HONDA ACCORD COUPE 2003 CL7 / 7.G Owners Manual

To get into the rear seat on the
driver’s side, open the door and pull
the release lever up on the side of
the seat-back. The seat-back will tilt
f orward to allow easier entry to the
rear seat.To get into the rear seat on the
driver’s side, open the door and pull
up on the seat-back adjustment lever.
The seat-back will tilt f orward to
allow easier entry to the rear seat.
To get into the rear seat on the
passenger’s side, push downward on
the release lever at the base of the
seat-back. The seat-back will tilt
f orward and the entire seat will move
f orward to allow easier entry to the
rear seat.
On all V6 models and the 4-cylinder EX
model with leather interior On LX and EX models
Rear Seat Access
Driver’s Side
Passenger’s Side
Seat A djustments
Inst rument s and Cont rols98
SEAT-BACK ADJUSTMENT LEVER
RELEASE LEVER
RELEASE LEVER

See page f or important saf etyinf ormation and a warning about how toproperly position the head restraints. 16
Your car has adjustable head
restraints on the f ront seats. They
are also on the outside positions of
the rear seat.
The head restraints adjust f or height.
You need both hands to adjust the
restraint.Donotattempttoadjustit
while driving. To raise it, pull upward.
To lower the restraint, push the
release button sideways, and push
the restraint down.
The head restraints help protect you
and your passengers f rom whiplash
and other injuries. They are most
ef f ective when you adjust them so
the back of the occupant’s head rests
against the center of the restraint. A
taller person should adjust the
restraint as high as possible.
Af ter a passenger gets into the back
seat, push the seat-back to the
upright position and push the whole
seat backwards until it latches. Make
sure the seat is f ully latched bef ore
sitting in it.
CONT INUED
Head Restraints
Seat A djustments
Inst rument s and Cont rols99
RELEASE BUTTON
FRONT

To f old down either side of the seat-
back f rom inside the car, insert the
master key in the lock on the rear
shelf. To fold down the driver’s side,
turn the key clockwise, pull down the
top of the seat-back, then release the
key. To f old down the passenger’s
side, turn the key counterclockwise
and perf orm the same procedure.
The back of the rear seat folds down
to give you direct access to the trunk.
Each side f olds down separately.
With only half the seat f olded, you
can still carry a passenger in the
back seat. The seat-back can be
released f rom inside the car or inside
the trunk.
To remove a head restraint f or
cleaning or repair, pull it up as f ar as
it will go. Push the release button
and pull the restraint out of the seat-
back. Folding Rear Seat
Seat A djustments
Inst rument s and Cont rols100
REAR
MASTER KEY

When storing cargo, you can move
therearcentershoulderbeltoutof
the way by removing the belt f rom
the guide.To release the seat-back from inside
the trunk, pull the release under the
trunk panel. Push the seat-back
down, then let go of the release.
To lock the seat-back upright, push it
f irmly against the trunk panel. Make
sure it is latched in place by pulling
on the top of the seat.
Do not put any heavy items on the
seat-back when it is folded.Make sure all rear shoulder belts are
positioned in f ront of the rear seat-
back whenever the seat-back is in its
upright position.
Make sure all items in the trunk, or
items extending through the opening
into the back seat, are secured.
Looseitemscanflyforwardand
cause injury if you have to brake
hard. See
on page
.
Never drive with the seat-back
f olded down and the trunk lid open.
See on
page . 56
234
Carrying Cargo
Carbon Monoxide Hazard
Seat A djustments
Inst rument s and Cont rols101
GUIDE Pull
CENTER
SHOULDER BELT

The HI or LO indicator lights and
remains lit until you turn it of f by
pushing the opposite side of the
switch lightly. The indicator will turn
off.
In HI, the heater turns of f when the
seat gets warm, and turns back on
after the seat’s temperature drops. It
continues to cycle as long as you
leave it set on HI. The HI indicator
remains lit as a reminder that you
have the heater on.
In LO, the heater runs continuously.
It does not cycle with temperature
changes.Do not use the seat heaters, even
on the LO setting, if the engine is
lef t idling f or an extended period.
They can weaken the battery,
causing hard starting. Use the HI setting only to heat the
seats quickly. Select the LO
setting when the seats f eel warm.
The HI setting draws large
amounts of current f rom the
battery.
Follow these precautions whenever
you use the seat heaters:
Both f ront seats are equipped with
seat heaters. Because of the sensors
f or the side airbag system, there is
no heater in the passenger’s seat-
back. The ignition switch must be
ON (II) to use the heaters. Push the
f ront of the switch, HI, to rapidly
heat up the seat. After the seat
reaches a comf ortable temperature,
select LO by pushing the back of the
switch. This will keep the seat warm.
On EX-V6 model and EX model with leather interior
Seat Heaters
Inst rument s and Cont rols102
SEAT
HEATER
SWITCH

Your car’s windows are electrically-
powered. Turn the ignition switch to
ON (II) to raise or lower either
window.
Each door has a switch that controls
its window. To open the window,
push the switch down and hold it.
Release the switch when you want
the window to stop. Close the
window by pulling back on the
switch and holding it.The driver’s armrest has a master
power window control panel. To
open the passenger’s window, push
down on the switch and hold it down
until the window reaches the desired
position. To close the window, pull
back on the window switch. Release
the switch when the window gets to
the position you want.
CONT INUED
Inst rument s and Cont rols
Power Windows
103
MAIN SWITCH
DRIVER’S WINDOW
SWITCH
Closing a power window on
someone’s hands or fingers can
cause serious injury.
Make sure your passengers are
away from the windows before
closing them.

µ
The master control panel also con-
tains these extra features:
To open the driver’s
window f ully, push the window
switch f irmly down, then release it.
The window automatically goes
down all the way. To stop the
window f rom going all the way down,
pull back on the window switch
brief ly.
To open or close the driver’s window
partially, push down or pull back on
the window switch lightly and hold it.
The window will stop when you
release the switch. To close the driver’s window f ully,
pull back the window switch f irmly,
then release it. The window
automatically goes all the way up. To
stop the window f rom going all the
way up, push down on the window
switch brief ly. If the driver’s window runs into any
obstacle while it is closing
automatically, it will reverse
direction, and then stop. To close the
window, remove the obstacle, then
use the window switch again.
Auto reverse stops sensing when the
window is almost closed. You should
always check that all passengers and
objects are away from the window
bef ore closing it.
The MAIN switch controls power to
the passenger’s window. When you
push in the MAIN switch, the
passenger’s window cannot be raised
or lowered. The MAIN switch does
not af f ect the driver’s window. To
cancel this f eature, push on the
switch again to get it to pop out.
Keep the MAIN switch of f when you
have children in the car so they do
not injure themselves by operating
the window unintentionally.
AUTO
Auto Reverse
Power Windows
Inst rument s and Cont rols104

If your car’s battery is disconnected
or goes dead, or the driver’s window
f use is removed, the AUTO f unction
will be disabled. The power window
system needs to be reset af ter
reconnecting the battery or installing
the f use. You should do the f ollowing.Start the engine. Push down on
the driver’s window switch until
the window is f ully open.
Pull back on the driver’s window
switch to close the window
completely, then hold the switch
f or a second or two more.
If the power windows do not operate
properly af ter resetting, have your
car checked by a Honda dealer. The power window system has a key-
of f delay f unction. The windows will
stilloperateforuptotenminutes
after you turn off the ignition.
Opening either door cancels the
delay function. You must turn the
ignition switch ON (II) again before
you can raise or lower the windows.
1.
2.
Power Windows
Inst rument s and Cont rols105

You can open both windows f rom the
outside with the remote transmitter.
You cannot close the windows with
the remote transmitter.Turnthekeyclockwiseagain,and
hold it. Both windows start to open.
To stop the windows, release the
key.
You can open and close the windows
with the key in the driver’s door lock.
To open: Insert the key in the driver’s door
lock.
Turn the key clockwise, then
release it. To open the windows f urther, turn
andholdthekeyagain(within
10 seconds).
NOTE: If the window stops bef ore
the desired position, repeat steps 2
and 3.
Press the UNLOCK button once
to unlock the driver’s door.
Press the UNLOCK button a
second time, and hold it. The
passenger’s door unlocks, and
both windows start to open. To
stop the windows, release the
button.
To open the windows f urther,
press the button again.
1.
2.
3.
1.
2.3.
4.
Opening the Windows with the
Remote Transmitter
Opening/Closing the Windows
with the Key
Power Windows
Inst rument s and Cont rols106
UNLOCK BUTTONCloseOpen

To tilt up the back of the moonroof ,
press and hold the center button
( ). To close the moonroof ,
press and hold the upper part of the
switch ( ). To open the
moonroof , press and hold the lower
part of the switch ( ). Release
the switch when the moonroof gets
to the desired position. Make sure
everyone’s hands are away f rom the
moonroof bef ore opening or closing
it.
The moonroof has two positions: it
can be tilted up in the back f or
ventilation, or it can be slid back into
the roof . Use the switch under the
lef t dashboard vent to operate the
moonroof . The ignition switch must
be ON (II).
To close:
Insert the key in the driver’s door
lock.
Turn the key counterclockwise,
then release it.
Turn the key counterclockwise
again, and hold it. Both windows
starttoclose.Tostopthewindows,
release the key.
To close the windows f urther, turn
andholdthekeyagain(within
10 seconds).
NOTE: If the window stops bef ore
the desired position, repeat steps 2
and 3. 1.
2.
3.
4.
CONT INUED
On all EX and EX-V6 models
Power Windows, Moonroof
Inst rument s and Cont rols
Moonroof
107
MOONROOF SWITCH
Opening or closing the
moonroof on someone’s hands
or fingers can cause serious
injury.
Make sure all hands and fingers
are clear of the moonroof
before opening or closing it.
