HONDA ACCORD 2001 CF / 6.G Owners Manual

Loosen the drain plug on the
bottom of the radiator. The
coolant will drain through the
splash guard. Remove the drain
bolt and washer f rom the engine
block.
Openthehood.Makesurethe
engine and radiator are cool to the
touch.
Turn the ignition ON (II). Turn
the temperature control dial to
90°F (32°C). Turn of f the ignition
and remove the key.
Remove the radiator cap.
Turn the ignition ON (II). Turn
the temperature control Dial all
the way clockwise. Turn of f the
ignition and remove the key.
1.
3.
2.
4-cylinder models
EX-V6 model
Except EX-V6 model
Maint enance
Cooling Syst em
242
44--ccyylliinnddeerrmmooddeellss66--ccyylliinnddeerrmmooddeellss44--ccyylliinnddeerrmmooddeellss
DDRRAAIINNBBOOLLTT
DDRRAAIINNPPLLUUGG

Remove the reserve tank f rom its
holder by pulling it straight up.
Drain the coolant, then put the
tank back in its holder.
Loosen the drain plug on the
bottom of the radiator. The
coolant will drain through the
splash guard. Loosen the drain
bolt. When removing the reserve tank,
f irst remove the cruise control cable
and the ground cable f rom their clips.
After installing the tank back in
place, put the cables back in their
clips.
4.
3.6-cylinder models 6-cylinder models
CONT INUED
Cooling Syst em
Maint enance243
66--ccyylliinnddeerrmmooddeellss
RREESSEERRVVEETTAANNKKRREESSEERRVVEETTAANNKKCCAAPP
44--ccyylliinnddeerrmmooddeellssHHOOLLDDEERR
DDRRAAIINNPPLLUUGG
DDRRAAIINNBBOOLLTT66--ccyylliinnddeerrmmooddeellss

When the coolant stops draining,
tightenthedrainplugatthe
bottom of the radiator.
Put a new washer on the drain bolt,
then reinstall the drain bolt in the
engine block. Tighten it securely.
Tightening torque:Tighten the drain bolt at the rear
of the engine cylinder block
securely.
Tightening torque:
Loosen the bleeder bolt on top of
the engine.
Pour Honda All Season
Antif reeze/Coolant Type 2 into
the radiator. This coolant is a
mixture of 50 percent anti-f reeze
and 50 percent water. Pre-mixing
is not required.
Tighten the bleeder bolt when
coolant comes out in a steady
stream with no bubbles.
7.
6.
5.
4-cylinder models 6-cylinder models 4-cylinder models
Cooling Syst em
Maint enance
244
FFIILLLLEERRNNEECCKK
44--ccyylliinnddeerrmmooddeellssFFiilllluuppttoohheerree
FFIILLLLEERRNNEECCKK
66--ccyylliinnddeerrmmooddeellssFFiilllluuppttoohheerree
RREESSEERRVVEETTAANNKKCCAAPPRREESSEERRVVEETTAANNKK
66--ccyylliinnddeerrmmooddeellssHHOOLLDDEERR
61 lbf·ft (83 N·m , 8.5 kgf·m) 7 lbf·ft (10 N·m , 1.0 kgf·m)

Start the engine and hold it at
1,500 rpm until the cooling f an
comes on. Turn of f the engine.
Check the coolant level in the
radiator and add coolant if needed.
Start the engine and let it run f or
about 30 seconds. Then turn of f
the engine.
Fill the radiator with coolant up to
the base of the f iller neck.
Fill the reserve tank to the MAX
mark. Install the reserve tank cap.
Install the radiator cap, and
tighten it to the first stop.
Start the engine and let it run until
the radiator cooling f an comes on
at least twice. Then stop the
engine.
Remove the radiator cap. Pour
coolant into the radiator up to the
base of the f iller neck and into the
reserve tank up to the MAX mark. If necessary, f ill the reserve tank
to the MAX mark. Install the
reserve tank cap.
Install the radiator cap, and
tighten it fully.
Pour coolant into the radiator up
to the base of the f iller neck.
The cooling system capacity is: 8. 9.
10. 11.12. 13. 14. 15. 16.
With automatic transmission:
6-cylinder models
With 5-speed manual transmission:
6-cylinder models
Cooling Syst em
Maint enance
245
44--ccyylliinnddeerrmmooddeellssBBLLEEEEDDEERRBBOOLLTT
1.45 US gal (5.5
, 1.21 Imp gal)
1.43 US gal (5.4
, 1.19 Imp gal)
1.48 US gal (5.6
, 1.23 Imp gal)

Check the level in the windshield
washer reservoir at least monthly
during normal usage. In bad weather,
when you use the washers of ten,
check the level every time you stop
for fuel.
The windshield washer reservoir is
located behind the headlight.
Check the reservoir’s f luid level by
removing the cap and looking at the
level gauge attached to the cap.
The low washer level indicator will
light when the level is low (see page).
Fill the reservoir with a good-quality
windshield washer f luid. This
increases the cleaning capability and
prevents f reezing in cold weather. When you ref ill the reservoir, clean
the edges of the windshield wiper
blades with windshield washer fluid
on a clean cloth. This will help to
condition the blade edges.
57
Canadian Models
Windshield Washers
Maint enance
246
LLEEVVEELLGGAAUUGGEE
44--ccyylliinnddeerrmmooddeellss66--ccyylliinnddeerrmmooddeellss
Do not use engine antif reeze or a
vinegar/water solution in the
windshield washer reservoir.
Antif reeze can damage your car’s paint,
while a vinegar/water solution can
damage the windshield washer pump.
Use only commercially-available
windshield washer f luid.

Remove the dipstick (yellow loop)
f rom the transmission and wipe it
with a clean cloth.
Check the f luid level with the engine
at normal operating temperature. If the level is below the lower
mark, add f luid into the tube to
bring it to the upper mark. Always
use Genuine Honda ATF-Z1
(Automatic Transmission Fluid). If
it is not available, you may use a
DEXRON
III automatic
transmission f luid as a temporary
replacement. However, continued
use can affect shift quality. Have
the transmission drained and
ref illed with Genuine Honda ATF-
Z1 as soon as it is convenient.
Insert the dipstick all the way into
the transmission securely as
shown in the illustration.
Remove the dipstick and check
the f luid level. It should be
between the upper and lower
marks.
Park the car on level ground. Shut
of f the engine. To thoroughly f lush the transmission,
the technician should drain and ref ill
it with genuine Honda ATF-Z1
(Automatic Transmission Fluid),
then drive the vehicle a short
distance. Do this three times. Then
drain and ref ill the transmission a
final time.
1. 2. 3.5.
4.
4-cylinder models
CONT INUED
Automatic Transmission
T ransmission Fluid
Maint enance 247
UUPPPPEERRMMAARRKK
LLOOWWEERRMMAARRKK
DDIIPPSSTTIICCKK

Insert the dipstick all the way into
the transmission securely as
shown in the illustration.
Remove the dipstick and check
the f luid level. It should be
between the upper and lower
marks.
Check the f luid level with the engine
at normal operating temperature.
Park the car on level ground. Shut
of f the engine.
Remove the dipstick (yellow loop)
f rom the transmission and wipe it
with a clean cloth.
Insert the dipstick all the way back
into the transmission securely as
shown in the illustration.
The transmission should be drained
and ref illed with new f luid according
to the time and distance recommen-
dations in the maintenance schedule.
1. 2.3. 4.
6.
6-cylinder models
T ransmission Fluid
Maint enance Automatic Transmission
248
UUPPPPEERRMMAARRKK
DDIIPPSSTTIICCKKLLOOWWEERRMMAARRKK

Check the f luid level with the
transmission at normal operating
temperature and the car sitting on
level ground. Remove the
transmission f iller bolt and caref ully
f eel inside the bolt hole with your
f inger. The f luid level should be up
to the edge of the bolt hole. If it is
not, add Genuine Honda Manual
Transmission Fluid (MTF) until it
starts to run out of the hole. Reinstall
the f iller bolt and tighten it securely.
If the level is below the lower
mark, add f luid into the tube to
bring it to the upper mark. Always
use Genuine Honda ATF-Z1
(Automatic Transmission Fluid). If
it is not available, you may use a
DEXRON
III automatic
transmission f luid as a temporary
replacement. However, continued
use can affect shift quality. Have
the transmission drained and
ref illed with Genuine Honda ATF-
Z1 as soon as it is convenient.
To thoroughly f lush the transmission,
the technician should drain and ref ill
it with genuine Honda ATF-Z1
(Automatic Transmission Fluid),
then drive the vehicle a short
distance. Do this three times. Then
drain and ref ill the transmission a
final time. Insert the dipstick all the way back
into the transmission securely as
shown in the illustration.
The transmission should be drained
and ref illed with new f luid according
to the time and distance recommen-
dations in the maintenance schedule.
5.
6.
T ransmission Fluid
Maint enance
5-speed Manual Transmission
249
CCoorrrreeccttlleevveell
FFIILLLLEERRBBOOLLTT

If Honda MTF is not available, you
may use an API service SG, SH or SJ
grade motor oil with a viscosity of
SAE 10W-30 or 10W-40 as a
temporary replacement. An SG
grade is pref erred, but an SH or SJ
grade may be used if SG is not
available. However, motor oil does
not contain the proper additives and
continued use can cause stif f er
shif ting. Replace as soon as it is
convenient.
The transmission should be drained
and ref illed with new f luid according
to the time and distance recommen-
dations in the maintenance schedule.
T ransmission Fluid
Maint enance
250

The f luid level should be between
theMINandMAXmarksontheside
of the reservoir. If the level is at or
below the MIN mark, your brake
system needs attention. Have the
brake system inspected f or leaks or
worn brake pads.
Always use Genuine Honda DOT 3
brake f luid. If it is not available, you
should use only DOT 3 or DOT 4
f luid, f rom a sealed container, as a
temporary replacement. However,
theuseof anynon-Hondabrakefluid
can cause corrosion and decrease
the lif e of the system. Have the
brake system f lushed and ref illed
with Honda DOT 3 brake f luid as
soon as possible.
Check the f luid level in the reser-
voirs monthly. There are up to two
reservoirs, depending on the model.
They are:
The brake f luid should be replaced
accordingtothetimeanddistance
recommendations in the mainte-
nance schedule.
Brake f luid reservoir (all models)
Clutch f luid reservoir
(manual transmission only)
Brake f luid marked DOT 5 is not
compatible with your car’s braking
system and can cause extensive
damage.
CONT INUED
Brake System
Brake and Clutch Fluid
Maint enance251
MMAAXX
44--ccyylliinnddeerrmmooddeellssMMIINN
