GREAT WALL SO COOL 2006 Service Manual

B0-18
10. Adjust the door window glass Vehicle Body
Rear Door
Adjust the balance arm upwardly or downwardly until the
dimensions A and B shown in the drawing are equal, and then
fix the balance arm.
11. Mount the outerauchi
8. Mount lower rear glass guide track (Dr SF)
Mount the bolts and guide track.
9. Mount the door window glass;
(Dr SF SL SK SY SJ)
Put the glass in the door cavity and then fix the glass on the
glass elevator with two bolts.
Mount on the tailgate baffle and lower dust strip (Dr) 5. Mount the door glass channel;
6. Mount on the quarter window glass (SF SJ)
7. Mount the upper glass guide track (SF)
Mount the bolts and guide track.
12. Mount the door interior trim panel;
13. Mount the indoor handle:
(a) Push the indoor handle in the door paneling and slide it
backwardly.
(b) Tighten the screws.
ABA=B
SF
SJ

B0-19
14. Mount the elevator handle (Dr)
Mount the paneling and elevator handle with spring snapping
ring as shown in the drawing under the condition that the all
of doors and windows of vehicle are closed. Vehicle Body
Rear Door
forward30

B0-20Vehicle Body
Adhesive Strip On Body Collision Avoidance
Adhesive strip of body collision avoidance
Notices on storing the adhesive strip of body collision avoidance:
1. The adhesive strip should be stored in the cool shadow place where can avoid the direct lighting of sun,
the high temperature and the dust.
2. As the adhesive strip is the PVC product, do not make it touch the paint thinner, other solvents and the
boiling water.
3. The limit storage period of adhesive strip is 9 months.
Element figure
exterior adhesive
strip at front doorexterior adhesive
strip at rear column
exterior adhesive
strip on wing panelexterior adhesive
strip at tailgateexterior adhesive
strip at rear body

B0-21
Disassembly of adhesive strip of body
collision avoidance
1. Tear down the ends of adhesive strip;
Loosen the ends of adhesive strip for 31 mm with the scraper.
2. Tear down the adhesive strip and clear away the adhe-
sive agent;
(a) Cut down the adhesive agent with knife and pull down the
adhesive strip;
(b) Clear away the adhesive agent with knife or abrasive
paper.
Remark: Do not reuse the adhesive strip that is disassembled.
Mount of adhesive strip of body collision
avoidance
1. Clean the mounting face of adhesive strip;
Scrape the feculence with cleaning materials.
2. Heat the adhesive strip;
Heat the new adhesive strip with heating lamp to the 30
60
.
Notice: do not overheat the adhesive strip and the
temperature should not higher than 80
.
3. Pull out the separation paper from the adhesive strip
surface;
Remark: notice should be taken not to let the feculence and
dust enter into when separating the separation paper.
4. Mount the adhesive strip along with the body pinching line.
Mount the adhesive strip along with the body pinching line as
shown in the drawing.
Remark: the convex and concave line of the adhesive strip
should be in consistent with the body pinching line.
Notice:
1. Heat the body and adhesive strip to the moderate
temperature;
2. Press the adhesive strip with thumb and exert
moderate pressure so as to ensure the mount is
fastening.
3. Do not wash the vehicle within 24 hours once the
mount is finished. Vehicle Body
Adhesive Strip On Body Collision Avoidance

B0-22Vehicle Body
Adhesive Strip On Body Collision Avoidance
Adhesive strip of body collision avoidance (
)
Element mounting position
B: 7 mm
C: 3 mm
D:10 mm
E: 4 mm
B: 7 mm
C: 3 mm
D:10 mm
E: 4 mm
B: 7 mm
C: 3 mm
D:10 mm
E: 4 mm
B
CD
E
B
CD
E
B
CD
E
SL small double-row model
SLbig double-row model
SY

B0-23Vehicle Body
Adhesive Strip OSn Body Collision Avoidance
Adhesive strip of body collision avoidance (
)
Element mounting position
A: 2 mm
B: 3 mm
C: 3 mm
D: 3 mm
E: 6 mm
F: 2 mm
G:18 mm
Drsmall double-row model
BCDEAFd
A: 2 mm
B: 3 mm
C: 3 mm
D: 3 mm
E: 6 mm
F: 2 mm
G:18 mm
Drbig double-row model
AB CD
EFG
B AC
DE
FG

B0-24
Wheel-trims
Wheel-trims of stainless steel
Element mounting position
Vehicle Body
Wheel-Trims
Change of shield of front wheel
1. Tear down the shield of front wheel;
Tear down the five screws to take down the Wheel-trims;
2. Mount the shield of front wheel
(a) Tap the front shield manually to ensure it contact the
body closely.
(b) Mount the five screws.
shield of front wheel
rear wheel-trims
Dr
Change of rear Wheel-trims
1. Tear down the rear Wheel-trims.
Tear down the five screws and take down the Wheel-trims.
Prize up the snapping plate of Wheel-trims with screwdriver to
take down the Wheel-trims (SF)
2. Mount the rear Wheel-trims:
(a) Tap the rear Wheel-trims manually to ensure it contacts
the body closely.
(b) Mount the five screws.
Clamp the Wheel-trims with snapping plate. (SF)

B0-25
large wheel trims
Element mounting position
Vehicle Body
Wheel-Trims
shield of front wheel
wrapping angle of
shield of front wheel
rear wheel-trims
SF
Change of shield of front wheel and wrapping angle
1. Tear down the shield of front wheel and wrapping angle;
Tear down the seven screws and take down the Wheel-trims.
2. Mount the shield of front wheel:
(a) Mount the adhesive strip of Wheel-trims first, ensure the adhesive
strip contact the Wheel-trims closely;
(b) Mount the five screws.
3. Mount the wrapping angle of the front Wheel-trims.
Mount the wrapping angle on the front bar first, and then fix it with two
screws.
Change of rear wheel-trims
1. Tear down the rear Wheel-trims
Tear down the five screws and take down the Wheel-trims;
2. Mount the rear Wheel-trims
(a) Mount the adhesive strip of Wheel-trims first, ensure the adhesive
strip contact the Wheel-trims closely;
(b) Mount the five screws

B0-26
Wheel-trims wrapping angle and exterior trim panel (
)
Element mounting position
Vehicle Body
Wheel-Trims Wrapping Angle and Exterior Trim Panel
adhesive strip of wheel-trims
front wheel-trimsrear wheel-trims
front wrapping anglerear wrapping angle
SY

B0-27
Wheel-trims wrapping angle and exterior trim panel (
)
Element mounting position
Vehicle Body
Wheel-Trims Wrapping Angle and Exterior Trim Panel
trim panel at front door front wheel-trimsrear wheel-trims
front wrapping anglerear wrapping angle
Top-grade SY
trim panel at rear door
luminous channel
