HONDA ACCORD SEDAN 2001 Owner's Manual (in English)

Climate Control System
PASSENGER'S-SIDE VENT

Comfort and Convenience Features

Climate Control System

Fully-automatic Operation
To put the Automatic Climate Control in fully-automatic mode,
press the AUTO button and set the
fan control dial to AUTO, then set
the desired temperature by turning
the temperature control dial. You will see FULL AUTO in the system's
display. The light above the button also shows you which
mode, Recirculation or Fresh Air, is
selected.

The system automatically selects the proper mix of conditioned and/or
heated air that will, as quickly aspossible, raise or lower the interior
temperature from its current level to
the set temperature.
When you set the temperature to its lower limit (60°F/18°C) or its upper
limit (90°F/32°C), the system runs at full cooling or heating only. It does
not regulate the interior temperature.
When the temperature is set
TEMPERATURE

CONTROL DIAL
FULL AUTO
DISPLAY
FAN CONTROL DIAL
AUTO BUTTON OFF BUTTON
between the lower and upper limits,
the system regulates the interior
temperature to the set value. In cold weather, the fan will not
come on automatically until the car
has been driven for a short time and
the heater starts to develop warm air. Pressing the OFF button shuts the
climate control system completely
off. Keep the system completely off
only for short periods. To keep stale
air and mustiness from collecting,
you should have the fan running at all times.
Comfort and Convenience Features

Climate Control System

Semi-automatic Operation
You can manually select various functions of the Climate Control system when it is in FULL AUTO.
All other features remain auto- matically controlled. Making anymanual selection causes the word
FULL to go out.

Air Conditioning (A/C) Button
Press the A/C button to turn the air
conditioning on and off. You will see
A/C ON or A/C OFF in the display.
When you turn the A/C off, the sys- tem cannot regulate the inside tem-
perature if you set the dial below theoutside temperature. With the A/C
on, use the temperature control dial
to adjust the temperature of the air
flow to a comfortable setting.
TEMPERATURE

CONTROL DIAL
RECIRCULATION BUTTON
Comfort and Convenience Features AIR CONDITIONING BUTTON

Climate Control System

Recirculation Button
This button controls the source of the air going into the system. When
the indicator above this button is lit, air from the car's interior is sent
through the system again (Recircula-
tion mode). When the indicator is off, air is brought in from outside the car
(Fresh Air mode).
You can, for example, manually put the system in recirculation mode
when driving through an area of smoke or fumes.

Fan Control Dial

You can manually select the fan speed by turning the fan control dial.
When you turn the dial clockwise, the fan is taken out of automatic
mode and starts to run at its lowestspeed. Turning the dial fully
clockwise increases the fan's speed,
which increases air flow. MODE BUTTON
RECIRCULATION BUTTON

Mode Button

Use the MODE button to select the
vents the air flows from. Some air
will flow from the dashboard corner
vents in all modes. Each time you press the MODE button, the displayshows the mode selected. Press the
button four times to see all the

modes.
Some air will come out of the side
vents in all modes.

CONTINUED

Comfort and Convenience Features FAN CONTROL DIAL

Climate Control System

The main air flow is divided
between the floor vents and de-
froster vents at the base of the wind-
shield.
The main air flow comes
from the floor vents. The main air flow is divided
between the dashboard vents and
the floor vents. The main air flow comes
from the dashboard vents.
Comfort and Convenience Features

Climate Control System

The button directs the main
air flow to the windshield for fasterdefrosting. It also overrides any
MODE selection you may have made. When you select , the A/C
turns on automatically and the system selects Fresh Air mode. For
faster defrosting, manually set the
fan speed to high. You can also increase air flow to the windshield by
closing the side vents in the
dashboard.
When you turn off by
pressing the button again, the system returns to its former settings.
Rear Window Defogger Button
This button turns the rear window defogger on and off (see page 66 ).
REAR WINDOW DEFOGGER BUTTON

Comfort and Convenience Features

Climate Control System
Sunlight Sensor/Temperature

Sensor

SUNLIGHT
SENSOR

The climate control system has two
sensors. A sunlight sensor is located
in the top of the dashboard and a
temperature sensor is next to thesteering column. Do not cover the
sensors or spill any liquid on them. TEMPERATURE
SENSOR


Comfort and Convenience Features

Audio System

AM/FM/Cassette Stereo Audio
System

For DX model

Your Honda's audio system provides clear reception on both AM and FM
bands, while the preset buttons allow
you to easily select your favorite stations.
The cassette system features Dolby B* noise reduction, automatic
sensing of chromium-dioxide
(CrO2)

tape, and autoreverse for continuous
play.

* Dolby noise reduction manufactured under

license from Dolby Laboratories Licensing Corpo-
ration. "DOLBY" and the double-D symbol
are trademarks of Dolby Laboratories

Licensing Corporation.

Comfort and Convenience Features

Audio System

Operating the Radio
The ignition switch must be in ACCESSORY (I) or ON (II) to
operate the audio system. Turn the
system on by pushing the PWR/

VOL knob.

Adjust the volume by turning the PWR/VOL knob.
The band and frequency that the
radio was last tuned to is displayed.
To change bands, press the AM/FM button. On the FM band, ST will bedisplayed if the station is broadcast-
ing in stereo. Stereo reproduction on
AM is not available. You can use any of four methods to
find radio stations on the selectedband: TUNE, SEEK, SCAN or thePreset buttons.
TUNE — Use the TUNE bar to tune the radio to a desired frequency. Press the upper part ( ) to tune
to a higher frequency, or the lower part ( ) to tune to a lower
frequency. The frequency numbers
will start to change rapidly. Release the bar when the display reaches the desired frequency. To change the
frequency in small increments, press and release the TUNE bar quickly. SEEK — The SEEK function
searches the band for a station with
a strong signal. To activate it, push
the SEEK switch up or down, then
release it. Depending on which way
you push the switch, the system scans upward or downward from the
current frequency. It stops when it
finds a station with a strong signal.
Comfort and Convenience Features

Audio System
SCAN — The SCAN function samples all the stations with strongsignals on the selected band. To
activate it, press the SCAN button,
then release it. The system will scan up the band for a station with a strong signal. When it finds one, it
will stop and play that station for approximately five seconds. If you do
nothing, the system will then scan
for the next strong station and play that for five seconds. When it plays astation that you want to continue
listening to, press the SCAN button
again.

CONTINUED

Comfort and Convenience Features

AM/FM
BUTTON
SCAN BUTTON

PWR/VOL
KNOB
SEEK SWITCH
TUNE BAR
