Hyundai Coupe 2003 Owner's Manual

CONTROLS AND EQUIPMENT1- 45
SB410A1-E
FRONT DOOR EDGE WARNING LAMP The red door edge warning lamp which serves to indicate an open door to following traffic in con-ditions of darkness illuminates whenever thedoor is open.
B620A01GK-D
WARNING:
o Always double check to be sure that the
bonnet is firmly latched before drivingaway. If it is not latched, the bonnet couldfly open while the vehicle is being driven,causing a total loss of visibility, whichmight result in an accident.
o Do not move the vehicle with the bonnet in the raised position, as vision is obstructedand the bonnet could fall or be damaged.
B570A01GK-EAT BONNET RELEASE
1. Pull the release knob to unlatch the bonnet.
HGK106-DBonnet Release Lever
HGK098
2. Press the safety hook lever up and lift the
bonnet.
3. Raise the bonnet by hand. When closing the bonnet, slowly close the bon- net and make sure it locks into place.

CONTROLS AND EQUIPMENT
1- 46 SB450A2-E HATCHBACK DOOR Remote Hatchback door Release The hatchback door may be opened by pulling the lever to release the lock. The hatchback doorshould be closed by depressing the lid firmly untilthe latch engages. Ensure that hatchback door issecurely latched before setting the vehicle inmotion. WARNING: The hatchback door should always be closedwhilst the vehicle is in motion to preventexhaust gases from being drawn into thepassenger compartment.
HGK103-D
SB440A1-E REMOTE FUEL FILLER LID RELEASE (Not all models) The fuel filler lid may be opened from inside the vehicle by pulling up on the fuel filler lid release. NOTE: If the fuel filler lid will not open because icehas formed around it, tap lightly or push onthe lid to break the ice and release the lid. Donot lever the lid. If necessary, spray aroundthe lid with an approved de-icer fluid (do notuse radiator anti-freeze) or move the vehicleto a warm place and allow the ice to melt.
HGK105-D
HGK124
WARNING: Fuel vapours are dangerous. Before refuel- ling, turn off the engine and never allowsparks, lit cigarettes or open flames near thefiller area. When releasing the filler cap, asmall amount of residual pressure may gen-erate a slight hissing sound which is notindicative of an abnormality. In the event ofthe fuel filler cap requiring replacement, onlya Genuine Hyundai replacement part shouldbe used to prevent fuel leakage.

CONTROLS AND EQUIPMENT1- 47
SB450C2-E To Unlock Using the Key To open the hatchback door using the ignition key, insert the key into the lock barrel and turnclockwise to release the latch. The hatchbackdoor compartment lamp will illuminate wheneverthe hatchback door is opened.
B540C01GK
B540D01GK-GAT When you close the hatchback door
HGK226
HGK227
WARNING:
Do not close an open hatchback door while a person(s) is sitting upright on the rear seat.The hatchback door or hatchback door glassmay contact the head of a person sittingupright on the rear seat. Closing the hatch-back door onto a person's head may causeserious injuries, including death.
SB510A1-E SUNVISOR Sun visors are fitted to both the driver and pas- senger side of the vehicle. Certain derivativesare equipped with a vanity mirror which is locatedon the back of the passenger visor. The visormay be lowered to reduce the amount of glarefrom directly ahead, or may be moved towardsthe side window to reduce glare from the side ofthe vehicle, once the inner pivot has beenunclipped from the bracket. WARNING: Do not place the sunvisor in such a mannerthat it obscures visibility of the roadway,traffic or the objects. Vanity mirror
HGK145-D

CONTROLS AND EQUIPMENT
1- 48 Some objects can be kept in the net at the luggage compartment.Use the luggage net on the floor (Not all models)or at the back of the luggage compartment toprevent the objects from slipping. CAUTION: To prevent damage to the goods or the ve-hicle, care should be taken when carryingfragile or bulky objects in the luggage com-partment. WARNING: Avoid eye injury. DO NOT overstretch. AL-WAYS keep face and body out of recoil path.DO NOT use when strap has visible signs ofwear or damage.
SB530B1-F HORN Press the pad on the steering wheel to sound the horn.
HGK141
Working Zone
B540D02HP-DAT LUGGAGE NET (Not all models)HGK241
A Type
B Type
B600A01HP-AAT STEERING WHEEL TILT LEVER (Not all models) To adjust the steering wheel:
1. Pull the lever toward you and hold it to unlock.
2. Raise or lower the steering wheel to the
desired position.
3. After adjustment, release the lever. WARNING: Do not attempt to adjust the steering wheelwhile driving as this may result in loss ofcontrol of the vehicle and serious injury ordeath.
HGK127-D

CONTROLS AND EQUIPMENT1- 49
SB700A1-E CRUISE CONTROL (Not all models) The cruise control system provides automatic speed control for your comfort when driving onfreeways, tollroads, or other noncongested high-ways.This is designed to function above approximately25 mph (40 km/h).
B660A01GK
Main switch
B660B01GK
B660B01E-AAT To Set the Cruise Speed
1. Push in the cruise control main switch on the
end of the barrel. The "CRUISE" indicator light in the instrument cluster will be illumi-nated. This turns the system on.
2. Accelerate to the desired cruising speed above 25 mph (40 km/h).
3. Push the control switch downward to "SET (COAST)" and release it.
4. Remove your foot from the accelerator pedal and the desired speed will automatically bemaintained.
5. To increase speed, depress the accelerator pedal enough for the vehicle to exceed thepreset speed. When you remove your footfrom the accelerator pedal, the vehicle willreturn to the speed you have set.
B660C01GK
B660C01E-AAT To Cancel the Cruise Speed Do one of the followings:
o Pull the control switch toward steering wheelto "CANCEL" position.
o Depress the brake pedal.
o Depress the clutch pedal (Manual transaxle).
o Shift the selector lever in "N" position (Auto- matic transaxle).
o Decrease the vehicle speed lower than mem- orized speed by 12 mph (20 km/h).
o Decrease the vehicle speed approximately to less than 25 mph (40 km/h).
o Release the main switch.
WARNING:To avoid accidental cruise control engage-ment, keep the cruise control main switch offwhen not using the cruise control.

CONTROLS AND EQUIPMENT
1- 50 o During cruise-control driving with a manual
transaxle vehicle, do not shift into neutral without depressing the clutch pedal, or theengine will be overrevved. If this happens,depress the clutch pedal or release themain switch.
o With the cruise control engaged, when the brake pedal is applied, it is normal to hearthe cruise control system deactivate. Thisis an indication of normal system opera-tion.
o During normal cruise control operation, when the "SET(COAST)" is activated orreactivated after applying the brakes, thecruise control will energize after approxi-mately 3 seconds. This delay is normal.
B660B01GKB660D01GK
B660F01E-AAT To Reset at a Slower Speed
1. Push the control switch downward to "SET (COAST)" position and hold it. The vehicle will decelerate.
2. When the desired speed is obtained, release the control switch. While the control switch ispushed, the vehicle speed will gradually de-crease.
WARNING:
o Keep the main switch off when not using the cruise control.
o Do not use the cruise control when it may not be safe to keep the car at a constant speed, for instance, driving in heavy orvarying traffic, or on slippery (rainy, icy orsnow-covered) or winding roads or over6% up-hill or down-hill roads.
o Pay particular attention to the driving con- ditions whenever using the cruise controlsystem.
B660D01E-AAT To Resume the Preset Speed The vehicle will automatically resume the speed set prior to cancellation when you push thecontrol switch upward to "RESUME (ACCEL)"position and release it to return providing thevehicle speed is above 25 mph (40 km/h). B660E01E-AAT To Reset at a Faster Speed
1. Push the control switch upward to "RESUME
(ACCEL)" position and hold it.
2. Accelerate to desired speed and release the control switch. While the control switch is held, the vehicle will gradually gain speed.

CONTROLS AND EQUIPMENT1- 51
B710A01GK-EAT HEATING AND COOLING CONTROL
1. Side defrost nozzle
2. Side Ventilator
3. Centre Ventilator
4. WindScreen Defrost VentilatorHGK001A-D
1
2
3
1
2 B710A01S-AAT VENTILATIONTo operate the ventilation system:
o Set the air intake control on "Fresh" mode
( ).
o To direct all intake air to the dashboard vents, set the airflow control to "Face".
o Adjust the fan speed control to the desired speed.
o Set the temperature control between "Cool" and "Warm".
B710C01S-AAT SIDE VENTILATORThe side ventilators are located on each side of dashboard. To change the direction of the airflow, move the knob in the center of the vent up-and-down and side-to-side. The side vent knobscontrol the amount of outside air entering thevehicle through the side vents. The vents areopened when the vent knob is moved to the upposition. The vents are closed when the ventknob is moved to the down position. Keep thesevents clear of any obstructions.
B710B01S-DAT CENTRE VENTILATOR The centre ventilators are located in the middle of the dashboard. The direction of air flow from thevents in the centre of the dashboard is adjust-able.To control the direction of the air flow, move theknob in the centre of the vent up-and-down andside-to-side.4

CONTROLS AND EQUIPMENT
1- 52
HGK002
B670A01GK-GAT ROTARY TYPE (Not all models)
This control is used to adjust the degree of heating or cooling desired.B670E02A-AAT Temperature ControlCool
Warm
B670B01A-AAT Fan Speed Control (Blower Control)HGK006
This is used to turn the blower fan on or off and to select the fan speed.This blower fan speed, and therefore the volumeof air delivered from the system, may be con-trolled manually by setting the blower controlbetween the "1" and "4" positions.
123
456
1. Air Conditioning switch
2. Air intake control switch
3. Rear window defroster switch
4. Air flow control switch
5. Fan speed control switch
6. Temperature control switch HGK007

CONTROLS AND EQUIPMENT1- 53
HGK016B670D01GK-EAT Air Flow Control This is used to direct the flow of air. Air can be directed to the floor, dashboard outlets, orwindscreen. Five symbols are used to representFace, Bi-Level, Floor, Floor-Defrost and Defrostair position.HGK005
B670C01FC-EAT Air Intake Control This is used to select fresh outside air or recircu- lating inside air.To change the air intake control mode, (Freshmode, Recirculation mode) push the control but-ton. FRESH MODE ( ) : The indicator light on the button goes off when the air intake control isfresh mode. RECIRCULATION MODE ( ): The indicator light on the button is illuminated when the airintake control is recirculation mode. With the "Fresh" mode selected, air enters the vehicle from
the outside and is heated or cooled
according to the function selected. With the "Recirculation" mode selected, air fromwithin the passenger compartment
will be drawn
through the heating system and heated or cooledaccording to the function selected. NOTE:
o It should be noted that prolonged opera- tion of the heating in "Recirculation" modewill give rise to fogging of the windscreenand side windows and the air within thepassenger compartment will become stale.In addition, prolonged use of the air con-ditioning with the "Recirculation" modeselected may result in the air within thepassenger compartment becoming exces-sively dry.
o When the ignition switch is turned "ON" the air intake control will change to "Re-circulation" mode (regardless of switchposition). It is normal operation.

CONTROLS AND EQUIPMENT
1- 54
HGK023-D
HGK024-D
Floor-Level
Air is discharged through the floor vents, windscreen defroster nozzle, side defrosternozzle, side ventilator.
Floor-Defrost Level
Air is discharged through the windscreen defrostnozzle, the floor vents, side defroster nozzle,side ventilator.
HGK025-D
Face-Level
Selecting the "Face" mode will cause air to be discharged through the face level vents.
HGK022-D
Bi-Level
Air is discharged through the face vents and the floor vents. This makes it possible to have coolerair from the dashboard vents and warmer air fromthe floor outlets at the same time.
HGK021-D If the "Floor-Defrost" mode is selected, the A/C will be on automatically and it will be changed to"Fresh" mode.
Defrost-Level
Air is discharged through the windscreen defrostnozzle, side defroster nozzle, side ventilator. Ifthe "Defrost" mode is selected, the A/C will be onautomatically and it will be changed to "Fresh"mode.
