HONDA ODYSSEY 1996 Workshop Manual

Keys and Locks

LOCK (0) — You can insert or
remove the key only in this position.
When you turn the key from LOCK to ACCESSORY, you may have to
turn the steering wheel to release the anti-theft lock. To switch from
ACCESSORY to LOCK, you must push the key in slightly as you turn it.
The shift lever must also be in Park. The anti-theft lock will lock the steering column when you remove
the key.
ACCESSORY (I) — In this position, you can operate the audio systemand cigarette lighter.
ON (II) — This is the normal key
position when driving. All features and accessories on the car are usable.
Several of the lights on the instru-
ment panel come on as a test when
you turn the ignition switch from
ACCESSORY to ON (see page 35 ). START (III) — Use this position
only to start the engine. The switch
returns to ON when you let go of the

key.

You will hear a reminder beeper if
you open the driver's door with the key in the LOCK or ACCESSORYposition. Remove the key to turn itoff. Power Door Locks
Each front door has a master door
lock switch. Either switch locks andunlocks all doors. Push the switchdown to lock all doors, and up to
unlock them. The lock tab on the
tailgate also locks and unlocks when
you use the master door lock switch.
Instruments and Controls MASTER DOOR LOCK SWITCHProCarManuals.comMain Menu s t Table of Contents

Keys and Locks
LOCK TAB

Each door also has a lock tab on the
top. When you push down the lock
tab on the driver's door, all the doors and the tailgate lock. Pulling up the
lock tab on the driver's door unlocks only that door. The lock tab on each
passenger's door locks and unlocks
only that door. To lock any passenger's door when
getting out of the car, push the lock
tab in and close the door. To lock thedriver's door, pull the outside door
handle and push the lock tab in or push the master switch down.
Release the handle, then close the
door.

All doors and the tailgate can be locked from the outside by using thekey in either front door. To unlockonly the driver's door from theoutside, turn the key and release it.
If you turn the key and hold it, all doors and the tailgate will unlock. All
four doors and the tailgate will
unlock when you unlock the
passenger's door with the key. Remote Transmitter

U.S. EX model

You can lock and unlock your car using the remote transmitter. If you
push "LOCK" on the transmitter, all doors and the tailgate will lock.
If you push "UNLOCK" once, only
the driver's door will unlock; if you
push "UNLOCK" again, all doors and the tailgate will unlock.

Instruments and ControlsProCarManuals.comMain Menu s t Table of Contents

Keys and Locks

If you use the unlock feature on the
remote transmitter, and a door or the
tailgate is not opened within 20 seconds, all doors and the tailgate
will automatically lock. The remote transmitter will not work if the key isin the ignition.

This device complies with Part 15 of the

FCC rules. Operation is subject to the

following two conditions: (1) This device

may not cause harmful interference, and
(2) this device must accept any

interference received, including
interference that may cause undesired
operation.

Changes or modifications not expressly
approved by the party responsible for
compliance should void the user's

authority to operate the equipment.
Childproof Door Locks
The childproof door locks are
designed to prevent children seated
in the rear from accidentally opening
the rear doors. Each rear door has a
lock lever near the edge. With the
lever in the LOCK position, the door cannot be opened from the inside
regardless of the position of the lock
tab. To open the door, pull the lock
tab up and use the outside door
handle.
Tailgate
Use your key to lock and unlock the
tailgate. (On the U.S. EX model, you remote transmitter will also lock andunlock the tailgate.)
To open the tailgate, pull the handle, then lift up the tailgate.

Instruments and Controls
LEVERProCarManuals.comMain Menu s t Table of Contents

Keys and Locks

Glove Box
Open the glove box by pulling the
bottom of the handle. Close it with a
firm push. Lock or unlock the glove
box with the master key.

Instruments and Controls

An open glove box can cause
serious injury to your passengerin a crash, even if thepassenger is wearing the seat

belt.

Always keep the glove box
closed while driving.ProCarManuals.comMain Menu s t Table of Contents

Seats

Passenger Seating

Six-passenger model

The six-passenger model has
separate seats with armrests for two

front passengers, separate seats with
armrests for two passengers in thesecond row, and a bench seat for two
passengers in the third row.
For greater cargo capacity, the seats

in the second row can be removed,

and the bench seat in the third row-
can be folded into the floor. Seven-passenger model
The seven-passenger model has separate seats with armrests for twofront passengers, a bench seat for
three passengers in the second row,
and a bench seat for two passengers in the third row.
For greater cargo capacity, the seat
in the second row can be folded out of the way in sections, and the bench
seat in the third row can be folded
into the floor.
Seat Adjustments

Adjust the seat before you startdriving.
To adjust the seat forward and backward, pull up on the lever under
the seat cushion's front edge. Move the seat to the desired position and
release the lever. Try to move the seat to make sure it is locked in

position.

Instruments and ControlsProCarManuals.comMain Menu s t Table of Contents

Seats
Adjust the scat-back before you start driving. The seat-backs should be in
an upright position for you and your
passengers to get the most protec-
tion from the seat belts.
To change the seat-back angle of the front seats, or the second-row seatsin the six passenger model, pull up
on the lever on the outside of the
seat bottom. To adjust the seat-back
angle of the second seat in the seven- passenger model, pull up on the lever
on the side of the seat-back.
Move the seat-back to the desired
position and release the lever. Let
the seat-back latch in the new
position.
Driver's Seat Power Height
Adjustment

U.S. EX model only

The height of your driver's seat is power adjustable. Pull up on the
switch to raise the seat. Push it down
to lower the seat.

Instruments and Controls

Reclining the seat-back can
decrease the protection you get
from your seat belt in a crash.
You can slide under the seatbelt and be seriously injured.
Adjust the seat-back to an upright position and sit well
back in the seat.ProCarManuals.comMain Menu s t Table of Contents

Seats

Head Restraints

KNOB

The head restraints are designed to help reduce the risk of neck injuries.
Your Honda has adjustable head restraints in all the outside seating
positions. Adjust the head restraint so the top is even with the tops of
your ears. The head restraints adjust for height.
You need both hands to adjust the restraint. Do not attempt to adjust it
while driving. To raise it, pull upward.
To lower the restraint, press the release button and push the restraint
down.

To remove a head restraint for cleaning or repair, pull it up as far as
it will go. Push the release buttonand pull the restraint out of the seat-

back.
Third Seat Access

Six-passenger model

To get into or out of the third row seat, walk between the second row

seats.

Instruments and Controls Driving your vehicle without

head restraints can lead to a

serious injury to you and your passengers in a crash.
Make sure the head restraints
are in place and adjusted properly before driving.ProCarManuals.comMain Menu s t Table of Contents

Seats

Seven-passenger model

LOCK RELEASE LEVER

Pull the seat-back angle adjustment
lever on the second row seat to tilt
the seat-back forward. Pull the lock release lever and pivot the seat upout of the way. Move the second seat back into
place by pivoting the seat down.
Make sure it locks to the floor. Pull
the seat-back angle adjustment lever
forward and push the seat-back to
the desired position, then release the
lever. Make sure the seat is securely locked in place. Removing the Second Seats in the
Six-Passenger Model
Both seats can be removed to give
more cargo capacity.
To remove a seat, unlock the seat from the floor by pulling both lock
release levers up at the same timeand pulling up on the rear of the seat.

CONTINUED

Instruments and Controls
LOCK RELEASE LEVERProCarManuals.comMain Menu s t Table of Contents

Seats

Unhook the front of the seat from
the floor by pulling it back slightly,
then pivoting it upward.
Always remove an unlocked seat from the vehicle before driving. Aseat that is not locked in place could
fly around and cause injury in a sudden stop or crash. To reinstall a seat, hook the front of
the seat to the floor, then push the
back into the locks. Make sure both
the front and the back of the seat are securely fastened down before
driving. Folding the Second Seats in the
Seven-Passenger Model
The left and right halves of the second seat can be folded up
separately to create more cargo

space.

Instruments and ControlsProCarManuals.comMain Menu s t Table of Contents

Seats

SEAT-BACK ANGLE

ADJUSTMENT LEVER

LOCK RELEASE LEVER

Pull the seat-back angle adjustment
lever and tilt the seat-back forward.
Then pull the lock release lever and pivot the seat forward.
RIVET

Pull out the fastening strap. Hook
the ring on the fastening strap to the rivet on the side of the seat-back.
Make sure the seat is secure.
Reverse this procedure to return the seat to the upright position. Make
sure you store the fastening strap
properly, and that the seat is locked securely before driving. Reclining the Second Seat
Seven-passenger model only
You can recline the seat-backs on the second seat so they are level with
the seat cushion of the third seat,
making a large, cushioned area. To do this:
1. Remove the head restraints. Store them in the pocket in the left side
panel behind the third seat.

Instruments and Controls
CONTINUED

FASTENING STRAPProCarManuals.comMain Menu s t Table of Contents
