HONDA ODYSSEY 2000 RA6-RA9 / 2.G Owners Manual

Center Table , Beverag e Holde r
Sitting on or getting under the table,
or putting heavy objects on the table,
may damage or deform it.
Do not put any items on the table
while driving. They may fall down or
fly around when you go around corners or brake hard. The center table can be extended by
pulling on the rear. Beverag
e Holde r
To use the front beverage holder, pull on the bottom edge. Push the
holder all the way in to close it.
Instrument s an d Control s

Beverage Holde r
Additional beverage holders for the
front seat passengers, and the
beverage holders for the passengers
in the second row, are in the center
table.The beverage holders for the third seat passengers are located in the
armrests on the rear side panels.
Be careful when you are using the
beverage holder. A spilled liquid that
is very hot can scald you or your
passengers. Spilled liquids can also damage the upholstery, carpeting,
and electrical components in the
interior.
Instrument s an d Control s

Sunglasses Holde r
To open the sunglasses holder, push
on the front edge. It will unlatch andswing down. To close it, push it until
it latches. Make sure the holder is
closed while you are driving. Some larger styles of sunglasses
may not fit in the holder.
Instrument
s an d Control s

Su
n Visor , Vanit y Mirro r

Su n Viso r
To use the sun visor, pull it down. You can also use the sun visor at the side window. Remove the support
rod from the clip and swing the sun
visor toward the side window. In this position, the sun visor can beextended by sliding out the

extension.
Make sure you put the sun visor
back in place when you are getting
into or out of the vehicle. Do not use
the sun visor extension over the rear
view mirror.
Vanit
y Mirro r

To use a vanity mirror on the back of the sun visor, pull up the cover.
The light beside the mirror comes on only when the parking lights are

on.

Instrument s an d Control s

SU
N VISO R

EXTENSIO
N

Rear Compartment , Cente r Pocket , Coi n Holde r
Rear Compartmen t
A storage compartment is located by the third seat on the driver's side. Toopen the compartment, pull the lever
and lift the lid. To close, lower the lid and push it down until it latches. Cente
r Pocke t
CENTER
POCKE T
Open the center pocket by pulling
the handle. Close it with a firm push.
On EX model
The light in the pocket comes on when the instrument panel lights are
on.
Coi n Holde r
COIN
HOLDE R
The coin holder is located in the
front beverage holder. To open it,
pull on the bottom edge. Close it
with a firm push.
Instrument s an d Control s
REA
R COMPARTMEN T
LEVER

Storage Box , Coa t Hoo k
Storag e Bo x
STORAG E BO X
On EX model
A storage box is located under the
front passenger's seat. To use it, pull
the handle and slide the box out. To remove the box for cleaning,
push on the lock tab under the seat
bottom and pull the tray out. Do not try to force the box. You coulddamage it. Coa
t Hoo k
To use a coat hook, push on the lid. Close it with a firm push.
Make sure the coat hook is closed
when you are not using it. This hook is not designed for large or heavy
items.
Instrument s an d Control s
LID
LOC K TA B

Accessory Powe r Socket s
FRONT
Your vehicle has two accessory
power sockets. The front accessory
power socket is located under the center pocket. The rear socket is
behind the third seat on the driver's
side.
REA R
To use an accessory power socket,
pull out on the cover. The ignitionswitch must be in ACCESSORY (I)
or ON (II).
These sockets are intended to supply power for 12 volt DC accessories
that are rated 120 watts or less (10
amps).
When both sockets are being used,the combined power rating of both
accessories should be 120 watts or less (10 amps).
They will not power an automotive type cigarette lighter element.
Instrument s an d Control s

Interior Light s
Light Contro l Switc h
The light control switch controls the interior lights: the individual map
lights by the sun visors, the
individual map lights above the second and third row passengers,
and the cargo area light. This switch
has three positions: OFF, Door
Activated, and ON. When this switch is in the OFF
position:
None of the lights come on when a
door or the tailgate is opened.
The individual map lights in the front can be turned on and off with
the switches next to the lights.
The individual map lights in the second and third rows cannot be
turned on.
The cargo area light can be turned on with the switch in the light. When the switch is in the Door
Activated position:
The individual map lights in thefront come on when any door orthe tailgate is opened. When thedoors and the tailgate are closed,
each light can be turned on and off
with the switch next to the light.
The individual map lights in the second and third rows come on
when any door or the tailgate is opened. When the doors and the
tailgate are closed, each light can
be turned on and off by pushing on the lens.
CONTINUED
Instrument s an d Control s
LIGH
T CONTRO L SWITC H
DOO R
ACTIVATE D
POSITIO N
OFF
O
N

Interio
r Light s

The cargo area light comes on when any door or the tailgate is opened if the switch in the light is
in the door activated (center)
position. When the doors and the
tailgate are closed, it can be turned on with the switch in the light. When the switch is in the ON

position:
All the individual map lights come
on and stay on as long as the
switch remains in the ON position. The cargo area light comes on and
stays on if the switch in the light is
in the door activated (center)

position.
On EX model
The lights go out about six seconds after all the doors and the tailgate
have closed.
With the light control switch in the Door Activated position, all the
individual map lights and the cargo
area light (with the switch in the
center position) come on when you
unlock the door with the remote
transmitter (see page 81).
With any door or the tailgate left open, the lights stay on about three
minutes, then go out.
Instrument s an d Control s

Interior Light s
Individua l Ma p Light s
Turn on the front individual map lights by pushing the button next toeach light. Push the button again to
turn it off. You can also operate
these lights with the light control switch (see page 125).
REA R
Turn on each rear individual map
light by pushing the lens when the
ignition switch is in the
ACCESSORY (I) or ON (II) position. Push the lens again to turn it off.
You can also operate these lights with the light control switch (see
page 125). Carg
o Are a Ligh t
The cargo area light has a three- position switch. In the OFF position,
the light does not come on. In the
center position, it comes on when
you open the tailgate. In the ON position, it stays on continuously.
This light also works with the light control switch (see page 125).
Instrument s an d Control s
FRONT
OFF
O N
