Page 41 of 372
Protecting Children
Attach the tether strap hook to thetether anchorage point and tighten
the strap according to the child seat
maker's instructions. Using the Lower Anchorages
Your car is equipped with lower anchorages at the outer rear seats.
These anchorages are located between the seat-back and seat
bottom and are only to be used with a child seat designed to attach to the
lower anchorages.
The exact location of each anchor is marked with a small circle above the
lower anchor point. To install a child seat designed to
attached to the lower anchorages:
1. Move the seat belt buckle or center seat belt away from the
anchorages.
2. Make sure there are no foreign objects around the anchorages.
Foreign objects could get in the
way of a secure connection
between the child seat and the
anchorage.
Driver and Passenger Safety
LOWER ANCHORAGES
Rigid type
Page 42 of 372
Protecting Children
3. Put the child seat in the rear left or right vehicle seat and attach thechild seat to the lower anchorages
according to the child seat maker's
instructions.
4. Follow the child seat maker's instructions for any additionaladvice on adjusting or tightening
the fit.
5. Attach the tether strap hook to the
tether anchorage point and tightenthe strap according to the child seat maker's instructions.
6. Push and pull the child seat forward and from side to side to
verify that it is secure enough to stay upright during normal driving
maneuvers.
Driver and Passenger Safety
Flexible type
Page 43 of 372
Additional Information About Your Seat Belts
Seat Belt System Components
Your seat belt system includes lap/ shoulder belts in all five seating
positions.
The seat belt system alsoincludes a light on the
instrument panel to remind you and
your passengers to fasten your belts. If the driver's seat belt is not
fastened before the ignition is turned ON (II), the light will come on and a
beeper will also sound. The beeper
will stop after a few seconds, but the light will stay on until the driver'sseat belt is fastened. Lap/Shoulder Belt
This seat belt has a single belt that goes over your shoulder, across yourchest and across your hips.
To fasten the belt, insert the latch plate into the buckle, then tug on the
belt to make sure the buckle is
latched.
To unlock the belt, push the red
PRESS button on the buckle.
Guide the belt across your body to
the door pillar. After exiting the car, be sure the belt is out of the way and
will not get closed in the door.
All seat belts have an emergency locking retractor. In normal driving,
the retractor lets you move freely in
your seat while it keeps some tension on the belt. During a collisionor sudden stop, the retractor
automatically locks the belt to help
restrain your body.
The seat belts in all seating positions except the driver's have an additional
locking mechanism that must be activated to secure a child seat. (See
pages 29 and 33 for instructions on
how to secure child seats with this
type of seat belt.)
Driver and Passenger Safety
SHOULDER
PORTION
UPPER SEAT
BELT ANCHOR
LATCH
PLATE
BUCKLE LAP PORTION
Page 44 of 372
Additional Information About Your Seat Belts
If the shoulder part of the belt is
pulled all the way out, the locking
mechanism will activate. The belt
will retract, but it will not allow the passenger to move freely.
To deactivate the locking mechanism, unlatch the buckle and
let the seat belt fully retract. To
refasten the belt, pull it out only as
far as needed.
See page 14 for instructions on how
to wear the lap/shoulder belt
properly. Automatic Seat Belt Tensioners
The SRS indicator light willcome on if there is a
problem with your automatic seat
belt tensioners (see page 45 ).
Driver and Passenger Safety
S R S
Page 45 of 372
Additional Information About Your Seat Belts
Seat Belt MaintenanceFor safety, you should check the
condition of your seat belts regularly.
Pull each belt out fully and look for
frays, cuts, burns, and wear. Check that the latches work smoothly and
that the lap/shoulder belts retract easily. Any belt not in good conditionor not working properly will not
provide good protection and should
be replaced as soon as possible.
U.S. Models
Honda provides a lifetime warranty on seat belts. Honda will repair or
replace any seat belt component that
fails to function properly during
normal use. Please see your Honda
Warranty Information booklet for
details.
If a seat belt is worn during a crash,
you should have your dealer inspect the belt, and replace it if necessary.
A belt that has been worn during a crash may not provide the same levelof protection in a subsequent crash.
The dealer should also inspect the anchors for damage and replace
them if needed. Automatic seat belt tensioners that
deployed during a crash must be
replaced.
For information on how to clean yourseat belts, see page 294 .
Driver and Passenger Safety
Not checking or maintaining
seat belts can result in serious injury or death if the seat belts
do not work properly whenneeded.
Check your seat belts regularly
and have any problem
corrected as soon as possible.
Page 46 of 372
Additional Information About Your Airbags
SRS Components
Your Supplemental Restraint System (SRS) includes:
Two front airbags. The driver'sairbag is stored in the center of
the steering wheel; the front
passenger's airbag is stored in the dashboard. Both are marked "SRS
AIRBAG."
Automatic seat belt tensioners
(see page 41).
Sensors that can detect a
moderate to severe frontal
collision.
A sophisticated electronic system
that continually monitors andrecords information about thesensors, the control unit, the
airbag activators, and driver and
passenger seat belt use when the ignition is ON (II).
An indicator light on the instrument panel that alerts you toa possible problem with the
system (see page 44).
Emergency backup power in case
your car's electrical system is
disconnected in a crash.
How Your Front Airbags Work
If you ever have a moderate to
severe frontal collision, the sensors
will detect the vehicle's rapid deceleration. If the rate of
deceleration is high enough, the
control unit will instantly inflate the
front airbags.
CONTINUED
Driver and Passenger Safety
Page 47 of 372
Additional Information About Your Airbags
During a frontal crash, your seat
belts help restrain your lower body and torso. Your airbag provides a
cushion to help restrain and protect
your head and chest.
Since both airbags use the samesensors, both airbags normally
inflate at the same time. However, it
is possible for only one airbag to
inflate.
This can occur when the severity of a collision is at the margin, or
threshold, that determines whether or not the airbags will deploy. In
such cases, the seat belt will provide
sufficient protection, and the
supplemental protection offered by
the airbag would be minimal. After inflating, the front airbags
immediately deflate, so they won't
interfere with the driver's visibility,or the ability to steer or operate
other controls.
The total time for inflation and deflation is approximately one-tenth
of a second, so fast that most occupants are not aware that the
airbags deployed until they see them
lying in their laps. After a crash, you may see what
looks like smoke. This is actually
powder from the airbag's surface.
Although the powder is not harmful,
people with respiratory problems
may experience some temporary
discomfort. If this occurs, get out of
the car as soon as it is safe to do so.
U.S. Owners:
For additional information on how
your airbags work, see the booklet
titled SRS: What You Need to Know
About Airbags that came with your
owner's manual.
Canadian Owners:
For additional information on how
your airbags work, ask your dealer for a copy of the booklet titled SRS:
What You Need to Know About Airbags.
Driver and Passenger Safety
Page 48 of 372
Additional Information About Your Airbags
How Your Side Airbags Work
Some models are equipped with sideairbags for the driver and a front
seat passenger. The airbags are
stored in the outer edges of the front
seat-backs, and both are marked
"SIDE AIRBAG." If you ever have a moderate to
severe side impact, the sensors will
detect rapid deceleration and signal
the control unit to instantly inflate either the driver's or the passenger's
side airbag.
Only one airbag will deploy during aside impact. If the impact is on the
passenger's side, the passenger's side airbag will deploy even if there
is no passenger.
To get the best protection from the side airbags, front seat occupantsshould wear their seat belts and sit
upright and well back in their seats. How the SRS Indicator Light
Works
The purpose of the SRSindicator light is to alert
you to a potential problem with your front airbags. On cars with side airbags, this light will also alert you
to a potential problem with your automatic seat belt tensioners (page 41); or your side airbags or
passenger's side airbag automatic
cutoff system (page 46).
When you turn the ignition ON (II), this indicator will light up briefly
then go out. This tells you that thesystem is working properly.
CONTINUED
Driver and Passenger Safety
SRS
Page 49 of 372
Additional Information About Your Airbags
If the light comes on at any other
time, or does not come on at all, youshould have the system checked by
your dealer. For example:
If the SRS indicator light does not
come on after you turn the ignition
ON (II).
If the light stays on after the
engine starts.
If the light comes on or flashes on
and off while you drive.
If you see any of these indications,
your front or side airbags may not deploy, your passenger's side airbag
automatic cutoff system may not
work properly, or your seat belt tensioners may not work when you
need them. See your Honda dealer
as soon as possible.
How The Side Airbag Indicator
Light Works
This light alerts you thatthe passenger's side airbag
has been automatically shut off.
To reduce the risk of injury from an inflating side airbag, your car has an
automatic cutoff system for the
passenger's side airbag.
Although Honda does not encourage children to ride in the front, thissystem is designed to shut off the
side airbag if a child leans sideways
and the child's head is in the side airbag deployment path.
Driver and Passenger Safety
SIDEAIRBAG
Ignoring the SRS indicator light
can result in serious injury or
death if the airbags, cutoff system, or tensioners do not
work properly.
Have your vehicle checked by a
dealer as soon as possible if
the SRS light alerts you to a potential problem.
Page 50 of 372
Additional Information About Your Airbags
If a small-statured adult leans
sideways, or larger adult slouches
and leans sideways into the
deployment path of the side airbag,
the system may also shut off the side
airbag.
If the side airbag indicator light
comes on, you should have the
passenger sit upright. Once the
passenger is out of the deployment
path of the side airbag, the system
will turn the airbag back on and the light will go out. A front seat passenger should not
use a cushion or other object as a
backrest. It may prevent the cutoff
system from working properly.
When you turn the ignition ON (II),
the indicator should light briefly and go out (see page 55). If it doesn't
light, stays on, or comes on while
driving without a passenger in the
front seat, have the system checked.
Driver and Passenger Safety
