove box by lifting up on
the lever.
Cupholders
Two cupholders are in the center
console. Cupholders may be located
in the second row seat armrest. To
access, pull the armrest down.
Center Console Storage
There is storage in the center
console; lift the lever on the front
to open.
If equipped, there are two USB
ports for data and charging.
Page 176 of 434
GMC Terrain/Terrain Denali Owner Manual (GMNA-Localizing-U.S./Canada/
Mexico-12146071) - 2019 - crc - 7/27/18
Climate Controls 175
Air Vents
Use the louvers located on the air
vents to change the direction of the
airflow.
To open or close off the airflow:
.On the center air vents, move
the slider knobs up or down.
. On the outer and rear air vents,
move the slider knobs right
or left.
Operation Tips
. Clear away any ice, snow,
or leaves from air inlets at the
base of the windshield that could
block the flow of air into the
vehicle.
. Clear snow off the hood to
improve visibility and help
decrease moisture drawn into
the vehicle, which may improve
long term system performance.
. Keep the path under the front
seats clear of objects to help
circulate the air inside of the
vehicle more effectively. .
Use of non-GM approved hood
deflectors can adversely affect
the performance of the system.
Check with your dealer before
adding equipment to the outside
of the vehicle.
. Do not attach any devices to the
air vent slats. This restricts
airflow and may cause damage
to the air vents.
Maintenance
Passenger Compartment
Air Filter
The filter removes dust, pollen, and
other airborne irritants from outside
air that is pulled into the vehicle.
The filter should be replaced as part
of routine scheduled maintenance.
See Maintenance Schedule 0378.
To find out what type of filter to use,
see Maintenance Replacement
Parts 0388.
1. Open the glove box.
Page 177 of 434
GMC Terrain/Terrain Denali Owner Manual (GMNA-Localizing-U.S./Canada/
Mexico-12146071) - 2019 - crc - 7/27/18
176 Climate Controls
2. Disconnect the glove box doordamper (1) from the glove box
door assembly by squeezing
the pivot (2) to release the
damper ring.3. Squeeze both sides of theglove box bin inward to lower
beyond the stops.
4. Remove the two screwssecuring the door.
5. Press the latches on either side of the service door inward to
release. Open the service door
and remove the old filter.
6. Install the new air filter.
7. Close the service door completely.
8. Reverse the steps to reinstall the glove box.
See your dealer if additional
assistance is needed.
Service
All vehicles have a label underhood
that identifies the refrigerant used in
the vehicle. The refrigerant system
should only be serviced by trained
and certified technicians. The air
conditioning evaporator should
never be repaired or replaced by
one from a salvage vehicle.
It should only be replaced by a new
evaporator to ensure proper and
safe operation.
Page 392 of 434
GMC Terrain/Terrain Denali Owner Manual (GMNA-Localizing-U.S./Canada/
Mexico-12146071) - 2019 - crc - 7/27/18
Technical Data 391
Technical Data
Vehicle Identification
Vehicle IdentificationNumber (VIN) . . . . . . . . . . . . . . . 391
Service Parts Identification Label . . . . . . . . . . . . . . . . . . . . . . . . 391
Vehicle Data
Capacities andSpecifications . . . . . . . . . . . . . . . 392
Engine Drive Belt Routing . . . . 394
Vehicle Identification
Vehicle Identification
Number (VIN)
This legal identifier is in the front
corner of the instrument panel, on
the driver side of the vehicle. It can
be seen through the windshield from
outside. The Vehicle Identification
Number (VIN) also appears on the
Vehicle Certification and Service
Parts labels and certificates of title
and registration.
Engine Identification
The eighth character in the VIN is
the engine code. This code
identifies the vehicle's engine,
specifications, and replacement parts. See
“Engine Specifications”
under Capacities and Specifications
0 392 for the vehicle's engine code.
Service Parts
Identification Label
There may be a label on the inside
of the glove box that contains the
following information:
.
Vehicle Identification
Number (VIN)
. Model designation
. Paint information
. Production options and special
equipment
If there is no label, there is a
barcode on the certification label on
the center (B) pillar to scan for this
same information.
Page 426 of 434
GMC Terrain/Terrain Denali Owner Manual (GMNA-Localizing-U.S./Canada/-
Mexico-12146071) - 2019 - crc - 7/27/18
Index 425
Flashers, Hazard Warning . . . . . . 164
Flat Tire . . . . . . . . . . . . . . . . . . . . . . . . 345Changing . . . . . . . . . . . . . . . . . . . . . 354
Floor Mats . . . . . . . . . . . . . . . . . . . . . . 375
Fluid Automatic Transmission . . . . . . 299
Brakes . . . . . . . . . . . . . . . . . . . . . . . . 308
Diesel Exhaust . . . . . . . . . . . . . . . . . 28
Washer . . . . . . . . . . . . . . . . . . . . . . . 307
Fog Lamps . . . . . . . . . . . . . . . . . . . . . 165
Folding Mirrors . . . . . . . . . . . . . . . . . . 51
Folding Seatback . . . . . . . . . . . . . . . . 66
Forward Automatic Braking . . . . . 252
Forward Collision Alert (FCA) System . . . . . . . . . . . . . . . . . 250
Frequency Statement
Radio . . . . . . . . . . . . . . . . . . . . . . . . . 405
Front Fog Lamp Light . . . . . . . . . . . . . . . . . . . . . . . . . . 141
Front Pedestrian Braking (FPB) System . . . . . . . . . . . . . . . . . 253
Front Seats Adjustment . . . . . . . . . . . . . . . . . . . . . 60
Heated and Ventilated . . . . . . . . . . 65
Front Turn Signal Lamps . . . . . . . 315
Fuel
Additives . . . . . . . . . . . . . . . . 261, 262
Biodiesel . . . . . . . . . . . . . . . . . . . . . 263 Fuel (cont'd)
Cold Weather Operation . . . . . . 264
Diesel Engines . . . . . . . . . . . . . . . 262
Economy Driving . . . . . . . . . . . . . . . 27
Filling a Portable Fuel
Container . . . . . . . . . . . . . . 272, 273
Filling the Tank . . . . . . . . . . 268, 270
Filter Replacement . . . . . . . . . . . 268
Foreign Countries . . . . . . . . . . . . 261
Gauge . . . . . . . . . . . . . . . . . . . . . . . . 129
Low Fuel Warning Light . . . . . . . 140
Prohibited Fuels . . . . . . . . . . . . . . 261
Recommended . . . . . . . . . . . . . . . 260
Running out of Fuel . . . . . . . . . . . 267
Top Tier . . . . . . . . . . . . . . . . . . . . . . 260
Water in Fuel . . . . . . . . . . . . . . . . . 264
Fuel for Diesel Engines . . . . . . . . . 262
Fuses Engine Compartment FuseBlock . . . . . . . . . . . . . . . . . . . . . . . . 318
Fuses and Circuit Breakers . . . 318
Instrument Panel Fuse Block . . . . . . . . . . . . . . . . . . . . . . . . 321
Rear Compartment Fuse Block . . . . . . . . . . . . . . . . . . . . . . . . 323G
Garage Door Opener . . . . . . . . . . . 157Programming . . . . . . . . . . . . . . . . . 157
Gas Strut(s) . . . . . . . . . . . . . . . . . . . . 313
Gauges Engine CoolantTemperature . . . . . . . . . . . . . . . . 130
Fuel . . . . . . . . . . . . . . . . . . . . . . . . . . 129
Odometer . . . . . . . . . . . . . . . . . . . . . 128
Speedometer . . . . . . . . . . . . . . . . . 128
Tachometer . . . . . . . . . . . . . . . . . . . 128
Trip Odometer . . . . . . . . . . . . . . . . 128
Warning Lights and Indicators . . . . . . . . . . . . . . . . . . . 121
General Information Service and Maintenance . . . . . 376
Towing . . . . . . . . . . . . . . . . . . . . . . . . 273
Vehicle Care . . . . . . . . . . . . . . . . . . 285
Glove Box . . . . . . . . . . . . . . . . . . . . . . 109
GM Mobility Reimbursement
Program . . . . . . . . . . . . . . . . . . . . . . . 399
H
Halogen Bulbs . . . . . . . . . . . . . . . . . . 314
Hazard Warning Flashers . . . . . . . 164
Head Restraints . . . . . . . . . . . . . . . . . 58
HeadlampsAiming . . . . . . . . . . . . . . . . . . . . . . . . 314
Page 431 of 434
GMC Terrain/Terrain Denali Owner Manual (GMNA-Localizing-U.S./Canada/-
Mexico-12146071) - 2019 - crc - 7/27/18
430 Index
Service (cont'd)Maintenance Records . . . . . . . . 390
Maintenance, General
Information . . . . . . . . . . . . . . . . . . 376
Parts Identification Label . . . . . 391
Scheduling Appointments . . . . . 401
Service Electric Parking Brake Light . . . . . . . . . . . . . . . . . . . . 136
Services
Special Application . . . . . . . . . . . 383
Servicing the Airbag . . . . . . . . . . . . . 89
Shifting Into Park . . . . . . . . . . . . . . . . . . . . . . 202
Out of Park . . . . . . . . . . . . . . . . . . . 203
Side Blind Zone Alert (SBZA) . . . 255
Signals, Turn and Lane-Change . . . . . . . . . . . . . . . . . 165
Spare Tire
Compact . . . . . . . . . . . . . . . . . . . . . . 359
Special Application Services . . . . 383
Specifications and Capacities . . . . . . . . . . . . . . . . . . . . . 392
Speedometer . . . . . . . . . . . . . . . . . . . 128
StabiliTrak
OFF Light . . . . . . . . . . . . . . . . . . . . . 138
Start Assist, Hill . . . . . . . . . . . . . . . . . 221
Start Vehicle, Remote . . . . . . . . . . . 36
Starter Switch Check . . . . . . . . . . . 310 Starting the Engine . . . . . . . . . . . . . 197
Steering . . . . . . . . . . . . . . . . . . . . . . . . 182
Heated Wheel . . . . . . . . . . . . . . . . .114
Wheel Adjustment . . . . . . . . . . . . .114
Wheel Controls . . . . . . . . . . . . . . . .114
Stop/Start System . . . . . . . . . . . . . . 199
Storage Areas Cargo Cover . . . . . . . . . . . . . . . . . . .110
Center Console . . . . . . . . . . . . . . . 109
Convenience Net . . . . . . . . . . . . . . 111
Glove Box . . . . . . . . . . . . . . . . . . . . 109
Roof Rack System . . . . . . . . . . . . . 111
Storage Compartments . . . . . . . . . 109
Storing the Tire Sealant and Compressor Kit . . . . . . . . . . . . . . . 353
Struts
Gas . . . . . . . . . . . . . . . . . . . . . . . . . . . 313
Stuck Vehicle . . . . . . . . . . . . . . . . . . . 190
Summer Tires . . . . . . . . . . . . . . . . . . 327
Sun Visors . . . . . . . . . . . . . . . . . . . . . . . 54
Sunroof . . . . . . . . . . . . . . . . . . . . . . . . . . 55
Symbols . . . . . . . . . . . . . . . . . . . . . . . . . . 3
System Forward CollisionAlert (FCA) . . . . . . . . . . . . . . . . . . 250
Infotainment . . . . . . . . . . . . . 169, 408
Roof Rack . . . . . . . . . . . . . . . . . . . . . 111 Systems
Driver Assistance . . . . . . . . . . . . . 242
T
Tachometer . . . . . . . . . . . . . . . . . . . . . 128
Taillamps . . . . . . . . . . . . . . . . . . . . . . . 316
Text Telephone (TTY) Users . . . . 398
Theft-Deterrent Systems . . . . . . . . . 50
Immobilizer . . . . . . . . . . . . . . . . . . . . . 49
Time . . . . . . . . . . . . . . . . . . . . . . . . . . . . 117
Tires . . . . . . . . . . . . . . . . . . . . . . . . . . . . 325 All-Season . . . . . . . . . . . . . . . . . . . . 326
Buying New Tires . . . . . . . . . . . . . 341
Chains . . . . . . . . . . . . . . . . . . . . . . . . 345
Changing . . . . . . . . . . . . . . . . . . . . . 354
Compact Spare . . . . . . . . . . . . . . . 359
Designations . . . . . . . . . . . . . . . . . 329
Different Size . . . . . . . . . . . . . . . . . 342
If a Tire Goes Flat . . . . . . . . . . . . 345
Inspection . . . . . . . . . . . . . . . . . . . . 339
Pressure . . . . . . . . . . . . . . . . . . . . . . 332
Pressure Light . . . . . . . . . . . . . . . . 139
Pressure Monitor Operation . . 335
Pressure Monitor System . . . . . 334
Rotation . . . . . . . . . . . . . . . . . . . . . . 339
Sealant and
Compressor Kit . . . . . . . . . . . . . 347
