FEATURES OF YOUR HYUNDAI 1- 33
To operate the headlights, turn the barrel on the end of the multi-function switch. The first positionturns on the parking lights, sidelights, tail lightsand instrument panel lights. The second positionturns on the headlights. NOTE: The ignition must be in the "ON" position toturn on the headlights. Parking light auto cut (If installed) If you do not turn the parking lights "OFF" after driving, the parking lights will automatically shut"OFF" when the driver's door is opened.To turn them "ON" again, you must simply turnthe ignition key to the "ON" position.
Instantaneous Fuel Consumption gauge It shows instantaneous fuel consumption ac- cording to the driving condition. The more indi-cated figure is low, the more it indicates efficientdriving situation. Volt gauge It shows moment volt change and makes for diver correspond to low volt situation.
HGK231B340B01A-AAT Lane Change Signal
To indicate a lane change, move the lever up or down to a point where it begins flashing.
B340C03E-AAT Headlight Switch
HGK038 HGK039
B340A01A-AAT COMBINATION TURN SIGNAL, HEADLIGHT AND HIGH-BEAMSWITCH Turn Signal Operation Pulling down on the lever causes the turn signals on the left side of the car to blink. Pushingupwards on the lever causes the turn signals onthe right side of the car to blink. As the turn iscompleted, the lever will automatically return tothe center position and turn off the turn signals atthe same time. If either turn signal indicator lightblinks more rapidly than usual, goes on but doesnot blink, or does not go on at all, there is amalfunction in the system. Check for a burned-out fuse or bulb or see your Hyundai dealer.
The lever will automatically return to the center position when released.

FEATURES OF YOUR HYUNDAI
1- 34
B340D01A-AAT High-beam Switch To turn on the headlight high beams, push the lever forward (away from you). The high beamindicator light will come on at the same time. Forlow beams, pull the lever back toward you.
B340E01A-AAT Headlight Flasher
HGK233
To flash the headlights, pull the switch lever toward you, then release it. The headlights canbe flashed even though the headlight switch is inthe "OFF" position. B350A01A-AAT WINDSHIELD WIPER AND WASHER SWITCH
HGK042
(1)
(3) (2)
The windshield wiper switch has three positions:
(1) Intermittent wiper operation
(2) Low-speed operation
(3) High-speed operation NOTE: To prevent damage to the wiper system, donot attempt to wipe away heavy accumula-tions of snow or ice. Accumulated snow andice should be removed manually. If there isonly a light layer of snow or ice, operate theheater in the defrost mode to melt the snow orice before using the wiper.
B340F01A-GAT Daytime Running Lights (If Installed) Your Hyundai is equipped with daytime running lights. The daytime running lights are used toimprove visibility for oncoming traffic. Your ve-hicle daytime running lights are designed toremain on continuously when the engine is oper-ating even though the headlight switch is in the"OFF" position. However, the daytime running
lights will be off while the parking brake is applied.
To operate the automatic light feature, turn thebarrel on the end of the multi-function switch. Ifyou set the multi-function switch to "AUTO", thetail lights and headlights will be turned automati-cally on or off according to external illumination.
B340G01L-GAT Auto Light (If installed)
HGK041

FEATURES OF YOUR HYUNDAI 1- 35
HGK046
B350A01O-AAT Tailgate Wiper And Washer Switch
1. :The washer fluid will be sprayed onto the
rear window and the wiper operates while the rear window wiper barrel is placed inthis position.
2.OFF3.INT :To use the intermittent wiper feature,
place the rear window wiper barrel in the"INT" position.
4.ON :When the point indicates "ON", the rear
window wiper operates continuously.
To use the windshield washer, pull the wiper/ washer lever toward the steering wheel. Whenthe washer lever is operated, the wipers auto-matically make two passes across the wind-shield. The washer continues to operate until thelever is released. NOTE:
o Do not operate the washer more than 15 seconds at a time or when the fluid reser-voir is empty.
o In icy or freezing weather, be sure the wiper blades are not frozen to the glassprior to operating the wipers.
o In areas where water freezes in winter, use windshield washer antifreeze.
B350B01O-AAT Windshield Washer Operation
HGK044
B350C01S-AAT Adjustable Intermittent Wiper Opera- tion
To use the intermittent wiper feature, place the wiper switch in the "INT" position. With the switchin this position, the interval between wipes can bevaried from 2 to 10 seconds by turning theinterval adjuster barrel.
HGK043
Mist Wiper Operation
HGK045
If a single wipe is desired in mist, push the windshield wiper and washer control lever up-wards.

FEATURES OF YOUR HYUNDAI
1- 36
B370A01A-AAT HAZARD WARNING SYSTEM The hazard warning system should be used whenever you find it necessary to stop the car ina hazardous location. When you must makesuch an emergency stop, always pull off the roadas far as possible.The hazard warning lights are turned on bypushing in the hazard switch. This causes all turnsignal lights to blink. The hazard warning lightswill operate even though the key is not in theignition.To turn the hazard warning lights off, push theswitch a second time.
HGK140 B380A01A-AAT REAR WINDOW DEFROSTER SWITCH The rear window defroster and heated outsides rearview mirrors are turned on by pushing in theswitch. To turn the defroster off, push the switcha second time. The rear window defroster auto-matically turns itself off after about 15 minutes.To restart the defroster cycle, push in the switchagain after it has turned itself off. CAUTION: Do not clean the inner side of the rear windowglass with an abrasive type of glass cleaneror use a scraper to remove foreign depositsfrom the inner surface of the glass as thismay cause damage to the defroster elements. NOTE: The ignition must be in the "ON" position forthe rear window defroster to operate. B400A01A-AAT DIGITAL CLOCK (If Installed) There are three control buttons for the digital clock. Their functions are: HOUR
- Push "H" to advance the hour indicated.
MIN - Push "M" to advance the minute indicated.
RESET - Push "R" to reset minutes to ":00" to
facilitate resetting the clock to the correct time. When this is done: Pressing "R" between 10 : 30 and 11 : 29 changes the readout to 11 : 00. Pressing "R" between 11: 30 and 12 : 29 changes the readout to 12 : 00.
B380A01GK
A Type
B TypeHGK143
A Type
B Type

FEATURES OF YOUR HYUNDAI 1- 37
For the cigarette lighter to work, the key must be in the "ACC" position or the "ON" position.To use the cigarette lighter, push it all the way intoits socket. When the element has heated, thelighter will pop out to the "ready" position.Do not hold the cigarette lighter pressed in. Thiscan damage the heating element and create afire hazard.If it is necessary to replace the cigarette lighter,use only a genuine Hyundai replacement or itsapproved equivalent. CAUTION: Do not use electric accessories or equipmentother than the Hyundai genuine parts in thesocket. B430A01GK-AAT FRONT ASHTRAY The front ashtray may be opened by pushing and releasing the ashtray door at its top edge. To remove the ashtray in order to clean it, the metal ash receptacle should be lifted out from theashtray door. Do not attempt to remove the entireashtray door assembly or damage will result. Toreinstall it, place it in the proper position andpress it down in the ashtray door. The ashtraylamp will only illuminate when the exterior bodylights are switched on.
HGK146
B410A01A-AAT INSTRUMENT PANEL LIGHT CON- TROL (RHEOSTAT) The instrument panel lights can be made brighter or dimmer by turning the instrument panel lightcontrol knob. B420A02A-AAT CIGARETTE LIGHTERHGK134AHGK144

FEATURES OF YOUR HYUNDAI
1- 38 B340G01A-GAT HEADLIGHT LEVELING DEVICE SYS- TEM (If Installed) To adjust the headlight beam level according to the number of the passengers and the loadingweight in the luggage area, turn the beam level-ing switch.The higher the number of the switch position, thelower the headlight beam level. Always keep theheadlight beam at the proper leveling position, orheadlights may dazzle other road users.Listed below are the examples of proper switchsettings. For loading conditions other than thoselisted below, adjust the switch position so that thebeam level may be the nearest as the conditionobtained according to the list.
HGK157
B450A01GK-GAT DRINK HOLDER (If Installed)
HGK149
The drink holder is used for holding cups or cans. To use the passenger's drink holder, push thedrink holder. WARNING: Do not place objects other than cups or cansin the drink holder. Such objects can bethrown out in the event of a sudden stop or anaccident, possibly injuring the passengers inthe vehicle. Driver's
Passenger's
Switch
positionLoading condition
Driver only Driver + front passenger Full passengers (including driver)Full passengers (including driver) + full trunk loading (or light trailer loading)Driver + full trunk loading (or maximum trailer loading)
0 0 1 23
B460A01Y-AAT SUNROOF (If installed) Sun Shade
HGK029
Your HYUNDAI is equipped with a sliding sun- shade which you can manually adjust to let inlight with the sunroof closed, or to block sunlight.

FEATURES OF YOUR HYUNDAI 1- 39
WARNING: Never adjust the sunshade while driving. B460B01GK-GAT Opening the Sunroof System
HGK030
The sunroof can be electrically opened or closed with the ignition key in the "ON" position. Thesunroof is moved to its fully open position by
pushing the "OPEN" switch, and to stop at thedesired position, push in any switches (Open,Close, Up, Down). To close, press and hold the"CLOSE" button.Release the button when the sunroof reachesthe desired position. WARNING:
o Do not close a sunroof if anyone's hands, arms or body are between the slidingglass and the sunroof sash, as this couldresult in injury.
o Do not place your head or arms out of the sunroof opening at any time. CAUTION:
o Do not open the sunroof in severely cold
temperature or when it is covered with iceor snow.
o Periodically remove any dirt that may have accumulated on the guide rails.
B460D03GK-AAT Manual Operation of SunroofIf the sunroof does not electrically operate:
HGK032
1. Remove the cap located in the rear roof panel by using a coin or screw driver.
2. Insert the hexagonal head wrench provided with the vehicle into the socket. This wrench can be found in the vehicle's trunk or glovebox.
HGK033
B460C01GK-GAT Tilting the Sunroof System
HGK031
The sunroof is moved to its fully tilt up position by pushing the "UP" switch, and to stop at thedesired position, push in any switches (Open,Close, Up, Down).To tilt down, press and hold the "DOWN" button.Release the button when the sunroof reachesthe desired position. NOTE: After washing the car or after there is rain, besure to wipe off any water that is on thesunroof before operating it.

FEATURES OF YOUR HYUNDAI
1- 40
3. Push and turn the wrench clockwise to close
or counterclockwise to open the sunroof. B480A01GK-GAT MAP LIGHT
HGK034
(1) Push in the map light switch to turn on the driver side light.
(2) In the "DOOR" position, the interior courtesy light comes on when any door is opened regardless of the ignition key position. Thelight goes out gradually 6 seconds after thedoor is closed.
(3) Push in the map light switch to turn on the passenger side light. B491A01F-GAT SPECTACLE CASE (If Installed)HGK036
The spectacle case is located on the front over- head console.Push the end of the cover to open the spectaclecase. WARNING: Do not open the spectacle case while thevehicle is moving. The rear view mirror of thevehicle can be blocked by an open spectaclecase.(1) (2) (3)
B460E02GK-GAT Resetting the Sunroof SystemIf the battery has been recharged, disconnected or if the sunroof is operated with the hexagonalhead wrench manually, you may need to resetthe sunroof. To do this;
1. Turn the ignition switch "OFF".
2. With pressing "open" "up" button at the same
time, turn the ignition switch "ON". The resetting is failed when the ignition key to the "OFF" within 1.5 seconds.
3. If the sunroof is set like this, the sunroof is reset with tilting up/down automatically oncefor all.
CAUTION:If the sunroof is not reset, it may not beoperated properly.

FEATURES OF YOUR HYUNDAI 1- 41
B510D01Y-AAT OUTSIDE REARVIEW MIRROR HEATER (If Installed)
B510B01Y-AAT OUTSIDE REAR VIEW MIRROR Electric Type
HGK128
The outside rearview mirrors can be adjusted to your preferred rear vision, both directly behindthe vehicle, and to the rear of the left and rightsides.The remote control outside rearview mirror switchcontrols the adjustments for both the right and leftoutside mirror. To Adjust the Position of Either Mirror:
1. Move the selecting switch to the right or left to activate the adjustable mechanism for the corresponding door mirror.
2. Now, adjust the mirror angle by depressing the appropriate perimeter switch as illustrated. CAUTION:
o Do not operate the switch continuously
for an unnecessary length of time.
o Scraping ice from the mirror face could cause permanent damage. To remove any ice, use a sponge, soft cloth or approveddeicer.
WARNING:Be careful when judging the size or distanceof any object seen in the passenger side rear-view mirror. It is a convex mirror with a curvedsurface. Any objects seen in this mirror arecloser than they appear.
B380A01GK
A Type
B Type
B500A01A-AAT GLOVE BOX WARNING: To avoid the possibility of injury in case of an accident or sudden stop, the glove box doorshould be kept closed when the car is inmotion.
o To open the glove box, pull on the glove box release lever.
HGK147

FEATURES OF YOUR HYUNDAI
1- 42 B520A01A-AAT DAY/NIGHT INSIDE REARVIEW MIR- ROR
B520A01GK
Your Hyundai is equipped with a day/night inside rearview mirror. The "night" position is selectedby flipping the tab at the bottom of the mirrortoward you. In the "night" position, the glare ofheadlights of cars behind you is reduced. B520B01O-GAT DAY/NIGHT REAR VIEW MIRROR (Electric type) (If installed)
The electric type day/night inside rearview mirror automatically controls the glare of headlights ofthe car behind you. Adjust the rearview mirror tothe desired position.
B520B01GK
WARNING: Do not adjust or fold the outside rearviewmirrors while the vehicle is moving.This could result in loss of control, and anaccident which could cause death, seriousinjury or property damage.
Sensor
The outside rearview mirror heater is actuated in connection with the rear window defroster. Toheat the outside rearview mirror glass, push inthe switch for the rear window defroster. Therearview mirror glass will be heated for defrostingor defogging and will give you improved rearvision in inclement weather conditions. Push theswitch again to turn the heater off. The outsiderearview mirror heater automatically turns itselfoff after 15 minutes.
B510C01A-AAT FOLDING THE OUTSIDE REARVIEW MIRRORS
B510C01GK
To fold the outside rearview mirrors, push them towards the rear.The outside rearview mirrors can be folded rear-ward for parking in narrow areas.
