HONDA ACCORD COUPE 2007 CL7 / 7.G Repair Manual

This indicator comes on f or several
seconds when you turn the ignition
switch to the ON (II) position. If it
comes on at any other time, it
indicates a potential problem with
your f ront airbags. This indicator will
also alert you to a potential problem
with your side airbags, passenger’s
side airbag automatic cutoff system,
side curtain airbags, automatic seat
belt tensioners, driver’s seat position
sensor, or the f ront passenger’s
weight sensors. For more
inf ormation, see page .This indicator comes on when you
turn the ignition switch to the ON
(II) position. If it comes on at any
other time, it indicates that the
passenger’s side airbag has
automatically shut off. For more
inf ormation, see page .
This indicator has two f unctions:
Itcomesonwhenyouturnthe
ignition switch to the ON (II)
position. It is a reminder to check
the parking brake. A beeper
sounds if you drive with the
parking brake not f ully released.
Driving with the parking brake not
fully released can damage the
brakes and tires.
If it stays on after you have fully
released the parking brake while
the engine is running, or if it
comes on while driving, there
could be a problem with the brake
system. For more inf ormation, see
page .
1. 2.
29
28
278 Supplemental Restraint
System Indicator
Side A irbag Of f
Indicator
Parking Brake and
Brake System
Indicator
Instrument Panel Indicators
58
U.S.
U.S.
Canada Canada
——y

y
(#yy

This indicator normally comes on f or
a f ew seconds when you turn the
ignition switch to the ON (II)
position. If it comes on at any other
time, there is a problem with the
ABS. If this happens, have your
vehicle checked at a dealer. With
this indicator on, your vehicle still
has normal braking ability but no
anti-lock f unction. For more
inf ormation, see page .This indicator comes on f or a f ew
seconds when you turn the ignition
switch to the ON (II) position. It will
then go of f if you have inserted a
properly-coded ignition key. If it is
not a properly-coded key, the
indicator will blink, and the engine
will not start (see page ).
This indicator also blinks several
times when you turn the ignition
switch f rom the ON (II) position to
the ACCESSORY (I) or LOCK (0)
position.The lef t or right turn signal indicator
blinks when you signal a lane change
or turn. If the indicator does not
blink or blinks rapidly, it usually
means one of the turn signal bulbs is
burned out (see page ). Replace
the bulb as soon as possible, since
other drivers cannot see that you are
signaling.
When you press the hazard warning
button, both turn signal indicators
and all turn signals on the outside of
the vehicle f lash.
75
249
209
Anti-lock Brake System
(A BS) Indicator
Immobilizer System
Indicator Turn Signal and
Hazard Warning
Indicators
Instrument Panel Indicators
Inst rument s and Cont rols
59
——y

y
(#yy

This indicator is located in the f uel
gauge. It comes on as a reminder
that you must ref uel soon.
When the indicator comes on, there
are about 2.72 U.S. gal (10.3
)of
f uel remaining in the tank bef ore the
needle reaches E. There is a small
reserve of f uel remaining in the tank
when the needle does reach E.
This indicator reminds you that the
exterior lights are on. It comes on
when the light switch is in either the
or position. If you turn the
ignition switch to the ACCESSORY
(I) or LOCK (0) position without
turning of f the light switch, this
indicator will stay on. A reminder
chime will also sound when you open
the driver’s door.
This indicator comes on when the
washer f luid level is low. Add washer
f luid when you see this indicator
(see page ).
If this indicator comes on when the
ignition switch is turned to the ON
(II) position and the parking brake is
released, it means there is a problem
in the high beam headlight’s circuit.
Have your vehicle checked by your
dealer.
This indicator comes on with the
high beam headlights. For more
inf ormation, see page .
This indicator also comes on with
reduced brightness when the
daytime running lights (DRL) are on
(see page ).
69
238
70
Canadian models only
Instrument Panel Indicators
‘‘Daytime Running
Lights’’ Indicator Low Fuel Indicator
Lights On Indicator
Washer Level Indicator
High Beam Indicator
60
LOW FUEL INDICATOR
——y


y
(#yy

This indicator comes on when the
security system is set. For more
inf ormation, see page .
If the remaining engine oil lif e is
more than 16 percent, this indicator
comes on f or a f ew seconds when
you turn the ignition switch to the
ON (II) position.
This indicator reminds you that it is
time to take your vehicle in for
scheduled maintenance. The
maintenance main items and sub
items will be displayed in the
inf ormation display. See page f or
more inf ormation on the
maintenance minder.
This indicator goes of f when your
dealer resets it after completing the
required maintenance service.
The appropriate indicator comes on
in this monitor if the trunk or either
door is not closed tightly.
All the indicators in the monitor
come on f or a f ew seconds when you
turn the ignition switch to the ON
(II) position.
174
221 Security System Indicator
Maintenance Minder
Indicator Door and T runk Open Monitor
Instrument Panel Indicators
Inst rument s and Cont rols
61
SECURITY SYSTEM INDICATOR
——y

y
(#yy

On all V6 models On all V6 models
This indicator normally comes on f or
a f ew seconds when you turn the
ignition switch to the ON (II)
position.
If itcomesonandstaysonatany
other time, or if it does not come on
when you turn the ignition switch to
the ON (II) position, there is a
problem with the VSA system. Take
your vehicle to a dealer to have it
checked. Without VSA, your vehicle
still has normal driving ability, but
will not have VSA traction and
stability enhancement. See pagef or more inf ormation on the
VSA system. This indicator comes on when you
turn on the cruise control system by
pressing the CRUISE button (see
page ).
This indicator comes on when you
set the cruise control. See page
f or inf ormation on operating the
cruise control.
This indicator has three f unctions:
Itcomesonasareminderthatyou
have turned off the vehicle
stability assist (VSA) system.
It flashes when VSA is active (see
page ).
It comes on along with the VSA
system indicator if there is a
problem with the VSA system.
This indicator normally comes on f or
a f ew seconds when you turn the
ignition switch to the ON (II)
position. For more inf ormation, see
page .
1. 2. 3.
211 211
211 175
175
Instrument Panel Indicators
Vehicle Stability Assist
(VSA ) System Indicator Cruise Main Indicator
Cruise Control Indicator
VSA A ctivation Indicator
62
——y

y
(#yy

To switch the information display
between the odometer/trip meter,
outside temperature/trip meter (if
equipped), and engine oil lif e and
maintenance item code(s), press the
When you turn the ignition switch to
the ON (II) position, your last
selection appears in the display.
The odometer shows the total
distance your vehicle has been
driven. It measures miles in U.S.
models and kilometers in Canadian
models. It is illegal under U.S.
federal law and Canadian provincial
regulations to disconnect, reset, or
alter the odometer with the intent to
change the number of miles or
kilometers indicated.
Gauges
Odometer
Inst rument s and Cont rols
63
TACHOMETERSPEEDOMETER
FUEL GAUGE
TEMPERATURE
GAUGE
INFORMATION DISPLAY
U.S. A/T model is shown. ODOMETER/TRIP METER/OUTSIDE
TEMPERATURE INDICATOR/CHECK FUEL CAP
INDICATOR/MAINTENANCE MINDER
SELECT/RESET KNOB
——y

y
(#yy
select/reset knob repeatedly.

This shows how much f uel you have.
It may show slightly more or less
than the actual amount. The needle
returns to the bottom after you turn
of f the ignition.This shows the temperature of the
engine’s coolant. During normal
operation, the pointer should rise
from the bottom white mark to about
the middle of the gauge. In severe
driving conditions, such as very hot
weather or a long period of uphill
driving, the pointer may rise into the
upperhalfofthegauge.Ifitreaches
the red (Hot) mark, pull safely to the
side of the road. See page f or
instructions and precautions on
checking the engine’s cooling
system.
This meter shows the number of
miles (U.S.) or kilometers (Canada)
driven since you last reset it.
There are two trip meters: Trip A
repeatedly. Each trip meter works
independently, so you can keep track
of two dif f erent distances.
To reset a trip meter, display it and
then press and hold the select/reset
274
Fuel Gauge T emperature Gauge
Trip Meter
Gauges
64
Avoid driving with an extremely low
f uel level. Running out of f uel could
cause the engine to misf ire, damaging
the catalytic converter.
——y


y
(#yy
and Trip B. Switch between them by
knob until the number resets to ‘‘0.0’’.
pressing the select/reset knob

¶¶µµ
µµµ µµµ
In certain weather conditions,
temperature readings near f reezing
(32°F, 0°C) could mean that ice is
f orming on the road surf ace.
When the temperature reaches the
outside temperature displayed.
NOTE: The temperature must be
stabilized bef ore doing this
procedure.
If the outside temperature is
incorrectly displayed, you can adjust
it 5°F in U.S. models ( 3°C in
Canadian models) warmer or cooler.
This indicator displays the outside
temperature in Fahrenheit (U.S.
models) or Centigrade (Canadian
models). To see the outside
temperature, press and release the
temperature is displayed.
The temperature sensor is in the
f ront bumper. Theref ore, the
temperature reading can be af f ected
by heat ref lection f rom the road
surf ace, engine heat, and the
exhaust f rom surrounding traf f ic.
This can cause an incorrect
temperature reading when your
speed is under 19 mph (30 km/h). Select the outside temperature
indicator, then press the Select/
Reset knob f or 10 seconds. The
f ollowing sequence will appear f or 1
secondeach:0,1,2,3,4,5, 5, 4,
3, 2, 1, 0 (U.S.) or 0, 1, 2, 3,
3, 2, 1, 0 (Canada).
The sensor delays the display update
until it reaches the correct outside
temperature. This may take several
minutes. If your f uel f ill cap is loose or
missing, a ‘‘CHECK FUEL CAP’’
message appears on the information
display af ter you start the engine.
Turn the engine of f , and conf irm the
f uel f ill cap is installed. If it is, loosen
it, then retighten it until it clicks at
least once. When you restart the
engine, the message appears again.
The message goes of f af ter several
days of normal driving once you
tighten or replace the fuel fill cap. To
scroll to another display, press the
CONT INUED
On 4-cylinder EX-L, SE, and
Outside Temperature Indicator
Check Fuel Cap Indicator
Gauges
Inst rument s and Cont rols
65
——y
y
(#yy
V6 EX models
select/reset knob until the
desired value, release the select/
reset knob. You should see the new select/reset knob.

The inf ormation display in the
instrument panel shows you the
engine oil lif e and maintenance
service items when the ignition
switch is in the ON (II) position. This
inf ormation helps to keep you aware
of the periodic maintenance your
vehicle needs f or continued trouble-
f ree driving. Ref er to page f or
more inf ormation.
If the system still detects a leak in
your vehicle’s evaporative emissions
system, the malf unction indicator
lamp (MIL) comes on. If the f uel f ill
cap was not already tightened, turn
the engine of f , and check or
retighten the f uel f ill cap until it
clicks at least once. The MIL should
go off after several days of normal
driving once the cap is tightened or
replaced. If the MIL does not go of f ,
have your vehicle inspected by a
dealer. For more inf ormation, see
page .
277 221
Gauges
Maintenance Minder
66
——y
y
(#y
y

Î Î
Î
Î Î
Î
To use the horn, press the pad around the ‘‘H’’ logo.
If equipped.
1:2:
Controls Near the Steering Wheel
Inst rument s and Cont rols
67
EX-V6 model without navigation system is shown. CRUISE CONTROLS
TILT/TELESCOPIC ADJUSTMENT
REMOTE AUDIO
CONTROLS
WINDSHIELD
WIPERS/WASHERS
REAR WINDOW
DEFOGGER
AUDIO SYSTEM
HAZARD WARNING
BUTTON
PASSENGER
AIRBAG OFF
INDICATOR
(P.69) HORN
MOONROOF
SWITCH
(P.94) (P.73)INSTRUMENT PANEL
BRIGHTNESS
(P.71)
(P.68)
(P.29)
(P.71)
(P.72)
SEAT HEATERS(P.90)
(P.171)
(P.212) (P.124)
(P.175)
VEHICLE STABILITY ASSIST
OFF SWITCH
HEADLIGHTS/
TURN SIGNAL
1
2 2
2
——y


y
(#yy
