HONDA ELEMENT 2005 1.G Owners Manual

µEach time you
press and release the , the
player skips f orward to the
beginning of the next track (f iles in
MP3/WMA mode). Press and
release the to skip backward to
the beginning of the current track.
Press it again to skip to the
beginning of the previous track.
To move rapidly within a track, press
andholdthe or .
You will see CUE or REW in the
display while moving within a track.
If you turn the system of f while a
disc is playing, either with the PWR/
VOL knob or by turning of f the
ignition switch, the disc will stay in
the drive. When you turn the system
back on, the disc will begin playing
where it lef t of f .
Insert a disc into the slot. The drive
will pull the disc in the rest of the
waytoplayit.Whenthesystem
reaches the end of the disc, it will
return to the beginning and play the
disc again.
You can also play 3-inch (8-cm) discs
without using an adapter ring. If you press the DISP/MODE button
while playing a disc, additional
information (track, album, artist, etc.)
maybedisplayed.
To play the radio when a disc is
playing, press the AM/FM button.
Press the CD/AUX button again to
switch back to the disc player.
You can use the SEEK/SKIP button
while a disc is playing to select
passages and change tracks (f iles in
MP3/WMA mode).
In MP3/WMA mode, use the
FOLDER knob to select f olders in
the disc, and use the SEEK/SKIP
button to change f iles.
CONT INUED
Except EX models
Playing a Disc
SEEK /SK IP
T o Change or Select T racks/Files
Features
109

µµ µ
µ µ
To continuously replay
a track (f iles in MP3/WMA mode),
press and release the RPT button.
You will see RPT in the display.
Press the RPT button again to turn it
off.
To
select a different folder, use the
FOLDER knob to move to the
beginning of the next f older. Turn
the knob right to move to the
beginning of the current f older. Turn
the knob lef t to skip to the beginning
of the previous f older. This feature,
when activated, replays all the f iles
on the selected f older in the order
they are compressed in MP3/WMA.
To activate f older repeat mode, press
andholdtheRPTbuttonfor2
seconds. You will see RPT in
the display. The system continuously
replays the current f older. Press and
hold the RPT button for 2 seconds to
turn it off.
This f eature plays the
tracks (all f iles in each f older in
MP3/WMA mode) within a disc in
random order. To activate random
play, press and release the RDM
button. You will see RDM in the
display. Press the RDM button again
to return to normal play. This
f eature, when activated, plays the
f iles within a f older in random order,
rather than in the order they are
compressed in MP3/WMA. To
activate folder random play, press
andholdtheRDMbutton.Youwill
see RDM in the display. The
system will then select and play f iles
randomly. This continues until you
deactivate f older random play by
pressing the RDM button again or
selecting a dif f erent f older with the
FOLDER knob.
In MP3/WMA mode
On EX models
Playing a Disc
REPEAT (TRACK/FILE
REPEAT)
FOLDER SELECTION FOL DER-REPEA T
RANDOM (Random within a
Disc)FOLDER-RANDOM
110

µµ
Pressing either side of the SEEK/
SKIP button also turns of f the scan
feature. If you turn the system of f while a
disc is playing, either with the PWR/
VOL knob or by turning of f the
ignition switch, the disc will stay in
the drive. When you turn the system
back on, the disc will begin playing
where it lef t of f .
The SCAN f unction
samples all tracks/f iles on the
selected disc in the order they are
recorded. To activate the scan
f eature, press and hold the SCAN
button until you hear a beep. You will
see SCAN in the display. You will get
a10secondsamplingof eachtrack/
f ile on the selected disc. Press the
SCAN button again to get out of scan
mode and play the last track/f ile
sampled. This feature,
when activated, samples all files on
the selected f older in order. To
activate the folder scan feature,
press and hold the SCAN button
until you hear a beep. You will see SCAN in the display. The
system will then play the f irst f ile f or
about 10 seconds. If you do nothing,
the system will then play the first file
in each f older f or 10 seconds. When
it plays a f ile you want to continue
listening to, press the SCAN button
again.
Pressing either side of the SEEK/
SKIP button or selecting a dif f erent
folder with the FOLDER knob also
turns off the scan feature. Press the eject button ( ) to
remove the disc. If you eject the disc,
but do not remove it f rom the slot,
the system will automatically reload
the disc af ter 15 seconds and put it in
pause mode. To begin playing, press
the CD/AUX button.
Press the AM/FM button to switch
to the radio while a disc is playing.
To play the disc, press the CD button.
Playing a Disc
To Stop Playing a Disc
SCA N FOL DER-SCA N
Features
111

µ´µ
´ If you select an empty slot in the
magazine, the changer will search
f or the next available disc to load and
play.
The auxiliary input jack is on the
dashboard next to the accessory
power socket. The system will accept
auxiliary input f rom standard audio
accessories.
When the accessory is connected to
the auxiliary input jack, press the
AUX button to select it.
See pages and for
inf ormation on error messages.
For inf ormation on how to handle
and protect discs, see page . To select the disc changer, press the
CD/AUX button. The disc and track
numbers will be displayed. To select
a dif f erent disc, use the preset 5
(DISC ) or the preset 6 (DISC )
button. To select the previous disc,
press the preset 5 (DISC ), or the
preset 6 (DISC ) to select the next
disc in sequence. Load the desired discs in the
magazine, and load the magazine in
the changer according to the
instructions that came with the unit. An optional six disc changer is
available f or your vehicle. This disc
changer uses the same controls used
f or the in-dash disc player or the
radio.
113
115
114
On EX models
LX model only
Auxiliary Input Jack
Audio System Malf unction
Protecting DiscsOperating the Optional Disc
Changer
Playing a Disc
112

Never try to insert f oreign objects in
the CD player or the magazine. When a disc is not being played,
store it in its case to protect it f rom
dust and other contamination. To
prevent warpage, keep discs out of
direct sunlight and extreme heat.
To clean a disc, use a clean sof t cloth.
Wipe across the disc f rom the center
to the outside edge.Handle a disc by its edges; never
touch either surf ace. Do not place
stabilizer rings or labels on the disc.
These, along with contamination
f rom f inger prints, liquids, and f elt-
tip pens, can cause the disc to not
play properly, or possibly jam in the
drive.
When using CD-R or CD-RW discs,
use only high quality CDs labeled
f or audio use.
When recording a CD-R or CD-
RW, the recording must be closed
f or it to be used by the system.
Play only standard round discs.
Odd-shaped discs may jam in the
driveorcauseotherproblems.
Handle your discs properly to
prevent damage and skipping.
A new disc may be rough on the
inner and outer edges. The small
plastic pieces causing this roughness
can f lake of f and f all on the recorded
surf ace of the disc, causing skipping
or other problems. Remove these
pieces by rubbing the inner and
outer edges with the side of a pencil
or pen.
General Inf ormation
Protecting Discs
Protecting Your Discs
Features
113

Indication
If you see an error message in the
display while playing a disc, f ind the
cause in the chart to the right. If you
cannot clear the error message, take
the vehicle to your dealer. Cause
Solution
FOCUS error
Mechanical error
High temperature Press the EJECT button and pull out the disc.
Check if it is inserted correctly in the player.
Make sure the disc is not scratched or damaged.
Press the EJECT button and pull out the disc.
Check the disc for damage or deformation.
If the disc cannot be pulled out, or the error
message does not disappear after the disc is
ejected, see your dealer.
Will disappear when the temperature returns to
normal.
EX models
Except EX models
:
:
Disc Player Error Messages
114

Indication
If you see an error message in the
display while playing a disc, f ind the
cause in the chart to the right. If you
cannot clear the error message, take
the vehicle to your dealer. Solution
Cause
Press the magazine eject button, and pull the
magazine out.
If the message does not disappear or the
magazine cannot be pulled out, see your dealer.
Insert disc.
Press the magazine eject button, and pull the
magazine out. Check for an error message, and
insert the magazine again. If the message does
not disappear or the magazine cannot be pulled
out, see your dealer.
Will disappear when the temperature returns to
normal.
Insert magazine.
FOCUS error
No disc in the magazine
Mechanical error
High temperature
No magazine in the
changer
:EX models
:Except EX models
Disc Changer Error Messages
Features
115

Your vehicle’s audio system will
disable itself if it is disconnected
f rom electrical power f or any reason.
To make it work again, you must
enter a specif ic f ive-digit code in the
preset buttons. Because there are
hundreds of number combinations
possible f rom f ive-digits, making the
system work without knowing the
exact code is nearly impossible.
Youshouldhavereceivedacardthat
lists your audio system’s code and
serial numbers. It is best to store this
card in a saf e place at home. In
addition, you should write the audio
system’s serial number in this
Owner’s Manual.
If you lose the card, you must obtain
the code number f rom a dealer. To
do this, you will need the system’s
serial number.If your vehicle’s battery is
disconnected or goes dead, or the
radio f use is removed, the audio
system will disable itself . If this
happens, you will see ‘‘CODE’’ in the
frequencydisplaythenexttimeyou
turn on the system. Use the preset
buttons to enter the five-digit code.
Thecodeisontheradiocodecard
included in your Owner’s Manual kit.
When it is entered correctly, the
radio will start playing.
If you make a mistake entering the
code, do not start over; complete the
f ive-digit sequence, then enter the
correct code. You have ten tries to
enter the correct code. If you are
unsuccessful in ten attempts, you
must then leave the system on for 1
hour bef ore trying again.
On EX models
Radio T hef t Prot ect ion
116

If your vehicle’s battery is
disconnected or goes dead, you will
need to set the clock.You can use the R button to quickly
set the time to the nearest hour.
Press the R button while pressing
the CLOCK button. If the displayed
time is before the half hour, pressing
Rsetstheclockbacktotheprevious
hour. If the displayed time is af ter
the half hour, pressing R sets the
clock f orward to the beginning of the
next hour.
For example:
1:06 will reset to 1:00
1:53 will reset to 2:00
To set the hour, press the H button
while pressing the CLOCK (SCAN/
RPT) button until the hour advances
to the desired time. Change the
minute by pressing the M button
while pressing the CLOCK (SCAN/
RPT) button until the minute
advances to the desired time.
Press and hold the CLOCK button
until the numbers f lash and you hear
abeep.Changethehourbypressing
the H button until the numbers
advance to the desired time. Change
the minute by pressing the M button
until the numbers advance to the
desired time.
CONT INUED
U.S. LX and Canadian DX models On U.S. EX models
Setting the Clock
Features
117
CLOCK
BUTTON
H BUTTON R BUTTON TIME DISPLAY
M BUTTON CLOCK
BUTTON
H BUTTON R BUTTON
M BUTTON
TIME
DISPLAY

You can quickly set the time to the
nearest hour. If the displayed time is
bef ore the half hour, press the R
(RESET) button to set the clock
back to the previous hour. If the
displayed time is af ter the half hour,
pressing R sets the clock f orward to
the beginning of the next hour.For example:
1:06 will reset to 1:00
1:53 will reset to 2:00
When you are f inished, press the
CLOCK button again.
On Canadian EX models
Setting the Clock
118
H BUTTON
R BUTTON
M BUTTON
TIME
DISPLAY
CLOCK BUTTON
