display HONDA ODYSSEY 2013 RC1-RC2 / 5.G Navigation Manual

31

Interface Settings
Language
System Setup
LanguageHINFO button
 Setup
 Other
 Language
Set the system language used on all scr eens. You can choose from three languages:
English , Français (French), Español (Spanish).
Rotate i to select the system
language. Press u.
1Language
Voice confirmation of ci ties and streets only
occurs when English is the system language.
When Français or Español is selected, some
messages continue to be displayed in English.

32

Interface Settings
Wallpaper
System Setup
WallpaperHINFO button
 Clock/Wallpaper
 Picture Setup
Select, delete, and import wallpaper pi ctures for display on the screen.
Rotate i to select an item. Press u .
The following item s are available:
• Select a Picture for Wallpaper : Sets the desired picture for the wallpaper.
2Selecting a Wallpaper Picture
P. 34
• Delete Pictures on HDD : Deletes pictures on the Hard Disc Drive.
2Deleting Pictures from HDD
P. 35
• Import Pictures from USB : Stores pictures on the Hard Disc Drive.
2Importing Pictures from USB
P. 36

34

Interface Settings
Wallpaper
System Setup
HINFO button
 Clock/Wallpaper
 Picture Setup
 Select a Picture for
Wallpaper
1.Rotate i to select a picture. Press
u .

The picture is displayed on the
screen.
2. Press u to select OK.
■Selecting a Wallpaper Picture
1 Selecting a Wallpaper Picture
Two images are provided for the HDD as a
factory default.

35

Interface Settings
Wallpaper
System Setup
HINFO button
 Clock/Wallpaper
 Picture Setup
 Delete Pictures on HDD
1. Rotate i to select a picture. Press
u .

The picture is displayed on the
screen.
2. Press u to select OK.

Repeat step 1 and 2 to delete
other pictures.

Items to be deleted are indicated
with a trash icon.
3. Move r to select OK.
4. Rotate i to select Yes. Press u
to delete the picture(s).
■ Deleting Pictures from HDD
1 Deleting Pictures from HDD
If there are no pictures on the HDD, “No Entries
Exist” is displayed.
You can only delete pictures when the vehicle is
in Park.
You can only delete pictures that have been fully
uploaded from a USB flash drive.
Trash icon
Continued

36

Interface Settings
Wallpaper
System Setup
HINFO button
 Clock/Wallpaper
 Picture Setup
 Import Pictures from
USB
1.Connect a USB flash drive
containing pictures.
2. Rotate i to select a picture to
upload. Press u.

Repeat the procedure to upload
more pictures.
3. Move r to select OK.
■Importing Pictures from USB
1 Importing Pictures from USB
You can only import pictures when the vehicle is
in Park.
You can connect a USB flash drive using the USB
adapter cable in the console compartment.
2 Connecting a USB Flash Drive P. 160
You can only import pict ures from the root
directory. Pictures in folders cannot be imported.
The display size is a fixed 800  480 pixels.
Smaller pictures are displayed against a black
background. Larger pictures are scaled down
without changing the aspect ratio.
Ten pictures (in BMP or JPEG format) can be
saved to the HDD.
Incompatible data format s or pictures greater
than 6 MB cannot be uploaded.
Pictures with a file name longer than 211
characters cannot be uploaded.
If you attempt to upload a picture with the same
name as an existing picture, a pop-up screen asks
if you want to overwrite the existing picture file.

38

Personal Information
Address Book
System Setup
Address BookHINFO button
 Setup
 Personal Information
 Address Book
Store up to 200 address entries in two address books. You can add, edit, and delete
information in the address books. Move w or y to display only the
addresses in the selected category.
H INFO button
 Setup
 Personal Information
 Address Book
This section explains how to enter the name and address.
1.Rotate i to select New Address .
Press u.
1Address Book
If you have PIN-protec ted your address book,
enter your PIN when prompted. Move r to
select OK. PIN numbers are optional.
2 PIN Numbers P. 43
Any address book categories you create are also
displayed on the Select an Address screen.
2 Selecting an Address Book Category P. 41
■Adding an Address Book Entry
1 Adding an Address Book Entry
If you do not give the address a name, one is
automatically assigned (e.g., Address 001). You
can re-enter, edit, or make changes to any entry.
“Address” is the only required field.

40

Personal Information
Address Book
System Setup
The following items are available:
• Current Position: Select your current position.
• Address: Enter an address on the character input screen when prompted.2Address
P. 70
• Previous Destinations: Select a previous destination.
2Previous Destination
P. 76
• Place Name: Enter the name of a place/landmark.
2Place Name
P. 77
• Place Category: Select a category to search for a place/landmark (e.g., Banking,
Lodging).
2 Place Category
P. 80
• Place Phone Number: Enter the phone number of a place/landmark.
2Place Phone Number
P. 84
H INFO button
 Setup
 Personal Information
 Address Book
1. Rotate i to select the address to
edit. Press u.
2. Enter the name, address, phone
number, and category fields.
2 Adding an Address Book Entry P. 38
3. Move r to select OK.
■Editing an Address Book Entry
1 Adding an Address Book Entry
When you use Place Name or Place Category ,
the phone number is automatically entered.1 Editing an Address Book Entry
The entered contents are displayed on the Edit
address screen.

41

Personal Information
Address Book
System Setup
HINFO button
 Setup
 Personal Information
 Address Book
1. Rotate i to select an address.
Press u.
2. Rotate i to select Edit
Category . Press u.
3. Rotate i to select BUSINESS ,
PERSONAL , or a category you
created. Press u.
■ Creating a New Category
1. Rotate i to select New Category . Press u.
2. Enter a name and select an icon when prompted.

The created category is displayed in the list of categories.
■ Deleting or Editing a Category
1. Move y to select Edit.
2. Rotate i to select Delete or Edit Category . Press u.
3. Delete an existing category, or change the name and icon.
■Selecting an Address Book Category
1 Selecting an Addr ess Book Category
You can have up to 100 categories (including
“UNFILED”).
If you delete a category that is used by other
addresses, the category type for those addresses
changes to “UNFILED.”
Category Icons
The following icons ca n be selected for a
category:
Continued

43

Personal Information
PIN Numbers
System Setup
PIN NumbersHINFO button
 Setup
 Personal Information
 PIN Number
Set a 4-digit PIN for protecting personal addresses and your home addresses. Once
you set a PIN, you are prompted to enter it whenever you access a personal address
or a home address.
1.Rotate i to select the PIN to
create. Press u.
2. Rotate i to select a digit to
enter. Press u. Repeat to enter a
new 4-digit PIN.
3. Re-enter the new PIN, when
prompted, to confirm the number
you just entered.

If you have not entered the
same number both times, an
“INCORRECT PIN” message is
displayed. Enter your PIN again.
1PIN Numbers
PIN
Personal Identification Number (PIN) is a
password used to access personal data.
PINs are optional. If you choose to use a PIN,
keep a note of the number in a secure location. If
you forget your PIN, your dealer will have to reset
the navigation system a nd all of your stored
information will be erased . The factory default is
no PIN.
If you want to stop using a PIN, move
r to select
DO NOT USE PIN .

49System Setup
Routing & GuidanceHINFO button
 Setup
 Other
 Routing & Guidance
Choose various settings that determine the navigation system functionality during
route guidance. Rotate i to select an item. Press u.
The following items are available:
• Rerouting : Sets the route recalculation to automatic or manual mode.
2Rerouting
P. 50
• Unverified Area Routing: Sets whether you use the rout e guidance in unverified
areas.
2 Unverified Area Routing
P. 51
• Edit Avoid Area : Specifies areas to avoid when calculating a route.
2Edit Avoid Area
P. 53
• Edit Waypoint Search Area: Sets the distance from the route to find waypoints.
2 Edit Waypoint Search Area
P. 55
• Guidance Mode : Sets whether to display only the map screen or a split map-
guidance screen.
2 Guidance Mode
P. 103
• Street Name Guidance : Sets whether to read out the street names during voice
guidance.
2 Street Name Guidance
P. 56
Continued
