Light
s

Replacin g a Fron t Tur n Signa l
Ligh t Bul b
1. Use a Phillips-head screwdriver to loosen the turn signal assembly's
mounting screw.
2. Remove the turn signal assembly from the bumper. 3. Remove the socket from the turn
signal assembly by turning it one-
quarter turn counterclockwise.
4. Pull the bulb straight out of its
socket.

Push the new bulb straight into
the socket until it bottoms. 5. Insert the socket back into the
turn signal assembly. Turn itclockwise to lock it in place.
6. Test the lights to make sure the new bulb is working.
7. Put the turn signal assembly into the bumper. Make sure the tab on
the turn signal assembly fits into
the bumper slot. Tighten the
mounting screw.

Maintenanc e

SCRE
W
TUR
N SIGNA L ASSEMBL Y

BUL B

SOCKE T

Light
s

Replacin g Rea r Bulb s
1. Open the trunk.
2. Undo the fastener on the side of the trunk lining by pushing on thecenter of the fastener's head until
it pops in. Pull the lining back. 3. Determine which of the five bulbs
is burned out: stop/taillight, turnsignal light, side marker light,
back-up light, or taillight.
4. Remove the socket by turning it one-quarter turn counterclockwise. 5. Pull the bulb straight out of its
socket.
Push the new bulb straight into
the socket until it bottoms.

CONTINUED

Maintenanc e

Light
s

6. Reinstall the socket into the light assembly by turning it clockwise
until it locks.
7. Test the lights to make sure the new bulb is working.
8. Reinstall the trunk lining.
9. Reset the fastener by pushing onthe pointed end until it pops backalmost flush with the fingers on
the housing.
10. Put the fastener in the hole in the side of the trunk lining and push
on the center until it locks (the
center is flush with the head).

Maintenanc e

Light
s

Replacin g a High-moun t Brak e
Ligh t Bul b
(Excep t Typ e S H model )
1. Remove the high-mount brake light assembly by pushing itslightly toward the rear windshield
and sliding it out of the rear shelf. 2. Remove the socket from the light
assembly by turning it one-quarter
turn counterclockwise.
3. Pull the bulb straight out of its socket.
Push the new bulb straight into
the socket until it bottoms. 4. Reinstall the socket. Turn it
clockwise until it locks.
5. Test the lights to make sure the new bulb is working.
6. Reinstall the high-mount brake light assembly on the rear shelf.
Make sure the tabs on the high-
mount brake light assembly fit
into the slots.
Maintenance
HIGH-MOUN
T BRAK E
LIGH T ASSEMBL Y

Light
s

Replacin g a Rea r Licens e Bul b
1. Use a Phillips-head screwdriver to remove the two screws holding
the license plate light assembly to
the bracket. Pull the assembly away from the bracket. 2. Remove the socket from the light
assembly by turning it one-quarter
turn counterclockwise.
3. Pull the bulb straight out of its socket. Push the new bulb in until
it bottoms in the socket.
4. Turn on the parking lights and
check that the new bulb is

working.

5. Put the license light assembly in place. Reinstall the two screws and
tighten them securely.
Maintenanc e

Light
s

Replacin g Bulb s in th e Interio r
Courtes y Light s
The courtesy lights in the doors and roof come apart the same way. Theydo not all use the same bulb.
The spotlight bulbs are in the ceiling light housing.
1. Remove the lens by carefully prying on the edge of the lens witha fingernail file or a small flat-tipscrewdriver. Do not pry on the
edge of the housing around the

lens.

Ceiling light:Pry on the front edge of the
lens in the middle.

On Type SH
Door light: Pry on the top middle of the

lens.
CEILIN
G LIGH T

2. Remove the bulb by pulling it
straight out of its metal tabs.

3. Push the new bulb into the metal
tabs. Snap the lens back in place.
DOO
R LIGH T

Maintenanc e

Lights
Replacin g th e Trun k Ligh t Bul b
1. Open the trunk. Pull down the trunk light cover.
2. Remove the bulb by pulling it straight out of its metal tabs.
3. Push the new bulb into the metal
tabs.
4. Push the cover back in place.
Maintenanc e
TRUNK LIGH T

Storin
g You r Ca r

If you need to park your car for an
extended period (more than one
month), there are several things you should do to prepare it for storage.
Proper preparation helps prevent deterioration and makes it easier to
get your car back on the road. If possible, store your car indoors. Fill the fuel tank.
Change the engine oil and filter
(see page 183 ). Wash and dry the exterior
completely. Clean the interior. Make sure the
carpeting, floor mats, etc. are
completely dry. Leave the parking brake off. Put
the transmission in Reverse (5- speed manual) or Park (automatic). Block the rear wheels.
If the car is to be stored for a
longer period, it should be
supported on jackstands so the
tires are off the ground. Leave one window open slightly (if
the car is being stored indoors). Disconnect the battery.
Support the front wiper blade
arms with a folded towel or rag so
they do not touch the windshield. To minimize sticking, apply a
silicone spray lubricant to all door
and trunk seals. Also, apply a
vehicle body wax to the painted surfaces that mate with the door
and trunk seals. Cover the car with a "breathable"
cover, one made from a porous
material such as cotton.
Nonporous materials, such as
plastic sheeting, trap moisture,
which can damage the paint. If possible, run the engine for a
while periodically (preferably once a month).
If you store your car for 12 months or longer, have your Honda dealer
perform the inspections called for in
the 24 months/30,000 miles (48,000
km) maintenance schedule (Normal Conditions) as soon as you take it
out of storage (see page 172). The
replacements called for in the
maintenance schedule are not
needed unless the car has actually
reached that time or mileage.

Maintenance

226

Appearanc
e Car e

Regular cleaning and polishing of
your Honda helps to keep it "new" looking. This section gives you hintson how to clean your car and
preserve its appearance: the paint,
brightwork, wheels and interior. Also included are several things you cando to help prevent corrosion.
Exterior Care.................................. 228
Washing...................................... 228

Waxing........................................229

Aluminum Wheels..................... 229
Paint Touch-up........................... 229
Interior Care................................... 230 Carpeting....................................
230

Fabric.......................................... 230

Vinyl............................................ 230
Seat
Belts....................................231

Windows.....................................231

Air Fresheners........................... 232
Corrosion Protection..................... 232

Body Repairs.................................. 233
