Hyundai Coupe 2003 Owner's Manual

CONTROLS AND EQUIPMENT1- 5
HGK102-D
B070E01GK-GAT Replacing the batteryWhen the transmitter's battery begins to get weak, it may take several pushes on the buttonto lock or unlock the doors, and the LED will notlight. Replace the battery as soon as possible. Battery type : CR2032Replacement instructions:
1. Carefully seperate the case with a bladescrewdriver as shown in the illustration.
B070D03GK-AAT Disarmed Stage The system will be disarmed when either of the following steps are taken:
1) The driver's or passenger's door is unlocked
by depressing the "UNLOCK" button on the transmitter.
2) In the middle of alarming or after alarming, it disarms after 30 seconds if the key is turnedto and kept in the "ON" position.
3) If after disarming the system with the trans- mitter the doors are not opened within 30seconds, the system will automatically re-arm.
After completing one of steps above, the turnsignal lamp will blink twice to indicate that thesystem is disarmed.
HGK122
Screwdriver
B070F01A-GAT KEYLESS ENTRY SYSTEM (If installed) Locking doors
1. Close all doors.
2. Push the "LOCK" button on the transmitter.
3. At the same time all doors lock, the turn signal
lights will blink once to indicate that the sys-tem is armed.
Unlocking doors
1. Push the "UNLOCK" button on the transmit- ter.
2. At the same time the driver's door unlocks, the turn signal lights will blink twice to indicate that the system is disarmed.

CONTROLS AND EQUIPMENT
1- 6 B050A01GK-AAT DOOR WINDOWS Power window (Not all models)
HGK096-D(1)
HGK097-D
The power windows operate only when the igni- tion key is in the "ON" position. The main switchesare located on the driver's arm rest and controlthe front windows on the respective sides of thevehicle. The windows may be opened by de-pressing the front portion of the switch. To stop atthe desired opening, release the switch. Thewindow may be closed by pulling the front portionof the switch. In order to prevent operation of thepassenger front window by passenger, a windowlock switch (1) is provided on the arm rest of thedriver's door. To disable the passenger's powerwindow, push the window lock switch. To revertto normal operation, push in on the window lockswitch again.
CAUTION:Never try to operate the main switch and sub-switch in opposing directions at the sametime. If this is done, the window will stop andcannot be opened or closed. Auto-Down Window (Driver's Side) (Not all models) The Auto-Down window is moved to its fully open position by pushing the switch, and to stop at thedesired position push in on the switch again.
2. Remove the old battery from the case and
note the polarity. Make sure the polarity of thenew battery is the same(+side facing down),then insert it in the transmitter.
NOTE: Install a new battery within 30 seconds after remove the old one, if installing a new batterytakes more than 30 seconds, take the follow-ing steps.
1) Turn the ignition key to the "ACC" posi- tion.
2) Make sure that the turn signal lights blink once by pushing the "LOCK" or "UN- LOCK" button on the transmitter.
HGK121
Battery

CONTROLS AND EQUIPMENT1- 7
SB070A1-E FRONT SEAT ADJUSTMENT WARNING: Front seat adjustments must not be under- taken whilst the vehicle is in motion. Loss ofcontrol of the vehicle may result if seat ad-justments are made whilst the vehicle is inmotion. SB070B2-E Front seat rake adjustment The front seat rake adjustment is performed by raising the lever at the front of the seat base andsliding the seat to the desired position. At thisposition the lever should be released and theseat rocked to and fro to ensure that the mecha-nism has locked.
B050A02GK-D
WARNING:
o Be careful that head, hands and body are
not trapped by a closing window.
o If passengers remain in the car when you leave, especially if a child remains alone,always remove the ignition key for theirsafety.
HGK054-D
SB070C1-E Front seat recline adjustment The front seat back recline angle may be ad- justed by leaning forward slightly and raising therecline adjustment lever at the side of the seat.When the seatback is at the desired angle, thelever should be released. Ensure that theseatback is locked before driving the vehicle.
HGK051-D
WARNING: To ensure the seat is locked securely, at-tempt to move the seat forward or rearwardwithout using the lock release lever.

CONTROLS AND EQUIPMENT
1- 8 FB070F1-F Seat Cushion Height Adjustment (Driver's seat only) (Not all models) To raise or lower the front part of the seat cush- ion, turn the knob forward or rearward.
SB070E1-E Lumbar support adjustment (Driver's seat only) (Not all models) Some models are fitted with adjustable driver seat lumbar support which may be used to in-crease the amount of lumbar support offered bythe seat back. Adjustment is performed by mov-ing the handle at the side of the backrest in aforward direction to increase the support.
HGK052-D
FIRM
SOFT
HGK050-D
SB070D2-E Head restraint adjustment To raise the head restraint, pull it up. To lower it, push it down whilst pressing the lock knob. Formaximum effectiveness in the event of an acci-dent, the restraint must be adjusted so that therestraint is approximately at the level of the seatoccupant's ears. The restraint must never be soadjusted that it is centred about the level of theseat occupant's neck. WARNING: Do not operate the vehicle with the restraintsremoved. The restraints provide protectionagainst neck injury when installed and cor-rectly adjusted.
HGK049-D
Lock knob

CONTROLS AND EQUIPMENT1- 9
B129A01F-AAT REAR SEAT POSITIONS WARNING: This vehicle contains two rear seating posi-tions only and a seat belt for each seatingposition. Thus, never permit more than twooccupants to ride in the rear seat because anunrestrained occupant could be seriouslyinjured or killed in the event of a vehiclecrash.
B129A01GK
B100A01Y-AAT SEAT WARMER (Not all models) The seat warmer is provided to warm the front seats during cold weather. With the ignition keyin the "ON" position, push either of the switchesto warm the driver's seat or the passenger's seat.During mild weather or under conditions wherethe operation of the seat warmer is not needed,keep the switches in the "OFF" position.
HGK123
B130A01GK-DAT REAR SEAT ENTRY (Walk in device)The driver and front passenger's seatback should be tilted to enter the rear seat.
HGK053-D
(2)
(1)
By pulling up the walk in device lever (1) at the right-up side of the driver side seatback, theseatback will tilt forward. And then pull the lockrelease lever (2) up with moving the seat forward.

CONTROLS AND EQUIPMENT
1- 10 SB480A1-E FOLDING REAR SEAT The rear seatbacks may be folded to facilitate the carriage of long items or to increase the luggagecapacity of the vehicle.
o To unlock the seatback, release the catch by
operating the lock knob, pull the seatback forward and lower to the folded position.
o When the seatback is returned to the upright position, ensure that the latching mechanismhas engaged and that the seat may not moveunintentionally.
o Luggage which is carried within the passenger compartment must be securely restrained inorder to prevent injury in the event of suddendeceleration.
HGK108
B099A01F-AAT BEFORE FOLDING THE REAR SEATS
In order to prevent the shoulder belt from being
damaged, the shoulder belt must be passed through the hanger. And then fold the rear seat downwards. CAUTION: Seat belt must be removed from the hanger
when seat belt is in use.
HGK240-D
(1)
By pulling up the walk in device lever (1) at the left-up side of the passenger side seatback, theseatback will tilt forward. And then push the seatforward to enter the occupants. Recliner Memory By pulling up the walk in device lever (1) seatback is reclined and return to the memorized originalposition. WARNING: Don't drive with reclining of the passengerside seatback. It is dangerous to move it. Besure the seatback is fix firmly or not beforedriving.
B099A01GK

CONTROLS AND EQUIPMENT1- 11
SB090E1-E Injured Persons A seat belt should be used when an injured person is being transported. For specific recom-mendations, the advice of a qualified MedicalPractioner should be sought.
WARNING: The folding rear seats are intended to allow the carriage of longer objects than couldotherwise be accommodated. Do not allowpassengers to sit on top of the folded-downseatback whilst the car is in motion since thefolded seat does not provide a suitable sittingfacility and no seat belts are available for use.Objects carried on the folded seatback shouldnot extend higher than the top of the frontseats and must be securely restrained toprevent injury or damage during sudden de-celeration.
SB090A1-E SEAT BELT PRECAUTIONSSeat belts should be worn at all times by all occupants front and rear. The possibility of injuryor the severity of injuries suffered in the event ofan accident will be greatly reduced by the wear-ing of seat belts.In addition the following recommendations shouldbe observed. SB090B1-E Babies/Small Children Babies and small children must be restrained using a restraint system specifically designed forthis purpose. Under no circumstances should achild be carried in the vehicle without the use ofa suitable restraint which meets the regulationsin force in the country where the vehicle is inoperation. SB090C1-E Larger Children Larger children should occupy the rear seat and be restrained at all times. The restraint may takethe form of a special safety belt or the originalfactory fitted seat belt used in conjunction with anapproved booster cushion depending upon thesize and weight of the child. Under no circum-stances should children be allowed to travelstanding, kneeling or lying on the seat.Never allow children to ride in the front passen-ger seat.SB090O1-E Pregnant WomenThe use of a seat belt is recommended for pregnant women. The seat belt should be wornas low and snugly as possible across the hips,not across the abdomen. A qualified MedicalPractitioner should be consulted for further infor-mation.
SB500A1-E REAR PARCEL SHELF Large or heavy items must not be placed upon the rear parcel shelf to prevent the possibility ofinjury arising from such items in the event ofimpact.
B140A01GK
SB090F1-E Seat Belt OccupancyThe seat belts are designed to be used by one seat occupant only. The use of a seat belt bymore than one person increases the levels ofinjury which may be sustained in the event of anaccident. SE090G1-E Do Not Lie Down To ensure that the maximum level of protection may be afforded by the seat belt system, allpassengers should be sitting in an upright posi-tion throughout the journey. The seat belt will beunable to afford maximum protection if the frontseats are at or near the fully reclined position.

CONTROLS AND EQUIPMENT
1- 12
SB090H1-E CARE OF SEAT BELTSSeat belt assemblies must never be disassembled or modified in any way. In addition, care shouldbe exercised to ensure that the belt assembliesdo not become damaged by being trapped in seatmechanisms, door shuts etc. SB090I-E Periodic Inspection It is recommended that all seat belts be inspected periodically for wear or damage of any kind.Parts of the system that are damaged should bereplaced as soon as possible. Under no circum-stances must any part of the seat belt assem-blies be dismantled or repaired. SB090J1-E Keep Belts Clean and Dry Seat belts should be kept clean and dry. If belts become dirty, they can be cleaned using a mildsoap solution and warm water. Bleach, dye,strong detergents or abrasives should not beused since the fabric may become damaged andweakened.
SB090K1-E Replacement of Seat BeltsThe entire seat belt assembly or assemblies should be replaced if the vehicle has been in-volved in an accident even if no damage isevident. Additional questions concerning seatbelt operation should be directed to a HyundaiDealer. SB090O1-F FRONT SEATBELT PIVOT HEIGHT AD- JUSTMENT (Not all models)
attempt to adjust the height of the upper anchor- age point while the vehicle is moving.If you are any doubt as to the method of adjust-ment or the optimum height position for your frontseat belt always contact your nearest HyundaiDealer. WARNING:
o The height adjuster must be in the locked
position when the vehicle is moving.
o The misadjustment of height of the shoul- der belt could reduce the effectiveness ofthe seat belt in a crash.
HGK109
The location of the upper anchorage point can be set (for greater belt comfort and security) to anyone of five preset positions. To adjust the seatbelt pivot push the knob upward or downward tothe required setting, ensuring that it engages oneof the preset positions (on releasing the knob).The height adjuster must always be locked intoposition while the vehicle is stationary. Do not

CONTROLS AND EQUIPMENT1- 13
B210A01A-AAT To Release the Seat Belt
FUD1090R
The seat belt is released by pressing the release button in the locking buckle.When it is released, the belt should automaticallydraw back into the retractor.If this does not happen, check the belt to be sureit is not twisted, then try again.
SB090P1-E SEAT BELTS (3-Point Type) To Fasten The Seat Belt
B200A01S-GAT Adjusting Your seat BeltFUD1090P
The seat belts are fastened by pulling the belt buckle towards the seat belt stalk and insertingthe metal tongue of the buckle into the stalk. Thebuckle should be firmly pressed into the stalkuntil locked which will be indicated by an audible"click".The length of the seat belt webbing will be auto-matically adjusted by the seat belt mechanism toallow the wearer maximum freedom of move-ment whilst the belt is being worn. However, inthe event of rapid deceleration or impact, the beltmechanism will automatically lock.The mechanism will also lock if the seat beltwebbing is withdrawn too quickly when the belt isbeing fastened or if attempts are made to with-draw the webbing whilst the vehicle is not on levelground. Should the seat belt lock under theseconditions, it will be possible to release the mecha-
FUD1090Q
You should place the belt as low as possible on your hips, not on your waist. If the belt is locatedtoo high on your body, you could slide under it incase of accident or a sudden stop. This couldresult of death, serious injury or property dam-age. Both arms should not be under or over thebelt. Rather, one should be over and the otherunder, as shown in the illustration.Never wear the seat belt under the arm nearestthe door.
nism by allowing a small amount of webbing to beretracted and the belt withdrawn again.

CONTROLS AND EQUIPMENT
1- 14 shoulder belt must always be positioned as low as possible on the child's hips andas snug as possible.
o If the seat belt will not properly fit the child, Hyundai recommends the use of anapproved booster seat in the rear seat inorder to raise the child's seating height sothat the seat belt will properly fit the child.
o Never allow a child to stand up or kneel on the seat.
o Never use an infant carrier or child safety seat that "hooks" over a seatback; it maynot provide adequate security in an acci-dent.
o Never allow a child to be held in a person's arms while they are in a moving vehicle, asthis could result in serious injury to thechild in the event of an accident or asudden stop. Holding a child in a movingvehicle does not provide the child withany means of protection during an acci-dent, even if the person holding the childis wearing a seat belt.
o If the child restraint seat is not anchored properly, the risk of a child being seri-ously injured or killed in a collision greatlyincreases.
WARNING:
o A child restraint system must be placed in
the rear seat. Never install a child or infantseat on the front passenger's seat.Should an accident occur and cause thepassenger side airbag to deploy, it couldseverely injure or kill an infant or childseated in an infant or child seat. Thus, onlyuse a child restraint in the rear seat of yourvehicle.
o Since a safety belt or child restraint sys- tem can become very hot if it is left in aclosed vehicle, be sure to check the seatcover and buckles before placing a childthere.
o When the child restraint system is not in use, store it in the boot or fasten it with asafety belt so that it will not be thrownforward in the case of a sudden stop or anaccident.
o Children who are too large to be in a child restraint should sit in the rear seat and berestrained with the available lap/shoulderbelts. Never allow children to ride in thefront passenger seat.
o Always make sure that the shoulder belt portion of the outboard lap/shoulder beltis positioned midway over the shoulder,never across the neck or behind the back.Moving the child closer to the center of thevehicle may help provide a good shoulderbelt fit. The lap belt portion of the lap/
B230A02GK-EAT CHILD RESTRAINT SYSTEMChildren riding in the car should sit in the rear seat and must always be properly restrained tominimize the risk of injury in an accident, suddenstop or sudden maneuver. According to accidentstatistics, children are safer when properly re-strained in the rear seats than in the front seat.Larger children not in a child restraint should useone of the seat belts provided.You are required by law to use safety restraintsfor children. If small children ride in your vehicleyou must put them in a child restraint system(safety seat).Children could be injured or killed in a crash iftheir restraints are not properly secured. Forsmall children and babies, a child seat or infantseat must be used. Before buying a particularchild restraint system, make sure it fits your carseat and seat belts, and fits your child. Follow allthe instructions provided by the manufacturerwhen installing the child restraint system.
