If something electrical in your
vehicle stops working, the first thing
youshouldcheckforisablownfuse.
Determine f rom the chart on pagesand , or the diagram on the
fuse box lid, which fuse or fuses
control that device. Check those
f uses f irst, but check all the f uses
bef ore deciding that a blown f use is
the cause. Replace any blown f uses,
and check if the device works.
Turn the ignition switch to the
LOCK (0) position. Make sure the
headlights and all other
accessories are of f . Remove the cover f rom the under-
hood f use box located on the
battery (see page ).
Check each of the large f uses in
the under-hood f use box on the 12
volt battery by looking through
thetopatthewireinside.
Replacement of these f uses should
be done by your dealer.Check the smaller f uses in the
under-hood f use boxes and all the
fuses in the interior fuse box by
pulling out each one with the f use
puller provided in the interior f use
box.
1.
2.4.
3.
372 373
368
CONT INUED
Checking and Replacing Fuses
Fuses
T aking Care of t he Unexpect ed
369
BLOWNFUSE PULLER
