Hyundai Coupe 2003 User Guide

FEATURES OF YOUR HYUNDAI 1- 3
B040A02Y-AAT DOOR LOCKS WARNING:
o Unlocked doors can be dangerous. Be-
fore you drive away (especially if there are children in the car), be sure that all thedoors are securely closed and locked sothat the doors cannot be inadvertentlyopened from the inside. This helps ensurethat the doors will not be opened acciden- tally. Also, when combined with the proper use of seat belts, locking the doors helpskeep occupants from being ejected fromthe car in case of an accident.
o Before opening the door, always look for and avoid oncoming traffic.
o In case of accident, the door is unlocked automatically (If installed).
B880C02A-GAT Key Numbers
AX10030A-1
The vehicle key number is recorded upon a metal tag attached to the keys when the vehicleis first delivered to you.The key number should be recorded and kept ina safe place in case the need to order furtherkeys arises. New keys are available from anyHyundai dealer by quoting the relevant key num-ber.In the interest of security, the metal tag attachedto the keys which bears the key number shouldbe removed from the key ring after you receiveyour new vehicle. In addition, key numbers can-not be provided by Hyundai for security reasons.If you need additional keys or if you should loseyour keys, your authorized Hyundai dealer canmake new keys. B880D01GK-GAT Limp Home Procedures In case the immobilizer system is out of order, you cannot start the engine without the limphome procedures with ignition key.The following procedure is how to start the en-gine with the function of the limp home. (0, 1, 2,3 as a sample password). NOTE: You can get the limp home password whenthe vehicle is first delivered to you. If you donot have the password, consult your autho-rized Hyundai dealer.
1. To set the password, you may turn the ignition
key "ON" and then turn it "OFF" according to the digit numbers. For example, turn the igni- tion key once for digit number "1", and twice for "2", and so on. However, for the digitnumber "0", you must turn the ignition key for10 times.
2. Wait for 3~10 seconds.
3. You may set the remaining number of digits by following the same procedures 1 and 2.
4. If all of four digits have been tried success- fully, from this time, you have to start yourengine within 30 seconds. If you start yourengine after 30 seconds, your engine will notstart.
After doing the limp home procedure, you have toconsult with your authorized Hyundai dealer assoon as possible.
CAUTION: If you cannot start your engine in spite of limphome procedure, have your vehicle towed byan authorized Hyundai dealer.

FEATURES OF YOUR HYUNDAI
1- 4
o The door can be locked or unlocked with a
key.
o Lock the door by turning the key toward the front of the vehicle and unlock it by turning the key toward the rear.
B040B01A-AAT Locking and Unlocking Front Doors With a Key
HGK101
UNLOCK
LOCKHGK099
B040C01S-AAT Locking From the Outside The doors can be locked without a key. To lock the doors, first push the inside lock switchto the "LOCK" position so that the red mark on theswitch is not visible, then close the door. NOTE:
o When locking the door this way, be careful
not to lock the door with the ignition keyleft in the vehicle.
o To protect against theft, always remove the ignition key, close all windows, andlock all doors when leaving your vehicleunattended. B040D01S-AAT Locking From the Inside
To lock the doors from the inside, simply close the door and push the lock switch to the "LOCK"position. When this is done, neither the outsidenor the passenger's inside door handle can beused. NOTE: When the door is locked, the red mark on theswitch is not visible.HGK208
UNLOCK
LOCK

FEATURES OF YOUR HYUNDAI 1- 5
B070A01A-AAT THEFT-ALARM SYSTEM (If Installed)This system is designed to provide protection from unauthorized entry into the car. This systemis operated in three stages: the first is the "Armed"stage, the second is the "Alarm" stage, and thethird is the "Disarmed" stage. If triggered, thesystem provides an audible alarm with blinkingof the turn signal light.
B070C01GK-GAT Alarm StageThe alarm will be activated if any of the following occur while the car is parked and the system isarmed.
1) A front door is unlocked and opened without
using the transmitter.
2) The tail gate is opened without using the key.
3) The engine hood is opened. The siren will sound and the turn signal lights will blink continuously for 30 seconds. (E.C only/Except E.C : This happens 3 times). To turn offthe system, unlock the door with the transmitter. CAUTION: Avoid trying to start the engine while thesystem is armed.
B070B02GK-AAT Armed Stage Park the car and stop the engine. Arm the system as described below.
1) Remove the ignition key from the ignition
switch.
2) Make sure that the engine hood and tail gate are closed.
3) Lock the doors using the transmitter of the keyless entry system.
After completion of the steps above, the turn signal light will blink once to indicate that thesystem is armed. NOTE:
1) If any door, tail gate or engine hood re- mains open, the system will not be armed.
2) If this happens, rearm the system as de- scribed above.
3) Once the system is armed, only the tail gate may be unlocked using the key with-out disarming the system. CAUTION:Do not arm the system until all passengershave left the car. If the system is armed whilea passenger(s) remains in the car, the alarmmay be activated when the remainingpassenger(s) leaves the car.
HGK099
B040G01GK-GAT Central Door Lock The central door locking is operated by pushing the driver's door lock switch toward the front orrear of the vehicle. If the passenger door is openwhen the switch is pushed, the door will remainlocked when closed. NOTE:
o When pushing the switch toward the rear,
all doors will unlock.When pushing the switch toward the front,all doors will lock.
o When the door is unlocked, the red mark on the switch is visible.
o The central door locking is operated by turning the key (driver's door only) towardthe front or rear of the vehicle.

FEATURES OF YOUR HYUNDAI
1- 6
B070D03GK-AAT Disarmed Stage The system will be disarmed when either of the following steps are taken:
1) The driver's or passenger's door is unlocked by depressing the "UNLOCK" button on the transmitter.
2) In the middle of alarming or after alarming, it disarms after 30 seconds if the key is turnedto and kept in the "ON" position.
3) If after disarming the system with the trans- mitter the doors are not opened within 30seconds, the system will automatically re-arm.
After completing one of steps above, the turnsignal light will blink twice to indicate that thesystem is disarmed. HGK102B070E02GK-GAT Replacing the batteryWhen the transmitter's battery begins to get weak, it may take several pushes on the buttonto lock or unlock the doors, and the LED will notlight. Replace the battery as soon as possible. Battery type : CR2032Replacement instructions:
1. Carefully separate the case with a blade
screwdriver as shown in the illustration.
HGK122
Screwdriver
HGK121
Battery
2. Remove the old battery from the case and note the polarity. Make sure the polarity of the new battery is the same(+side facing down),then insert it in the transmitter.
NOTE: Install a new battery within 30 seconds after removing the old one. If installing a newbattery takes more than 30 seconds, take thefollowing steps.
1) Turn the ignition key to the "ACC" posi- tion.
2) Make sure that the turn signal lights blink once by pushing the "LOCK" or "UN- LOCK" button on the transmitter.

FEATURES OF YOUR HYUNDAI 1- 7
B050A01GK-AAT WINDOW GLASS Power Window
HGK096
(1)
The power windows operate only when the igni- tion key is in the "ON" position. The main switchesare located on the driver's arm rest and controlthe front windows on the respective sides of thevehicle. The windows may be opened by de-pressing the front portion of the switch. To stop atthe desired opening, release the switch. Thewindow may be closed by pulling the front portionof the switch. In order to prevent operation of thepassenger front window by the passenger, awindow lock switch (1) is provided on the armrest of the driver's door. To disable thepassenger's power window, push the windowlock switch. To revert to normal operation, pushin on the window lock switch again.
B050A02GK
CAUTION: Never try to operate the main switch and sub-switch in opposing directions at the sametime. If this is done, the window will stop and cannot be opened or closed. Auto-Down Window (Driver's Side) (If Installed) The Auto-Down window is moved to its fully open position by pushing the switch. To stop at thedesired position push in on the switch again. WARNING:
o Be careful that head, hands and body are
not trapped by a closing window.
o If passengers remain in the car when you leave, especially if a child remains alone,always remove the ignition key for theirsafety.
HGK097

FEATURES OF YOUR HYUNDAI
1- 8 B080C01A-AAT Adjusting Seatback Angle To recline the seatback, lean forward to take your weight off it, then pull up on the recliner controllever at the outside edge of the seat. Now leanback until the desired seatback angle is achieved.To lock the seatback into position, release therecliner control lever. WARNING: To minimize risk of severe injury in the eventof a collision or a sudden stop, both thedriver's and passenger's seatbacks shouldalways be in an upright position while thevehicle is in motion. The protection providedby the seat belts and airbags in a frontal
HGK051
collision may be reduced significantly when the seat backs are reclined. There is greaterrisk that the driver and passenger will slideunder the seat belt which may result in seri-ous injury if a crash occurs when theseatbacks are reclined. The seat belt cannotprovide full protection to an occupant if theseat back is reclined. B080D02A-AAT Adjustable Headrests Headrests are designed to help reduce the risk of neck injuries. To raise the headrest, pull it up. Tolower it, push it down while pressing the lockknob. WARNING:
o For maximum effectiveness in case of an
accident, the headrest should be adjustedso the top of the headrest is at the sameheight as the top of the occupant's ears.
HGK049
Lock Knob
B080A01A-AAT ADJUSTABLE FRONT SEATS WARNING: Never attempt to adjust the seat while thevehicle is moving. This could result in loss ofcontrol or an accident which may cause death,serious injury or property damage. B080B02A-AAT Adjusting Seat Forward and Rearward
To move the seat toward the front or rear, pull
the lock release lever upward. This will release the seat on its track so you can move it forwardor rearward to the desired position. When youfind the position you want, release the lever andslide the seat forward or rearward on its trackuntil it locks into the desired position and cannotbe moved further.
HGK054
WARNING: To ensure the seat is locked securely, at-tempt to move the seat forward or rearwardwithout using the lock release lever.

FEATURES OF YOUR HYUNDAI 1- 9
The use of a cushion that holds the body away from the seatback is not recom-mended.
o Do not operate the vehicle with the head- rests removed as severe injury to an occu-pant may occur in the event of an acci-dent. Headrests may provide protectionagainst severe neck injuries when prop-erly adjusted.
B080E01F-AAT Lumbar Support Control (Driver's seat only) (If Installed) The driver's seat is equipped with adjustable lumbar support.To increase the amount of lumbar support, pullthe lever forward.To decrease it, push the lever toward the rear. B080F01F-AAT Seat Cushion Height Adjustment (Driver's Seat Only) (If Installed) To raise or lower the front part of the seat cush- ion, turn the knob forward or rearward.
HGK052
SOFT
FIRM
HGK050
B100A01Y-AAT SEAT WARMER (If Installed) The seat warmer is provided to warm the front seats during cold weather. With the ignition keyin the "ON" position, push either of the switchesto warm the driver's seat or the passenger's seat.During mild weather or under conditions wherethe operation of the seat warmer is not needed,keep the switches in the "OFF" position.
HGK123
B129A01F-AAT REAR SEAT POSITIONS
B129A01GK
WARNING: This vehicle contains two rear seating posi-tions only and a seat belt for each seatingposition. Thus, never permit more than twooccupants to ride in the rear seat because anunrestrained occupant could be seriouslyinjured or killed in the event of a vehiclecrash.

FEATURES OF YOUR HYUNDAI
1- 10 The rear seatbacks may be folded to facilitate carrying long items or to increase the luggagecapacity of the vehicle.
o To unlock the seatback, push the seatback
locking button, then pull forward on the seatback panel.
o When you return the seatback to its upright position, always be sure it has locked intoposition by pulling and pushing on the top ofthe seatback.
B110A02S-AAT FOLDING REAR SEATBACKS
HGK108
By pulling up the walk in device lever (1) at the right-upper side of the passenger side seatback,the seatback will tilt forward. Then push the seatforward to allow the occupants to enter. Recliner Memory By pulling up the walk in device lever (1), the seatback is reclined and returned to the originalposition. WARNING: Don't drive with the passenger side seatbackreclined. It is dangerous to move it whiledriving. Be sure the seatback is caterredfirmly before driving.B130A01GK-AAT REAR SEAT ENTRY (Walk in device)The driver and front passenger's seatbacks should be tilted to enter the rear seat.
HGK053
(2) (1)
By pulling up the walk in device lever (1) at the left-
upper side of the driver side seatback, the seatback
will tilt forward. Then pull the lock release lever (2)
up to move the seat forward.
HGK240
(1)
B099A01F-AAT BEFORE FOLDING THE REAR SEATS
B099A01GK
In order to prevent the shoulder belt from being damaged while folding the rear seat, the shoulderbelt must be passed through the hanger to keepit out of the way. CAUTION: Seat belts must be removed from the hangerwhen in use.

FEATURES OF YOUR HYUNDAI 1- 11
B150C02A-AAT Larger ChildrenChildren who are too large for child restraint systems should always occupy the rear seat anduse the available lap/shoulder belts. The lapportion should be fastened snug on the hips andas low as possible. Check belt fit periodically. Achild's squirming could put the belt out of posi-tion. Children are afforded the most safety in theevent of an accident when they are restrained bya proper restraint system in the rear seat. If alarger child (over age 13) must be seated in thefront seat, the child should be securely restrainedby the available lap/shoulder belt and the seatshould be placed in the rearmost position. Chil-dren under the age of 13 should be restrainedsecurely in the rear seat. NEVER place a childunder the age of 13 in the front seat. NEVERplace a rear facing child seat in the front seat ofa vehicle. B150D01A-AAT Pregnant WomenThe use of a seat belt is recommended for pregnant women to lessen the chance of injury inan accident. When a seat belt is used, the lap beltportion should be placed as low and snugly aspossible on the hips, not across the abdomen.For specific recommendations, consult a physi-cian.
WARNING:The purpose of the fold-down rear seatbacksis to allow you to carry longer objects thancould otherwise be accommodated. Neverallow passengers to sit on top of the foldeddown seat back while the car is moving asthis is not a proper seating position and noseat belts are available for use. This couldresult in injury in case of an accident orsudden stop. Objects carried on the foldeddown seatback should not extend higher thanthe top of the front seats. This could allowcargo to slide forward and cause injury ordamage during sudden stops.
B150A02A-GAT SEAT BELT PRECAUTIONS All occupants of the vehicle should wear their
seat belts at all times. Indeed, your province'slaws may require that some or all occupants ofthe vehicle use seat belts.The possibility of injury or the severity of injury inan accident will be decreased if this elementarysafety precaution is observed. In addition, thefollowing recommendations are made: B150B01A-GAT Infant or Small Child Some countries require the use of child restraint systems for infants and small children. Whetherthis is required by law or not, it is stronglyrecommended that a child restraint seat or infantrestraint system be used for infants or small
children weighing less than 18 kilograms (40pounds).
B140A01S-AAT REAR SEAT WARNING
B140A01GK
For the safety of all passengers, luggage or other
cargo should not be piled higher than the top of
the seatback. In addition, do not place objects on
the rear shelf as they may move forward during braking or in an accident and strike vehiclepassengers.

FEATURES OF YOUR HYUNDAI
1- 12 B160D01A-AAT When to Replace Seat Belts
Entire in-use seat belt assembly or assemblies should be replaced if the vehicle has been in-volved in an accident. This should be done evenif no damage is visible. Additional questionsconcerning seat belt operation should be direct-ed to your Hyundai Dealer.
The shoulder belt can't do its job because itwon't be against your body. Instead, it will bein front of you. In a crash you could go into itwith great force, receiving serious neck orother injuries.The lap belt can't do its job either. In a crashthe belt could go up over your abdomen. Thebelt forces would be applied there, not at yourstrong pelvic bones.This could cause serious internal injuries.For proper protection when the vehicle is inmotion, have the seatback upright. Then sitback in the seat and wear your seat beltproperly.
B160A01S-GAT CARE OF SEAT BELTS Seat belt systems should never be disassembled or modified. In addition, care should be taken toassure that seat belts and belt hardware are notdamaged by seat hinges, doors or other abuse. B160B01A-AAT Periodic InspectionIt is recommended that all seat belts be inspected periodically for wear or damage of any kind.Parts of the system that are damaged should bereplaced as soon as possible. B160C01A-AAT Keep Belts Clean and DrySeat belts should be kept clean and dry. If belts become dirty, they can be cleaned by using amild soap solution and warm water. Bleach, dye,strong detergents or abrasives should not beused because they may damage and weaken thefabric.
B150E01A-AAT Injured PersonA seat belt should be used when an injured person is being transported. When this is neces-sary, you should consult a physician for recom-mendations. B150F01A-AAT One Person Per Belt Two people (including children) should never attempt to use a single seat belt. This couldincrease the severity of injuries in case of anaccident. B150G01A-AAT Do Not Lie Down To reduce the chance of injuries in the event of an accident and to achieve maximum effectivenessof the restraint system, all passengers should besitting up and the front seats should be in anupright position when the car is moving. A seatbelt cannot provide proper protection if the per-son is lying down in the rear seat or if the frontseat is in a reclined position. WARNING: Sitting in a reclined position or lying downwhen your vehicle is in motion can be dan-gerous. Even if you buckle up, your seat beltscan't do their job when you're reclined.
