Interior Care
Dirt build-up in the loops of the seat
belt anchors can cause the belts to
retract slowly. Wipe the insides of
the loops with a clean cloth dampened in mild soap and warm
water or isopropyl alcohol. Windows
Clean the windows, inside and out,
with a commercially-available glass cleaner. You can also use a mixture
of one part white vinegar to ten parts
water. This will remove the haze that
builds up on the inside of the
windows. Use a soft cloth or paper towels to clean all glass and clear
plastic surfaces.
The rear window defogger wires are
bonded to the inside of the glass. Wiping vigorously up-and-down can
dislodge and break the defogger wires. When cleaning the rear window, use
gentle pressure and wipe side-to-side. Air Fresheners
If you want to use an air freshener/deodorizer in the interior of your
vehicle, it is best to use a solid type. Some liquid air fresheners contain
chemicals that may cause parts of
the interior trim and fabric to crack or discolor.
If you use a liquid air freshener, make sure you fasten it securely so it
does not spill as you drive.
Appearance Care

NOTICEProCarManuals.comMain Menu Table of Contents s t

Corrosion Protection

Two factors normally contribute to causing corrosion in your vehicle:
1. Moisture trapped in body cavities. Dirt and road salt that collects in
hollows on the underside of the
vehicle stays damp, promoting corrosion in that area.
2. Removal of paint and protective coatings from the exterior and
underside of the vehicle. Many corrosion-preventive measures
are built into your Honda. You can
help keep your vehicle from corroding by performing some
simple periodic maintenance: Repair chips and scratches in the
paint as soon as you discover them. Inspect and clean out the drain
holes in the bottom of the doors
and body. Check the floor coverings for
dampness. Carpeting and floor
mats may remain damp for a long
time, especially in winter. This dampness can eventually cause
the floor panels to corrode. Use a high-pressure spray to clean
the underside of your vehicle. This is especially important in areas
that use road salt in winter. It is also a good idea in humid climates
and areas subject to salt air. Be
careful of the ABS wheel sensors
and wiring at each wheel. Have the corrosion-preventive
coatings on the underside of your
vehicle inspected and repaired periodically.

Appearance CareProCarManuals.comMain Menu Table of Contents s t

Body Repairs

Body repairs can affect your vehicle's
resistance to corrosion. If your
vehicle needs repairs after a collision, pay close attention to the parts used
in the repair and the quality of the
work.
Make sure the repair facility uses
Genuine Honda replacement body
parts. Some companies make sheet
metal pieces that seem to duplicate
the original Honda body parts, but
are actually inferior in fit, finish, and
corrosion resistance. Once installed,
they do not give the same high- quality appearance.
When reporting your collision to the
insurance company, tell them you
want Genuine Honda parts used in
the repair. Although most insurers recognize the quality of original
parts, some may try to specify that
the repairs be done with otheravailable parts. You should investi-
gate this before any repairs have

begun.

Take your vehicle to your authorized Honda dealer for inspection after the
repairs are completed. Your dealer
can make sure that quality materials
were used, and that corrosion-
preventive coatings were applied to all repaired and replaced parts.

Appearance CareProCarManuals.comMain Menu Table of Contents s t

Taking Care of the Unexpected

This section covers the more- common problems that motorists
experience with their vehicles. It
gives you information about how to safely evaluate the problem and what
to do to correct it. If the problem has stranded you on the side of the road,
you may be able to get going again. If not, you will also find instructions
on getting your vehicle towed. Compact Spare Tire....................... 286
Changing a Flat Tire..................... 287
If Your Engine Won't Start........... 296
Nothing Happens or the Starter Motor OperatesVery Slowly......................... 296
The Starter Operates
Normally.................................297

Jump Starting................................. 297 If Your Engine Overheats............. 299
Low Oil Pressure Indicator.......... 301
Charging System Indicator........... 302
Malfunction Indicator Lamp ........ 303
Brake System Indicator................ 304

Fuses............................................... 305

Checking and Replacing........... 306

Emergency Towing....................... 311

Taking Care of the UnexpectedProCarManuals.comMain Menu s t

Compact Spare Tire

Your vehicle has a compact spare tire that takes up less space. Use thisspare tire as a temporary replace-
ment only. Get your regular tire
repaired or replaced and put back on
your vehicle as soon as you can.
Check the inflation pressure of the
compact spare tire every time you
check the other tires. It should be
inflated to: 60 psi (420 kPa , 4.2 kgf/cm2)
Follow these precautions whenever
you are using the compact spare tire: Do not exceed 50 mph (80 km/h)
under any circumstances. This tire gives a harsher ride and
less traction on some road sur-
faces than the regular tire. Use
greater caution while driving on this tire. Do not mount snow chains on the

compact spare.

Do not use the compact spare tire
if you are towing a trailer. The wheel of the compact spare
tire is designed especially to fit
your vehicle. Do not use your spare tire on another vehicle
unless it is the same make and

model.

On EX model
Turn off the Traction Control
System (see page 207 ). Driving
with the compact spare tire may activate the TCS.
INDICATOR LOCATION MARK

TREAD WEAR INDICATOR BAR

The compact spare tire has a shorter
tread life than a regular tire. Replace

it when you can see the tread wear

indicator bars. The replacement
should be the same size and design

tire, mounted on the same wheel.

The compact spare tire is not
designed to be mounted on a regular

wheel, and the compact wheel is not
designed for mounting a regular tire.

Taking Care of the UnexpectedProCarManuals.comMain Menu Table of Contents s t

Changing a Flat Tire
If you have a flat tire while driving, stop in a safe place to change it.
Stopping in traffic or on the shoulder
of a busy road is dangerous. Drive slowly along the shoulder until you
get to an exit or an area to stop that
is far away from the traffic lanes. JACK

VINYL BAG
TOOLS

1. Park the vehicle on firm, level and non-slippery ground away from
traffic. Put the transmission in
Park. Apply the parking brake. SPARE TIRE
2. Turn on the hazard warning lights and turn the ignition switch to
LOCK (0). Have all the
passengers get out of the vehicle
while you change the tire.

CONTINUED

Taking Care of the Unexpected

The vehicle can easily roll off

the jack, seriously injuring
anyone underneath.
Follow the directions for
changing a tire exactly, and never get under the vehicle
when it is supported only by the

jack.ProCarManuals.comMain Menu Table of Contents s t

Changing a Flat Tire

COVER

3. Open the tailgate. Remove the cargo net.
4. The tools and jack are behind a cover in the cargo area on thedriver's side. Remove the cover by
turning the handle
counterclockwise, then pulling out
the cover. 5. Take the tools out of the storage
compartment.
6. Turn the jack's end bracket counterclockwise to loosen it, thenremove the jack. 7. The spare tire is stored under the
floor between the first and second
row of seats. If the front seats areadjusted to the rear-most position,
move the seats forward slightly and adjust the seat-backs to an
upright position (see page 100).
Lift up the center table (see page 117).
Taking Care of the UnexpectedProCarManuals.comMain Menu Table of Contents s t

Changing a Flat Tire

8. Open either of the rear sliding doors. Pull the floor carpet up by
lifting up on the edge, then raise
the floor lid by pulling up on the
handle. To keep the floor carpet and lid out of the way, pull out the
hook on the back of the floor lid and attach it into the seat-back
handle on the driver's seat.
SPARE TIRE

BASKET

SPARE TIRE
WING BOLT

9. On EX model
Remove the spare tire basket.
10. Unscrew the wing bolt and take the spare tire out of its well. After
you have removed the spare tire, screw this wing bolt back into

place.
WHEEL NUTS

11.On EX model
If you are changing a rear tire,
close the sliding door. Then turnoff the sliding door MAIN switch.
12. Loosen the five wheel nuts 1/2 turn with the wheel wrench.
CONTINUED
Taking Care of the Unexpected

HOOK

HANDLEProCarManuals.comMain Menu Table of Contents s t

Changing a Flat Tire

13. Locate the jacking point nearest the tire you need to change. It is
pointed to by a A mark moldedinto the underside of the body.
Place the jack under the jacking
point. Turn the end bracketclockwise until the top of the jack
contacts the jacking point. Makesure the jacking point tab is
resting in the jack notch. WHEEL
WRENCH
14. Use the extension and wheel wrench as shown to raise the
vehicle until the flat tire is off theground. 15.Remove the wheel nuts and flat
tire. Temporarily place the flat tireon the ground with the outside
surface of the wheel facing up.
You could scratch the wheel if you put it face down.

Taking Care of the Unexpected

JACKING POINT
EXTENSIONProCarManuals.comMain Menu Table of Contents s t

Changing a Flat Tire

On LX model
Do not attempt to forcibly pry the
wheel cover off with a screwdriver or
other tool. The wheel cover cannot

be removed without first removing

the wheel nuts.
16.Before mounting the spare tire,
wipe any dirt off the mountingsurface of the wheel and hub with
a clean cloth. Wipe the hub
carefully, it may be hot from

driving.
17.Put on the spare tire. Put the
wheel nuts back on finger-tight,
then tighten them in a crisscross
pattern with the wheel wrench
until the wheel is firmly against
the hub. Do not try to tighten
them fully.

CONTINUED

Taking Care of the Unexpected

WHEEL

COVER

BRAKE HUBProCarManuals.comMain Menu Table of Contents s t
