VEHICLE SPECIFICATIONS
Measurement ................................................................ 9-2
Engine ........................................................................... 9-3
Lubrication Chart .......................................................... 9-4
9

9VEHICLE SPECIFICATIONS
2
Type Wheel free playRack stroke Oil pump type 4 DOOR
167.7 (4260)
66.1 (1680) 54.9 (1395) 96.1 (2440) 56.5(1435 )56.1 (1425)
ItemOverall length Overall width Overall height (unladen)Wheel base Wheel tread J030A02A-EAT TYRE
PETROL
MF45AH
90A (13.5V) 0.7 KW 0.9 KW
Dual hydraulic with brake booster Ventilated disc DrumCable operated on rear wheel
J010A01A-EAT MEASUREMENT
J060A01A-GAT FUEL SYSTEM
Rack and pinion 0 ~ 1.18 in. (0 ~ 30 mm) 5.3 in. (134 mm) Vane type
175/70 R13, 185/60R14, 185/55 R15 Full size
Option Spare
Front Rear
in. (mm)
J020A01A-EAT POWER STEERING Fuel tank Capacity Imp.gal
9.9 Litre
45
J040A03A-EAT ELECTRICAL
Item Battery Alternator Starter
J050A01A-GAT BRAKE Type Front brake typeRear brake type Parking brake
3/5 DOOR
65.9 (4215)
DIESEL
CMF60AH 90A(12V) 1.7 KW
-
Manual T/A Automatic T/A

9
VEHICLE SPECIFICATIONS
3ENGINE
1.3 MPI
71.5 x 83.5 1,341
800 ± 100
BTDC 10° ± 5° 1.5 MPI
75.5 x 83.5 1,495
4-Cylinder in-line SOHC DIESEL
1.5 TCI
3-Cylinder in-line SOHC
83 x 92
1,4931-3-2
- - -
800 ± 100
Auto control
1.6 MPI
76.5 x 87 1,599
Engine TypeBore x StrokeDisplacement (cc) Firing order/Injection order Spark plug Spark plug gap Idle speed (RPM) Ignition timing (Base)/Injection timing
J070A03A-EAT
ITEMS
4-Cylinder in-line DOHC
PETROL
1-3-4-2
NGK:BKR5ES-11
CHAMPION:RC10YC4
0.039 ~ 0.043 in. (1.0 ~ 1.1 mm)

9VEHICLE SPECIFICATIONS
4
Oil & Grease Standard
API SJ, SL or ABOVE SAE 5W-20, 5W-30
ILSAC GF-3 or ABOVE SAE 10W-30 (ABOVE -18°C) SAE 15W-40 (ABOVE -13°C) SAE 20W-50 (ABOVE -7°C)
API CF-4 SAE 30 [32°F ~ 104°F(0°C ~ 40°C)]
or ABOVE, SAE 20W-40 [ABOVE 14°F(-10°C)]
ACEA B4 SAE 15W-40 [ABOVE 5°F(-15°C)]
or ABOVE SAE 10W-30 [-4°F ~ 104°F(-20°C ~ 40°C)] SAE 5W-30 [-13°F ~ 50°F(-25°C ~ 10°C)] SAE 0W-30 [BELOW 50°F(10°C)] *1, *2
*1. Restricted to driving condition and vehicle destination*2. Not recommended for sustained high speed vehicle operationNormal driving condition Severe driving condition HYUNDAI GENUINE PARTS MTF 75W/85 (API GL-4)Hyundai Genuine ATF S III, Diamond ATF SP III or other brands approved by Hyundai Motor Co. PSF-3 or Dexron 2DOT 3, DOT 4 or equivalent Ethylene glycol base for aluminium radiatorLUBRICATION CHART
Manual T/A Automatic T/AItem
Engine Oil Petrol Diesel
Engine Oil Consumption Transaxle Power Steering
Brake Fluid Coolant
J080A09A-EAT
Q'ty (Imp.qts)(Litre)
Drain and refill (with oil filter) : 2.9(3.3) Drain and refill (with oil filter) : 4.2(4.8) MAX. 1L / 1,500 Km MAX. 1L / 1,000 Km 1.86(2.15) 5.3(6.1) (Petrol Engine only) As required As required1.3/1.5L:4.8, 1.6L:5.2 Diesel:4.7 1.3/1.5L:5.2, 1.6L:4.8
Manual Automatic

INDEX
10
10

10INDEX
2
